LG Pentouch Dongle Operation manual

[KOREA]
목 차
1. LG Pentouch Dongle 의 개요 및 제원
(1) 개 요
(2) 제 원
2. 주의 사항
3. 고객지원
4. User notice
(1) 개 요
이 LG Pentouch Dongle 은 PC에 접속하여 사용자가 가정이나 사무실에서 PDP TV에
직접 글이나 그림을 나타낼 수 있으며, 2.4GHz 대역의 무선방식을 LG Touch Pen과
연동하여 PDP 화면을 제어하는 수신부 제품입니다.
(2) 제 원
구 분 내 용
모 델 명 AN-TD200
주파수 대역 2402MHz ~ 2480MHz
채 널 79EA
송신 출력 0 dBm
수신 감도 -82dBm
크 기 폭 18 x 두께9.5 x 52.9
(공차 ± 1mm)
무 게 6.14g
전 원 5V
(USB 전원)
동작 온도 0℃ ~ + 40 ℃
1. LG Pentouch Dongle 의 개요 및 제원
LG Pentouch Dongle User Information
(Model Name: AN-TD200)

2. 주의 사항
(1) LG Pentouch Dongle 구입 후 Touch Pen이 정상적으로 작동할 수 있도록 USB Dongle
드라이버 설치 방법에 따라 PC에 설치하세요.
(2) LG Pentouch Dongle 구입 후 제품 사용법에 따라 페어링 후에 사용하세요.
(3) 제품을 분해하거나, 열을 가해서는 안됩니다.
(4) 케이스가 손상될 정도로 극심한 충격을 줘서는 안됩니다.
(5) 제품을 물에 넣어서는 안됩니다.
3. 고객 지원
(1) TV 매뉴얼의 서비스 연락처를 참조하세요.
(2) 보증기간 : 1년
보증 기간 중에 정상적인 사용 중에 기술상의 결함이나 문제가 나타났을 때, 구입처를
방문하세요. 이 보증은 제품을 구매한 그 지역의 구매자에게만 적용됩니다.
(3) KCC 인증 마크 및 인증번호
KCC-CMM-LGE-EBX615088
기자재의 명칭(모델명) : 특정소출력무선 기기
(무선데이터 통신 시스템용 무선기기)/AN-TD200
상호명 : 엘지전자㈜
제조자/제조국가: 엘지전자㈜/대한민국
제조년월: . .

[ENGLISH]
Contents
1. Overview and Specifications of LG Pentouch Dongle
(1) Overview
(2) Specifications
2. Cautions
3. Customer Support
4. User Notice
(1) Overview
This LG Pentouch Dongle allows you to access your PC and type text or draw a picture
directly on the PDP TV at home or in the office. It is a receiver that controls the PDP screen
by working with the LG Touch Pen using the 2.4 GHz wireless band.
(2) Specifications
Item Description
Model Name AN-TD200
Frequency band 2402 MHz to 2480 MHz
Channels 79
Tx power 0 dBm
Reception sensitivity -82 dBm
Size 18 x 9.5 x 52.9
(Tolerance ± 1 mm)
Weight 6.14 g
Power supply 5 V
(USB power source)
Operating
temperature
0℃ to +40℃
1. Overview and Specifications of LG Pentouch Dongle

2. Cautions
(1) Install the LG Pentouch Dongle on your PC according to the USB dongle installation instructions;
this allows the LG Touch Pen to work properly.
(2) Start using the LG Pentouch Dongle by first pairing it with the TV, as instructed in the user manual.
(3) Do not disassemble or heat the product.
(4) Avoid extreme shocks to the product that can damage the case.
(5) Do not put the product in water.
3. Customer Support
(1) See the service contact in the TV manual.
(2) Warranty period: 1 year
If you find a technical defect or problem in the course of normal use during the warranty
period, please contact your dealer. This warranty applies only to the purchaser in the region where
the product is purchased.

[GERMAN]
Inhalt
1. Überblick und Spezifikationen des LG Pentouch Dongle
(1) Überblick
(2) Spezifikationen
2. Warnhinweise
3. Kundendienst
4. Hinweis für Benutzer
(1) Überblick
Mit dem LG Pentouch Dongle können Sie auf Ihren PC zugreifen und auf Ihrem PDP-
Fernseher zu Hause oder im Büro direkt Text eingeben oder zeichnen. Es handelt sich um
einen Empfänger, der den PDP-Bildschirm steuert. Dies geschieht im Zusammenspiel mit dem
LG Touch Pen über die Drahtlosfrequenz 2,4 GHz.
(2) Spezifikationen
Element Beschreibung
Modellname AN-TD200
Frequenzband 2.402 bis 2.480 MHz
Kanäle 79
TX Power 0 dBm
Empfängerempfindlichkeit -82 dBm
Größe 18 x 9,5 x 52,9
(Toleranz ± 1 mm)
Gewicht 6,14 g
Stromversorgung 5 V
(Stromversorgung über USB)
Betriebstemperatur 0℃ bis +40℃
1. Überblick und Spezifikationen des LG Pentouch Dongle

2. Warnhinweise
(1) Schließen Sie den LG Pentouch Dongle an Ihren PC gemäß der USB-Dongle-Installationsanleitung
an. Damit wird sichergestellt, dass der LG Touch Pen ordnungsgemäß funktioniert.
(2) Wenn Sie den LG Pentouch Dongle zum ersten Mal verwenden, koppeln Sie ihn mit Ihrem
Fernsehgerät wie in der Bedienungsanleitung beschrieben.
(3) Bauen Sie das Produkt nicht auseinander, und erhitzen Sie es nicht.
(4) Vermeiden Sie extreme Erschütterungen des Produkts, die das Gehäuse beschädigen können.
(5) Bringen Sie das Produkt nicht mit Wasser in Berührung.
3. Kundendienst
(1) Siehe Service-Kontakt in der Bedienungsanleitung Ihres Fernsehgeräts.
(2) Garantiezeitraum: 1 Jahr
Sollte bei normaler Verwendung während des Garantiezeitraums ein Defekt oder sonstiges
Problem auftreten, wenden Sie sich an Ihren Fachhändler. Diese Garantie gilt nur für den Käufer in
der Region, wo das Produkt gekauft wurde.

[FRENCH]
Sommaire
1. Présentation et spécifications du module de sécurité LG Pentouch Dongle
(1) Présentation
(2) Spécifications
2. Précautions
3. Support technique
4. Avertissement utilisateur
(1) Présentation
Le module de sécurité LG Pentouch Dongle vous permet d'accéder à votre PC et de
saisir un texte ou de dessiner une image directement sur un téléviseur PDP à la maison ou au
bureau. Il s'agit d'un récepteur qui contrôle l'écran PDP grâce à une interaction avec le stylet
LG Touch Pen via une bande sans fil de 2,4 GHz.
(2) Spécifications
Élément Description
Nom du modèle AN-TD200
Bande de fréquence De 2 402 à 2 480 MHz
Canaux 79
Puissance
d'émission
0 dBm
Sensibilité de
réception
- 82 dBm
Taille 18 x 9,5 x 52,9
(Tolérance ± 1 mm)
Poids 6,14 g
Alimentation
électrique
5 V
(Source d'alimentation USB)
Température de
fonctionnement
De 0℃ à + 40℃
1. Présentation et spécifications du module de sécurité LG Pentouch Dongle

2. Précautions
(1) Installez le module de sécurité LG Pentouch Dongle sur votre PC en suivant les instructions
d'installation du dongle USB afin que le stylet LG Touch Pen fonctionne normalement.
(2) Utilisez tout d'abord le module de sécurité LG Pentouch Dongle en association avec votre téléviseur
en suivant les instructions du guide de l'utilisateur.
(3) N'essayez pas de désassembler ni de faire chauffer le produit.
(4) Évitez tout choc violent avec produit. Cela pourrait endommager le boitier.
(5) N'immergez pas le produit dans l'eau.
3. Support technique
(1) Consultez le guide d'utilisation du téléviseur pour connaître les coordonnées du support
technique.
(2) Durée de la garantie : 1 an
Si vous constatez un défaut ou un problème technique lors de l'utilisation normale du produit
et que la garantie est toujours valable, contactez votre revendeur. Cette garantie n'est valable
qu'auprès des revendeurs de la région où le produit a été acheté.

[PORTUGUESE]
Sumário
1. Visão geral e especificações da LG Pentouch Dongle
(1) Visão geral
(2) Especificações
2. Cuidados
3. Apoio ao cliente
4. Aviso aos usuários
(1) Visão geral
Este LG Pentouch Dongle permite que você acesse seu PC e digite textos ou desenhe
diretamente na TV PDP em casa ou no escritório. É um receptor que controla a tela PDP
trabalhando com a LG Touch Pen usando a banda de 2,4 GHz sem fio.
(2) Especificações
Item Descrição
Nome do modelo AN-TD200
Banda de freqüência 2402 MHz a 2480 MHz
Canais 79
Tx power 0 dBm
Sensibilidade de
recepção
-82 dBm
Tamanho 18 x 9,5 x 52,9
( ± 1 mm de tolerância)
Peso 6,14 g
Fonte de
alimentação
5 V
(fonte de alimentação USB)
Temperatura
operacio
nal
0℃ a +40℃
1. Visão geral e especificações da LG Pentouch Dongle

2. Cuidados
(1) Instale o LG Pentouch Dongle no seu PC de acordo com as instruções de instalação do dongle USB;
isso permite que a LG Touch Pen funcione adequadamente.
(2) Comece a usar o LG Pentouch Dongle emparelhando-o com a TV, como instruído no manual do
usuário.
(3) Não desmonte ou aqueça o produto.
(4) Evite choques extremos ao produto que possam danificar o estojo.
(5) Não molhe o produto.
3. Apoio ao cliente
(1) Veja o contato de serviços no manual da TV.
(2) Período da garantia: 1 ano
Se você encontrar defeitos técnicos ou problemas durante o uso normal dentro do período da
garantia, entre em contato com o revendedor. Essa garantia se aplica somente ao comprador na
região onde o produto foi adquirido.

[SPANISH]
Contenido
1. Información general y especificaciones del LG Pentouch Dongle
(1) Información general
(2) Especificaciones
2. Precauciones
3. Asistencia al cliente
4. Aviso al usuario
(1) Información general
El LG Pentouch Dongle permite acceder al PC y escribir texto o dibujar imágenes
directamente en el televisor PDP de casa o de la oficina. Es un receptor que controla la
pantalla PDP junto con el LG Touch Pen a través de la banda inalámbrica de 2,4 GHz.
(2) Especificaciones
Elemento Descripción
Nombre del modelo AN-TD200
Banda de frecuencia De 2402 a 2480 MHz
Canales 79
Potencia de
transmisión
0 dBm
Sensibilidad de
recepción
-82 dBm
Tamaño 18 x 9,5 x 52,9
(tolerancia ± 1 mm)
Peso 6,14 g
Fuente de
alimentación
5 V
(fuente de alimentación USB)
Temperatura de
funcionamiento
De 0℃ a +40℃
1. Información general y especificaciones del LG Pentouch Dongle

2. Precauciones
(1) Instale el LG Pentouch Dongle en su PC siguiendo las instrucciones de instalación de dispositivos de
seguridad USB; de este modo, el LG Touch Pen funcionará correctamente.
(2) Para comenzar a utilizar el LG Pentouch Dongle vincúlelo al televisor, tal y como se indica en el
manual del usuario.
(3) No desmonte ni caliente el producto.
(4) Evite dar golpes fuertes al producto ya que se podría dañar la carcasa.
(5) No sumerja el producto en agua.
3. Asistencia al cliente
(1) Consulte los datos del Servicio de Atención al Cliente en el manual del televisor.
(2) Periodo de garantía: 1 año
Si descubre un defecto o problema técnico durante el uso normal dentro del periodo de
garantía, póngase en contacto con su distribuidor. Esta garantía solo se aplica al comprador en la
región en que se compra el producto.

[RUSSIAN]
Содержание
1. Обзор и технические характеристики LG Pentouch Dongle
(1) Обзор
(2) Технические характеристики
2. Предупреждения
3. Поддержка клиента
4. Примечание для пользователя
(1) Обзор
Аппаратный ключ LG Pentouch Dongle позволяет получать доступ к ПК и вводить
текст или рисовать непосредственно на экране плазменной панели дома или в офисе. Он
является приемником, управляющим изображением на экране плазменной панели с
помощью пера LG Touch Pen на частоте 2,4 ГГц.
(2) Технические характеристики
Элемент Описание
Модель AN-TD200
Частотный
диапазон
2402–2480 МГц
Каналы 79
Модность
передачи
0 дБм
Чувствительность
приемника
-82 дБм
Размер 18 x 9,5 x 52,9
(допустимая погрешность ± 1
мм)
Вес 6,14 г
Блок питания 5 В
(питание через USB)
Рабочая
температура
от 0℃ до +40℃
1. Обзор и технические характеристики LG Pentouch Dongle

2. Предупреждения
(1) Установите LG Pentouch Dongle на ПК в соответствии с инструкциями к аппаратному ключу;
это обеспечит надлежащую работу пера LG Touch Pen.
(2) Для использования LG Pentouch Dongle выполните сопряжение ключа с телевизором, как
описано в руководстве пользователя.
(3) Не разбирайте и не нагревайте устройство.
(4) Избегайте чрезмерных вибраций или воздействий, которые могут повредить корпус
устройства.
(5) Не помещайте устройство в воду.
3. Поддержка клиента
(1) Контактные данные сервисного центра см. в руководстве к телевизору.
(2) Гарантия: 1 год
При обнаружении технического дефекта или проблемы при нормальном использовании
продукта в течение гарантийного периода обратитесь к дилеру. Данная гарантия
распространяется только на покупателей, проживающих в регионе приобретения продукта.

[ITALIAN]
Sommario
1. Panoramica e specifiche tecniche di LG Pentouch Dongle
(1) Panoramica
(2) Specifiche tecniche
2. Precauzioni
3. Assistenza clienti
4. Avviso utente
(1) Panoramica
LG Pentouch Dongle consente di accedere al PC e digitare testo o disegnare figure
direttamente sullo schermo del TV PDP a casa o in ufficio. È un ricevitore che controlla lo
schermo PDP operando con LG Touch Pen e utilizzando la banda wireless a 2,4 GHz.
(2) Specifiche tecniche
Voce Descrizione
Nome modello AN-TD200
Banda di frequenza Da 2402 MHz a 2480 MHz
Canali 79
Potenza Tx 0 dBm
Sensibilità di
ricezione
-82 dBm
Dimensioni 18 x 9,5 x 52,9
(Tolleranza ± 1 mm)
Peso 6,14 g
Alimentazione
elettrica
5 V
(Alimentazione USB)
Temperatura di
funzionamento
Da 0℃ a +40℃
1. Panoramica e specifiche tecniche di LG Pentouch Dongle

2. Precauzioni
(1) Installare LG Pentouch Dongle sul PC attenendosi alle istruzioni di installazione del dongle USB; ciò
consente il corretto funzionamento di LG Touch Pen.
(2) Iniziare a utilizzare LG Pentouch Dongle eseguendone preliminarmente l'associazione con il TV,
attenendosi alle istruzioni fornite nel manuale utente.
(3) Non disassemblare o riscaldare il prodotto.
(4) Evitare che il prodotto subisca urti eccessivi che possono danneggiare l'involucro esterno.
(5) Non immergere il prodotto in acqua.
3. Assistenza clienti
(1) Vedere le informazioni di contatto per l'assistenza presenti nel manuale del TV.
(2) Periodo di garanzia: 1 anno
Se si nota un difetto tecnico o un problema al prodotto nel corso del normale utilizzo dello
stesso e durante il periodo di garanzia, contattare il rivenditore. La garanzia è valida solo per
l'acquirente del prodotto nel paese in cui il prodotto è stato acquistato.

4. User notice
(1) KCC Statement(Korea)
1) “제작자 및 설치자는 해당 무선설비가 전파혼신 가능성이 있으므로 인명안전 과 관련된
서비스는 할 수 없음.”
2) 이 기기는 가정용(B급) 전자파적합기기로서 주로 가정에서 사용하는 것을 목적으로 하며,
모든지역에서 사용할 수 있습니다.
(2) ANATEL Statement(Para Brazil)
Este equipamento opera em caráter secundário, isto é, não tem direito à proteção
contra interferência prejudicial, mesmo de estações do mesmo tipo e não pode
causar interferência a sistemas operando em caráter primário.

(3) Federal Communications Commission(FCC) Statement
You are cautioned that changes or modifications not expressly approved by the part responsible
for compliance could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
-. Reorient or relocate the receiving antenna.
-. Increase the separation between the equipment and receiver.
-. Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected
-. Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1) this device may not cause harmful interference, and
2) this device must accept any interference received, including interference that may
cause undesired operation of the device.
Indoor use only
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate
this equipment.
FCC RF Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20 cm between the radiator & your body.
End users must follow the specific operating instructions for satisfying RF
exposure compliance. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.

(4) Industry Canada(IC) Statement
This device complies with RSS-210 of the Industry Canada Rules.
Operation is subject to the following two conditions:
1) this device may not cause interference and
2) this device must accept any interference. Including interference that
may cause undesired operation of device.
This class B digital apparatus complies with Canadian ICES-003
Avis d'Industrie Canada
Cet appareil est conforme à norme CNR-210 des règlements d'Industrie
Canada. Son fonctionnement est sujet aux deux conditions suivantes:
1) Cet appareil ne doit pas provoquer d'interférences et
2) Cet appareil doit accepter toute les interférences. y compris celles
pouvant entraîner son dys-fonctionnement.
Cet appareil numérique de classe B est conforme à la norme NMB-003
du Canada.
IC Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an
uncontrolled environment.
This equipment should be installed and operated with minimum distance
20 cm between the radiator & your body.
NOTE: THE MANUFACTURERE IS NO T RESPONSIBLE FOR ANY RADIO OR
TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY
TO OPERATE THE EQUIPMENT.
Avis d'Industrie Canada sur I'exposition aux rayonnements
Cet appareil est conforme aux limites d'exposition aux rayonnements
d'Industrie Canaca pour unenvironnement non contrôlé.
II doit être installé de façon à garder une distance minimale de 20
centimètres entre la source de rayonnements et votre corps.
REMARQUE: LE FABRICANT N'EST PAS RESPONSIBLE DES INTERFÉRENCES
RADIOÉLECTRIQUES CAUSÉES PAR DES MODIFICATIONS NON AUTORISÉES
APPORTÉES APPORTÉES À CET APPAREIL. DE TELLES MODIFICATIONS
POURRAIT ANNULER L'AUTORISATION ACCORDÉE À L'UTILISATEUR DE FAIRE
FONCTIONNER L'APPAREIL.

(5) CE Statement
1) CE conformity Notice
LG Electronics hereby declares that this product is in compliance with
the following Directives.
R&TTE Directive 1999/5/EC
LOW VOLTAGE Directive 2006/95/EC
The products described above comply with the essential requirements
of the directives specified.
This device is a 2.4 wideband transmission system, intended for use in
all EU member states and EFTA countries, except in France.
This device may not be used for setting up outdoor radio links in France
and in some areas the RF output power may be limited to 10 mW EIRP
in the frequency range of 2454 – 2483.5 MHz. For detailed information
the end user should contact the national spectrum authority in France.
European representative:
LG Electronics Service Europe B.V. Veluwezoom 15, 1327
AE Almere. The Netherlands
(Tel : [phone])
2) CE Notified Body statement:
This is a Class B product. In a domestic environment, this product may
cause radio interference, in which case the user may be required to take
adequate measures.
Explosive device proximity warning – Do not operate a portable
transmitter (such as a wireless network device) near unshielded blasting
caps or in an explosive environment unless the device has been modified
to be qualified for such use.
This CE marking is valid for EU non-harmonized telecommunications
products R&TTE Directive (1999/5/EC) issued by the Commission of the
European Community.
3) Certification Marking
