LG LG535 User manual

LLGG553355
User Guide
MMBB0136301(1.1)
UUsseerrGGuuiiddee
LLGG553355
H
GGuuiiddeeddeeLL’’uuttiilliissaatteeuurr
LLGG553355
*LG535-cover 5/10/05 1:14 PM Page 1

LG535 1
Important Safety Precautions
Read these simple guidelines. Breaking the rules may be dangerous or illegal. Further detalied information is given in this
user guide.
Violation of the instructions may cause serious injury or death.
●Never use an unapproved battery since this could damage the phone and/or battery and could cause
the battery to explode.
●Never place your phone in a microwave oven as it will cause the battery to explode.
●Do not dispose of your battery by fire or with hazardous or flammable materials.
●Make sure that no sharp-edged items such as animal’s teeth, nails, come into contact with the
battery. There is a risk of this causing a fire.
●Store the battery in a place out of reach of children.
●Be careful that children do not swallow any parts such as rubber plugs (earphone, connection parts of
the phone, etc.). This could cause asphyxiation or suffocation.
●Unplug the power cord and charger during lightning storms to avoid electric shock or fire.
Warning
*LG535-(E)(150X120).QXD 5/10/05 1:17 PM Page 1

2LG535
Important Safety Precautions
●When riding in a car, do not leave your phone or set up the hands-free kit near to the air bag. If
wireless equipment is improperly installed and the air bag is activated, you may be seriously injured.
●Do not use a hand-held phone while driving.
●Do not use the phone in areas where its use is prohibited. (For example: aircraft).
● Do not expose the battery charger or adapter to direct sunlight or use it in places with high humidity,
such as a bathroom.
●Never store your phone in temperatures less than -4°F or greater than 122°F.
●Do not use harsh chemicals(such as alcohol, benzene, thinners, etc.) or detergents to clean your
phone. There is a risk of this causing a fire.
●Do not drop, strike, or shake your phone severely. Such actions may harm the internal circuit boards
of the phone.
●Do not use your phone in high explosive areas as the phone may generate sparks.
●Do not damage the power cord by bending, twisting, pulling, or heating. Do not use the plug if it is loose
as it may cause a fire or electric shock.
*LG535-(E)(150X120).QXD 5/10/05 1:17 PM Page 2

LG535 3
●Do not place any heavy items on the power cord. Do not allow the power cord to be crimped as it may
cause fire or electric shock.
●Do not handle the phone with wet hands while it is being charged. It may cause an electric shock or
seriously damage your phone.
●Do not disassemble the phone.
●Do not place or answer calls while charging the phone as it may short-circuit the phone and/or cause
electric shock or fire.
●Only use the batteries, antennas, and chargers provided by LG. The warranty will not be applied to
products provided by other suppliers.
●Only authorized personnel should service the phone and its accessories. Faulty installation or
service may result in accidents and consequently invalidate the warranty.
●Do not hold or let the antenna come in contact with your body during a call.
●An emergency call can be made only within a service area. For an emergency call, make sure that you
are within a service area and that the phone is turned on.
*LG535-(E)(150X120).QXD 5/10/05 1:17 PM Page 3

4LG535
Contents
Welcome . . . . . . . . . . . . . . . . . . . . . . . . 8
FCC RF Exposure Information . . . . . . 9
Phone Overview . . . . . . . . . . . . . . . . .10
Menus Overview . . . . . . . . . . . . . . . . 11
Getting Started with Your Phone . 13
The Battery . . . . . . . . . . . . . . . . . . . . . 13
Charging the Battery . . . . . . . . . . . . . 13
Turning the Phone On and Off . . . . 14
Screen Icons . . . . . . . . . . . . . . . . . . . .15
Making Calls . . . . . . . . . . . . . . . . . . . . 16
Receiving Calls . . . . . . . . . . . . . . . . . 16
Quick Access to Convenient
Features . . . . . . . . . . . . . . . . . . . . . . . . 17
Manner Mode . . . . . . . . . . . . . . . . . 17
Lock Mode . . . . . . . . . . . . . . . . . . . . . . 17
Mute Function . . . . . . . . . . . . . . . . . . 17
Volume Quick Adjustment . . . . . . . . 17
Call Waiting . . . . . . . . . . . . . . . . . . . . . 18
Caller ID . . . . . . . . . . . . . . . . . . . . . . . . 18
Speed Dialing . . . . . . . . . . . . . . . . . . 18
Entering and Editing Information . 19
Text Input . . . . . . . . . . . . . . . . . . . . . . . 19
Text Input Examples . . . . . . . . . . . . . 20
Contacts in Your Phone’s Memory . 22
The Basics of Storing Contacts
Entries . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Options to Customize Your
Contacts . . . . . . . . . . . . . . . . . . . . . . . . 23
Editing Contacts Entries . . . . . . . . . . 25
Deleting . . . . . . . . . . . . . . . . . . . . . . . . 27
Phone Numbers With Pauses . . . . 28
Searching Your Phone’s Memory . 29
Making a Call From Your
Phone’s Memory . . . . . . . . . . . . . . . . 29
Using Phone Menus . . . . . . . . . . . . . 30
Menu Access . . . . . . . . . . . . . . . . . . . . . 30
1. Contacts . . . . . . . . . . . . . . . . . . . . . . 31
1. List Entries . . . . . . . . . . . . . . . . . . . . . . .31
2. New Entry . . . . . . . . . . . . . . . . . . . . . . .31
3. Speed Dials . . . . . . . . . . . . . . . . . . . . . .32
4. Groups . . . . . . . . . . . . . . . . . . . . . . . . . . 32
5. Voice Dial . . . . . . . . . . . . . . . . . . . . . . . .32
6. Erase All Contacts . . . . . . . . . . . . . . . .32
2. Call History . . . . . . . . . . . . . . . . . . .33
1. Recent Calls . . . . . . . . . . . . . . . . . . . 33
2. Incoming Calls . . . . . . . . . . . . . . . . . . 33
3. Outgoing Calls . . . . . . . . . . . . . . . . . . 34
4. Missed Calls . . . . . . . . . . . . . . . . . . . . 34
5. Erase Logs . . . . . . . . . . . . . . . . . . . . . 34
6. Call Timer . . . . . . . . . . . . . . . . . . . . . . . 34
3. Messaging . . . . . . . . . . . . . . . . . . . 35
*LG535-(E)(150X120).QXD 5/10/05 1:17 PM Page 4

LG535 5
1. Voice Mail . . . . . . . . . . . . . . . . . . . . . 36
2. Text Message . . . . . . . . . . . . . . . . . . . 36
2.1 Send Message . . . . . . . . . . . . . . . . .36
2.2 Inbox . . . . . . . . . . . . . . . . . . . . . . . . . .37
Message Icon Reference . . . . . . . . . . . . 37
2.3 Outbox . . . . . . . . . . . . . . . . . . . . . . . .38
2.4 Favourites . . . . . . . . . . . . . . . . . . . . .38
2.5 Erase Messages . . . . . . . . . . . . . . . .38
2.6 Draft . . . . . . . . . . . . . . . . . . . . . . . . . .39
2.7 Saved . . . . . . . . . . . . . . . . . . . . . . . . .39
2.8 Msg Settings . . . . . . . . . . . . . . . . . . .39
3. Multimedia Message . . . . . . . . . . . . .40
3.1 Send Message . . . . . . . . . . . . . . . . .40
3.2 Inbox . . . . . . . . . . . . . . . . . . . . . . . . . .41
3.3 Outbox . . . . . . . . . . . . . . . . . . . . . . . .41
3.4 Favourites . . . . . . . . . . . . . . . . . . . . .41
3.5 Erase Messages . . . . . . . . . . . . . . . .41
3.6 Draft . . . . . . . . . . . . . . . . . . . . . . . . . .42
3.7 Saved . . . . . . . . . . . . . . . . . . . . . . . . .42
3.8 Msg Settings . . . . . . . . . . . . . . . . . . .42
3.9 Memory Status . . . . . . . . . . . . . . . . .42
4. Web Alert . . . . . . . . . . . . . . . . . . . . . . .42
5. E-mail . . . . . . . . . . . . . . . . . . . . . . . . . . .42
6. IM & Chat . . . . . . . . . . . . . . . . . . . . . . .42
4. Do More . . . . . . . . . . . . . . . . . . . . . .43
5. Settings . . . . . . . . . . . . . . . . . . . . . . .47
1 . Sounds . . . . . . . . . . . . . . . . . . . . . . . . .47
1.1 Ringers . . . . . . . . . . . . . . . . . . . . . . .47
1.2 Key Tone . . . . . . . . . . . . . . . . . . . . .48
1.3 Volume . . . . . . . . . . . . . . . . . . . . . . . 48
1.4 Alerts . . . . . . . . . . . . . . . . . . . . . . . . 48
2. Display . . . . . . . . . . . . . . . . . . . . . . . . . 49
2.1 Banner . . . . . . . . . . . . . . . . . . . . . . . .49
2.2 Backlight . . . . . . . . . . . . . . . . . . . . . .49
2.3 Picture Album . . . . . . . . . . . . . . . . . .49
2.4 Menu Style . . . . . . . . . . . . . . . . . . . 49
2.5 Theme Colors . . . . . . . . . . . . . . . . . . 49
2.6 Time . . . . . . . . . . . . . . . . . . . . . . . . . 49
2.7 Date . . . . . . . . . . . . . . . . . . . . . . . . . .49
3. Games/Tools . . . . . . . . . . . . . . . . . . . . .50
3.1 Volume . . . . . . . . . . . . . . . . . . . . . . . .50
3.2 Notification . . . . . . . . . . . . . . . . . . . . .50
3.3 Backlight . . . . . . . . . . . . . . . . . . . . . . .50
3.4 Memory Status . . . . . . . . . . . . . . . . .50
4. System . . . . . . . . . . . . . . . . . . . . . . . . . 50
4.1 Set Mode . . . . . . . . . . . . . . . . . . . . . .50
4.2 Set NAM . . . . . . . . . . . . . . . . . . . . . . 51
4.3 Call Guard . . . . . . . . . . . . . . . . . . . . . .51
5. Security . . . . . . . . . . . . . . . . . . . . . . . . 51
5.1 Lock Phone . . . . . . . . . . . . . . . . . . . 51
5.2 Change Lock . . . . . . . . . . . . . . . . . . .51
5.3 Reset Defaults . . . . . . . . . . . . . . . . . .52
6. Airplane Mode . . . . . . . . . . . . . . . . . . .52
*LG535-(E)(150X120).QXD 5/10/05 1:17 PM Page 5

6LG535
Contents
7. Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
7.1 Shortcut . . . . . . . . . . . . . . . . . . . . . . .52
7.2 Call Answer . . . . . . . . . . . . . . . . . . . .52
7.3 Auto Answer . . . . . . . . . . . . . . . . . . .52
7.4 Data In . . . . . . . . . . . . . . . . . . . . . . . .53
7.5 Auto Key Guard . . . . . . . . . . . . . . . . .53
7.6 Language . . . . . . . . . . . . . . . . . . . . . .54
8. Voice Dial . . . . . . . . . . . . . . . . . . . . . . . .54
8.1 Voice Dial Prompt . . . . . . . . . . . . . . .54
8.2 Train Words . . . . . . . . . . . . . . . . . . . .54
9. Mini SD Card . . . . . . . . . . . . . . . . . . . .54
9.1 Pictures . . . . . . . . . . . . . . . . . . . . . . .55
9.2 Videos . . . . . . . . . . . . . . . . . . . . . . . . .55
9.3 MP3 . . . . . . . . . . . . . . . . . . . . . . . . . .55
9.4 Memory Info . . . . . . . . . . . . . . . . . . .55
9.5 Reset Card . . . . . . . . . . . . . . . . . . . . .55
0. Phone Info . . . . . . . . . . . . . . . . . . . . . . .55
0.1 Phone Info . . . . . . . . . . . . . . . . . . . . .55
0.2 Icon Glossary . . . . . . . . . . . . . . . . . . .55
6. Camera . . . . . . . . . . . . . . . . . . . . . . .56
1. Take Picture . . . . . . . . . . . . . . . . . . . . .56
2. Make Video . . . . . . . . . . . . . . . . . . . . . .56
3. Picture Album . . . . . . . . . . . . . . . . . . . .57
4. Video Album . . . . . . . . . . . . . . . . . . . . .57
5. Online Album . . . . . . . . . . . . . . . . . . . .57
6. Camera Settings . . . . . . . . . . . . . . . . .57
6.1 Shutter Sound . . . . . . . . . . . . . . . . . .57
6.2 Resolution . . . . . . . . . . . . . . . . . . . . .57
6.3 Flash . . . . . . . . . . . . . . . . . . . . . . . . . .57
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . 58
TIA Safety Information . . . . . . . . . . . 58
Safety Information . . . . . . . . . . . . . . . 61
FDA Consumer Update . . . . . . . . . . . 63
Consumer Information on SAR . . . 69
Accessories . . . . . . . . . . . . . . . . . . . . 71
Warranty Information . . . . . . . . . . . . 72
Index . . . . . . . . . . . . . . . . . . . . . . . . . . 74
*LG535-(E)(150X120).QXD 5/10/05 1:17 PM Page 6

LG535 7
Welcome
Congratulations for choosing the advanced and compact
LG535 cellular phone, designed to operate with the latest
digital mobile communication technology, Code Division
Multiple Access (CDMA) and Advanced Mobile Phone
Service (AMPS). Along with the many advanced features of
the CDMA system, such as greatly enhanced voice clarity,
this phone offers:
●Large, easy-to-read, 7-line backlight LCD with status
icons.
●Text Message, Multimedia Message, Web Alert,
Voicemail, and Caller ID.
●18-key keypad.
●Speaker phone feature.
●Menu-driven interface with prompts for easy operation
and configuration.
●Any key answer, auto answer, auto retry, one-touch and
speed dialing with 99 memory locations.
●Bilingual (English and Spanish) capabilities.
Check Accessories
Your mobile phone comes with a rechargeable battery and
an AC adapter. Please verify that these accessories are
included.
Important Information
This user’s guide provides important information on the use
and operation of your phone. Please read all the information
carefully prior to using the phone for the best performance
and to prevent any damage to or misuse of the phone. Any
unapproved changes or modifications will void your
warranty.
FCC Part 15 Class B Compliance
This device and its accessories comply with part 15 of FCC
rules. Operation is subject to the following two conditions:
(1) This device and its accessories may not cause harmful
interference, and (2) this device and its accessories must
accept any interference received, including interference
that causes undesired operation.
Industry Canada Compliance
This phone complies with Industry Canada RSS 133. This
phone complies with the Class B limits for radio noise
emissions as set out in the interference causing standard
entitled "Digital Apparatus" ICES-003 of Industry Canada.
*LG535-(E)(150X120).QXD 5/10/05 1:17 PM Page 7

Technical Details
The LG 535 is an all digital phone that operates on both Code
Division Multiple Access (CDMA) frequencies: cellular
services at 800 MHz and Personal Communication Services
(PCS) at 1.9 GHz. Also, the LG 535 works on Advanced Mobile
Phone Service (AMPS). We call it a tri-mode phone. Since the
phone operates on Cellular, PCS and AMPS, the call fail rate is
less than on a conventional dual-mode or singlemode phone.
CDMA technology uses a feature called DSSS (Direct
Sequence Spread Spectrum) that enables the phone to keep
communication from being crossed and to use one frequency
channel by multiple users in the same specific area. This
results in a 10-fold capacity increase when compared with
analog mode. In addition, features such as soft / softer
handoff, hard Handoff, and dynamic RF power control
technologies combine to reduce call interruptions.
The Cellular and PCS CDMA networks consist of MSO (Mobile
Switching Office), BSC (Base Station Controller), BTS (Base
Station Transmission System), and MS (Mobile Station). The
following table lists some major CDMA standards.
*TSB -74: Protocol between an IS-95A system and ANSI J-STD-008
1xRTT system receives twice as many subscribers in the wireless
section as IS-95. Its battery life is twice as long as IS-95. High-
speed data transmission is also possible.
8LG535
Welcome
CDMA
Standard
Basic Air
Interface
TIA/EIA-95A
TSB-74
ANSI J-STD-008
TIA/EIA-IS2000
ANSI TIA/EIA
553A
CDMA Dual-Mode Air Interface
14.4kbps radio link protocol and
inter-band operations
IS-95 adapted for PCS frequency
band cdma2000 1xRTT
AirInterface
Advanced Mobile Phone Service
MAS-BS
PCSC-RS
Intersystem operations
Nom-signaling data comm.
Cellular base station
Cellular mobile station
PCS personal station
PCS base station
Speech CODEC
TIA/EIA/IS-634
TIA/EIA/IS/651
TIA/EIA/IS-41-C
TIA/EIA/IS-124
TIA/EIA/IS-97
TIA/EIA/IS-98
ANSI J-STD-018
ANSI J-STD-019
TIA/EIA/IS-125
TIA/EIA/IS-96-B
TIA/EIA/IS-99
TIA/EIA/IS-637
TIA/EIA/IS-657
IS-801
TIA/EIA/IS-707-A
Speech CODEC
Async Data and Fax
Short message service
Packet Data
Position Determination
Service (gpsOne)
High Speed Packet Data
Network
Service
Performance
Designator Description
*LG535-(E)(150X120).QXD 5/10/05 1:17 PM Page 8

LG535 9
FCC RF Exposure Information
WARNING! Read this information before operating the
phone.
In August 1996, the Federal Communications Commission
(FCC) of the United States, with its action in Report and
Order FCC 96-326, adopted an updated safety standard for
human exposure to Radio Frequency (RF) electromagnetic
energy emitted by FCC regulated transmitters. Those
guidelines are consistent with the safety standard
previously set by both U.S. and international standards
bodies.
The design of this phone complies with the FCC guidelines
and these international standards.
Bodily Contact During Operation
This device was tested for typical use with the back of the
phone kept 3/4 inches (2 cm) from the body. To comply with
FCC RF exposure requirements, a minimum separation
distance of 3/4 inches (2 cm) must be maintained between
the user’s body and the back of the phone, including the
antenna, whether extended or retracted. Third-party belt-
clips, holsters, and similar accessories containing metallic
components should not be used. Avoid the use of
accessories that cannot maintain 3/4 inches (2 cm)
distance between the user’s body and the back of the
phone and have not been tested for compliance with FCC
RF exposure limits.
Vehicle-Mounted External Antenna (Optional, if available.)
A minimum distance of 8 inches (20 cm) must be
maintained between the user / bystander and the vehicle-
mounted external antenna to satisfy FCC RF exposure
requirements. For more information about RF exposure,
visit the FCC website at www.fcc.gov.
Caution
Use only the supplied and approved antenna. Use of
unauthorized antennas or modifications could impair call
quality, damage the phone, void your warranty and/or
result in violation of FCC regulations.
Do not use the phone with a damaged antenna. If a
damaged antenna comes into contact with the skin a
minor burn may result. Contact your local dealer for a
replacement antenna.
*LG535-(E)(150X120).QXD 5/10/05 1:17 PM Page 9

10 LG535
Phone Overview
1
2
3
4
5
6
9
Camera Lens
Flash
17
8
7
10
11
12
13
14
15
1616
1. Earpiece
2. Slide Slide up the case to answer an incoming call and close
to end the call.
3. LCD Screen Displays messages and indicator icons.
4. Headset Jack
5. Side Keys Use to adjust the ringer volume in Main Menu
Screen and the earpiece volume during a call.
6. Voice Dial Key Use for quick access to Voice Dial.
7. Left Soft Key Use to display the function setting menu.
8. SEND Key Use to place or answer calls.
9. Mini SD Card Provides the folder for Pictures, videos, and
MP3s, When you insert the SD Card into the Phone.
10. Message Key Use to retrieve or send voice and text messages.
11. Navigation Key Use for quick access to messages, contacts,
recent calls, and wireless web.
12. Camera Key Use for quick access to Camera function.
13. OK Key Use for quick access to DO More menu.
14. Right Soft/MP3 Key Use to select an action within a menu. Use
for quick access to MP3 function.
15. END/Power Key Use to turn the power on/off and to end a call.
Also return to the main menu display screen.
16. BACK Key Press to delete a single space or character. Press and
hold to delete entire words. Press this key once in a menu to go
back one level.
17. Microphone
*LG535-(E)(150X120).QXD 5/10/05 1:17 PM Page 10

LG535 11
Menus Overview
Contacts
1. List Entries
2. New Entry
3. Speed Dial
4. Groups
5. Voice Dial
6. Erase All Contacts
Call History
1. Recent Calls
2. Incoming Calls
3. Outgoing Calls
4. Missed Calls
5. Erase Logs
1. Incoming Calls
2. Outgoing Calls
3. Missed Calls
4. All Calls
6. Call Timer
1. Last Call
2. Recent Calls
3. Life time
Messages
1. Voicemail
2. Text Message
1. Send Message
2. Inbox
3. Outbox
4. Favourites
5. Erase Messages
6. Draft
7. Saved
8. Msg Settings
1. Save to Outbox
2. Auto Delete Inbox
3. Auto Scrolling
4. Callback Number
5. Msg Reminder
6. Canned Message
7. Default Entry Mode
3. Multimedia Message
1. Send Message
2. Inbox
3. Outbox
4. Favourites
5. Erase Messages
6. Draft
7. Saved
8. Msg Settings
1. Save Message
9. Memory Status
4. Web Alert
5. E-mail
6. IM & Chat
Do More
1. Wireless Web
2. Tunes
3. Favourites
4. Games
5. Messaging
6. Tools
7. Camera
8. Images
9. IM & Chat
*LG535-(E)(150X120).QXD 5/10/05 1:17 PM Page 11

12 LG535
Menus Overview
Settings
1. Sounds
1. Ringers
2. Key Tones
3. Volume
4. Alerts
2. Display
1. Banner
2. Backlight
3. Picture Album
4. Menu Style
5. Theme Color
6. Time
7. Date
3. Games/Tools
1. Volume
2. Notification
3. Backlight
4. Memory Status
4. System
1. Set Mode
2. Set NAM
3. Call Guard
5. Security
1. Lock Phone
2. Change Lock
3. Reset Defaults
6. Airplane Mode
7. Setup
1. Shortcut
2. Call Answer
3. Auto-Answer
4. Data In
5. Auto Key Guard
6. Language
8. Voice Dial
1. Voice Dial Prompt
2. Train Words
9. Mini SD Card
0. Phone Info
1. Phone Info
2. Icon Glossary
Camera
1. Take Picture
2. Make Video
3. Picture Album
4. Video Album
5. Online Album
6. Camera Settings
*LG535-(E)(150X120).QXD 5/10/05 1:17 PM Page 12

LG535 13
Getting Started with Your Phone
The Battery
NNOOTTEE
It is important to fully charge the battery before initial
use of the phone.
The phone comes with a rechargeable battery. Keep the
battery charged while not in use in order to maximize talk
and standby time. The battery charge level is shown at the
top of the LCD screen.
Installing the Battery
To install the battery, insert the battery into the opening on
the back of the phone. Put the battery cover on the battery
and push it slightly upwards.
Removing the Battery
Turn the power off. While pressing the PUSH button on the
back of the phone, pull the battery cover downward and
remove it. Then remove the battery by pressing the upper
area of it.
Charging the Battery
To use the charger provided with your phone:
Warning! Use only the charger provided with the phone.
Using any charger other than the one included with the LG
535 may damage your phone or battery.
1. Plug the round end of the adapter into the phone’s
charger jack and the other end into an electrical outlet.
2. The charge time varies depending upon the battery
level. The maximum charge time for a fully discharged
battery is 3.5 hours.
Battery Charge Level
The battery charge level is shown at the top right of the
LCD screen. When the battery charge level becomes low,
the low battery sensor alerts you in three ways: sounding
an audible tone, blinking the battery icon, and displaying
POWERING DOWN! If the battery charge level becomes
exceedingly low, the phone automatically switches off and
any function in progress is not saved.
Fully DischargedFully Charged
*LG535-(E)(150X120).QXD 5/10/05 1:17 PM Page 13

14 LG535
Getting Started with Your Phone
Turning the Phone On and Off
Turning the Phone On
1. Install a charged battery or connect the phone to an
external power source such as a vehicle power
charger or hands-free car kit.
2. Press for a few seconds until the LCD screen lights
up.
NNOOTTEE
Like any other radio device, avoid any unnecessary
contact with the antenna while your phone is on.
Turning the Phone Off
1. Press and hold until the display turns off.
Signal Strength
Call quality depends on the signal strength in your area.
The signal strength is indicated on the screen as the
number of bars next to the signal strength icon: The more
bars, the better the signal strength. If the signal quality is
poor, move to an open area. If you are in a building, the
reception may be better near a window.
*LG535-(E)(150X120).QXD 5/10/05 1:17 PM Page 14

LG535 15
Screen Icons
When the phone is powered on, the top line of the LCD screen displays icons indicating the status of the phone.
Signal strength indicator. The strength of the signal
received by the phone is indicaed by the number of
bars displayed.
Battery indicator. Indicates battery charge level.
In use indicator. A call is in progress.
* No icon indicates the phone is in
Main Menu Screen.
No service indicator. The phone is not receiving a
system signal.
Analog
Ringer On
Digital indicator
Roaming indicator.
The phone is outside of the home service area
New text message indicator
Airplane Mode
New voice mail indicator
New text and voice message indicator
Alarm On
1x Data Active
Manner Mode Ringer Off
SSL TTY
New MMS Msgs 3G service
SD Card
SSL
*LG535-(E)(150X120).QXD 5/10/05 1:17 PM Page 15

16 LG535
Getting Started with Your Phone
Making Calls
1. Make sure the phone is turned on. If not, press for
about 3 seconds.
2. Enter the phone number (include the area code if
needed).
3. Press .
lf the phone is locked, enter the lock code.
Call Failed - indicates the call did not go through.
Restricted - indicates outgoing calls are in restricted
mode.
4. Press to end the call.
Correcting Dialing Mistakes
If you make a mistake while dialing a number, press
once to erase the last digit entered, or hold down
for at least 2 seconds to delete all digits.
Receiving Calls
1. When the phone rings or vibrates, press to answer.
NNOOTTEE
If you press or (the side keys) while the phone
is ringing, the ringing or vibration is muted for that call.
*LG535-(E)(150X120).QXD 5/10/05 1:17 PM Page 16

LG535 17
Quick Access to Convenient Features
Manner Mode
Use Manner Mode in public places. When Manner Mode
is set, is displayed on the screen, the key tones are
silent, and the phone is set to vibrate.
Manner Mode Quick Activation
1. From Main Menu Screen press From Main Screen, Hold
Key to Vibrate.
Manner Mode Quick Cancellation
1. Hold key about 2 seconds for Manner Mode
cancellation.
Lock Mode
Use Lock Mode to prevent others from using your phone.
When Lock Mode is set, your 4-digit password is required
to use the phone.
NNOOTTEE
The lock code/password is the last 4 digits of phone
number by default.
Mute Function
The Mute function prevents the other party from hearing
your voice, but allows you to hear the other party.
Mute Quick Activation
1. Press Right Soft Key Options and select Mute
during a call.
Mute Quick Cancellation
1. Press Right Soft Key Options and select Un
mute.
Volume Quick Adjustment
Use the side keys to adjust the earpiece and ringer
volumes. The upper key increases the volume and the
lower key decreases the volume.
●Earpiece volume can be adjusted during a call.
NNOOTTEE
Key beep volume is adjusted through the Menu.
*LG535-(E)(150X120).QXD 5/10/05 1:17 PM Page 17

18 LG535
Quick Access to Convenient Features
Call Waiting
Your cellular service may offer call waiting. While a call is
in progress, two beeps indicate another incoming call.
When call waiting is enabled, you may put the active call
on hold while you answer the other incoming call. Check
with your cellular service provider for information about
this function.
1. Press to receive a waiting call.
2. Press again to switch between calls.
Caller ID
Caller ID displays the phone number or name of the
incoming call. If the caller’s identity is stored in Contacts,
the name appears with the number. Check with your
service provider to ensure they offer this feature.
Speed Dialing
Speed Dialing is a convenient feature that allows you to
make phone calls quickly and easily with a few keystrokes.
Your phone recalls the number from your Contacts,
displays it briefly, and then dials it.
Dialing Speed Dials from 1 to 9
Press and hold the Speed Dial number.
OR
Enter the speed dial number and press .
Dialing Speed Dials from 10 to 99
Press the first digit and then press and hold the key of
the last digit.
OR
Enter the first and second digits and press .
*LG535-(E)(150X120).QXD 5/10/05 1:17 PM Page 18

LG535 19
Entering and Editing Information
Text Input
You can input and edit your Banner, Schedule, Contacts,
and messages.
Key Functions
Right Soft Key : Press to scroll through the
available text input modes:
Word -> Abc -> 123 -> Symbols -> Smileys ->
Canned Message
Shift: Press to change case.
text : Word -> WORD -> word
Abc text : Abc -> ABC -> abc
Next : In Word mode, press to display other
matching words.
Space : Press to complete a word and insert a
space.
Back : Press to delete a single space or
character. Hold to delete words.
Punctuation : In mode, press to insert
punctuation in a word and complete a
sentence.
Text Input Modes
There are five modes for entering text, numbers, special
characters, and punctuation. In a text entry field, pressing
Right Soft Key displays a pop-up list of text modes.
Word Mode
Use to type text using one keystroke per letter. The phone
translates keystrokes into common words by using the
letters on each key and a compressed database.
Abc (Multi-tap) Mode
Use to type text using up 4 strokes per letter.
123 (Numbers) Mode
Use to type numbers using one keystroke per number.
Symbols Mode
Use to insert special characters or punctuation. There are
35 special characters including “I__I” which inserts a
space and “¶” which forces the text to the next line.
Smileys Mode
Use to insert smiley graphics. There are 36 smiley
characters.
*LG535-(E)(150X120).QXD 5/10/05 1:17 PM Page 19
