LG CodePlus HCS6150R Series User manual

© Copyright 2012 LG Electronics U.S.A., Inc.
HCS6150R CodePlus™ Series
Card Frame with Power Supply
Installation & Setup Guide
Warranty
P/N: 206-4138 (Rev C)

2206-4138
© Copyright 2012 LG Electronics U.S.A., Inc.
WARNING:
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. ALL
CARDS USED IN THE HCS6150R MUST BE INSERTED AND REMOVED BY QUALIFIED
SERVICE PERSONNEL ONLY.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert
the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence
of important operating and maintenance (servicing) instructions in the literature accompanying
the appliance.
WARNING:
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such
as vases, shall be placed on the apparatus.
L’appareil ne doit pas être exposé à des égouttements d’eau ou des éclaboussures et de plus
qu’aucun objet rempli de liquide tel que des vases ne doit être placé sur l’appareil.
REGULATORY INFORMATION:
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial envi-
ronment. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference
to radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user should be required to correct the interference at
his own expense.
CAUTION:
Do not attempt to modify this product in any way without written authorization from LG
Electronics U.S.A., Inc. Unauthorized modification could void the user’s authority to operate
this product.
NOTE TO SATELLITE DISH INSTALLER:
This reminder is provided to call your attention to Articles 810 and 820 of the 2002 National
Electrical code. Refer to Article 810, in particular 810-1 and 810-15, for required grounding of
the metal dish antenna. Refer also to 810-2 which, by reference to Article 820, requires that
the satellite dish coaxial cable shield be connected to the grounding system of the building as
close to the point of cable entry as practical.
COMPLIANCE:
The responsible party for this product’s compliance is: LG Electronics U.S.A., Inc.
2000 Millbrook Drive, Lincolnshire, IL 60069, USA • Phone: [phone]
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
For Customer Support/Service, please call: 1-888-865-3026
The latest product information and documentation is available online at:
www.LGsolutions.com/products
Marketed and Distributed in the United States by LG Electronics U.S.A., Inc.
2000 Millbrook Drive, Lincolnshire, IL 60069

206-4138 3
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
Read all the safety and operating instructions
before operating the product.
2. Keep these instructions.
Retain the safety and operating instructions for
future reference.
3. Heed all warnings.
Adhere to all warnings on the product and in
the operating instructions.
4. Follow all instructions.
Follow all operating and use instructions.
5. Do not use this apparatus near water.
Do not use this product near water or moisture
or in an area, such as a basement, that might
become flooded.
6. Clean only with dry cloth.
Unplug this product before cleaning. Do not use
liquid cleaners or aerosol cleaners.
7. Do not block any ventilation openings.
Install in accordance with the manufacturer's
instructions.
This product is designed to fit in a rack. The
ventilation slots and openings in the cabinet are
provided to ensure reliable operation of the
product and to protect it from overheating. These
openings must not be blocked or covered.
This installation should be attempted only by a
qualified service technician and should conform
to all local codes. All cards used in the
HCS6150R must be inserted and removed by
qualified service personnel only.
8. Do not install near any heat sources, such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9. Do not defeat the safety purpose of the
polarized or grounding-type plug. A polar-
ized plug has two blades with one wider
than the other. A grounding-type plug has
two blades and a third grounding prong. The
wide blade or the third prong are provided
for your safety. If the provided plug does not
fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked
on or pinched, particularly at plugs,
convenience receptacles, and the point
where it exits from the apparatus.
11. Only use attachments/accessories specified
by the manufacturer.
12. Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination in order to avoid injury from tip-
over.
13. Refer all servicing to qualied service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the appara-
tus has been exposed to rain or moisture,
does not operate normally, or has been
dropped.
14. Power Sources
This product should be operated only from the
type of power source indicated on the marking
label. If you are not sure of the type of power
supply to your INSTALLATION, consult your
product dealer or local power company.
Important safeguards for you and your new product
THIS PRODUCT HAS BEEN MANUFACTURED AND TESTED WITH SAFETY IN MIND.
IMPROPER USE, HOWEVER, CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR
FIRE HAZARDS. TO AVOID DEFEATING THE SAFEGUARDS THAT HAVE BEEN BUILT
INTO THIS PRODUCT, PLEASE READ AND OBSERVE THE FOLLOWING SAFETY
POINTS WHEN INSTALLING AND USING THIS PRODUCT.
(Continued on next page)

4206-4138
IMPORTANT SAFETY INSTRUCTIONS
(Continued from previous page)
15. Overloading
Do not overload wall power outlets and
extension cords as this can result in a risk of
fire or electric shock.
16. Disconnect Device
The AC mains plug is used as the disconnect
device. The disconnect device must remain
readily operable.
17. Object and Liquid Entry
Never push objects of any kind into this product
through openings as they may touch dangerous
voltage points or short-out parts that could result
in a fire or electric shock. Never spill liquid of
any kind on the product.
18. Outdoor Use
Warning: To prevent fire or shock
hazards, do not expose this product
to rain or moisture.
19. Wet Location
The apparatus shall not be exposed to dripping
or splashing and no objects filled with liquids,
such as vases, shall be placed on the apparatus.
20. Test Equipment
In some cases, LG has supplied or recom-
mended the use of test equipment and devices
for the setup and testing of the equipment. The
operation and maintenance of test equipment
is described in their associated instruction
manuals. Please refer to these manuals for
explicit instructions regarding the safe use and
handling of the equipment.
21. Damage Requiring Service
Unplug this product from the wall power outlet
and refer servicing to qualied service personnel
under the following conditions:
a. If the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have
fallen into the product.
c. If the product has been exposed to rain or
water.
d. If the product does not operate normally by
following the operating instructions. Adjust
only those controls that are covered by the
operating instructions, as an improper
adjustment of other controls may result in
damage and will often require extensive
work by a qualied technician to restore the
product to its normal operation.
e. If the product has been dropped or the cabi-
net has been damaged.
f. If the product exhibits a distinct change in
performance.
22. Servicing
Caution: These servicing instructions
are for use by qualied service
personnel only. To reduce the risk of
electrical shock, do not perform any servicing
other than that described in the operating
instructions unless you are qualied to do so.
23. Replacement Parts
When replacement parts are required, be sure
the service technician uses replacement parts
specied by the manufacturer or that have the
same characteristics as the original parts.
Unauthorized substitutions may result in re,
electric shock, or other hazards.
24. Safety Check
Upon completion of any service or repairs to this
product, ask the service technician to perform
safety checks to determine that the product is in
proper operating condition.
Caution: Refer all servicing to qualied
service personnel.
(Continued on next page)

206-4138 5
(Continued from previous page)
HCS6150R Rack Installation (also see pages
12-13)
To install the HCS6150R in a rack:
• Carefully slide the HCS6150R into a standard
19-inch equipment rack.
• When mounting in the rack, make sure to use the
appropriate hardware. ALL FOUR MOUNTING
SCREWS MUST BE USED.
• This equipment is not designed to support other
devices. Do NOT stack other equipment on the
top of the HCS6150R.
• Rear cabling must be dressed and supported so
that the weight of the cabling is not a strain on
the HCS6150R connectors.
• MOUNTING OF THE EQUIPMENT IN THE
RACK SHOULD BE SUCH THAT A HAZARDOUS
CONDITION IS NOT ACHIEVED DUE TO
UNEVEN MECHANICAL LOADING.
Rack-mount Considerations
A. Elevated Operating Ambient
If installed in a closed or multi-unit rack assembly,
the operating ambient temperature of the rack
environment may be greater than room ambient.
Therefore, consideration should be given to
installing the equipment in an environment com-
patible with the maximum ambient temperature
(Tma) specified by the manufacturer (see
Specifications information in this document).
B. Reduced Air Flow
Installation of the equipment in a rack should be
such that the amount of air flow required for safe
operation of the equipment is not compromised.
To ventilate the system normally and avoid over-
heating, leave at least 1 inch (2.5 cm) on each
side of the HCS6150R unit. Do NOT stack other
equipment on the top of the HCS6150R unit.
C. Circuit Overloading
Consideration should be given to the connection
of the equipment to the supply circuit and the
effect that overloading of the circuits might have
on overcurrent protection and supply wiring.
D. Reliable Earthing
Maintain reliable earthing of rack-mounted
equipment. Particular attention should be given
to supply connections other than direct connec-
tions to the branch circuit (e.g. use of power
strips).
E. Mains Outlet Earthing
The apparatus with Class I construction must be
connected to a mains socket outlet with a pro-
tective earthing connection.
HCS6150R Installation on a Flat Surface
To install the HCS6150R on a level surface (table
top, shelf, etc.):
• Install the equipment in an environment compatible
with the maximum operating ambient temperature
(Tma) specied by the manufacturer (see
Specications information in this document).
• P lace spacers or rubber feet (not provided) on the
bottom of the HCS6150R.
• Carefully place the HCS6150R on the level
surface.
• Air ow is from bottom to top (when viewed from
the front). To ventilate the system normally and
avoid overheating, leave at least 1 inch (2.5 cm)
on each side of the HCS6150R unit. Do NOT
stack other equipment on the top of the
HCS6150R.
IMPORTANT SAFETY INSTRUCTIONS

6206-4138
Safety Warnings ....................... 2
Important Safety Instructions. . . . . . . . . . . . 3 – 5
Table of Contents / Setup Checklist . . . . . . . . 6
HCS6150R Product Description . . . . . . . . . . . 7
Back Panel Overview . . . . . . . . . . . . . . . . . 8 – 9
Installing CodePlus Transcoder Cards . . . . . 10
Front Panel Overview / Ventilation . . . . . . . . .11
Rack Installation . . . . . . . . . . . . . . . . . . . 12 – 13
Equipment Setup Review / Specifications. . . 14
Document Revision History / Notes . . . . . . . 15
Warranty . . . . . . . . . . . . . . . . . . . . . Back Cover
Table of Contents / Setup Checklist
Setup Checklist
Check the following items before you begin HCS6150R installation and setup procedures.
__ Unpack the HCS6150R unit and all accessories.
HCS6150R Accessory: AC Power Cord and Adapter
__ Unpack the CodePlus transcoder card(s) and all accessories and also the feature card,
if applicable. Refer to the appropriate Installation & Setup Guide for the transcoder
card(s) and the feature card for further information.
Note: All transcoder cards to be installed in the card frame must be the same type, i.e.,
all HCS7700 or all HCS7710 or all HCS7720 cards.
__ Select the location for mounting the HCS6150R. Ensure that adequate ventilation is
available . Make sure the fan cooling vents are unobstructed.
__ Obtain the necessary attachment hardware to mount the HCS6150R chassis in its
targeted location.
__ Plan and install the necessary cabling and AC power access for the HCS6150R, the
CodePlus™ series transcoder cards, and, if applicable, the CodePlus feature card to be
installed. (Refer to the setup procedures for the individual transcoder cards and the
feature card for further information on cabling.)
__ Carefully follow the installation procedures for the CodePlus series cards (see page 10)
and the HCS6150R (see pages 12 to 13).
__ Refer to the Installation & Setup Guide for the transcoder card(s) and, if applicable, the
feature card being installed for instruction on completing the system setup for each card.
Table of Contents

206-4138 7
HCS6150R Product Description
HCS6150R CodePlus Series Card Frame with Power Supply
The HCS6150R is a 19-inch rack-mountable card frame that provides the
operating environment for the LG HCS7700, HCS7710, or HCS7720 CodePlus
series transcoder cards. Using one or more HCS6150R units containing
appropriate transcoder cards, a variety of transcoding systems can be realized.
Features
• Self-contained 180W power supply
• Slots for nine CodePlus cards (eight transcoders plus one feature card)
• Built-in fan for active ventilation
• 19-inch rack-mountable
• Short 3U height prole to minimize rack space usage
Note: Design and specifications subject to change without prior notice.

8206-4138
Back Panel Overview
Slot 1 Slot 2 Slot 3
(HCS6400)
Slot 4 Slot 5 Slot 8 Slot 9 Slot 11 Slot 12
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
CONTROLLER
Slot
HCS6300
RF OUT
ETHERNET
HCS6400 HCS6400
HCS6400
HCS6400 HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
Slot 10
(HCS6400)
Slot 7
(HCS6400)
Slot 6
(HCS6400)
SERVICE
PORT
RESET
STATUS
AC Power Input
(AC Mains Plug)
The following gure shows a typical installation with all the available card slots lled.
Disconnect Device
The AC mains plug is used as the disconnect
device. The disconnect device must remain
readily operable.
HCS6400 HCS6400
HCS6400
HCS6400
Blank Cover Plates
As shipped, the HCS6150R has blank cover plate port
covers. Simply remove the blank cover plates on ports
that will be used. For ports that will not be used, leave
the blank cover plates in place for proper ventilation and
FCC and safety agency compliance.

206-4138 9
Output/Terminal Marking
The following ratings must be observed when cards are added to the HCS6150R.
Marking Location Voltage (VDC) Amperage (A)
For Card Slot numbers: 1, 2, 4, 5, 8, 9, 11, and 12 12 1.2
For Card Slot numbers: 3, 6, 7, and 10 12 0.7
For Card Slot: CONTROLLER 12 1.35
Note: The CodePlus series products are NOT designed to be hot-swappable!!!
Power must be removed to the HCS6150R before any CodePlus cards are
inserted or removed.
Note: The slot bus is proprietary and should only use CodePlus-compliant
products.
Note: All cards used in the HCS6150R must be inserted and removed by
qualified service personnel only.
Note: The card slots in the HCS6150R are NOT all identical!!! Refer to the
Installation & Setup Guide for the CodePlus card(s) being installed for more
information, and select the appropriate card slot(s).
• Slots 1, 2, 4, 5, 8, 9, 11, and 12 are designated only for HCS7700, HCS7710, or
HCS7720 transcoder cards, and Slots 3, 6, 7, and 10 are designated for (pre-
installed) HCS6400 fan cards.
• The CONTROLLER slot between Slots 6 and 7 has different edge connector
locations and pinouts and is incompatible with transcoder cards. This slot is
intended for optional feature cards (Example: HCS6300).
Note: Do not try to force a CodePlus card into any slot that does not allow it
to be easily and fully seated using the installation procedure on the following
page.
Back Panel Overview (Cont.)
Important Card Slot Information

10 206-4138
Installing CodePlus Transcoder Cards
Note: The CodePlus series products are NOT designed to be hot-swappable!!! Power
must be removed to the HCS6150R before any CodePlus cards are inserted or removed .
Note: All cards used in the HCS6150R must be inserted and removed by qualified
service personnel only.
Note: Use extreme care when handling a transcoder card. Always observe proper
precautions with respect to static electricity and mechanical shock. When not installed
in a card frame, return the transcoder card to the anti-static bag in which it was shipped.
Note: No more than eight HCS7700, HCS7710, or HCS7720 cards may be installed in
the HCS6150R card frame. Cards should be inserted in the following slots: 1, 2, 4, 5, 8,
9, 11, and 12. HCS6400 fan cards are pre-installed in the following slots: 3, 6, 7, and 10.
Note: The card slots in the HCS6150R are NOT all identical!!! See also “Back Panel
Overview” on pages 8 to 9. The CONTROLLER slot between Slots 6 and 7 is dedicated
for optional feature cards and is not compatible with HCS7700/HCS7710/HCS7720 cards.
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS6300
RF OUT
ETHERNET
HCS6400 HCS6400
HCS6400
SERVICE
PORT
RESET
STATUS
1. Unpack the CodePlus transcoder card(s) and all accessories.
2. Select the slot(s) in the card frame in which to install the transcoder card(s). Note: All
cards must be used in an LG-approved card frame for this product.
3. If applicable, remove the HCS6150R AC power cord from the power outlet.
4. Remove the blank cover plate from each slot into which a card is to be inserted.
5. Without using force, slide each new card into its designated slot, and ensure it is fully
inserted.
6. Engage and tighten the top and bottom thumbscrews securely. Note that the thumb-
screws should only be finger tight; overtightening may damage the assembly.
7. Refer to the Installation & Setup Guide for the individual transcoder card(s) for cabling and
setup information.
Note: If applicable, repeat steps 1 to 7 for the feature card to be installed. The feature
card will be installed in the CONTROLLER SLOT.

206-4138 11
Front Panel Overview / Ventilation
Bottom
Front
Top Back
The following gure shows the HCS6150R front panel. Back panel features are described
on pages 8 to 9.
Ventilation Holes
Air flow must not be obstructed. To ventilate the system normally and avoid
overheating, leave at least 1 inch (2.5 cm) on each side of the HCS6150R unit.
Do NOT stack other equipment on the top of the HCS6150R unit.

12 206-4138
Rack-mount Considerations
A. Elevated Operating Ambient
If installed in a closed or multi-unit rack assembly, the operating ambient temperature of
the rack environment may be greater than room ambient. Therefore, consideration should
be given to installing the equipment in an environment compatible with the maximum
ambient temperature (Tma) specified by the manufacturer (see Specifications information
in this document).
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS6300
SERVICE
PORT
RESET
RF OUT
ETHERNET
HCS6400 HCS6400
HCS6400
HCS6400
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
Power Guide
VIDEO OUT AUDIO OUT
USB
S-VIDEO OUT
PHONE JACK
ETHERNET
HDMI OUT
SATELLITE IN
AC 100V-240V
50/60 Hz
VIDEO OUT AUDIO OUT
USB
S-VIDEO OUT
PHONE JACK
ETHERNET
HDMI OUT
SATELLITE IN
AC 100V-240V
50/60 Hz
VIDEO OUT AUDIO OUT
USB
S-VIDEO OUT
PHONE JACK
ETHERNET
HDMI OUT
SATELLITE IN
AC 100V-240V
50/60 Hz
VIDEO OUT AUDIO OUT
USB
S-VIDEO OUT
PHONE JACK
ETHERNET
HDMI OUT
SATELLITE IN
AC 100V-240V
50/60 Hz
VIDEO OUT AUDIO OUT
USB
S-VIDEO OUT
PHONE JACK
ETHERNET
HDMI OUT
SATELLITE IN
AC 100V-240V
50/60 Hz
VIDEO OUT AUDIO OUT
USB
S-VIDEO OUT
PHONE JACK
ETHERNET
HDMI OUT
SATELLITE IN
AC 100V-240V
50/60 Hz
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS6300
SERVICE
PORT
RESET
RF OUT
ETHERNET
HCS6400 HCS6400
HCS6400
HCS6400
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7700
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
Rack Installation
Install HCS6150R
unit in rack.
Typical Rack Installation
1. Carefully slide the card frame with cards into a standard 19-inch equipment rack.
2. Use all four mounting screws to secure the chassis to the rack.
Rear View
of Rack Cabinet
Disconnect Device
The AC mains plug is used
as the disconnect device.
The disconnect device must
remain readily operable.

206-4138 13
Front View
of Rack Cabinet
Rack Installation (Cont.)
1 inch minimum
1 inch minimum
B. Reduced Air Flow
Installation of the equipment in a rack should be such that the amount of air flow required
for safe operation of the equipment is not compromised. To ventilate the system normally
and avoid overheating, leave at least 1 inch (2.5 cm) on each side of the HCS6150R unit.
Do NOT stack other equipment on the top of the HCS6150R unit.
C. Circuit Overloading
Consideration should be given to the connection of the equipment to the supply circuit and
the effect that overloading of the circuits might have on overcurrent protection and supply
wiring.
D. Reliable Earthing
Maintain reliable earthing of rack-mounted equipment. Particular attention should be given
to supply connections other than direct connections to the branch circuit (e.g. use of
power strips).
E. Mains Outlet Earthing
The apparatus with Class I construction must be connected to a mains socket outlet with
a protective earthing connection.

14 206-4138
Equipment Setup Review / Specifications
Specications
Dimensions
Height: 5.25 inches (133 mm)
Width: 19.0 inches (482.6 mm) (for EIA standard 19-inch rack mount)
Depth: 10.3 inches (262 mm)
Weight: 7.70 pounds (3.5 kgrms) rack-only weight
Environmental Storage Conditions
Temperature: -20° to 70° Celsius
-4° to 158° Fahrenheit
Humidity: 95% non-condensing
Environmental Operating Conditions
Temperature (Tma): 0° to 40° Celsius
32° to 104° Fahrenheit
Humidity: 95% non-condensing
Electrical
AC Input to Power Supply: 120V 3A 60Hz
Power Factor Corrected. Maximum Watts = 180
Power Supply: +12V DC @ 15 Amps
DC Input to each HCS6400 card: +12V DC @ 0.17 Amps
Note: Design and specications subject to change without prior notice.
Equipment Setup Review
• Make sure all connectors and connections are tight and secure on all entertainment system
components.
• Check to make sure each device supplying the signal to a transcoder card is functioning
properly.
• Check the CodePlus transcoder card(s) plugged into the HCS6150R. With AC power
applied, you should see LED activity on each card.
• Make sure the HCS6150R fan is working and fan cooling vents are unobstructed. Check
the exit vent area adjacent to the AC power connector on the back panel of the card frame.
With AC power applied, there should be a strong airstream from the vent area.
For troubleshooting information, refer to the Installation & Setup Guide for the individual
transcoder(s).

206-4138 15
Document Revision History / Notes
Document Revision History
Date Description
February 2010 Revision A: New document
March 2010 Revision B: Safety Instructions update
July 2012 Revision C: Transcoder updates
Product documentation is available online at: www.LGsolutions.com/products. From the Products
page, select TVs, Systems & Solutions, then Head End Systems, then CodePlus Transcoder
Series (click Show [+] to view the list of products), then the applicable Modular System option. Click
the Literature & Downloads tab at the bottom of the Modular System page, and select the required
document(s) from the Downloads list.
Notes

206-4138
Revision C
© Copyright 2012 LG Electronics U.S.A., Inc.
Broadcast Products Welcome to the LG family! We believe that you will be pleased with your new HCS6150R Card Frame with Power Supply.
Please read this warranty carefully, it is a “LIMITED WARRANTY” as defined under Federal Law. This warranty gives you
specific legal rights, and you may also have other rights that vary from state-to-state within the U.S.A.
LG’s RESPONSIBILITY
Warranty Term One year parts and labor from date of purchase or delivery date.
Parts New or remanufactured replacements for factory-defective parts may be used. Such replacement parts are warranted for
the remaining portion of the original warranty period.
Warranty Service Warranty service is provided at LG. Customer pays for shipping charges to LG; LG pays for return shipping charges to
return HCS6150R Card Frame with Power Supply to customer. Call 1-888-865-3026 for further information.
Not Covered This warranty covers manufacturing defects and does not cover installation, adjustment of customer controls, installation or
repair of antenna systems, cable converters or cable company-supplied equipment; it also does not cover damage due to
misuse, abuse, negligence, acts of God or other causes beyond the control of LG. Any alteration of the product after man-
ufacture voids this warranty in its entirety.
This warranty does not cover any missing or stolen access cards.
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, EXPRESS OR IMPLIED, INCLUDING WITHOUT
LIMITATION, ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, AND LG
SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL, INDIRECT, OR INCIDENTAL DAMAGES OF ANY KIND,
INCLUDING LOST REVENUES OR PROFITS IN CONNECTION WITH THIS PRODUCT. SOME STATES DO NOT
ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS OR THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY
TO YOU.
OWNER’S RESPONSIBILITY
Effective Warranty Date Warranty begins on the date of delivery of the HCS6150R.
For your convenience, keep the dealer’s dated bill of sale or delivery ticket as evidence of the purchase date.
Installation Guide Read the Installation & Setup Guide carefully so that you will understand the operation of the HCS6150R Card Frame with
Power Supply and how to adjust the controls.
Antenna Reception problems caused by inadequate antenna or faulty antenna connections are the owner’s responsibility.
Warranty Service For warranty service information, call 1-888-865-3026. Parts and service labor that are LG’s responsibility (see above)
will be provided without charge. Other service is at the owner’s expense. If you have any problem in obtaining satisfactory
warranty service, call 1-888-865-3026.
You must provide the model number, serial number and date of purchase or date of original installation.
CodePlus is a trademark of LG Electronics U.S.A., Inc. All other trademarks
or registered trademarks are the property of their respective owners.
LG HCS6150R Card Frame with Power Supply Warranty
For Customer Support/Service, please call:
1-888-865-3026
www.LGsolutions.com
