LG JS750 User manual

14 JS750
Technical Details
FCC RF Exposure Information
WARNING! Read this information
before operating the phone.
In August 1996, the Federal
Communications Commission (FCC)
of the United States, with its action
in Report and Order FCC 96-326,
adopted an updated safety standard
for human exposure to Radio
Frequency (RF) electromagnetic
energy emitted by FCC regulated
transmitters. Those guidelines are
consistent with the safety standard
previously set by both U.S. and
international standards bodies. The
design of this phone complies with
the FCC guidelines and these
international standards.
Bodily Contact During Operation
This device was tested for typical
use with the back of the phone
kept 0.79 inches (2.0 cm) from
the body. To comply with FCC RF
exposure requirements, a minimum
separation distance of 0.79 inches
(2.0 cm) must be maintained
between the user’sbodyand the
back of the phone, including the
antenna. Third-party belt-clips,
holsters, and similar accessories
containing metallic components
should not be used. Avoid the use
of accessories that cannot maintain
0.79 inches (2.0 cm) distance
between the user’s body and the
back of the phone and have not
been tested for compliance with
FCC RF exposure limits.
Vehicle-Mounted External Antenna
(Optional, if available.)
To satisfy FCC RF exposure
requirements, keep 8 inches (20
cm) between the user / bystander
and vehicle-mounted external
antenna. For more information
about RF exposure, visit the FCC
website atwww.fcc.gov.
FCC Notice and Cautions
This device and its accessories
complywith part 15 of FCC rules.
Operation is subject to the
following twoconditions: (1) This
device and its accessories may not
cause harmful interference, and (2)
this device and itsaccessories must
accept any interference received,
including interference that causes
undesired operation.
Any changes or modifications not
expressly approved in this user
guide could void your warranty for
this equipment. Use onlythe

JS750 15
supplied antenna. Use of
unauthorized antennas (or
modifications to the antenna)
could impair call quality, damage
the phone, void your warranty
and/or violate FCC regulations.
Don't use the phone with a
damaged antenna. A damaged
antenna could cause a minor skin
burn. Contact your local dealer for
areplacement antenna.
Part 15.21 statement
Changes or modifications that are
not expresslyapproved by the
manufacturer could void the user's
authority to operate the
equipment.
Part 15.19 statement
This device and its accessories
comply with part15 of FCC rules.
Operation is subject to the
following two conditions:
(1) This device & itsaccessories
may not cause harmful
interference.
(2) This device & its accessories
must accept any interference
received, including interference
that may cause undesired
operation.
Part 15.105 statement
This equipment has been tested
and found to comply with the limits
for a class B digital device, pursuant
to Part 15 of the FCC Rules. These
limits are designed to provide
reasonable protection against
harmful interference in a residential
installation. This equipment
generates, uses, and can radiate
radio frequency energy and, if not
installed and used in accordance
with the instructions, may cause
harmful interference to radio
communications. However, there is
no guarantee that interference will
notoccur in a particular installation.
if this equipment does cause
harmful interference or television
reception, which can be determined
byturning the equipment off and
on, the user is encouraged to try to
correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving
antenna.
-Increase the separation between
the equipment and receiver.
-Connect the equipment into an
outlet on a circuit different from
that towhich the receiver is
connected.
-Consult the dealer or an experienced
radio/TV technician for help.

1.1 About Your Phone
Your JS750 phone allows you to keep in touch with friends and family back
home when traveling to another country or outside your network carrier
service area.
1.2 Getting to Know Your Touch Phone
16 JS750
Chapter 1 Getting Started
1. Notification LED LED lights blue when there are pending
notifications, lights red when charging, and lights green when fully
charged.
2. Earpiece Allows you to hear the caller.
3. Light and ProximitySensor Sensesthe ambient light and adjuststhe
screen backlight accordingly. Will also lock the screen during a call, so
thatkeys are not accidentally pressed.
4. LCD Screen Allows you to view incoming calls, messages and icon
indicators as well as a wide varietyof content you select for viewing.
5. End Key Use to end a call. Also returns to the Today Screen.
6. Start Key Press to open the Start menu.
7. SEND Key Use to make and answer calls. Press and hold to activate
voice commands.
Front panel

JS750 17
12. Headset Jack Allows you to plug in an optional 3.5mm headset for
convenient, hands-free conversations.
13 . Volume Keys Use to adjust the Master Volume in standby mode
and the Earpiece Volume during a call.
14 . Accessory/Charger Port Cover
15 . Reset Key Resets your phone (will end all applications currently
running).
1
6 . Accessory/ Charger Port Connects the phone to the battery
charger, or other compatible accessories.
17 . microSD™Slot Accommodates an optional microSD™card.
18 . Task Manager Key Allows you to view all programs currently
running on the device and corresponding memory usage. Also
allows you toend or go tothose tasks.
19. Camera/Video Key Press for quick access to the Camera function.
Press and hold this key to record a video.
Left panel Right panel
Back panel
9. Speaker Lets you hear the caller's voice in speakerphone mode. Also
lets you hear music and video sounds.
10. Camera Lens Use to take pictures and record video. Keep it clean
for optimal image quality.
11. Stylus Use to activate the Touch screen commands with ease. The
slot allows for convenient storage so your stylus is always at hand.
Top panel
8. Power/Lock(Unlock) Key Press and hold to turn the power on/off.
Press to lock and unlock the phone.

18 JS750
Getting Started
1. QWERTY Keypad Use to enter numbers and characters and select menu items.
2. Email Tab Key Use toaccess E-mail account(s) tosend/receiveemail messages.
3. Sym Key Use toinsertsymbols when entering text. Press the key, then touch the symbol on screen or press the
Qwerty key that corresponds with the onscreen symbol. Press the Sym Key again to exit from symbol mode.
4. Caps/ Shift Key Use to change letter case when typing.
5. Fn Key Use to insert symbols (at the top of each Qwerty key) into text or change input function from abc to
XT9.
6. Vibrate Key Use to turn Vibrate mode on/off (From the Today Screen, press and hold for about 3 seconds).
7. Space/Voice Command Key Use to enter a space while entering text. From the Today Screen, press to access
the call history or hold down for 3 seconds to access Voice Commands.
8. International Dial Key Press and hold the International Dial Key to display the + symbol. The symbol
automatically inserts the exit code for the country from which you are calling.
9. Speakerphone Key Use to activate Speakerphone during a call.
1
0. Back Key Press to return to back out of menus.
11. OK Key Use to activate a selected screen item.
1
2. Directional Key Use for quick, convenient navigation. In menus use to scroll to choices and settings.
1
3. Clear Key Press to delete a single space or character, or press and hold to delete a specific word plus its space.
14. Return Key Moves cursor to the next line.
1.3 Qwerty Keyboard
The Qwerty keyboard allows you to quickly and easily enter any kind of
data, whether it's a message (Text, Picture or Video), an Office file (Word,
Excel, Powerpoint or OneNote), or when using the Internet.

JS750 19
pictur
picture es s
m
music usic
phone
phone
fa
fav vorit oritecont econtact acts s
v
voicemail oicemail
clock
clock
ge
get tting st ting star art ted ed
me
message ssage
e-mail
e-mail
calendar
calendar
fa
fav vorit orite es s
Inicio
Inicio
T
Teléfono eléfono
T
Te ext xto o
E-mail
E-mail
C
Cont ontact actos os
V
Visual V isual Voice Mail oice Mail
Mobile Email
Mobile Email
Mobile IM
Mobile IM
Cit
CityID yID
Int
Interne ernetExplor tExplorer er
Today Screen Menu Start Menu
1.4 Menus and Applications Overview

20 JS750
Getting Started
C
Configur onfiguración ación
Reloj y alarmas
Inicio
Bloquear
Sonidos y notificaciones
Conexiones
Administrador de conexiones ina
Cambiar USB
Conexiones
Conexión del navegador
Configuración GPRS
Insctipción en dominio
USB a PC
WI-Fi
Personal
Cotones
Datos propietario
Teléfono
Voice Commands
Sistema
Acerca de
Administrador de tareas
Cerrificados
Cifrado
Comentarios del cliente
Configuración regional
Energía
GPS externo
Información del sisterma
Informe de errores
Limpiar Almacen.
Luz de fondo
Memoria
Pantalla
Programas administrados
Qualcomm Control Panel
Quitar programas Sensor
Microsoft My Phone
Bluetooth
Bloquear tecla
R
RSSV SSVie iew wer er
Alarma
Alarmas s
Calendario
Calendario
T
Tar area eas s
No
Not ta
as s
Explor
Explorador de ar ador de archiv chivos os

JS750 21
Office Mobile
Office Mobile
Imágene
Imágenesyvídeos syvídeos
W
Windo indow wsMedia sMedia
W
World Clock orld Clock
Buscar T
Buscar Teléfono eléfono
Calculador
Calculadora a
A
Adobe R dobe Reader LE eader LE
V
Voice C oice Commands ommands
Juegos
Juegos
Solitario
A
Administr dministrador de ador de
t
tar area eas s
Mark
Marke etplace tplace
Micr
Microsoft My Phone osoft My Phone
MSN Mone
MSN Money y
MSN El T
MSN El Tiempo iempo
Cámer
Cámera a
Intr
Introducción oducción
A
Activ ctive S e Sync ync
W
Windo indow wsLiv sLive e
NOTES :
●
All screen shotsin this guide are
simulated. Actual displaysmayvary.
●
Instructions to perform tasks in this
guide may change depending on the
software version of your phone.
●
Unless specified otherwise, all
instructions to perform tasks in this
guide assume that you are starting
from the Today screen.

22 JS750
Getting Started
1.5 Installing the Battery
and Storage Card
The Battery
NOTE It is important to fully charge the
battery before initial use of the phone.
The phone comes with a
rechargeable battery. Keep the
battery charged while not in use in
order to maximize talk and standby
time. The battery charge level is
shown at the top of the LCD screen.
Installing the Battery
To install the battery, insert the top
edge (aligning the battery
terminals) of the battery into the
opening on the back of the phone.
Push the battery down until it clicks
into place. Place the top edge of
battery cover with the tabs and
slots aligned, then apply steady
upward pressure until it clicks into
place.
Removing the Battery
Turn power off. Apply steady
downward pressure to the center of
the battery cover release it. Remove
the cover, then use the fingertip
cutout to lift the bottom edge of
the battery out.
Installing the microSD
1. Remove the microSD card slot
cover.
2. Push the microSD cardinto the
slot with its gold contacts facing
down until it clicks into place
and then replace the slotcover.

JS750 23
1.6 Charging the Battery
Your JS750 phone device comes
with a cableless wall adapter and a
USB data cable which connect
together to charge your phone. To
charge your phone:
NOTICE
Please use only an approved charging
accessory to charge your LG phone.
Improper handling of the charging port, as
well as the use of an incompatible charger,
may cause damage to your phone and
void the warranty.
Battery Charge Level
You can find the battery charge
level at the top right of the LCD
screen. When the charge level
becomes low, the phone blinks the
battery icon, and displays a warning
message. As the charge level
approaches empty, the phone will
turn off. Unsaved items may be lost.
NOTICE
Please make sure that the side with the
USB symbol faces up before inserting a
charger or data cable into the charger
port of your phone.

24 JS750
Getting Started
Charging with USB
You can use your computer to
charge your phone. Connect one
end of the USB cable to the
charging accessory port on your
phone and the other end to a
highpower USB port on your PC
(commonly located on the front
panel of the computer). It is best to
use the rear USB port when
connecting to a desktop PC. A USB
Hub should be powered by an
external power source (see Note
below).
NOTES
●
Low-power USB ports are not
supported, such as the USB
porton your keyboard or bus-
powered USB hub.
●
When the device needs to
charge from USB port of the
computer, the necessary USB
driver should be first installed
on the computer.
-When the device is in, LG
USB Modem Driver should be
installed in advance for USB
charging.
-When the device is in
ActiveSync mode as a default
setting, the computer needs
ActiveSync program including
USB driver to be installed for
USB charging.
-On the other hand, you do not
need to install the specific
driver for USB charging when
the device is in USB Mass
Storage, because OS like
Windows has the driver.
●
Another way for USB charging
with ActiveSync mode
1Press the Start Key , tap
Settings , tap Connections
,and then tap USB to PC.
2. Unchecked "Enable advanced
network functionality.
1.7 Starting Up
Turning the power on and off
Turning the Phone On
1. Press and hold the Power/Lock
Key for a couple of
seconds.
NOTE When you turn on your phone
for the first time, followthe
instructions on the screen to
activate your device.
Turning the Phone Off
1. Press and hold the Power/Lock
Key for a few seconds.
2. Tap
Yes to confirm that you want
to shut down the device.

JS750 25
1.8 Today Screen
The Today Screen provides quick access to various frequently used device
programs and applications. It also displays the Notification and Status Icon
taskbar and the Options taskbar for additional quick and easy access options.
1.9 Notification and Status Icon Taskbar
The Icon taskbar displays a variety of icons to let you know device status
and notification of events. Status icons can include connectivity, network,
signal strength, volume, battery and time. Notifications can include missed
calls, new SMS/MMS messages, and more. The following is an example of
the icons you may see on the Icon taskbar.
Notification and Status
Icon taskbar
See "Notification and Status
Icon T
askbar" below for details.
Current selection
Options Icon
Options will depend on the selected menus.
Options taskbar
See "Options Taskbar" on page
28 for details.
Contacts Icon
Tap to open Contacts panel.
Start icon
T
ap to open the
Start menu.
Today Screen
See "Today Screen"
on page 50 for
details.

26 JS750
Getting Started
Tap the Icon taskbar to display a drop-down menu that allows you to zoom,
access the wireless manager for network connection status, change volume,
see remaining battery power, set the Clock/Alarm, and more.
1.10Options Taskbar
The Options Taskbar displays options that are dependent on the current
menuor function.
Today Screen Options Taskbar
The TodayScreen Options taskbar includesaccess icons for the Start
screen , and Contacts list .
NOTE If you havenew notifications waiting, the Notifications icon will be
displayed instead.
Notifications
Contacts
Notification and Status
Icon taskbar
Drop-down taskbar

JS750 27
1.11 Start Menu
The Start menu is home to all the programs, applications and settings of
your Windows Phone-powered device, giving you complete access at the tip
of your finger.
To open the Start screen press the
Start Key at the bottom center of
the phone or tap the Start icon in the Options taskbar on the lower left
corner of the LCD.
To launch a program application or open a panel, simply tap the
program icon.
Tap to return to the
Today Screen.
Flick up or down to scroll the screen.
Tap an icon to launch it.
Lock icon
Tap to temporarily lock.
See page 30for details.
Close icon
Tap toclose the Start menu.
Notification and Status
Icon taskbar
Options taskbar

1.12 Lock
Locking the Phone
You can lock your phone to guard
against accidental or intentional
use. Press the Power/Lock Key
to lock your phone.
Unlocking the Phone
To unlock your phone, press the
Power/Lock Key to turn the
screen on. Then, touch and slide
the Lock icon to either left or
right. If you wish, you can set the
phone to require a password before
it is unlocked. Tosetup a password
requirement, go tothe Lock menu
(Start > Settings > Lock ).
Unlocking with Gestures
Another option to unlock your
phone is available that allows you to
go to a specific function. Gestures
allows you to perform the gesture
on the lock screen. For Gestures
information, go to the Gesture
Unlock page on the Lock menu
(Start > Settings > Lock >
scroll to Gesture Unlock page).
To go to the Calendar from the
Lock screen, follow the images
below:
Sleep Mode
Sleep mode automatically locks the
phone against accidental actions
and conserves battery power. While
in Sleep mode, only the Power/Lock
Key at the top edge of the
phone will wake up your phone.
The phone automaticallyenters
Sleep mode after a period of
inactivity.
28 JS750
Getting Started
Locked Screen Gesture Entered on
Locked Screen
Activated Gesture

JS750 29
NOTE If a phone password is required to
unlock, you will be prompted for
the password when you unlock
the phone.
Unlocking the Phone
The steps and instructions in this
guide begin with the screen already
unlocked. If your phone screen is in
sleep mode, press the Power/Lock
button on the top side of the
phone. Then, slide the Unlock icon
to the left, or right, to unlock the
screen.
Notifications on the Lock
panel
Your phone still alerts you to
incoming calls and alarms even if the
screen is locked. The device only
responds to a deliberate touch and
slide action, not to simple taps which
could be accidental. To unlock the
screen, touch and slide a displayed
icon. For instance, to answer an
incoming call, touch and slide the
Answer icon to the right.
Tracking notifications on the Lock
panel
Your phone keeps track of
notifications not responded to on
the lock screen. When the screen is
locked, the Lock icon shows the
number of pending notifications,
including missed calls, new
messages and upcoming
appointments.
To view notifications on the Lock
panel
1. On the Lock screen, tap the Lock
icon ( ). Notification icons
representing each type of
notification arethen displayed
below the Lock icon.
2. Slide a notification icon right or
left to view the respective
information. For instance, slide
the Missed Call icon toview your
list of missed calls.

30 JS750
Getting Started
1.13 Adjusting the Volume
Asingle Volume Control panel
adjusts both the system volume
(notifications and audio/video
playback volume) and the phone
ring volume of your phone.
Accessing the Volume Control panel
To open the Volume Control panel:
●Press the Volume Keys on the
left side of the phone.
●Tap the Volume Control icon in
the Status Icon taskbar.
NOTE The Volume Control panel
automatically closes after a few
seconds if accessed by pressing
the Volume Keys. If accessed from
the Status Icon taskbar, tap
to close the panel.
To change volume settings using
the Volume Keys
1. Press the side volume keys .
2. Tap the volume bar you want to
adjust, then press the Volume
Up/ Down Key to adjust the
volume level. You can also:
●Tap
Vibrate to switch to vibrate
mode.
●Tap
Off to mute the volume.
NOTE If you press the Volume Down Key
repeatedly, both volumes are
silenced.
Tochange volume settings using
the volume bars
1. Open the Volume Control panel.
2. Tap or drag your finger up/down
either of the volume bars. You
can also:
●Tap
Vibrate toswitch to vibrate
mode.
●Tap
Off to mute the volume.
NOTE Use the Volume Up / Down Key
on the left side of your phone
toadjust the conversation phone
volume during an ongoing call.
OK

JS750 31
1.14 Finger Movement
Gestures
The touch screen is sensitive to
fingertip movements allowing you to
scroll and pan with ease.
Finger scrolling
Finger scrolling is available in all
directions (up and down or left and
right) and can be used to move
through web pages, documents, and
lists (like the Contacts, file,
message, calendar, and
appointmentslists).
Toscroll up and down
●To scroll down, drag your finger
upward on the touch screen.
●To scroll up, drag your finger
downward on the touch screen.
●To auto-scroll, flick your finger
upward or downward on the
touch screen. Tap the screen to
stop scrolling.
To scroll left and right
●To scroll towards the right, drag
your finger to the left.
●To scroll towards the left, drag
your finger to the right.
●Toauto-scroll, flick your finger
left or right. Tap the screen to
stop scrolling.
When finger
scrolling, drag or
flick your finger
on the touch
screen.

32 JS750
Finger panning
Finger panning doesn't limit you to
opposite 90 degree directions. You
can use finger panning to move to
and view other parts of a zoomed-in
photo, web page, document, or an
email. To pan, touch and keep your
finger on the touch screen, then
drag your finger in any direction.
1.15 Using the Zoom Bar
Your JS750 phone has a handy and
unique zoom control tool right on
the touch screen. When viewing a
Web page in the Web browser,
touch the Menu icon to display
the Zoom bar. Simply slide your
finger across the Zoom bar to easily
set the zoom to the level that's best
for you.

JS750 33
Changing Networks with Your
JS750
You can change network modes
manually in phone settings.
To change networks manually
1. From the Today Screen, tap the
Notification and Status Icon
taskbar.
2. Tap the connections indicator
to access the following
menu.
3. Tap
Settings .
4. Scroll horizontally (at the top of
the screen) tothe
Network tab.
5. Tap under Mode of
operation, then tap the network
you want to set.
●
GSM/UMTS Mode: access GSM
networks only.
6. Tap tosavesettings.
OK
Network
tab
Settings
