FCC CONCERNS
RF Exposure Statement:
The antenna(s) used for this device must not be co-located or operating in conjunction
with any other antenna or transmitter.
Do not
Any changes or modifications to the equipment not expressly approved by
the party responsible for compliance could void user’s authority to operate
the equipment.

The LG Bluetooth® headset HBM-560 is a light weight wireless Headset
utilizing Bluetooth® technology.
This product can be used as an audio accessory for devices supporting
either the Headset or Handsfree Bluetooth® Profiles.
■Included in package

■Change direction

■Charging
- Remove the cover on the charging port and connect the charger.
- When the charger is connected, with power on or off, the headset will
turn off. While charging, the LED indicator will show a solid blue light.
- The buttons will not function while the device is charging.
- It takes 2 hours to fully charge the headset.
- When charging is complete, the LED indicator will turn off.
■Low battery
- The LED indicator will blink blue when the battery power is low.
- When the battery is not charged, the LED indicator will blink blue and
then turn off.
■Power on
- Press and hold the PWR/END button for 2 seconds.
●The headset will turn on and a booting tone will play.
■Power off
- Press and hold the PWR/END button for at least 2 seconds.
● A shutdown tone will play, the Bluetooth® link will disconnect, and the
headset will turn off.

■Pairing
- Prior to using the Headset for the first time, you must pair it with a
Bluetooth-enabled handset.
- Enter the pairing mode with pressing and holding the CALL button for 5
seconds.
● You will hear two short beeps and the LED indicator will show a solid
blue light, when the device enters Pairing Mode.
▶Using your Handset, find the Bluetooth® Menu and "search for" or
"add” new devices.
▶Select ”LG HBM-560” from the list of devices and pair it with your
handset.
▶When asked for the Pass/PIN code during the pairing procedure,
please enter “0000” (4Zeros).
● Once pairing has completed successfully, you will hear a beep.
▶After pairing successfully, be sure to “Connect” to the HBM-560.
● If you want to pair with other devices in the future, the headset must be
placed in Pairing Mode.
● If the HBM-560 is in "Pairing Mode" for 3 minutes, without being paired
to a device, the Headset will automatically turn off.

■Auto Reconnect
When the HBM-560 turns off accidentally or intentionally during connected
condition, the headset and handset will disconnect.
The Headset and handset will automatically reconnect without pairing
when the HBM-560 turns on. HBM-560 will enter the pairing mode if
there’s no device to connect (Easy Pairing)
[ Out of range ]
- When the HBM-560 and your handset are separated by a distance of 33
feet (10meters) or more, the headset and handset will disconnect. When
the handset and HBM-560 are brought back within the required distance,
the HBM-560 will automatically reconnect with the handset.
- If the headset and handset do not automatically reconnect when they are
back within the required range, briefly press the CALL button to reconnect
manually.
■Volume control
- Briefly press the VOLUME UP or VOLUME DOWN button to adjust the
speaker volume.
- There are eight levels of speaker volume.
■Answering a call
- When there is an incoming call, the Headset will ring.
- Briefly press the CALL button to answer an incoming call.

Making a call
- If you make a call from the Handset, the call will (subject to phone
settings) transfer automatically to the Headset. If not automatically
transferred, you can transfer the call manually by briefly pressing the
CALL button on the HBM-560 (headset and handset must be paired).
Voice dialing*
- Briefly press the CALL button. (You will get the best results if you record
the voice dialing tag through your Headset.)
NOTE : If the Handset does not support the Voice Dial, the Headset will
activate the last number redialing.
Last number redial*
- Press and hold the CALL button for 1second to activate "Last Number
Redial". The headset will beep, and call the last number dialed.
Ending a call
- Briefly press the CALL button.
Transferring a call*
- While on a call on your handset, briefly press the CALL button on the
HBM-560 to transfer the audio to the headset.(headset and handset must
be paired).
- And to transfer a call from the Headset to Handset, press and hold
VOLUME UP button for 5 seconds.

Call waiting*
- Answer a second call without hanging up the first call by pressing the
CALL button for 1seconds. Press the CALL button for 1seconds to return
to the original call.
- Briefly press the CALL button to terminate the active call.
Call reject*
Activate call reject by pressing the CALL button for 1 second when
receiving a call.
* It is possible to use these functions only when your Handset supports
them.
For further information about using these features please consult your
Handset's user manual.

Function HBM-560 Status Action
Power on Power off Press the PWR/END button for at
least 2 seconds
Power off Power on Press the PWR/END button for at
lea
Volume Up Talking Briefly press the Volume Up
button
Volume Down Talking Briefly press the Volume Down
button
Transferring a call Talking
- Handset to Headset
Briefly press the CALL button
- Headset to Handset
Press and hold the VOLUME
UP button for 5 seconds
Answering a call Ringing Briefly press the CALL button
Ending a call Talking Briefly press the CALL button
Call waiting Talking Press the CALL button for 1
second
Last number
redialing Idle Press the CALL button for 1
second
Voice dialing
(Handset must support) Idle Briefly press the CALL button
Call Reject Ringing Press the CALL button for 1
second
Pairing mode Power Off or Idle Press the CALL button for 5
seconds

Function HBM-560 Status LED Status
Power on The blue LED light
flickers fast 4 times
Power off The blue LED light
flickers fast 4 times
Pairing mode The blue LED light turn
on
Headset / Handsfree
Profile Connected
The blue LED light
flickers twice every 5
seconds.
Call connected
The blue LED light
flickers twice every
5 seconds.
Operating
Unintentional Link Loss
(until the lost link is
recovered)
The blue LED light
flickers once every 5
seconds.
Charging The blue LED is turned
on
Charging
Charging complete The blue LED is turned
off

Does not turn on Check whether the battery
Charge the battery.
of the HBM- 560 is fully
discharged.
Charge the battery.
Unable to
communicate
with the HBM-
560
Check whether the
Handset supports the
Headset or Handsfree
Bluetooth® Profiles.
Determine whether
your Handset
supports the
Headset, or
Handsfree profiles.
Check whether the battery
of the HBM- 560 is low
Charge the battery.
Unable to pair the
HBM-560 with
the Bluetooth®
device
Check and make sure the
Headset is on.
Press the
PWR/END button
for at least 2
seconds to turn on
the Headset.
Check and make sure the
Headset is placed in
pairing mode.
With the power off,
press and hold the
CALL button for at
least 5 seconds to
place the Headset
in pairing mode.
Low sound
(speaker)
Check the speaker volume Increase the
volume level.

ITEM Description
Bluetooth® Specification V2.0 (Handsfree / Headset profiles) + EDR
Battery 3.7V, Li - Polymer
Standby Time Up to 150Hrs
Talk Time Up to 6Hrs
Charging Time 2Hrs
Operation Temperature -10℃~ 60℃
Dimension / Weight 18.4(W) x 43(L) x 25.6(H) / 11 g

1. Do not drop the unit from high places.
2. Do not modify, repair, or take apart.
3. Do not expose directly to water, alcohol. Benzene, etc. for
cleaning.
4. Do not expose directly to flammables.
5. Do not place or keep the unit near flammables.
6. Keep unit away from humidity &dust.
7. Do not place the heavy objects on the unit.
- Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate
the equipment.
- There is a risk of explosion if the battery is replaced by on incorrect
type.
- Dispose of used batteries according to the instructions.
- The ear loop is made of a durable plastic that does not break but bend.
However, repetition of bending is not recommended.

FCC NOTICE TO USERS :
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
IMPORTANT NOTE :
To comply with the FCC RF exposure compliance requirements, no
change to the antenna or the device is permitted. Any change to the
antenna or the device could result in the device exceeding the RF
exposure requirements and void user's authority to operate the device.

1. Radio frequency exposure
This Bluetooth® Headset, HBM-560, is a radio transmitter and receiver.
When in operation, it communicates with a Bluetooth® equipped mobile
device by receiving and transmitting radio frequency (RF) electromagnetic
fields (microwaves) in the frequency range 2.4 to 2.4835 GHz. The output
power of the radio transmitter is low, 0.001 watt. Your Bluetooth® Headset
is designed to operate in compliance with the RF exposure guidelines and
limits set by national authorities and international health agencies when
used any compatible LG Electronics mobile phone.
2. Potentially explosive atmosphere
Turn off your electronic device when in any area with a potentially
explosive atmosphere. It is rare, but your electronic device could generate
sparks. Sparks in such areas could cause an explosion or fire resulting in
bodily injury or even death. Areas with a potentially explosive atmosphere
are often, but not always, clearly marked.
3. Emergency calls
IMPORTANT!
This Bluetooth® Headset and the electronic device connected to the
Headset operate using radio signals, cellular and landline networks as well
as user- programmed functions, which cannot guarantee connection under
all conditions.
Therefore you should never rely solely upon any electronic device for
essential communications (e.g. medical emergencies). Remember, in
order to make or receive calls, the Headset and the electronic device

connected to the Headset must be switched on and in a service area with
adequate cellular signal strength. Emergency calls may not be possible on
all cellular phone networks or when certain network services and/ or
phone features are in use. Check with your local service provider.
4. Battery information
A rechargeable battery has a long service life if treated properly. A new
battery or one that has not been used for a long period of time could have
reduced capacity the first few times it is used. Do not expose the battery to
extreme temperatures, never above +60�(+140�F) or under -20�(-
4�F).
For maximum battery capacity, use the battery in room temperature. If the
battery is used in low temperatures, the battery capacity will be reduced.
The battery can only be charged in temperatures between +10�(+50�F)
and +45�(+113�F).
5. Recycling the battery in your Bluetooth® Headset
The battery in your Bluetooth® Headset must be disposed of properly and
should never be placed in municipal waste. The LG Electronics service
partner removing battery will dispose of it according to local regulations.
6. Conditions
- The warranty is valid only if the original receipt issued to the original
purchaser by the dealer, specifying the date of purchase and serial

number, is presented with the product to be repaired or replaced.
LG Electronics reserves the right to refuse warranty service if this
information has been removed or changed after the original purchase of
the product from the dealer.
- If LG Electronics repairs or replaces the product, the repaired or replaced
product shall be warranted for the remaining time of the original warranty
period or for ninety (90) days from the date of repair, whichever is longer.
Repair or replacement may involve the use of functionally equivalent
reconditioned units. Replaced parts or components will become the
property of LG Electronics.
- This Warranty does not cover any failure of the product due to normal
wear and tear, or due to misuse, including but not limited to use in other
than the normal and customary manner, in accordance with instructions
for use and maintenance of the product. Nor does this warranty cover any
failure of the product due to accident, modification or adjustment, acts of
God or damage resulting from liquid.
- This warranty does not cover product failures due to improper repair
installations, modifications or service performed by a non- LG Electronics
authorized person.
- Tampering with any of the seals on the product will void the warranty.
- THERE ARE NO EXPRESS WARRANTIES, WHETHER WRITTEN OR
ORAL, OTHER THAN THIS PRINTED INCLUDING WITHOUT
LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO THE
DURATION OF THIS LIMITED WARRANTY. IN NO EVENT SHALL LG
ELECTRONICS OR ITS VENDORS BE LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES OF ANY NATURE WHATSOEVER,
INCLUDING BUT NOT LIMITED TO LOST PROFITS OR COMMERCIAL
LOSS, TO THE FULL EXTENT THOSE DAMAGES CAN BE

DISCLAIMED BY LAW.
�Some countries/states do not allow the exclusion or limitation of
incidental or consequential damages, or limitation of the duration of
implied warranties, so the preceding limitations or exclusions may not
apply to you. The warranty provided does not affect the consumer's
statutory rights under applicable national legislation in force, nor the
consumer's rights against the dealer arising from
their sales/purchase contract.

Subject to the conditions of this Limited Warranty, LG Electronics warrants
this product to be free from defects in design, material and workmanship
at the time of its original purchase by a consumer, and for a subsequent
period of one (1) year. Should your product need warranty service, please
return it to the dealer from whom it was purchased or contact your local
LG Electronics contact center to get further information.
