ENERGY RECOVERY
VENTILATOR
ENGINEERING MANUAL
ARVU053ZEA2
ARVU063ZEA2
ARVU093ZFA2
ARVU123ZFA2
ARV00903RA6
ARV01203RA6

For continual product development, LG Electronics U.S.A., Inc., reserves the right to change specifications without notice.
© LG Electronics U.S.A., Inc.
PROPRIETARY DATA NOTICE
This document, as well as all reports, illustrations, data, information,
and other materials are the property of LG Electronics U.S.A., Inc., and are
disclosed by LG Electronics U.S.A., Inc. only in confidence.
This document is for design purposes only.
For more technical materials such as submittals, catalogs, installation,
owner’s, and service manuals, visit www.lghvac.com.

TABLE OF CONTENTS
TABLE OF SYMBOLS
DANGER
This symbol indicates an imminently hazardous situation which, if not avoided, will result in death or
serious injury.
WARNING
This symbol indicates a potentially hazardous situation which, if not avoided, could result in death or
serious injury.
CAUTION
This symbol indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury.
Note:
This symbol indicates situations that may result in equipment or property damage accidents only.
This symbol indicates an action that must not be performed.
Mechanical Specications.....................................................................................................................................................4
ERV Benets...........................................................................................................................................................................5
GENERAL DATA......................................................................................................................................................................6
Accessories ............................................................................................................................................................................8
Dimensions ...........................................................................................................................................................................10
Efciency Curves .................................................................................................................................................................13
Electrical and Acoustic Data ...............................................................................................................................................19
Acoustic Data........................................................................................................................................................................20
Wiring Diagrams...................................................................................................................................................................21
Installation and Layout Best Practices............................................................................................................................... 24
ZE Chassis .......................................................................................................................................................................... 24
ZF Chassis .......................................................................................................................................................................... 25
ZR Chassis.......................................................................................................................................................................... 26
ZE / ZF Chassis Power Wiring ............................................................................................................................................ 29
ZE / ZF Chassis Power Wiring ............................................................................................................................................ 30
ZR Chassis Power Wiring.................................................................................................................................................... 31
Duct Connection.................................................................................................................................................................. 32
ZE /ZF Chassis V-Net Wiring............................................................................................................................................... 34
ZE /ZF Chassis V-Net Wiring............................................................................................................................................... 35
ZR Chassis Group Control .................................................................................................................................................. 36
Maintenance and Service.....................................................................................................................................................38
Due to our policy of continuous product innovation, some specications may change without notication.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 3

MECHANICAL SPECIFICATIONS
General
ERV indoorunits are factory assembled and provided with an
internally mounted control circuit board, exhaust fan, supply fan,
cross-flowairto airheat exchanger, washable outdoorairand return
airfilters, and bypass damper. Each unit is designed to operate
using 208-230/60/1 power with voltage variances of ±10%. ERV
operation range is 14°F - 113°F outdoortemperature.
Casing
The metal casing is designed to mount concealed above a finished
ceiling. Supply fan discharge and exhaust fan inlet (return air)
are front horizontal. Supply fan inlet (outdoorair) and exhaust fan
discharge are rearhorizontal. Cold metal surfaces are externally
insulated. The case is provided with hangerbrackets designed
to support the unit weight on forcorners. Hangerbrackets have
pre-punched holes designed to accept field supplied, all-thread rod
hangers.
Fan Assemblies
ERV units have two fans; one fan forsupply airand one fan for
exhaust air. Both fans are direct driven. Fan motors are brushless,
digitally-controlled (BLDC) design with permanently sealed
bearings. The fan/motorassemblies are mounted in vibration
attenuated rubbergrommets. The fan speeds are controlled using a
microprocessor-based direct digital control algorithm that provides
three fan speeds. Fan speeds are superhigh, high, and low. Each
fan speed can be adjusted from the factory setting using external
static pressure (ESP) control settings to change fan speeds to
compensate forairflow resistance caused by field installed ductwork.
Cross flow Air-to-air Heat Exchanger
Cross flowair-to-airheat exchangeris constructed of non-
flammable, specially processed paperthat allows transferof heat
and humidity. The air-to-airheat exchanger recovers energy from
indoorairas it is exhausted outdoors. The recovered energy is
transferred to the in-coming outdoorair without mixing airstreams.
Ahinged access panel allows removal of air-to-airheat exchanger
forvacuum orbrush cleaning. Since both heat and humidity are
transferred, condensate drain is not required.
Air Filter
Two washable mesh filters are provided at the outdoorairand return
airinlets of the air-to-airheat exchanger.
Microprocessor Controls
The ERV is provided with an integrated microprocessor-based
controller. All unit operation parameters, excluding the unit operating
schedule, are stored in non-volatile memory, resident on the ERV
microprocessor. Operating schedules are stored in the wall
controllerorcentral controller. ERV units can be operated
independently with a wall controllerorinterlocked to a Multi V
system. When interlocking to a Multi Vsystem, the field supplied
communication cable between the ERV and outdoorunit is to be
a minimum of 18 AWG, 2-conductor, stranded, and shielded cable
(RS485), terminated via screw terminals on the control board. The
microprocessorcontrol provides the following functions:
• Auto restart following power restoration
• External static pressure (ESP) control of fans
• ERV mode allowing airto pass thru air-to-airheat exchanger
• Bypass mode allowing exhaust airto bypass air-to-airheat
exchanger
The control board is also provided with terminals forconnection of a
field supplied CO2 sensor. DIP switch settings on the control board
allowthe ERV to operate independently oras a slave to a Multi V
indoorunit.
Due to our policy of continuous product innovation, some specications may change without notication.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
4
Energy Recovery Ventilator Engineering Manual

ERV BENEFITS
Ventilation
Ventilation is a process that allows users to exchange indoorair
with outdoorairin orderto improve the airquality and to maintain
environmental temperature conditions. The Energy Recovery
Ventilation (ERV) system reduces the temperature and humidity of
incoming outside air. A balance is achieved between indoorand
outdoorambient which enables the cooling orheating load placed
on the airconditioning system to be reduced. It can be controlled
individually oras an integral part of the airconditioning system.
Benefits
The ERV system provides efficiency, cost savings, superior
performance, compact and light design, linear E.S.P control and
easy maintenance. The ERV system is ideal forhotels, dormitories,
restaurants,hospitals, retail establishments, theaters, schools, and
office buildings.
ZE ChassisZF Chassis
Energy Savings
The indoorairis passed through the heat exchangerto pre-warm or
pre-cool the incoming outside air which saves energy and money.
Design
Acoustically engineered and tested forquiet operation.
Easy Maintenance
Offers easy filter replacement and heat exchangercleaning.
ZR Chassis
List of Functions for Residential ERV
Note
1. O : Applied, X: Not applied
Accessory : Ordered and purchased separately the accessory package referring to the model name provided and install at field.
Accessory line-ups varies by region, so check your local catalogue or local sales material.
2. Some functions can be limited by remote controller.
3. * : These functions need to connect the wired remote controller.
snoitcnuFyrogetaC
Air Flow
11teltuOylppuSriA
-/-/3-/-/3)taeh/looc/naf(spetSwolfriA
cisaBcisaB*otuAdeepSnaF
Air Purification
XXrezinoI
OOonanVU
OOretliF-erP
Fine Filter(ePM195%) OO
OOsisongaiDfleSytilibaileR
Convenience
OOtratseRotuA
OO*kcoLdlihC
OOnoitarepOdecroF
OO*lortnoCpuorG
XXremiTpeelS
OOnoitavreseRffO/nOnruT
OO*eludehcS
OOnoitarepOgnilooCtneliSthgiN
OOnoitarepOdeyaleD
OOnoitarepOdezimotsuCtnuomAwolfriA
OOnoi
tarepOdezimotsuClanosaeS
OOnoitarepOotuAlanosaeS
XX*lortno
CrotsimrehTowT
Installation XXpmuPniarD
OO*lortnoC.P.S.E
ETC
OOmralAretliF
CO2Sensor OO
yrosseccAyrosseccAiF-iW
ARV00903RA6 ARV01203RA6
Due to our policy of continuous product innovation, some specications may change without notication.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 5

GENERAL DATA
ARVU053ZEA2, ARVU063ZEA2, ARVU093ZFA2, ARVU123ZFA2
Type ERV Units
ARVU053ZEA2 ARVU063ZEA2 ARVU093ZFA2 ARVU123ZFA2
Performance
Capacity (CFM) 470 590 880 1,180
Power Input (SH1) Watts 360 470 720 930
Operating Range
Operating Range (°F DB) 14-113 14-113 14-113 14-113
Heat Exchanger Data
Air-to-Air Heat Exchanger Cross flow fixed core Cross flow fixed core Cross flow fixed core Cross flow fixed core
Quantity 1111
Temperature Exchanger Efficiency (%) (fan speed SH1)
Cooling (fan speed SH1)62 59 62 59
Heating (fan speed SH1)61 58 61 58
Enthalpy Exchange Efficiency (%)
Cooling (fan speed SH1)37 34 37 34
Heating (fan speed SH1)52 49 52 49
Unit Data
Sound Pressure dB(A) 40/37/31 41/39/33 44/41/35 45/41/35
Net Unit Weight (lbs) 148 148 331 331
Shipping Weight (lbs) 177 177 397 397
Fan
Type Cross Flow Cross Flow Cross Flow Cross Flow
Quantity 2222
Motor/Drive Brushless Digitally
Controlled/Direct
Brushless Digitally
Controlled/Direct
Brushless Digitally
Controlled/Direct
Brushless Digitally
Controlled/Direct
Airflow Rate SH/H/L (CFM) 471/471/388 589/589/471 883/883/706 1177/1177/942
External Static Pressure
SH/H/L (in wg) 0.80/0.44/0.24 0.64/0.36/0.20 0.80/0.44/0.24 0.64/0.36/0.20
Filters
Quantity 2244
Size 41-9/16” x 8-3/8” x 13/32” 41-9/16” x 8-3/8” x 13/32” 41-9/16” x 8-3/8” x 13/32” 41-9/16” x 8-3/8” x 13/32”
1SH - Super High
Condensate drain not required.
Cooling: Outdoor 95°F DB, 78°F WB; Exhaust 75°F DB, 63°F WB
Heating: Outdoor 35°F DB, 33°F WB; Exhaust 70°F DB, 58°F WB
Table 1:Energy Recovery Ventilator (ERV) Unit General Data
Due to our policy of continuous product innovation, some specications may change without notication.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
6
Energy Recovery Ventilator Engineering Manual

GENERAL DATA
ARV00903RA6, ARV01203RA6
Table 2:Residential Energy Recovery Ventilator (ERV) Unit General Data
ARV00903RA6 ARV01203RA6
m³/h 150 200
ft3/min 90 120
Cooling 100% Air Flow % 65 62
Cooling 75% Air Flow % 69 65
Heating 100% Air Flow % 61 58
Heating 75% Air Flow % 65 61
Cooling 100% Air Flow % 61 55
Cooling 75% Air Flow % 66 61
Heating 100% Air Flow % 58 52
Heating 75% Air Flow % 61 58
V, Ø, Hz 208/230, 1, 60 208/230, 1, 60
No. x mm2(AWG) 3C x 0.82 (18) 3C x 0.82 (18)
No. x mm2(AWG) - -
mm 640 x 320 x 640 640 x 320 x 640
inch 25-3/16'' x 12-9/16'' x 25-3/16'' 25-3/16'' x 12-9/16'' x 25-3/16''
kg(lbs) 23.4(51.6) 23.4(51.6)
- SH / H / L SH / H / L
Power Input Rated SH / H / L W 54.3 / 47.6 / 27.9 79.2 / 71.4 / 30.5
Running Current Rated SH / H / L A 0.44 / 0.40 / 0.26 0.62 / 0.56 / 0.28
SH / H / L m3/h 150 / 150 / 80 200 / 200 / 100
SH / H / L ft3/min 90 / 90 / 47 120 / 120 / 60
SH / H / L Pa 100 / 70 / 50 100 / 70 / 50
SH / H / L in. H2O 0.4 / 0.28 / 0.2 0.4 / 0.28 / 0.2
SH / H / L dB(A) 28 / 26 / 21 30 / 28 / 22
- SH / H / L SH / H / L
Power Input Rated SH / H / L W 62.6 / 53.8 / 31.9 83.6 / 75.6 / 35.9
Running Current Rated SH / H / L A 0.50 / 0.44 / 0.29 0.65 / 0.59 / 0.32
SH / H / L m3/h 150 / 150 / 80 200 / 200 / 100
SH / H / L ft3/min 90 / 90 / 47 120 / 120 / 60
SH / H / L Pa 100 / 70 / 50 100 / 70 / 50
SH / H / L in. H2O 0.4 / 0.28 / 0.2 0.4 / 0.28 / 0.2
SH / H / L dB(A) 28 / 26 / 21 30 / 28 / 22
- Air to Air Cross Flow Air to Air Cross Flow
-Specially pocessed non-
fiammable paper
Specially pocessed non-
fiammable paper
EA 1 1
- Direct-Drive Direct-Drive
- BLDC BLDC
W 30 30
EA 1 1
- Direct-Drive Direct-Drive
- BLDC BLDC
W 30 30
EA 4 4
Connection Duct Diameter Outer Dia. Ø, mm(inch) Ø 125 (4-23/25") Ø 125 (4-23/25")
EA 2 2
- Pre Pre
mm 275 x 280 x 7 275 x 280 x 7
inch 10-13/16'' x 11'' x 1/4'' 10-13/16'' x 11'' x 1/4''
EA 1 1
- MERV 13 MERV 13
mm 275 x 277 x 50 275 x 277 x 50
inch 10-13/16'' x 10-7/8'' x 1-15/16'' 10-13/16'' x 10-7/8'' x 1-15/16''
Min. ~ Max. ºC DB(Fº DB) -10~40 (14~104) -10~40 (14~104)
Operation Range (Outdoor Temperature)
Connecting Quantity
Type
Quantity
Fan Type
Dimensions W x H x D
W x H x DDimensions
Duct Connecting
Filters_2
Filters_1
Type
Quantity
Motor Output
Motor Type
Model Name
Temperature Exchange
Efficiency
(AHRI condition)
Enthalpy Exchange
Efficiency
(AHRI condition)
Power Supply
Wiring Connections
Ventilation Capacity
Power Supply Cable(included Earth)
Power and Communication Cable(included Earth)
Exhaust Air Fan
Supply Air Fan
External Static Pressure
Sound Pressure Level
Heat Exchanger
Quantity
Element
System Type
Fan Type
Quantity
Motor Output
Motor Type
Dimensions W x H x D
Air Flow Control Step
ERV
Mode
Bypass
Mode
Net Weight
Air Flow Rate
External Static Pressure
Sound Pressure Level
Air Flow Control Step
Air Flow Rate
Due to our policy of continuous product innovation, some specications may change without notication.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 7

ACCESSORIES
Table 3:ERV Residential Controller
Type Name Model Number
Remote Controller Standard III Wired Remote Controller PREMTB100 (RS3)
Dry Contact 220V, 1 Input PDRYCB000
Dry Contact 24V, 1 Input PDRYCB100
IDU Accessory Group Control PZCWRCG3
IDU Accessory Cable Extension PZCWRC1
Central Control System AC EZ PQCSZ250S
Central Control System AC Smart IV BACnet PBACNA000
Central Control System ACP IV BACnet PQNFB17C1
Central Control System AC Smart 5 PACS4B000
Central Control System ACP 5 PACP4B000
Required for Central Control System PI-485 PSNFP14A1
Due to our policy of continuous product innovation, some specications may change without notication.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
8
Energy Recovery Ventilator Engineering Manual

Table 4:ZE/ZF Chassis Central Controllers
Integration
Solution Name Model No.
Devices
per
Controller
Systems
per
Comm
Bus
Devices
per Comm
Bus
No. of
Comm
Bus
Ports
Power
Binary
Signals
Input/
Output
Description
BACnet®
Gateway PQNFB17C1 256 16
64 (128
with PDI
Premium)
4 24 VAC 10/4 Allow integration of LG equipment
for control and monitoring by open
protocol BACnet®and LonWorks®
building automation and controls
systems.
LonWorks®
Gateway PLNWKB100 64 16 64 1 24 VAC 2/2
Before specifying or placing an order, refer to the V-Net Network Solution Engineering Product Data Book and review the detailed technical data provided to fully understand the capabilities and limitations of
these devices.
Before specifying or placing an order, refer to the V-Net Network Solution Engineering Product Data Book and review the detailed technical data provided to fully understand the capabilities and limitations of
these devices.
Central
Controller Name Model No.
Devices
per
Controller
Systems
per Comm
Bus
Devices
per Comm
Bus
No. of
Comm
Bus Ports
Binary
Signals
Input/
Output
Power,
Conn Description
AC Smart
Premium PQCSW421E0A 128 16 128 1 2/2 24 VAC
Provides scheduling,
autochangeover,
setback, remote controller
lock, setpoint,range limit, run
time limit, web access, email
alarm notification, visual
floorplan navigation,
peak/demand control,
software device interlocking,
PDI integration, and AC
Manager Plus integration
advanced functionality in
addition to basic unit control
and monitoring.
AC Ez PQCSZ250S0 32 16 256 1 12 VDC,
ODU
Provides for scheduling in
addition to basic indoor unit
control and monitoring.
Advanced
Control
Platform(ACP)
Standard
PQCPA11A0E 256 16
64 (128
with PDI
Premium)
4
2/2 24 VAC
Provides for scheduling,
remote controller lock,
setpoint range limit, web
access, peak/demand
control, PDI integration,
and AC Manager Plus
integration advanced
functionality in addition to
basic unit control and
monitoring.
Advanced
Control
Platform (ACP)
Premium
PQCPB11A0E 256 16
64 (128
with PDI
Premium)
10/4 24 VAC
Table 5:ZE/ZF Chassis Integration Solutions
Due to our policy of continuous product innovation, some specications may change without notication.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 9

DIMENSIONS
ZE Chassis
Due to our policy of continuous product innovation, some specications may change without notication.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
10
Energy Recovery Ventilator Engineering Manual

DIMENSIONS
ZF Chassis
Due to our policy of continuous product innovation, some specications may change without notication.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 11

DIMENSIONS
ZR Chassis
Due to our policy of continuous product innovation, some specications may change without notication.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
12
Energy Recovery Ventilator Engineering Manual

EFFICIENCY CURVES
ARVU053ZEA2
Air Flow Rate [ft
3
/min]
Air Flow Rate [ft
3
/min]
0
0.2
0.4
0.6
0.8
1
1.2
1.4
0 100 200 300 400 500 600
External static pressure [inchAq]
30
35
40
45
50
55
60
65
70
100 200 300 400 500 600
High (ESP = 137)
Low (ESP = 111)
Super high (ESP = 158)
Temperature excha
Temperature excha
Enthalpy exch ncy(heating)
Temperature exchange e )
Temperature excha )
Enthalpy exch ncy(heating)
Ventilation
T
he graphs above show the available E.S.P range.
Figure 1:ARVU053ZEA2.
Due to our policy of continuous product innovation, some specications may change without notication.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 13

EFFICIENCY CURVES
ARVU063ZEA2
Ventilation
Air Flow Rate [ft
3
/min]
Air Flow Rate [ft
3
/min]
External static pressure [inchAq]
0
0.2
0.4
0.6
0.8
1
1.2
1.4
0 100 200 300 400 500 600
30
35
40
45
50
55
60
65
70
200 300 400 500 600 700 800
Super high
h(ESP = 158)
Low (ESP = 120)
Super high
Temperature excha
Temperature excha
(cooling)
Temperature excha )
Temperature excha )
(cooling)
T
he graphs above show the available E.S.P range.
(ESP = 165)
High (ESP = 148)
Figure 2:ARVU063ZEA2.
Due to our policy of continuous product innovation, some specications may change without notication.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
14
Energy Recovery Ventilator Engineering Manual

EFFICIENCY CURVES
ARVU093ZFA2
Figure 3:ARVU093ZFA2.
Ventilation
Air Flow Rate [ft
3/min]
Air Flow Rate [ft
3/min]
External static pressure [inchAq]
0
0.2
0.4
0.6
0.8
1
1.2
1.4
0 200 400 600 800 1000 1200
30
35
40
45
50
55
60
65
70
200 400 600 800 1000 1200
High (ESP = 137)
Low (ESP = 111)
Super high (ESP = 158)
Temperature excha
Temperature excha
(cooling)
Temperature exchange
Temperature excha )
)
(cooling)
The graphs above show the available E.S.P range.
Due to our policy of continuous product innovation, some specications may change without notication.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 15

EFFICIENCY CURVES
ARVU123ZFA2
Ventilation
Air Flow Rate [ft
3/min]
Air Flow Rate [ft
3/min]
External static pressure [inchAq]
0
0.2
0.4
0.6
0.8
1
1.2
1.4
0 200 400 600 800 1000 1200
30
35
40
45
50
55
60
65
70
400 600 800 1000 1200 1400
High (ESP = 148)
Low (ESP = 120)
Super high (ESP = 165)
Temperature excha
eating)
Temperature excha )
eating)
ciency(heating)
The graphs above show the available E.S.P range.
Figure 4:ARVU123ZFA2.
Due to our policy of continuous product innovation, some specications may change without notication.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
16
Energy Recovery Ventilator Engineering Manual

EFFICIENCY CURVES
ARV00903RA6
Figure 5:ARV00903RA6.
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1
0 20 40 60 80 100 120 140
External static pressure [inAq]
Air Flow Rate [CFM]
Due to our policy of continuous product innovation, some specications may change without notication.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 17

EFFICIENCY CURVES
ARV01203RA6
Figure 6:ARV01203RA6.
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1
0 20 40 60 80 100 120 140
External static pressure [inAq]
Air Flow Rate [CFM]
Due to our policy of continuous product innovation, some specications may change without notication.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
18
Energy Recovery Ventilator Engineering Manual

ELECTRICAL AND ACOUSTIC DATA
Model Voltage
Range
Rated Amps
(A)
Power Supply Power Input (W)
Hz Volts Phase Cooling Heating
ARVU053ZEA2
187-253
2.8
60 208-230V 1
360/270/165 360/270/165
ARVU063ZEA2 3.44 470/385/210 470/385/210
ARVU093ZFA2 5.62 720/540/340 720/540/340
ARVU123ZFA2 6.82 930/770/420 930/770/420
Model Sound Levels dB(A)
Super High Fan Speed High Fan Speed Low Fan Speed
ARVU053ZEA2 40 37 31
ARVU063ZEA2 41 39 33
ARVU093ZFA2 44 41 35
ARVU123ZFA2 45 41 35
Units are suitable foruse on an electrical system where voltage supplied to unit terminals is within the listed range limits.
Sound pressure levels are tested in an anechoic chamberunderISO Standard 3745.
Power Input (W)
Hz Volts Phase SH / H / L
ARV00903RA6 0.44 54.3 / 47.6 / 27.9 0.5 15
ARV01203RA6 0.62 79.2 / 71.4 / 30.5 0.8 15
187-253 60 208-230 1
MFAMCA
Model
Voltage
Range
Rated Amps
(A)
Power Supply
ARV00903RA6 28 26 21
ARV01203RA6 30 28 22
Due to our policy of continuous product innovation, some specications may change without notication.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 19

ACOUSTIC DATA
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
63 125 250 500 1000 2000 4000 8000
Octave Band Sound Pressure Level (0dB = 20μPa )
Octave Band Center Frequency (Hz)
NC-15
NC-20
NC-25
NC-30
NC-35
NC-40
NC-45
NC-50
NC-55
NC-60
NC-65
Approximate
Hearing
Threshold
S-High
High
Low
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
63 125 250 500 1000 2000 4000 8000
Octave Band Sound Pressure Level (0dB = 20μPa )
Octave Band Center Frequency (Hz)
NC-15
NC-20
NC-25
NC-30
NC-35
NC-40
NC-45
NC-50
NC-55
NC-60
NC-65
Approximate
Hearing
Threshold
S-High
High
Low
Figure 7:ARVU053ZEA2 Figure 8:ARVU063ZEA2 Figure 9:ARVU093ZFA2
Figure 10:ARVU123ZFA2 Figure 11:ARV00903RA6 Figure 12:ARV01203RA6.
Due to our policy of continuous product innovation, some specications may change without notication.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
20
Energy Recovery Ventilator Engineering Manual
