LG A133R User manual

LG-A133R Quick Start Guide
Some contents in this manual may differ from your phone depending on
the software of the phone or your service provider.
P/N: MBM63316301(1.0) Printed in China
Bluetooth QD ID B016672
Getting started
Installing the SIM and battery
1 Remove the battery cover
Use your right thumb to press on the bottom centre of the battery
cover, then slide the cover upwards (as depicted below). Then, lift
the cover to remove it.
2 Remove the battery
Hold the top edge of the phone and use the fingernail
cutouts near the bottom of the battery to lift the battery
from the phone.
WARNING: Do not remove the battery when the phone
is turned on; this can damage the phone.
3 Install the SIM card
Slide the SIM card into the SIM card slot (as shown
below). Make sure that the gold contact area on the
card is facing downwards. To remove the SIM card, pull it
gently in the opposite direction.
4 Install the battery
Insert the top of the battery first into the top edge of the
battery compartment. Ensure that the battery contacts
align with the terminals on the phone. Press the bottom
of the battery down until it snaps into place.
5 Charging your phone
Unfasten the cover of the Charger/USB port on the left
side of your phone. Insert the charger to the phone (the
‘LG’ side of the connector has to be facing down when
connecting to the phone) and then plug it into the power
socket. Your LG-A133R need to be charged until the Full
Battery message appears on the screen.
Important!: You must insert the battery before charging.
WARNING: Use unauthorized accessories could damage
your phone and void your warranty.
Artists -This shows the list of artists in your music library.
Albums -This shows the list of albums in your music
library.
Genres -This shows the list of genres in your music
library.
Shuffle Tracks - This allows you to play all songs in your
music library in random order.
FM Radio
You can receive FM radio with your external earphone.
You can listen to your favourite radio station anytime.
Voice Recorder
Use the Voice Recorder to record voice memos or other
sounds.
Ringtone Creator
This menu allows you to make ringtones form other
audio files in your phone.
FCC Part 15 Class B Compliance
This device and its accessories comply with part 15 of FCC rules
and ICES-003 Class B digital apparatus requirements for Industry
Canada. Operation is subject to the following two conditions:
(1) This device and its accessories may not cause harmful
interference, and (2) this device and its accessories must accept any
interference received, including interference that may cause
undesired operation.
Part 15.21 statement
Changes or modifications that are not expressly approved by
the manufacturer could void the user’s authority to operate the
equipment.
Part 15.105 statement
This equipment has been tested and found to comply with the
limits for a class B digital device, pursuant to Part 15 of the FCC
Rules.These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. if this equipment does cause harmful interference
or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC RF Exposure Information
WARNING! Read this information before operating the phone.
In August 1996, the Federal Communications Commission (FCC) of
the United States, with its action in Report and Order FCC 96-326,
adopted an updated safety standard for human exposure to Radio
Frequency (RF) electromagnetic energy emitted by FCC regulated
transmitters. Those guidelines are consistent with the safety
standard previously set by U.S, Canada and international standards
bodies. The design of this phone complies with the FCC guidelines
and these international standards.
Body-worn Operation
This device was tested for typical body-worn operations with the
back of the phone kept 0.79 inches (2cm) from the user’s body. To
comply with FCC RF exposure requirements, a minimum separation
distance of 0.79 inches (2cm) must be maintained between the
user’s body and the back of the phone.Third-party belt-clips,
holsters, and similar accessories containing metallic components
should not be used.
Body-worn accessories that cannot maintain 0.79 inches (2cm)
separation distance between the user’s body and the back of the
phone, and have not been tested for typical body-worn operations
may not comply with FCC RF exposure limits and should be
avoided.
Vehicle-Mounted External Antenna (Optional,
if available.)
A minimum separation distance of 8 inches (20 cm) must be
maintained between the user / bystander and the vehicle-mounted
external antenna to satisfy FCC RF exposure requirements. For
more information about RF exposure, visit the FCC website at
www.fcc.gov.
Caution
Use only the supplied and approved antenna. Use of unauthorized
antennas or modifications could impair call quality, damage
the phone, void your warranty and/or result in violation of FCC
regulations.
Do not use the phone with a damaged antenna. If a damaged
antenna comes in contact with the skin a minor burn may result.
Contact your local dealer for a replacement antenna.
Call Log
Call Log
This menu is a list of the last phone numbers or Contact
entries for calls you placed, accepted, or missed.
Note: On the home screen, press the Send Key to
view Call Log.
Missed Calls
You can view a list of calls you have missed.
Received Calls
You can view a list of calls you have received.
Dialed Numbers
You can view a list of numbers you have called.
Call Duration
You can view the duration of all calls including all, dialed,
received calls, and the last call.
Packet Data Counter
You can check the amount of data transferred over the
network.
Call Costs
You can view the charges applied to your calls.
Media
Gallery
My Memory Card - If your phone has a memory card in
the card slot, the files saved on your memory card are
displayed.
My Images -The picture files saved on your phone are
displayed.
My Sounds -The audio files saved on your phone are
displayed.
My Videos - The video files saved on your phone are
displayed.
Installing a memory card
You can expand the memory available on your phone by
using a microSD™ memory card.
TIP: A memory card is an optional accessory.
1 Locate the microSD™ card slot on the right side of the
phone. Then, use your fingernail to gently lift the cover.
The cover will remain attached to the phone to prevent
it going missing.
2 With the microSD™ card facing up, slide it into the
microSD™ card slot (as demonstrated in the following
image).
Push the memory card in.
3 Replace the slot cover on the phone.
Note: This device supports a MicroSD memory card up
to 16 GB.
Note: Perform a backup of any existing content before
formatting the memory card.
Menu Tree
1 Call Log
1 Call Log
2 Missed Calls
3 Received Calls
4 Dialed Numbers
5 Call Duration
6 Packet Data Counter
7 Call Costs
3 My Account 5 Internet
1 Home
2 Google Search
3 Bookmarks
4 Last Web Address
5 Settings
6 Go to Address
7 Saved Pages
4 Media
1 Gallery
2 Camera
3 Camcorder
4 Music
5 FM Radio
6 Voice Recorder
7 Ringtone Creator
2 Contacts
1 Names
2 Settings
3 Groups
4 Speed Dials
5 Service Dial
Numbers
6 Own Number
7 My Business Card
6 Messaging
1 Create Message
2 Inbox
3 My Mailbox
4 Drafts
5 Outbox
6 Sent Items
7 Saved Items
8 Emoticons
9 Message Settings
7 Organizer
1 Alarm Clock
2 Calendar
3 To-Do List
4 Notes
5 Secret Notes
6 Cash Book
7 BMI calculator
8 Calculator
9 Stopwatch
10 Date Finder
11 Converter
12 World Time
13 Go To
14 Settings
8 Games &
Apps
1 My games & Apps
2 Settings
9 Settings
1 Proles
2 Display
3 Date and Time
4 Connectivity
5 Call
6 Phone
7 Network
8 Internet Proles
9 Access Points
10 Packet Data Conn.
11 Security
12 Memory Info
13 Restore Factory
Settings
Phone Components
Display screen
# key
Side volume keys
* key
Micro USB Port / Earphone jack /
Charger port
Earpiece
Navigation keys
Use for quick access to phone functions.
Number key
In most of the time, the numeric keys are used
to input numbers and letters.
Send key
- Dial a phone number and answer a call.
- In standby mode: Shows a history of calls. Soft keys (Left soft key / Right soft key)
These keys perform the function Indicated in
the bottom of the display.
End key
- Switch on/off (hold)
- End or reject a call.
General functions
Calls
Making a call
1 Make sure your phone is powered on.
2 Enter a phone number, including the area code. To
delete a number on the display screen, simply press
the right soft key key to erase one digit at a time.
TIP! Press and hold the right soft key key to erase
the entire numbers.
3 Press the [SEND] key to call the number.
4 To end the call, press the [END] key.
Making a Call with the Send Key
1 Press the [SEND] key, and the most recent
missed, dialed and received calls will be displayed.
2 Highlight the desired number by using the navigation
keys.
3 Press the [SEND] key.
My games & Apps - The game and application files
saved on your phone are displayed.
Others - When you receive fi les of an undefi ned format
(such as .vcs, .vcf, etc.) via email, the files are displayed.
Camera
Using the camera module built into your phone, you can
take pictures of people or events while on the move.
Additionally, you can send photos to other devices as a
picture message.
1. Open the flip and press [Menu].
2. Press Media.
3. Press Camera.
4. Using the phone’s main LCD as a viewfinder, aim the
camera lens to your subject.
5. Press key until the shutter sounds.
6. Press the left key Options to rename and edit
the photo.
Camcorder
When recording a video clip, you have many of the same
Settings options as with taking a photo.
1. Open the flip and press [Menu].
2. Press Media.
3. Press Camcorder.
4. Using the phone’s main LCD as a viewfinder, aim the
camera lens to your subject.
5. Press key to start recording. To stop recording, press
Stop. The recording will be saved automatically.
6. Press the left key Options to rename the video.
Music
Recently Played -This allows you to view the recently
played tracks.
All Tracks - This allows you to view all songs in your
music library.
Playlists - This allows you to create your own playlists.

phones emit low levels of radiofrequency energy (RF) in the
microwave range while being used.They also emit very low levels
of RF when in the Main Menu Screen. Whereas high levels of RF can
produce health effects (by heating tissue), exposure to low level RF
that does not produce heating effects causes no known adverse
health effects. Many studies of low level RF exposures have not
found any biological effects. Some studies have suggested that
some biological effects may occur, but such findings have not been
confirmed by additional research. In some cases, other researchers
have had difficulty in reproducing those studies, or in determining
the reasons for inconsistent results.
2. What is the FDA’s role concerning the safety of wireless
phones?
Under the law, the FDA does not review the safety of
radiationemitting consumer products such as wireless phones
before they can be sold, as it does with new drugs or medical
devices. However, the agency has authority to take action if
wireless phones are shown to emit radiofrequency energy (RF) at
a level that is hazardous to the user. In such a case, the FDA could
require the manufacturers of wireless phones to notify users of the
health hazard and to repair, replace, or recall the phones so that
the hazard no longer exists. Although the existing scientific data do
not justify FDA regulatory actions, the FDA has urged the wireless
phone industry to take a number of steps, including the following:
• Support needed research into possible biological effects of RF of
the type emitted by wireless phones.
• Design wireless phones in a way that minimizes any RF exposure
to the user that is not necessary for device function; and
cooperate in providing users of wireless phones with the best
possible information on possible effects of wireless phone use
on human health.
The FDA belongs to an interagency working group of the federal
agencies that have responsibility for different aspects of RF safety
to ensure coordinated efforts at the federal level. The following
agencies belong to this working group:
• National Institute for Occupational Safety and Health
• Environmental Protection Agency
• Occupational Safety and Health Administration
• National Telecommunications and Information Administration
The National Institutes of Health participates in some
interagency working group activities, as well. The FDA shares
regulatory responsibilities for wireless phones with the Federal
Communications Commission (FCC). All phones that are sold in the
United States must comply with FCC safety guidelines that limit RF
exposure. The FCC relies on the FDA and other health agencies for
safety questions about wireless phones. The FCC also regulates the
base stations that the wireless phone networks rely upon. While
these base stations operate at higher power than do the wireless
phones themselves, the RF exposures that people get from these
base stations are typically thousands of times lower than those they
can get from wireless phones. Base stations are thus not the subject
of the safety questions discussed in this document.
8. What has the FDA done to measure the radio frequency
energy coming from wireless phones?
The Institute of Electrical and Electronic Engineers (IEEE) is
developing a technical standard for measuring the radio
frequency energy (RF) exposure from wireless phones and other
wireless handsets with the participation and leadership of FDA
scientists and engineers. The standard,“Recommended Practice
for Determining the Spatial-Peak Specific Absorption Rate (SAR)
in the Human Body Due to Wireless Communications Devices:
Experimental Techniques,” sets forth the first consistent test
methodology for measuring the rate at which RF is deposited in
the heads of wireless phone users. The test method uses a tissue-
simulating model of the human head. Standardized SAR test
methodology is expected to greatly improve the consistency of
measurements made at different laboratories on the same phone.
SAR is the measurement of the amount of energy absorbed in
tissue, either by the whole body or a small part of the body. It is
measured in watts/kg (or milliwatts/g) of matter. This measurement
is used to determine whether a wireless phone complies with
safety guidelines.
9. What steps can I take to reduce my exposure to radio
frequency energy from my wireless phone?
If there is a risk from these products — and at this point we do
not know that there is — it is probably very small. But if you are
concerned about avoiding even potential risks, you can take a few
simple steps to minimize your exposure to radio frequency energy
(RF). Since time is a key factor in how much exposure a person
receives, reducing the amount of time spent using a wireless
phone will reduce RF exposure. If you must conduct extended
conversations by wireless phone every day, you could place more
distance between your body and the source of the RF, since the
exposure level drops off dramatically with distance. For example,
you could use a headset and carry the wireless phone away from
your body or use a wireless phone connected to a remote antenna.
Again, the scientific data do not demonstrate that wireless phones
are harmful. But if you are concerned about the RF exposure from
these products, you can use measures like those described above
to reduce your RF exposure from wireless phone use.
10. What about children using wireless phones?
The scientific evidence does not show a danger to users of wireless
phones, including children and teenagers. If you want to take steps
to lower exposure to radio frequency energy (RF), the measures
described above would apply to children and teenagers using
wireless phones. Reducing the time of wireless phone use and
increasing the distance between the user and the RF source will
reduce RF exposure. Some groups sponsored by other national
governments have advised that children be discouraged from
using wireless phones at all. For example, the government
in the United Kingdom distributed leaflets containing such a
recommendation in December 2000. They noted that no evidence
health effects, such as cancer.This is because the interval between
the time of exposure to a cancer-causing agent and the time
tumors develop — if they do — may be many, many years.The
interpretation of epidemiological studies is hampered by difficulties
in measuring actual RF exposure during day-to-day use of wireless
phones. Many factors affect this measurement, such as the angle at
which the phone is held, or which model of phone is used.
6. What is the FDA doing to find out more about the possible
health effects of wireless phone RF?
The FDA is working with the U.S. National Toxicology Program
and with groups of investigators around the world to ensure that
high priority animal studies are conducted to address important
questions about the effects of exposure to radio frequency energy
(RF). The FDA has been a leading participant in the World Health
Organization International Electromagnetic Fields (EMF) Project
since its inception in 1996. An influential result of this work has
been the development of a detailed agenda of research needs that
has driven the establishment of new research programs around
the world. The project has also helped develop a series of public
information documents on EMF issues.The FDA and the Cellular
Telecommunications & Internet Association (CTIA) have a formal
Cooperative Research and Development Agreement (CRADA) to do
research on wireless phone safety. The FDA provides the scientific
oversight, obtaining input from experts in government, industry,
and academic organizations. CTIA-funded research is conducted
through contracts with independent investigators. The initial
research will include both laboratory studies and studies of wireless
phone users. The CRADA will also include a broad assessment of
additional research needs in the context of the latest research
developments around the world.
7. How can I find out how much radio frequency energy
exposure I can get by using my wireless phone?
All phones sold in the United States must comply with Federal
Communications Commission (FCC) guidelines that limit radio
frequency energy (RF) exposures. The FCC established these
guidelines in consultation with the FDA and the other federal
health and safety agencies. The FCC limit for RF exposure from
wireless telephones is set at a Specific Absorption Rate (SAR)
of 1.6 watts per kilogram (1.6 W/kg).The FCC limit is consistent
with the safety standards developed by the Institute of Electrical
and Electronic Engineering (IEEE) and the National Council on
Radiation Protection and Measurement. The exposure limit takes
into consideration the body’s ability to remove heat from the
tissues that absorb energy from the wireless phone and is set well
below levels known to have effects. Manufacturers of wireless
phones must report the RF exposure level for each model of phone
to the FCC. The FCC website (http://www.fcc.gov/oet/ rfsafety)
gives directions for locating the FCC identification number on
your phone so you can find your phone’s RF exposure level in the
online listing.
health.The exposure standard for wireless mobile phones employs
a unit of measurement known as the Specific Absorption Rate, or
SAR. The SAR limit set by the FCC is 1.6 W/kg. *
Tests for SAR are conducted using standard operating positions
specified by the FCC with the phone transmitting at its highest
certified power level in all tested frequency bands.
Although SAR is determined at the highest certified power level,
the actual SAR level of the phone while operating can be well
below the maximum value. Because the phone is designed to
operate at multiple power levels to use only the power required to
reach the network, in general, the closer you are to a wireless base
station antenna, the lower the power output.
Before a phone model is available for sale to the public, it must
be tested and certified to the FCC that it does not exceed the
limit established by the governmentadopted requirement for
safe exposure. The tests are performed in positions and locations
(e.g., at the ear and worn on the body) as required by the FCC for
each model.
The highest SAR value for this model phone when tested for use at
the ear is 0.89 W/kg and when worn on the body, as described in
this user’s manual, is 1.00 W/kg. (Body-worn measurements differ
among phones models, depending upon available accessories and
FCC requirements.) While there may be differences between SAR
levels of various phones and at various positions, they all meet the
government requirement for safe exposure.
The FCC has granted an Equipment Authorization for this model
phone with all reported SAR levels evaluated as in compliance with
the FCC RF emission guidelines. SAR information on this model
phone is on file with the FCC and can be found under the Display
Grant section of http://www.fcc.gov/oet/ea/fccid/ after searching
on FCC ID BEJA133R.
Additional information on Specific Absorption Rates (SAR) can be
found on the CellularTelecommunications Industry Association
(CTIA) website at http://www.ctia.org
* In the United States and Canada, the SAR limit for mobile phones
used by the public is 1.6 watts/kg (W/kg) averaged over one gram
of tissue. The standard incorporates a substantial margin of safety
to give additional protection for the public and to account for any
variations in measurements.
* Product meets current FCC & IC Radio Frequency Exposure
Guidelines.
FCC ID BEJA133R,
IC ID: 2703C-A133R
3. What kinds of phones are the subject of this update?
The term“wireless phone”refers here to handheld wireless phones
with built-in antennas, often called“cell”, “mobile”, or “PCS” phones.
These types of wireless phones can expose the user to measurable
radiofrequency energy (RF) because of the short distance between
the phone and the user’s head. These RF exposures are limited by
FCC safety guidelines that were developed with the advice of the
FDA and other federal health and safety agencies. When the phone
is located at greater distances from the user, the exposure to RF is
drastically lower because a person’s RF exposure decreases rapidly
with increasing distance from the source. The so called“cordless
phones,” which have a base unit connected to the telephone wiring
in a house, typically operate at far lower power levels, and thus
produce RF exposures far below the FCC safety limits.
4. What are the results of the research done already?
The research done thus far has produced conflicting results, and
many studies have suffered from flaws in their research methods.
Animal experiments investigating the effects of radiofrequency
energy (RF) exposures characteristic of wireless phones have
yielded conflicting results that often cannot be repeated in other
laboratories. A few animal studies, however, have suggested that
low levels of RF could accelerate the development of cancer in
laboratory animals. However, many of the studies that showed
increased tumor development used animals that had been
genetically engineered or treated with cancer-causing chemicals
so as to be pre-disposed to develop cancer in the absence of RF
exposure. Other studies exposed the animals to RF for up to 22
hours per day. These conditions are not similar to the conditions
under which people use wireless phones, so we don’t know
with certainty what the results of such studies mean for human
health.Three large epidemiology studies have been published
since December 2000. Between them, the studies investigated
any possible association between the use of wireless phones and
primary brain cancer, glioma, meningioma, or acoustic neuroma,
tumors of the brain or salivary gland, leukemia, or other cancers.
None of the studies demonstrated the existence of any harmful
health effects from wireless phone RF exposures. However, none
of the studies can answer questions about long-term exposures,
since the average period of phone use in these studies was around
three years.
5. What research is needed to decide whether RF exposure
from wireless phones poses a health risk?
A combination of laboratory studies and epidemiological studies of
people actually using wireless phones would provide some of the
data that are needed. Lifetime animal exposure studies could be
completed in a few years. However, very large numbers of animals
would be needed to provide reliable proof of a cancer promoting
effect if one exists. Epidemiological studies can provide data
that is directly applicable to human populations, but 10 or more
years follow-up may be needed to provide answers about some
exists that using a wireless phone causes brain tumors or other
ill effects. Their recommendation to limit wireless phone use by
children was strictly precautionary; it was not based on scientific
evidence that any health hazard exists.
11. What about wireless phone interference with medical
equipment?
Radio frequency energy (RF) from wireless phones can interact with
some electronic devices. For this reason, the FDA helped develop
a detailed test method to measure electromagnetic interference
(EMI) of implanted cardiac pacemakers and defibrillators from
wireless telephones. This test method is now part of a standard
sponsored by the Association for the Advancement of Medical
instrumentation (AAMI). The final draft, a joint effort by the FDA,
medical device manufacturers, and many other groups, was
completed in late 2000. This standard will allow manufacturers
to ensure that cardiac pacemakers and defibrillators are safe
from wireless phone EMI. The FDA has tested hearing aids for
interference from handheld wireless phones and helped develop
a voluntary standard sponsored by the Institute of Electrical
and Electronic Engineers (IEEE). This standard specifies test
methods and performance requirements for hearing aids and
wireless phones so that no interference occurs when a person
uses a“compatible”phone and a“compatible” hearing aid at
the same time. This standard was approved by the IEEE in 2000.
The FDA continues to monitor the use of wireless phones for
possible interactions with other medical devices. Should harmful
interference be found to occur, the FDA will conduct testing to
assess the interference and work to resolve the problem.
12. Where can I find additional information?
For additional information, please refer to the following resources:
FDA web page on wireless phones (http://www.fda.gov/) Federal
Communications Commission (FCC) RF Safety Program (http://
www.fcc.gov/oet/rfsafety) International Commission on Non-
lonizing Radiation Protection (http://www.icnirp.de) World Health
Organization (WHO) International EMF Project (http://www.who.
int/peh-emf/en/) National Radiological Protection Board (UK)
(http://www.hpa.org.uk/radiation/)
Consumer Information on SAR (Specific
Absorption Rate)
This Model Phone Meets the Government’s Requirements for
Exposure to Radio Waves.
Your wireless phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed the emission limits
for exposure to radiofrequency (RF) energy set by the Federal
Communications Commission (FCC) of the U.S. Government. These
limits are part of comprehensive guidelines and establish permitted
levels of RF energy for the general population. The guidelines are
based on standards that were developed by independent scientific
organizations through periodic and thorough evaluation of
scientific studies.The standards include a substantial safety margin
designed to assure the safety of all persons, regardless of age and
1. WHAT THIS WARRANTY COVERS:
LG offers you a limited warranty that the enclosed subscriber unit and its enclosed accessories
will be free from defects in material and workmanship, according to the following terms and
conditions:
1. The limited warranty for the product extends for ONE (1) year beginning on the date of
purchase of the product by the original end user.
2. The limited warranty extends only to the original end user of the product and is not assignable
or transferable to any subsequent purchaser/end user.
3. This warranty is good only to the original end user of the product during the warranty period
as long as it is in Canada.
4. Upon request from LG, the consumer must provide information to reasonably prove the
date of purchase.
5. During the applicable warranty period, LG will repair or replace at LG’s sole option, without
charge to the original end user, any defective component part of the phone or accessory.
6. LG may use rebuilt, reconditioned or new parts or components when repairing any product or
replace a product with a rebuilt, reconditioned or new product.
2. WHAT THIS WARRANTY DOES NOT COVER:
1. Defects or damages resulting from use of the product in other than its normal and customary
manner.
2. Defects or damages from abnormal use, abnormal conditions, improper storage, exposure to
moisture or dampness, unauthorized modifications, unauthorized connections, unauthorized
repair, misuse, neglect, abuse, accident, alteration, improper installation or other acts which are
not the fault of LG, including damage caused by spills of food or liquids.
3. Breakage or damage to antennas unless caused directly by defects in material or workmanship.
4. The fact that the Customer Service Department at LG was not notified by the original end user
of the alleged defect or malfunction of the product,during the warranty period.
5. Products which have had their serial numbers removed or made illegible.
6. Damage resulting from use of non-LG approved accessories.
7. All plastic surfaces and all other externally exposed parts that are scratched or damaged due
to normal customer use.
8. Products serviced by non-authorized persons or companies.
Notes:
1. This limited warranty supersedes all other warranties, expressed or implied either in fact or by
operations of law, statutory or otherwise,including,but not limited to any implied warranty of
merchantability or fitness for a particular purpose.
2. Shipping damage is the sole responsibility of the shipping company.
3. EXCLUSION OF LIABILITY:
No other express warranty is applicable to this product.
THE DURATION OF ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF
MARKETABILITY, IS LIMITED TO THE DURATION OF THE EXPRESS WARRANTY HEREIN. LG
ELECTRONICS CANADA, INC. SHALL NOT BE LIABLE FOR THE LOSS OF THE USE OF THE
PRODUCT, INCONVENIENCE,LOSS OR ANY OTHER DAMAGES, DIRECT OR CONSEQUENTIAL,
ARISING OUT OF THE USE OF, OR INABILITY TO USE, THIS PRODUCT OR FOR ANY BREACH OF
ANY EXPRESS OR IMPLIED WARRANTY, INCLUDING THE IMPLIEDWARRANTY OF MARKETABILITY
APPLICABLE TO THIS PRODUCT.
4. HOW TO GET WARRANTY SERVICE:
To obtain warranty service, please call the following telephone number from anywhere in Canada:
LG Electronics Canada, Inc.
Tel. 1-888-LG-Canada (1-888-542-2623)
http://www.lg.com/ca_en (see links to “Support > Mobile Phone Support”)
LIMITED WARRANTY STATEMENT
• When the phone is not used for a long period time, store it in a
safe place with the power cord unplugged.
• Using the phone in proximity to receiving equipment (i.e., TV or
radio) may cause interference to the phone.
• Only authorized personnel should service the phone and its
accessories. Faulty installation or service may result in accidents
and consequently invalidate the warranty.
• Do not use the phone if the antenna is damaged. If a damaged
antenna contacts skin, it may cause a slight burn. Please contact
an LG Authorized Service Centre to replace the damaged
antenna.
• Do not use the phone in areas where its use is prohibited. (For
example: aircraft)
• Do not immerse your phone in water. If this happens, turn it off
immediately and remove the battery. If the phone does not work,
take it to an LG Authorized Service Centre.
• Use accessories, such as earphones and headsets, with caution.
Ensure that cables are tucked away safely and do not touch the
antenna unnecessarily.
Warning! Important Safety Information
Avoiding hearing damage
Permanent hearing loss may occur if you use your phone and/
or headset at a high volume. Set the volume to a safe level. You
can adapt over time to a higher volume of sound that may sound
normal but can be damaging to your hearing. If you experience
ringing in your ears or muffled speech, stop listening and have your
hearing checked.
The louder the volume, the less time is required before your
hearing could be affected. Hearing experts suggest that to protect
your hearing:
• Limit the amount of time you use your phone and/or headset
at high volume.
• Avoid turning up the volume to block out noisy surroundings.
• Turn the volume down if you can’t hear people speaking near
you.
For information about how to set a maximum volume limit on your
phone, see the features guide for your phone.
Using your phone safely
Use of your phone while operating a vehicle is not recommended
and is illegal in some areas. Be careful and attentive while driving.
Stop using your phone if you find it disruptive or distracting while
operating any type of vehicle or performing any other activity that
requires your full attention.
FDA Consumer Update
The U.S. Food and Drug Administration’s Center for Devices and
Radiological Health Consumer Update on Mobile Phones:
1. Do wireless phones pose a health hazard?
The available scientific evidence does not show that any health
problems are associated with using wireless phones. There is no
proof, however, that wireless phones are absolutely safe. Wireless
• Do not use harsh chemicals(such as alcohol, benzene, thinners,
etc.) or detergents to clean your phone. There is a risk of this
causing a fire.
• Do not handle the phone with wet hands while it is being
charged. It may cause an electric shock or seriously damage
your phone.
• Do not drop, strike, or shake your phone severely. Such actions
may harm the internal circuit boards of the phone.
• Do not put your phone in a place subject to excessive dust and
keep the minimum required distance between the power cord
and heat sources.
• Unplug the power cord prior to cleaning your phone, and clean
the power plug pin when it is dirty.
• Do not damage the power cord by bending, twisting, pulling, or
heating. Do not use the plug if it is loose as it may cause a fire or
electric shock.
• When using the power plug, ensure that it is firmly connected. If it
is not, it may cause excessive heat or fire.
• Do not place any heavy items on the power cord. Do not allow
the power cord to be crimped as it may cause fire or electric
shock.
• Do not disassemble the phone.
• Do not place or answer calls while charging the phone as it may
short-circuit the phone and/or cause electric shock or fire.
• If you put your phone in a pocket or bag without covering the
receptacle of the phone (power plug pin), metallic articles (such
as a coin, paperclip or pen) may short-circuit the phone. Always
cover the receptacle when not in use.
• Do not short-circuit the battery. Metallic articles such as a coin,
paperclip or pen in your pocket or bag may short-circuit the
+ and – terminals of the battery (metal strips on the battery)
upon moving.
• Short-circuit of the terminal may damage the battery and cause
an explosion.
• Never place your phone in a microwave oven as it will cause the
battery to explode.
General Warnings and Cautions
• Only use the batteries, antennas, and chargers provided by LG.
The warranty will not be applied to products provided by other
suppliers.
• Store the battery in a place out of reach of children.
• Using a damaged battery or placing a battery in your mouth may
cause serious injury.
• Do not place items containing magnetic components such as a
credit card, phone card, bank book or subway ticket near your
phone.The magnetism of the phone may damage the data
stored in the magnetic strip.
• Do not hold or let the antenna come in contact with your body
during a call.
• Talking on your phone for a long period of time may reduce call
quality due to heat generated during use.
bodily injury or even death. Areas with a potentially explosive
atmosphere are often, but not always marked clearly. Potential
areas may include: fueling areas (such as gasoline stations); below
deck on boats; fuel or chemical transfer or storage facilities; vehicles
using liquefied petroleum gas (such as propane or butane); areas
where the air contains chemicals or particles (such as grain, dust, or
metal powders); and any other area where you would normally be
advised to turn off your vehicle engine.
ForVehicles Equipped with an Air Bag
An air bag inflates with great force. DO NOT place objects, including
either installed or portable wireless equipment, in the area over
the air bag or in the air bag deployment area. If in-vehicle wireless
equipment is improperly installed and the air bag inflates, serious
injury could result.
Charger and Adapter Safety
• The charger and adapter are intended for indoor use only.
• Do not expose the battery charger or adapter to direct sunlight or
use it in places with high humidity, such as a bathroom.
Battery Information and Care
• Please dispose of your battery properly or take it to your local
wireless carrier for recycling.
• Do not dispose of your battery by fire or with hazardous or
flammable materials.
• Never use an unapproved battery since this could damage the
phone and/or battery and could cause the battery to explode.
• The battery does not need to be fully discharged before
recharging.
• Use only LG-approved chargers specific to your phone model
since they are designed to maximize battery life.
• Do not disassemble or shortcircuit the battery.
• Keep the battery’s metal contacts clean.
• Replace the battery when it no longer provides acceptable
performance. The battery can be recharged several hundred
times before replacement.
• Recharge the battery after long periods of non-use to maximize
battery life.
• Battery life will vary due to usage patterns and environmental
conditions.
• Use of extended backlighting, MiniBrowser, and data connectivity
kits affect battery life and talk/standby times.
Safety Information
Please read and observe the following information for safe and
proper use of your phone and to prevent damage. Also, keep the
user’s guide in an accessible place at all the times after reading it.
Explosion, Shock, and Fire Hazards
• Unplug the power cord and charger during lightning storms to
avoid electric shock or fire.
• Make sure that no sharp-edged items such as animal’s teeth,
nails, come into contact with the battery. There is a risk of this
causing a fire.
Electronics Canada Inc.
Mississauga, Ontario
Pacemakers
The Health Industry Manufacturers Association recommends
that a minimum separation of six inches be maintained between
a handheld wireless phone and a pacemaker to avoid potential
interference with the pacemaker. These recommendations
are consistent with the independent research by and
recommendations ofWireless Technology Research.
Persons with Pacemakers:
• Should ALWAYS keep the phone more than six inches from their
pacemaker when the phone is turned ON;
• Should not carry the phone in a breast pocket;
• Should use the ear opposite the pacemaker to minimize the
potential for interference;
• Should turn the phone OFF immediately if there is any reason to
suspect that interference is taking place.
Hearing Aids
Some digital wireless phones may interfere with some hearing
aids. In the event of such interference, you may want to consult
your service provider (or call the customer service line to discuss
alternatives.) Optional for each phone manufacturer.
Other Medical Devices
If you use any other personal medical device, consult the
manufacturer of your device to determine if it is adequately
shielded from external RF energy.Your physician may be able to
assist you in obtaining this information.
Health Care Facilities
Turn your phone OFF in health care facilities when any regulations
posted in these areas instruct you to do so. Hospitals or health care
facilities may use equipment that could be sensitive to external
RF energy.
Vehicles
RF signals may affect improperly installed or inadequately shielded
electronic systems in motor vehicles. Check with the manufacturer
or its representative regarding your vehicle. You should also consult
the manufacturer of any equipment that has been added to your
vehicle.
Posted Facilities
Turn your phone OFF in any facility where posted notices so
require.
Aircraft
FCC andTransport Canada regulations prohibit using your phone
while in the air. Switch OFF your phone before boarding an aircraft.
Blasting Areas
To avoid interfering with blasting operations, turn your phone
OFF when in a“blasting area”or in areas posted: “Turn off two-way
radio”. Obey all signs and instructions.
Potentially Explosive Atmosphere
Turn your phone OFF when in any area with a potentially explosive
atmosphere and obey all signs and instructions.
Sparks in such areas could cause an explosion or fire resulting in
Safety
TIA(Telecommunications Industry Association) Safety
Information
The following is the complete TIA Safety Information for wireless
handheld phones.
Exposure to Radio Frequency Signal
Your wireless handheld portable phone is a low power radio
transmitter and receiver.When it is ON, it receives and also sends
out Radio
Frequency (RF) signals. In August, 1996, the Federal
Communications Commissions (FCC) adopted RF exposure
guidelines with safety levels for handheld wireless phones. Those
guidelines are consistent with the safety standards previously set
by both U.S. and international standards bodies:
• ANSI C95.1 (1992) *
• NCRP Report 86 (1986)
• ICNIRP (1996)
• Health Canada, Safety Code 6, 1999.
Those standards were based on comprehensive and periodic
evaluations of the relevant scientific literature. For example,
over 120 scientists, engineers, and physicians from universities,
government health agencies, and industry reviewed the available
body of research to develop the ANSI Standard (C95.1). The design
of your phone complies with the FCC guidelines, IC Regulations
(and those standards).
Antenna Care
Use only the supplied or an approved replacement antenna.
Unauthorised antennas, modifications, or attachments could
damage the phone and may violate FCC regulations.
Phone Operation
NORMAL POSITION: Hold the phone as you would any other
telephone with the antenna pointed up and over your shoulder.
Tips on Efficient Operation
For your phone to operate most efficiently:
Do not touch the antenna unnecessarily when the phone is in use.
Contact with the antenna affects call quality and may cause the
phone to operate at a higher power level than otherwise needed.
Driving
Check the laws and regulations on the use of ireless phones in the
areas where you drive and always obey them. Also, if using your
phone while driving, please observe the following:
• Give full attention to driving -- driving safely is your first
responsibility;
• Use hands-free operation, if available;
• Pull off the road and park before making or answering a call if
driving conditions or the law so require.
Electronic Devices
Most modern electronic equipment is shielded from RF signals.
However, certain electronic equipment may not be shielded against
the RF signals from your wireless phone.
