LG Wine II User manual

P/NO : MMBB0369301(1.1) G
LG Wine II
LG Wine II
LG-UN430
Printed in Korea

Copyright ©2010 LG Electronics, Inc. All rights reserved.
LG and the LG logo are registered trademarks of LG
Group and its related entities. All other trademarks are
the property of their respective owners.

Important Safety Precautions
1
Important Safety Precautions
Read these instructions. Breaking the rules may be dangerous or
illegal. Further detailed information is given in this user guide.
WARNING! Violation of the instructions may cause serious injury or
death.
1. Never use an unapproved battery since this could
damage the phone and/or battery and could cause
the battery to explode.
2. Never place your phone in a microwave oven as it will
cause the battery to explode.
3. Never store your phone in temperatures less than
-4°F or greater than 122°F.
4. Do not dispose of your battery by fire or with
hazardous or flammable materials.
5. When riding in a car, do not leave your phone or set
up the hands-free kit near to the air bag. If wireless
equipment is improperly installed and the air bag is
deployed, you may be seriously injured.
6. Do not use a hand-held phone while driving.
7. Do not use the phone in areas where its use is
prohibited. (For example: aircraft)

Important Safety Precautions
2
Important Safety Precautions
1. Do not expose the battery charger or adapter to direct
sunlight or use it in places with high humidity, such as
a bathroom.
2. Do not use harsh chemicals (such as alcohol, benzene,
thinners, etc.) or detergents to clean your phone. This
could cause a fire.
3. Do not drop, strike, or shake your phone severely. It
may harm the internal circuit boards of the phone.
4. Do not use your phone in high explosive areas as the
phone may generate sparks.
5. Do not damage the power cord by bending, twisting,
pulling, or heating. Do not use the plug if it is loose as
it may cause a fire or electric shock.
6. Do not place any heavy items on the power cord. Do
not allow the power cord to be crimped as it may
cause electric shock or fire.
7. Do not handle the phone with wet hands while it is
being charged. It may cause an electric shock or
seriously damage your phone.
8. Do not disassemble the phone.

3
Important Safety Precautions
1. Do not place or answer calls while charging the phone as it may
short-circuit the phone and/or cause electric shock or fire.
2. Do not hold or let the antenna come in contact with your body
during a call.
3. Make sure that no sharp-edged items such as animal’s teeth or
nails, come into contact with the battery. This could cause a fire.
4. Store the battery out of reach of children.
5. Be careful that children do not swallow any parts (such as
rubber plugs, earphone, connection parts of the phone, etc.)
This could cause asphyxiation or suffocation resulting in serious
injury or death.
6. Unplug the power cord and charger during lightning storms to
avoid electric shock or fire.
7. Only use the batteries and chargers provided by LG. The
warranty will not be applied to products provided by other
suppliers.
8. Only authorized personnel should service the phone and its
accessories. Faulty installation or service may result in accidents
and consequently invalidate the warranty.
9. Your service provider programs one or more emergency phone
numbers, such as 911, that you can call under any
circumstances, even when your phone is locked. Your phone’s
preprogrammed emergency number(s) may not work in all
locations, and sometimes an emergency call cannot be placed
due to network, environmental, or interference issues.

Table of Contents
4
Table of Contents
Important Safety
Precautions 1
Table of Contents 4
Welcome 9
Technical Details 10
Important Information 10
FCC Part 15 Class B
Compliance 10
FCC RF Exposure Information 10
Phone Overview 13
Menus Overview 15
Getting Started with Your
Phone 18
The Battery 18
Installing the Battery 18
Removing the Battery 18
Charging the Battery 18
Battery Charge Level 19
Turning the Phone On and
Off 19
Turning the Phone On 19
Turning the Phone Off 19
Signal Strength 20
Screen Icons 20
Making Calls 20
Correcting Dialing Mistakes 21
How to Install Your microSDTM
Card 21
How to Remove Your microSDTM
Card 21
Redialing Calls 22
Receiving Calls 22
Quick Access to Convenient
Features 23
Lock Mode 23
Mute Function 23
Quick Volume Adjustment 23
Call Waiting 23
Caller ID 24
Speed Dialing 24
Entering and Editing
Information 25
Text Input 25

5
Table of Contents
Contacts in Your Phone’s
Memory 26
The Basics of Storing Contacts
Entries 26
Phone Numbers With Pauses 26
Storing a Number with Pauses 27
Adding a Pause to an Existing
Number 27
Your Phone’s Contacts List. 27
Scrolling Through Your Contacts28
Making a Call From Your Phone’s
Memory 29
Using Phone Menus 30
Contacts 30
1. New Contact 30
2. Contact List 31
3. Groups 31
4. Speed Dials 32
5. My VCard 32
Messaging 33
1. New Text Message 33
2. New Picture Message 34
3. Inbox 35
4. Sent 37
5. Drafts 38
6. Voicemail 39
7. Templates 39
8. Settings 40
8.1 All Messages 40
8.2 Text Message 41
8.3 Picture Message 41
8.4 Edit Voicemail # 41
9. Delete All 42
Call History 42
1. Missed Calls 43
2. Received Calls 43
3. Dialed Calls 43
4. All Calls 43
5. Call Timer 43
6. Data Counter 44
Multimedia 44
1. Take Photo 45
2. Record Video 46
3. Record Voice 47
4. Images 48

Table of Contents
6
Table of Contents
5. Videos 48
6. Sound 49
7. Shuffle 50
easyedgeSM 51
1. Launch 52
My Schedule 53
1. Alarm Clock 53
2. Calendar 53
3. Notepad 54
Music 55
1. Last Played Song / Now
Playing 55
2. All Songs 55
3. My Playlists 56
4. Albums 56
5. Artists 56
6. Genres 56
Tools 57
1. Voice Command 57
1.1 Start Command 57
1.1.1 Call <Name> or <Number> 57
1.1.2 Voicemail 57
1.1.3 Missed Calls 57
1.1.4 Messages 57
1.1.5 Time & Date 58
1.1.6 Help 58
1.2 Command Mode 58
1.3 Announce Alert 58
1.4 Train Word 58
1.5 Best Match 58
2. My Menu 59
3. Calculator 59
4. Ez Tip Calc 59
5. World Clock 60
6. Stopwatch 60
7. Unit Converter 60
Settings 61
1. Sound 61
1.1 Ringers 61
1.2 Volume 62
1.3 Message Alerts 62
1.4 Alert Type 62
1.5 Service Alerts 62
1.6 Power On/Off Tone 63
1.7 Flip Tone 63

7
Table of Contents
2. Display 64
2.1 Wallpaper 64
2.1.1 Main Screen 64
2.1.2 Front Screen 64
2.1.3 Shuffle 64
2.2 Widget 65
2.2.1 Widget Settings 65
2.2.2 Widget Location 65
2.3 Banner 65
2.4 Backlight 66
2.5 Menu Styles 66
2.6 Language 66
2.7 Clocks & Calendar 66
2.7.1 Main Screen 67
2.7.2 Front Screen 67
2.8 Font Settings 67
2.9 Color Schemes 68
2.0 Name Match for Dialing 68
3. Security 68
3.1 Lock Phone 68
3.2 Restrictions 69
3.3 Emergency #s 69
3.4 Change Lock Code 70
3.5 Master Reset 70
4. Call Settings 70
4.1 Answer Options 70
4.2 Auto Retry 71
4.3 One-Touch Dial 71
4.4 Voice Privacy 71
4.5 Noise Cancellation 72
4.6 Airplane Mode 72
4.7 TTY Mode 72
5. Bluetooth 73
5.1 Paired Devices 73
5.2 Power 74
5.3 My Visibility 74
5.4 My Bluetooth Name 74
5.5 My Bluetooth Info 75
6. PC Connection 75
7. System 75
7.1 Network 75
7.1.1 System Select 75
7.1.2 Set NAM 76
7.1.3 Auto NAM 76
7.1.4 Serving System 76
7.2 Location 76
8. Memory 77
9. Phone Info. 77
Tone Room 78
FM Radio 78
PAC-MAN 79

Table of Contents
8
Table of Contents
Safety 80
TIA (Telecommunications
Industry Association) Safety
Information 80
Exposure to Radio Frequency
Signal 80
Antenna Care 80
Phone Operation 81
Tips on Efficient Operation 81
Driving 81
Electronic Devices 81
Pacemakers 81
Persons with Pacemakers: 82
Hearing Aids 82
Other Medical Devices 82
Health Care Facilities 82
Vehicles 83
Posted Facilities 83
Aircraft 83
Blasting Areas 83
Potentially Explosive Atmosphere 83
For Vehicles Equipped with an Air
Bag 84
Charger and Adapter Safety 84
Battery Information and Care84
Safety Information 85
Explosion, Shock, and Fire
Hazards 85
General Warnings and Cautions 87
Warning! Important safety
information 88
Avoiding hearing damage 88
Using your phone safely 89
Using headsets safely 89
FDA Consumer Update 90
Consumer Information on
SAR 101
Accessories 105
Warranty Information 106
Index 109
Some content in this user guide may
differ from your phone depending on
the phone software. Features and
specifications are subject to change
without prior notice.
