ATTACHMENT M – USER’S MANUAL

-1-
LG-DB525 User Guide
Ver. 0.11
2001.07.20

-2-
Unlocking Your Phone..........................................................................4
View of Phone ......................................................................................4
Installing and Removing the Battery.....................................................5
Turning Your Phone On and Off...........................................................5
Main Menu...........................................................................................6
Power Save Mode.................................................................................6
Menu Navigation..................................................................................6
Entering Characters Using the Keypad(T9) ..........................................7
Display Icons........................................................................................8
Antenna................................................................................................8
Signal Strength .....................................................................................9
Battery Capacity...................................................................................9
Using the AC Adapter...........................................................................9
Using Your Phone..................................................................................................................................9
Placing a Call......................................................................................10
Roaming With Your Sprint PCS PhoneTM ...........................................10
Calling Experience .............................................................................10
Correcting Dialing Mistakes............................................................... 11
In Call Options ...................................................................................12
Incoming Call Notification .................................................................12
Answering Calls .................................................................................13
Displaying Your Sprint PCS Phone Number(phone book –not
functioning)........................................................................................13
Setting the Ring Volume to Vibrate.....................................................14
Getting the Most From Sprint PCS Service........................................................................................... 14
New Massage Alerts...........................................................................14
Retrieving Page/Text Messages..........................................................15
Page/Text Message Storage ................................................................16
Roaming on to Other Service Providers..............................................16
(Call History-not functioning)............................................................17
Page/Text Messages............................................................................17
Erasing Page/Text Messages...............................................................17
Sounds................................................................................................17
Adjusting the Volume .........................................................................17
Selecting Ring Types for Voice Calls..................................................18

-3-
Tone Length........................................................................................19
Display Menu ...................................................................................................................................... 20
Security ..............................................................................................20
Locking Your Phone...........................................................................20
Unlocking Your Phone........................................................................20
Changing the Lock Code ....................................................................21
Answering Your Phone with the Hands-Free Car Kit..........................21

-4-
Unlocking Your Phone
If you received your Sprint PCS DB-525 in the mail, you may need to unlock it before making calls.
1. Press the END/PWR Switch for 2~3 secs.
2. Highlight Unlock and press .
3
3
3.
.. Enter your four-digit lock code. For security purposes, the code will not be visible as you type.
Note: If you can’t recall your lock code, try using the last four digits of your Social Security number, the
last four digits of your Sprint PCS Phone Number or 0000.
View of Phone
1. END/PWR Switch: Lets you power the phone on or off.
2. Antenna: Fised antenna provides optimum reception for 1900 MHz frequencies.
3. Power On Indicator: Illuminates red when the phone powers on or when you receive incoming calls.
Flashes red when you have messages of scheduled alarms.
4. Headset Jack: Provides connection for an optional headsat.
5. Volume Control Keys: Adjust the Ring Volume in the Main Menu or the Voice Volume during a call.
The keys also scroll through mouths in the Calendar or pages in the MiniBrowser.
6. Mouse Key: Allows quick and easy scrolling through the menus.
7. OK: Lets you place a call, receive a call, end a call or select menu options.
8. CLR: Lets you clear an entry or back-up in the menu.
9. Folder : Lets you answer or end calls.
OK

-5-
Installing and Removing the Battery
To install the battery, insert the bottom of the battery into the opening on the back of the phone. Then,
push the battery down until the latch clicks.
To remove the battery, press down on the latch and remove the battery from the phone.
Turning Your Phone On and Off
To turn your phone on, move the On/Off Switch (near the antenna) to the ON position. Your phone
performs a short self-test before letting you know it is operational.
If your phone does not turn on, make sure the battery is installed correctly and is adequately charged or
has external power (via the AC Adapter, Cigarette Lighter Adapter or Hands-Free Car Kit).
Folder
Mouse
END/PWR
OK
CLR
Headset Jack
Volume
Control

-6-
To turn your phone off, move the On/Off Switch to the OFF position.
Main Menu
When your phone acquires Sprint PCS Service, the Greeting (a banner of text), the current time and date
and the Main Menu are displayed. If you are in a Sprint PCS or authorized analog cellular provider’s
service area, you are ready to send and receive calls.
Power Save Mode
When the phone is in an area without service for 15 minutes, it stops searching for service and enters into
the power Save Mode. When your phone activates this feature, Power Save is displayed on your screen.
The phone automatically checks for service periodically or you can check manually by pressing any key.
Menu Navigation
The Mouse Key lets you scroll circularly through menus quickly and easily.
As you navigate through a menu, the options are highlighted (Highlighted Test Example ) . Select an
option by highlighting it and pressing . The scroll bar at the right of the menu keeps track of your
position in the menu at all times.
For example, if you want to view your last incoming call:
1. From the Main Menu, highlight Call Logs and press . (It may already be highlighted.)
Up
Down
Left Right
OK
OK

-7-
2. Press the Mouse Key down to highlight and press .
If you have received any calls, they are displayed on the screen.
Entering Characters Using the Keypad(T9)
To enter a letter, punctuation or number when creating Phone Book or Scheduler entries, press the
corresponding key until the desired character appears. By default, the first letter of a word is capitalized
and following letters are lowercase. Characters in the following order:
1 . ? , ‘& -@ ( ) / ~P Q R S 7 p q r s
A B C 2 a b c 2 T U V 8 t u v 8
D E F 3 d e f 3 W X Y X 9 w x y z 9
G H I 4 g h i 4 Space 0
J K L 5 j k l 5 Forward
M N O 6 m n o 6 Backward
After a character is entered, the cursor automatically advances to the next space after two seconds. You
can also advance the cursor by pressing or entering a character not on the same key.
If you make a mistake, press to move the cursor left or to erase a character. To clear the
entire entry, press and hold for two seconds.
Incoming Log
1 7
PQRS
9
WXYZ
8
TUV
6
MNO
5
JKL
4
GHI
3
DEF
2ABC
1
#
*
0
Space
#
*
CLR
CLR

-8-
R
A
Display Icons
Display icons are the symbols your phone uses to communicate important information. They are as
follows:
ICON DESCRIPTION
Signal Strength (full strength)
In Use
No Service
May result from one of the following :
lSearching for service
lno service
lmaintenance required
Roaming
(occurs in a non-Sprint PCS area)
Analog Service Available
TNew page/text or Browser messages
V New voicemail <TBD>
Battery Charge Status (fully charged)
Antenna
The antenna on your Sprint PCS SP-510 provides maximum reception without the inconvenience of
extending of retracting it.
!!! WARNING –CHOKING HAZARD –ANTENNA MAY BECOME DISLODGED
Attempting to remove or repeated twisting of the antenna will loosened the materials securing it
into antenna. Once the antenna is loosened or removed, only an authorized Sprint PCS
Representative can restore the antenna’s original integrity. Do not attempt to remove or twist the

-9-
antenna.
Signal Strength
The quality of each call you make or receive depends on the signal strength on your area. The number of
bars in the Signal Strength icon informs you of the current strength. The more bars, the stronger the signal.
Battery Capacity
Your Sprint PCS SP-510 is equipped with a Lithium Ion (LiIon) battery. It allows you to recharge your
battery before it is fully drained. The battery provides approximately hours of continuous digital
talk time or approximately of continuous digital standby time.
Note: Long backlight settings affect the battery’s talk and standby times.
When the battery reaches 5% of its capacity, the battery icon blinks. When there is about one minute of
talk time left, the phone sounds an audible alert every 30 seconds and then powers down.
If the battery’s charge is completely run down, it takes 2 to 3 hours to fully recharge. It is not necessary to
let the battery completely run down before recharging.
To charge your batteries, use only Sprint PCS-approved charging accessories.
Using the AC Adapter
To charge the battery, plug the AC Adapter into a standard wall outlet and connect it to the phone via the
I/O Connector on the bottom of the phone. Alternatively, you can place the phone in the charging cradle
provided with your phone and connect the AC Adapter to the back of the cradle.
The battery Charge Status icon flashes during charging. When the battery is fully charged, the battery
icon stops flashing.
Using Your Phone
3.25
130hours
