LG HBM-W600 User manual

English
Español
Rev 1.0 US
All rights reserved.
LG Electronics Inc., 2012
Note: For the best performance and to prevent
any damage to, or misuse of the HBM-W600,
please read all of the information
carefully before to use.
WARNING :
This product contains chemicals known to the State of California
to cause cancer and birth defects or reproductive harm.
Wash hands after handling.
LG Electronics
BLUETOOTH®Headset
HBM-W600 User Manual

2 3
ENG
Introduction 3
- Included in package 3
Description of Parts 4
How to Use 4
- Change Direction 4
- Charging 5
- Low Battery 5
- Battery Status Alert 5
- Power On 5
- Power Off 5
- Pairing 6
- Auto-Reconnect 7
- Volume Control 7
- Calling 7
• Answering a call 7
• Making a call 7
• Voice dialing 8
• Last number redial 8
• Ending a call 8
• Transferring a call 8
• Call waiting 8
• Call reject 8
• Mic mute 8
- Advanced Multipoint 9
- Audio Streaming (A2DP) 10
- HD Voice 10
- SMS Reader 10
Summary of Button Functions 11
LED Indication 12
Troubleshooting 12
Specification 13
Precautions 13
Declaration of Confirmation 14
Additional Information 14
Limited Warranty 17
Important Safety Information 17
Table of Contents

2 3
ENG
Included in the Package
The LG HBM-W600 is a light weight wireless headset that uses Bluetooth®
technology.
This product can be used as an audio accessory for devices that support the
headset, hands-free or A2DP Bluetooth proles.
LG HBM-W600
Bluetooth®Headset Ear Loop Charger
User Manual Warranty CardNFC Tag Ear Buds(2)
Introduction

4 5
ENG
Change Direction
Power/Call Button
Volume Up/Down
Button
LED Indicator
Wireless
Charging Area
Microphone
Charging Port
Speaker
Left Right
Front
Back
Description of Parts
How to Use

4 5
ENG
Charging
1) Adaptor Charging
- When the charger is connected with power on or off, the headset will turn off.
- While charging, the LED indicator of HBM-W600 will show a solid white light
- The buttons will not function while the device is charging.
- It takes 2 hours to fully charge the headset.
- When charging is complete, the LED indicator of HBM-W600 will turn off.
2) Wireless Charging
- When HBM-W600 is placed on the LG WCP-700 Wireless
Charging Pad, the headset will remain on.
- While charging, the LED indicator of HBM-W600 will blink.
- It takes 2 hours to fully charge the headset.
- When charging is completed, the LED indicator of pad will turn solid green.
Low Battery
- An announcement will play once every 2 minutes.
- If the battery is not charged, the headset will turn off.
Power On
-
Press and hold the POWER/CALL button for 3 seconds.
• The power will turn on and a startup tone will play.
- The audible battery status alert will let you know the battery level.
Power Off
- Press and hold the POWER/CALL button for 3 seconds.
• A shutdown tone will play, the Bluetooth link will disconnect and the power will
turn off.
Battery Status Alert
- By pressing and holding the VOLUME DOWN button for 3 seconds, you can check
the battery status of the HBM-W600. The audible battery status alert will inform you
of the battery level. There are 3 levels of battery power:
1. Battery High
2. Battery Medium
3. Battery Low
How to Use

6 7
ENG
- Before using the headset for the rst time, it must be paired with a Bluetooth
enabled device.
- There are 2 pairing modes with the HBM-W600.
1) Easy Pairing
a) Press and hold the POWER/CALL button for 3 seconds to turn on the
HBM-W600.
b) The headset will enter auto-reconnect mode for 10 seconds.
(If your headset has already been paired with a device, the headset will
automatically reconnect to the device when the HBM-W600 is powered on.)
c) After 10 seconds, the HBM-W600 will automatically enter pairing mode.
d) When the headset enters pairing mode, the LED indicator will show a solid
white light.
e) Using your handset, nd the Bluetooth menu and “search for” or “add” new
devices.
f) Select “LG HBM-W600” from the list of devices to pair it with your device.
g) If you are asked for a passkey or PIN during pairing, please enter “0000”
(4 zeros).
h) Once the devices are paired, you will hear “Headset paired”.
i) After pairing has been completed, make sure you “connect” to the
LG HBM-W600.
j) If you want to pair with a different device in the future, the headset must be
placed into pairing mode.
k) If the headset is in pairing mode for 3 minutes without being connected to a
device, the HBM-W600 will automatically turn off.
2) Manual Pairing
a) With the power off, press and hold the POWER/CALL button for 6 seconds.
b) Continue pairing process from letter “e)” above.
3) NFC Pairing a) Place HBM-W600 into pairing mode.
b) Touch NFC and Bluetooth enabled handset to
NFC tag.
c) NFC and Bluetooth enabled handset will connect with
the HBM-W600 automatically.
NOTE: Place the NFC tag on the center of handset’s
battery door with NFC pairing feature.
Pairing
How to Use

6 7
ENG
Volume Control
- Press the VOLUME UP or VOLUME DOWN button to adjust the speaker volume.
- There are eight levels of speaker volume.
- To avoid hearing loss at high volume, HBM-W600 will play a warning tone when the
volume is raised into the upper 3 levels.
Calling
Answering a call
- When there is an incoming call, the headset will ring.
- Briey press and release the POWER/CALL button to answer the incoming call.
Making a call
- If you make a call from the connected handset, the call will (depending on the phone
settings) automatically transfer to the headset. If the call is not automatically transferred,
you can manually transfer the call by briey pressing the POWER/CALL button on the
HBM-W600 (handset and headset must be paired).
How to Use
Auto-Reconnect
- If the HBM-W600 is turned off (either accidentally or intentionally) while connected,
the headset will disconnect from the device.
The headset and handset will automatically reconnect when the HBM-W600 is
turned back on (provided that both devices are within the required range of 33 feet
(10 meters).
Out of range
- When the connected device and the HBM-W600 are separated by a range of
33 feet (10 meters) or more, the headset will alert the user with a beep, and the
headset and device will disconnect.
- When the device and the HBM-W600 are within the required range again, the
HBM-W600 will automatically reconnect to the device.
- If the headset and device do not automatically reconnect when they are back within
the required range, briey press the POWER/CALL button on the HBM-W600 to
reconnect manually.
- While trying to reconnect, your headset will beep and the LED indicator will icker
twice every 5 seconds.
- If the headset does not reconnect within 60 minutes, it will turn off.

8 9
ENG
Voice dialing
- Briey press the POWER/CALL button to activate “Voice dialing”.
For best results, record the voice dialing tag through your headset.
NOTE: If your handset does not support voice dialing, this action may activate Last
Number Redial.
Last number redial
- Press and hold the POWER/CALL button for 1 second to activate “Last number redial”.
The headset will beep and then call the last number dialed.
* Feature will not work if held for longer than 1 second.
Ending a call
- Briey press the POWER/CALL button.
Transferring a call
- While on a call on your handset, briey press the POWER/CALL button to transfer the
audio to the headset (the headset and handset must be paired).
- To transfer a call from the headset to handset, press and hold the VOLUME UP button
for 3 seconds.
Call waiting
- Answer a second call without hanging up the rst by pressing the CALL button for 1
second (You will hear a beep). Press the POWER/CALL button for 1 second to return
to the original call.
- Briey press the POWER/CALL button to end the active call or both calls at once.
(subject to handset support)
Call reject
- Activate call reject by pressing the POWER/CALL button for 1 second when the
handset rings.
* These functions may only be used if your handset supports them.
For further information about using these features, please consult your handset’s user
manual.
Mic mute
- Press and hold the VOLUME UP and VOLUME DOWN buttons simultaneously for 1
second to mute/unmute the mic during conversation.
How to Use

8 9
ENG
Advanced Multipoint
The HBM-W600 is capable of having two devices connected to the headset at the
same time. This will give you the freedom of using call waiting between calls on both
of your connected phones.
Connection
- Pair the headset with one of your Bluetooth-enabled handsets (per the pairing
instructions on page 6).
- Turn off the headset.
- With the power off, press the POWER/CALL button and move the power switch to
the ‘ON’ position at the same time for 4 seconds to enter Manual Pairing mode.
- Now, pair and connect the headset with your other Bluetooth-enabled handset.
(This will be your primary handset).
- Once this handset is paired and connected, go back and connect the originally paired
handset to the headset. (This will now be your secondary handset).
* NOTE: When the HBM-W600 is connected to two handsets at the same
time(multipoint), the headset calling functions will work with the primary
handset.
Calling function
- Voice Dialing and Last Number Redial features work with the primary handset (or
handset which made the last outgoing call).
Call waiting
- While speaking on an active call, press the call button for 1 second to switch to an
incoming call.
- To switch between 2 active calls, press the call button for 1 second.
- To end both calls briey press the call button.
- If both handsets are receiving an incoming call, the headset will default to the primary
device.
How to Use

10 11
ENG
Audio Streaming (A2DP)
The HBM-W600 supports music streaming (A2DP).
When you play music from yourA2DP enabled device, it will automatically transfer
to your headset. Music will automatically pause when you have an incoming call.
When the call is ended the music will start playing again.
A2DP allows streaming of all audio from your handset and running applications
including music and GPS navigation.
SMS Reader
The HBM-W600 supports SMS reading onAndroid TM based devices.
In Google Play search for the LG “BT Reader” application and install on your device
to use this function.
* The 2D barcode shown below helps you download the LG “BT Reader” application
from Google Play.
HD Voice
The HBM-W600 supports high denition voice calling and audio streaming.
*Network must support HD Voice for higher quality calling.
How to Use

10 11
ENG
Function
HBM-W600
Status
Action
Power on Power off Press the POWER/CALL button for 3 seconds.
Power off Power on Press the POWER/CALL button for 3 seconds.
Volume up Talking Briey press the VOLUME UP button.
Volume down Talking Briey press the VOLUME DOWN button.
Transferring a call Talking
- Handset to headset
Briey press the POWER/CALL button. (must
be paired)
- Headset to handset
Press and hold the VOLUME UP button for
3 seconds.
Answering a call Ringing Briey press the POWER/CALL button.
Ending a call Talking Briey press the POWER/CALL button.
Call waiting Talking Press the POWER/CALL button for 1 second.
Last number redial Idle Press the POWER/CALL button for 1 second.
Voice dialing
(handset must
support) Idle Briey press the POWER/CALL button.
Call reject Ringing Press the POWER/CALL button for 1 second.
Mic on/off Talking Press and hold VOLUME UP and VOLUME
DOWN buttons simultaneously for 1 second.
Pairing mode
(Manual) Power off Press the POWER/CALL button for 6 seconds.
Battery status check Idle Press the VOLUME DOWN button for 3
seconds.
NFC pairing Pairing Touch NFC and Bluetooth enabled handset
to NFC tag.
Summary of Button Functions

12 13
ENG
Function HBM-W600 Status Action
Operating
Power on The LED will ash 4 times.
Power off
The LED will ash 4 times and then turns off.
Pairing mode The LED stays on.
Headset / Hands-Free /
A2DP proles connected
The LED will ash twice every 5 seconds.
Call connected The LED will ash twice every 5 seconds.
Out of range
For the rst 15 minutes after the devices are
disconnected the LED will ash twice every 5
seconds. After that it will ash once every 5 seconds.
Charging Charging
(Adaptor Charging) The LED stays on.
(Wireless Charging) Depends on the HBM-W600 status.
Charging complete
(Adaptor Charging) The LED turns off.
(Wireless Charging) Depends on the HBM-W600 status.
Issue Possible problem Resolution
Does not turn on Check whether the battery of the HBM-W600 is fully
charged. Charge the battery.
Unable to
communicate with
the LG HBM-W600
Check whether the device
supports the headset or
hands-free Bluetooth proles.
Determine whether your device
supports the Headset or Hands-
free Bluetooth proles.
Check whether the battery of
the HBM-W600 is low.
Charge the battery.
Unable to pair the
HBM-W600 with
Bluetooth device
Check and make sure the
headset is on. Press and hold the POWER/CALL
button for at least 3 seconds to
turn on the headset.
Check and make sure the
headset is placed in pairing
mode.
With the Power off, press and
POWER/CALL button for 6 seconds
to manually place the headset in
pairing mode.
Low sound (speaker) Check the speaker volume. lncrease the volume level.
Cannot hear audio
streaming Check whether the device is streaming. Start device streaming.
LED Indication
Troubleshooting

12 13
ENG
Item Description
Bluetooth
®
Specication V3.0 (Headset / Hands-Free / A2DP Proles)
Battery 3.7V, Li- Polymer, 60mAh
Talk Time Up to 5 Hrs 30min
Standby Time Up to 230 Hrs
Charging Time < 2 hours
Operation Temperature 14°F ~ 140°F (-10°C ~ 60°C )
Dimension / Weight 20.4mm(W) X 50.5mm(L) X 11.6mm(H) / 12.5g
Do not drop the device.
Do not modify, repair, or disassemble.
Do not expose directly to water, alcohol or benzene for cleaning.
Do not expose directly to ammables.
Do not place or keep the device near ammables.
Keep the device away from humidity and dust.
Do not place heavy objects on the device.
Only use the headset with an original LG charger, otherwise it may be damaged.
Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
The earloop is made of a durable plastic. However, bending the earloop
repeatedly is not recommended.
Specication
Precautions

14 15
ENG
FCC NOTICE TO USERS:
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
IMPORTANT NOTE:
To comply with the FCC RF exposure compliance requirements, no change to
the antenna or the device is permitted. Any change to the antenna or the device
could result in the device exceeding the RF exposure requirements and void user’s
authority to operate the device.
CE NOTICE TO USERS:
Hereby, LG Electronics Inc. declares that the HBM-W600 is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC.
1. Radio frequency exposure
This Bluetooth®Headset HBM-W600, is a radio transmitter and receiver. When in
operation it communicates with a Bluetooth®equipped mobile device by receiving
and transmitting radio frequency (RF) electromagnetic elds (microwaves) in the
frequency range 2.4 to 2.4835 GHz. The output power of the radio transmitter is low
(0.001 watts). Your Bluetooth®Headset is designed to operate in compliance with the
RF exposure guidelines and limits set by national authorities and international health
agencies when used with any compatible LG Electronics mobile phone.
Declaration of Conrmation
Additional Information
FCC ID: BEJHBMW600

14 15
ENG
2. Potentially explosive atmosphere
Turn off your electronic device when in any area with a potentially explosive
atmosphere. Although this is uncommon, your electronic device could generate
sparks. Sparks in such areas could cause an explosion or re resulting in bodily
injury or even death. Areas with a potentially explosive atmosphere are often, but not
always, clearly marked.
3.Emergency calls
IMPORTANT!
This Bluetooth®headset and the electronic device connected to the headset
operate using radio signals, mobile and landline networks as well as user
- programmed functions, which cannot guarantee connection under all conditions.
Therefore you should never rely solely upon any electronic device for essential
communications (e.g. medical emergencies). Remember, in order to make or
receive calls, the headset and the electronic device connected to the headset
must be switched on and in a service area with adequate mobile signal strength.
Emergency calls may not be possible on all mobile phone networks or when certain
network services and/or phone features are in use. Check with your local service
provider.
4. Battery information
A rechargeable battery has a long service life if treated properly. A new battery or
one that has not been used for a long period of time could have reduced capacity
the rst few times it is used. Do not expose the battery to extreme temperatures,
never above +60°C(+140°F) or under -20°C(-4°F). For maximum battery capacity,
use the battery at room temperature. If the battery is used in low temperatures, the
battery capacity will be reduced. The battery can only be charged in temperatures
between +10°C(+50°F) and +45°C (+113°F). For your safety, do not remove the
battery incorporated in the product. If you need to replace the battery, take it to the
nearest authorized LG Electronics service point or dealer for assistance.
5. Recycling the battery in your Bluetooth®headset
The battery in your Bluetooth®Headset must be disposed of properly and should
never be placed in municipal waste. The LG Electronics service partner who
removes the battery will dispose of it according to local regulations.
Additional Information

16 17
ENG
6. Conditions
- The warranty is valid only if the original receipt issued to the original purchaser
by the dealer, specifying the date of purchase and serial number, is presented
with the product to be repaired or replaced. LG Electronics reserves the right to
refuse warranty service if this information has been removed or changed after
the original purchase of the product from the dealer.
- If LG Electronics repairs or replaces the product, the repaired or replaced
product shall be warranted for the remaining time of the original warranty period
or for ninety (90) days from the date of repair, whichever is longer. Repair or
replacement may involve the use of functionally equivalent reconditioned units.
Replaced parts or components will become the property of LG Electronics.
- This Warranty does not cover any failure of the product due to normal wear and
tear, or due to misuse, including but not limited to use in other than the normal
and customary manner, in accordance with instructions for use and maintenance
of the product. Nor does this warranty cover any failure of the product due to
accident, modication or adjustment, acts of God or damage resulting from
liquid.
- This warranty does not cover product failures due to improper repair
installations, modications or service performed by a non- LG Electronics
authorised person. Tampering with any of the seals on the product will void the
warranty.
- THERE ARE NO EXPRESS WARRANTIES, WHETHER WRITTEN OR
ORAL, OTHER THAN THIS PRINTED INCLUDING WITHOUT LIMITATION
THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE,ARE LIMITED TO THE DURATION OF THIS
LIMITED WARRANTY. IN NO EVENT SHALL LG ELECTRONICS OR ITS
VENDORS BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES
OF ANY NATURE WHATSOEVER, INCLUDING BUT NOT LIMITED TO
LOST PROFITS OR COMMERCIAL LOSS, TO THE FULL EXTENT THOSE
DAMAGES CAN BE DISCLAIMED BY LAW.
• Some countries/states do not allow the exclusion or limitation of incidental or
consequential damages, or limitation of the duration of implied warranties, so the
preceding limitations or exclusions may not apply to you. The warranty provided
does not affect the consumer’s statutory rights under applicable national
legislation in force, nor the consumer’s rights against the dealer arising from
their sales/purchase contract.
Additional Information

16 17
ENG
Subject to the conditions of this Limited Warranty, LG Electronics warrants this
product to be free from defects in design, material and workmanship at the time of
its original purchase by a consumer, and for a subsequent period of one (1) year.
Should your product need warranty service, please return it to the dealer from
whom it was purchased or contact your local LG Electronics contact centre to get
further information.
Avoiding hearing damage
Permanent hearing loss may occur if you use your headset at a high
volume.
Set the volume to a safe level. Over time you can become accustomed
to a higher volume that may sound normal but can be damaging to
your hearing. If you experience ringing in your ears or mufed speech,
stop listening and have your hearing checked. The louder the volume,
the less time is required before your hearing could be affected.
Hearing experts suggest that to protect your hearing:
• Limit the amount of time you use the headset at high volume.
• Avoid turning up the volume to block out noisy surroundings.
• Turn the volume down if you can’t hear people speaking near you.
Using Headsets safely
Use of headsets to listen to music while operating a vehicle is not
recommended and is illegal in some areas. Be careful and attentive
whilst driving. Stop using this device if you nd it disruptive or
distracting whilst operating any type of vehicle or performing any other
activity that requires your full attention.
Limited Warranty
Important Safety Information

MEMO

Español
English
Rev 1.0 US
Todos los derechos reservados.
LG Electronics Inc., 2012
Nota: para obtener un rendimiento óptimo y evitar cualquier
daño o uso incorrecto del auricular HBM-W600, lea
atentamente la información antes de utilizar el producto.
ADVERTENCIA:
Este producto contiene quimicos conocidos por el Estado de
California de causar cáncer y defectos de nacimiento u otros
daños reproductivos.
Lávese las manos después de manipular.
LG Electronics
Auricular BLUETOOTH®
Manual del usuario del HBM-W600

2 3
ESP
Introducción 3
- Contenido del paquete 3
Descripción de las partes 4
Modo de uso 4
- Cambio de orientación 4
- Carga 5
- Batería baja 5
- Alerta del estado de la batería 5
- Encender 5
- Apagar 5
- Asociación 6
- Reconexión automática 7
- Control del volumen 7
- Llamadas 7
• Contestar una llamada 7
• Realizar una llamada 7
• Marcado por voz 8
• Remarcado del último número 8
• Finalizar una llamada 8
• Transferir una llamada 8
• Llamada en espera 8
• Rechazar una llamada 8
• Silenciar micrófono 8
- Conexión avanzada de varios puntos 9
- Transmisión de audio (A2DP) 10
- Altavoz de HD 10
- Lector de SMS 10
Resumen de las funciones de los botones 11
Indicación del LED 12
Solución de problemas 12
Especificación 13
Precauciones 13
Aviso de conformidad 14
Información adicional 14
Garantía limitada 17
Información importante de seguridad 17
Contenido
