LG LG-E425 User manual

Internal Use Only
Service Manual
LG-E425
Date: April, 2013 / Issue 1.0

- 2 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Table Of Contents
1. INTRODUCTION..................................................................... 3
1.1 Purpose ........................................................................................................3
1.2 Regulatory Information.........................................................................3
2. PERFORMANCE...................................................................... 5
2.1 Product Name............................................................................................5
2.2 Supporting Standard..............................................................................5
2.3 Main Parts : GSM Solution.....................................................................5
2.4 HW Features ...............................................................................................6
2.5 SW Features............................................................................................. 10
2.6 HW SPEC. ................................................................................................. 13
3. CIC AND SERVICE CENTER .................................................. 21
3.1 CIC FAQ...................................................................................................... 21
4. TROUBLE SHOOTING .......................................................... 30
4.1 RF Component ....................................................................................... 30
4.2 SIGNAL PATH...........................................................................................32
4.3 Checking TCXO Block........................................................................... 35
4.4 Checking GSM TX Module(GSM PAM + ASM) Block ............... 37
4.5 Checking WCDMA Block .................................................................... 40
4.6 Checking GSM Block............................................................................50
4.7 GPS/WIFI/BT RF Component ............................................................ 57
4.8 GPS/WIFI/BT SIGNAL PATH ................................................................ 59
4.9 GPS/WIFI/BT Trouble shooting ........................................................ 60
4.10 Power ON Trouble Shooting........................................................... 66
4.11 Charging Trouble Shooting............................................................ 69
4.12 3M FF CameraTrouble Shooting.................................................. 71
4.13 Main LCD trouble................................................................................ 74
4.14 Proximity Sensor on/o Trouble Shooting...............................76
4.15 Motion Sensor on/o Trouble Shooting...................................78
4.16 Compass Sensor on/o Trouble Shooting ............................... 80
4.17 DC Motor Trouble Shooting........................................................... 82
4.18 SIM detect Trouble Shooting......................................................... 84
4.19 Audio Troble.......................................................................................... 87
5. DOWNLOAD......................................................................... 98
6. BLOCK DIAGRAM..............................................................118
7. CIRCUIT DIAGRAM ............................................................123
8. BGA PIN MAP.....................................................................132
9. PCB LAYOUT.......................................................................138
10. CALIBRATION...................................................................140
11. HIDDEN MENU.................................................................160
12. DISASSEMBLE GUIDE .................................................166
13. EXPLODED VIEW & REPLACEMENT PART LIST .............174
13.1 EXPLODED VIEW................................................................................174
13.2 Replacement Parts ...........................................................................175
13.3 Accessory .............................................................................................201

- 3 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
LGE Internal Use Only
1.1 Purpose
This manual provides the information necessary to repair, calibration, description and download the features of
this model.
1.2 Regulatory Information
A. Security
Toll fraud, the unauthorized use of telecommunications system by an unauthorized part (for example, persons
other than your company’s employees, agents, subcontractors, or person working on your company’s behalf)
can result in substantial additional charges for your telecommunications services.
System users are responsible for the security of own system. There are may be risks of toll fraud associated with
your telecommunications system. System users are responsible for programming and configuring the
equipment to prevent unauthorized use. The manufacturer does not warrant that this product is immune from
the above case but will prevent unauthorized use of common carrier telecommunication service of facilities
accessed through or connected to it. The manufacturer will not be responsible for any charges that result from
such unauthorized use.
B. Incidence of Harm
If a telephone company determines that the equipment provided to customer is faulty and possibly causing
harm or interruption in service to the telephone network, it should disconnect telephone service until repair can
be done. A telephone company may temporarily disconnect service as long as repair is not done.
C. Changes in Service
A local telephone company may make changes in its communications facilities or procedure. If these changes
could reasonably be expected to affect the use of the phones or compatibility with the net work, the telephone
company is required to give advanced written notice to the user, allowing the user to take appropriate steps to
maintain telephone service.
D. Maintenance Limitations
Maintenance limitations on the phones must be performed only by the manufacturer or its authorized agent.
The user may not make any changes and/or repairs expect as specifically noted in this manual. Therefore, note
that unauthorized alternations or repair may affect the regulatory status of the system and may void any
remaining warranty.
1. INTRODUCTION

- 4 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
LGE Internal Use Only
E. Notice of Radiated Emissions
This model complies with rules regarding radiation and radio frequency emission as defined by local regulatory
agencies. In accordance with these agencies, you may be required to provide information such as the following
to the end user.
F. Pictures
The pictures in this manual are for illustrative purposes only; your actual hardware may look slightly different.
G. Interference and Attenuation
A phone may interfere with sensitive laboratory equipment, medical equipment, etc. Interference from
unsuppressed engines or electric motors may cause problems.
H. Electrostatic Sensitive Devices
ATTENTION
Boards, which contain Electrostatic Sensitive Device (ESD), are indicated by the sign.
Following information is ESD handling:
• Service personnel should ground themselves by using a wrist strap when exchange system boards. • When
repairs are made to a system board, they should spread the floor with anti-static mat which is also grounded.
• Use a suitable, grounded soldering iron. • Keep sensitive parts in these protective packages until these are used.
• When returning system boards or parts like EEPROM to the factory, use the protective package as described.

2. PERFORMANCE
- 5 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
2.1 Product Name
LG-E430 : WCDMA900/2100+EGSM/GSM850/DCS/PCS
(HSDPA 3.6Mbps / GPRS Class 12 / EDGE Class 12)
2.2 Supporting Standard
Item Feature Comment
Supporting Standard WCDMA(FDD1,8)/EGSM/GSM850/DCS1800/PCS1900 with
seamless handover
Phase 2+(include AMR)
Frequency Range WCDMA(FDD1) TX : 1920 – 1980 MHz
WCDMA(FDD1) RX : 2110 – 2170 MHz
WCDMA(FDD8) TX : 880 - 915 MHz
WCDMA(FDD8) RX : 925 – 960 MHz
EGSM TX : 880 – 915 MHz
EGSM RX : 925 – 960 MHz
GSM850 TX : 824 – 849 MHz
GSM850 RX : 869 – 894 MHz
DCS1800 TX : 1710 – 1785 MHz
DCS1800 RX : 1805 – 1880 MHz
PCS1900 TX : 1850 – 1910 MHz
PCS1900 RX : 1930 – 1990 MHz
Application Standard WAP 2.0
2.3 Main Parts : GSM Solution
Item Part Name Comment
Digital Baseband MSM7225A: Qualcomm
Analog Baseband PM8029 : Qualcomm
RF Chip RTR6285A : Qualcomm
2. PERFORMANCE
2.1 Product Name
LG-E425 : WCDMA900/2100+EGSM/GSM850/DCS/PCS
(HSDPA 3.6Mbps / GPRS Class 12 / EDGE Class 12)
2.2 Supporting Standard
2.3 Main Parts : GSM Solution
