LG Minibeam Pro PF1500 User manual

www.lg.com
Owner's Manual
LG Minibeam Pro
DLP Projector
PF1500
Please read the safety information carefully before using this product.

2LICENSES
LICENSES
Supported licenses may differ by model. For more information about
licenses, visit www.lg.com.
Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol are
trademarks of Dolby Laboratories.
This DivX Certied®device has passed rigorous
testing to ensure it plays DivX®video.
To play purchased DivX movies, rst register your
device at vod.divx.com. Find your registration
code in the DivX VOD section of your device
setup menu.
DivX Certied®to play DivX®video up to HD
1080p, including premium content.
DivX®, DivX Certied®and associated logos are
trademarks of DivX, LLC and are used under
license.
Covered by one or more of the following U.S.
patents:
7,295,673; 7,460,668; 7,515,710; 7,519,274.
The terms HDMI and HDMI High-Denition
Multimedia Interface, and the HDMI logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.
For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS Licensing
Limited. DTS, the Symbol, & DTS and the Symbol
together are registered trademarks, and DTS
2.0+Digital Out is a trademark of DTS, Inc. © DTS,
Inc. All Rights Reserved.

3
LICENSES
This device meets the EMC requirements for home appliances (Class
B) and is intended for home usage. This device can be used in all
regions.

• Image shown may differ from your projector.
• Your projector’s OSD (On Screen Display) may differ slightly from
that shown in this manual.
NOTE

4SAFETYPRECAUTIONS
SAFETYPRECAUTIONS
Please take note of the safety instructions to prevent any potential accident
or misuse of the projector.
• Safety precautions are given in two forms, i.e., WARNING and CAUTION
as detailed below.
WARNING Failure to follow the instructions may cause serious
injury and even death.
CAUTION Failure to follow the instructions may cause personal
injury or product damage.
• Read the owner's manual carefully and keep it on hand.
WARNING/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning ash with
arrowhead symbol, within
an equilateral triangle, is
intended to alert the user to the
presence of uninsulated dangerous
voltage within the product’s
enclosure that may be of sufcient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point
within an equilateral
triangle is intended to alert
the user to the presence of
important operating and
maintenance (servicing)
instructions in the literature
accompanying the appliance.
WARNING/CAUTION
-TO REDUCE THE RISK
OF FIRE AND ELECTRIC
SHOCK, DO NOT EXPOSE
THIS PRODUCT TO RAIN OR
MOISTURE.
Readtheseinstructions.
Keeptheseinstructions.
Heedallwarnings.
Followallinstructions.
IndoorInstallation
WARNING
• Do not use the projector outside
and do not expose the product
to any humidity or water.
-Since the product is not
waterproof, this may result in
a re or electric shock.
• Do not place the projector in
direct sunlight or near heat
sources such as radiators, res,
stoves, etc.
-This may result in re.
• Do not place flammable
materials such as aerosols near
the projector.
-This may result in re.

5
SAFETYPRECAUTIONS
• Do not allow children to cling to
or climb up to the projector.
-This may cause the projector
to fall, causing injury or death.
• Do not install the product in a
place with no ventilation (e.g.,
on a bookshelf or in a closet) or
on a carpet or cushion.
-This may result in re due
to the increase in internal
temperature.
• Do not place the product close
to sources of steam, oil or oil
mist, such as humidiers and
kitchen counters.
-Failure to do so may result
in re, electric shock, or
corrosion.
• Do not install the product onto
a wall or ceiling that is close to
sources of oil or oil mist.
-The product may be
damaged and fall, resulting in
serious injury.
• Do not place the projector where
it might be exposed to dust.
-This may result in re.
• Do not use the projector in a
damp place such as a bathroom
where it is likely to get wet.
-This may result in re or
electric shock.
• Do not allow a tablecloth or
curtain to block the air vent.
-This may result in re due to
the increase in the internal
temperature.
• Ensure good ventilation around
the projector. The distance
between the projector and the
wall should be at least 30 cm.
-This will prevent re due to
the increase in the internal
temperature.
CAUTION
• When placing the projector on a
table or shelf, be careful not to
put it near the edge.
-The projector could fall due
to balance problems, which
may cause personal injury or
damage to the product. Make
sure to use the projector
cabinet or stand that ts the
projector.
• When moving the projector,
make sure to switch it off and
remove the power plug and
cords.
-The power cord may be
damaged, resulting in re or
electric shock.
• Do not place the projector on
an unstable or vibrating surface
such as a wobbly shelf or a
slope.
-It may fall and cause injury.
• Be careful not to tip the projector
over when connecting external
devices to the projector.
-This may cause personal
injury or damage to the
projector.

6SAFETYPRECAUTIONS
Power
WARNING
• The appliance coupler is used
as the disconnect device.
-Please make sure the device
is installed near the wall
outlet to which it is connected
and that the outlet is easily
accessible.
• The grounding wire should be
connected.
-Ensure that you connect the
grounding cable to avoid
electric shock. If it is not
possible to ground the unit,
have a qualified electrician
install a separate circuit
breaker.
Do not try to ground the
projector by connecting it to
telephone wires, lightning
rods or gas pipes.
• The power plug should be
inserted fully into the power
outlet.
-An unstable connection may
cause a fire.
• Do not place heavy objects on
the power cord.
-This may result in re or
electric shock.
• Never touch the power plug with
wet hands.
-This may result in electric
shock.
• Do not plug too many devices
into one multi-power outlet.
-This may result in re due to
the power outlet overheating.
• Prevent dust from collecting on
the power plug pins or outlet.
-This may result in re.
• To turn off the main power,
remove the power plug, which
should be positioned so it is
easy to access for operation.
CAUTION
• Hold the plug firmly when
unplugging.
-A damaged wire may create
a re hazard.
• Ensure the power cord and plug
are not damaged, modied,
severely bent, twisted, pulled,
sandwiched or hot. Do not use
the product if the power outlet
is loose.
-This may result in re or
electric shock.
• Keep the power cord away from
heating devices.
-The wire's sheath may melt,
which may result in re or
electric shock.
• Place the projector where
people will not trip over or step
on the power cord to protect the
power cord and plug from any
damage.
-This may result in re or
electric shock.
• Do not turn the projector on or
off by plugging in the power plug
or unplugging it from the power
outlet. (Do not use the power
plug as a switch.)
-This may result in electric
shock or damage to the
product.

7
SAFETYPRECAUTIONS
• Do not insert a conductor
into the other side of the wall
outlet while the power plug is
inserted into the wall outlet.
In addition, do not touch the
power plug immediately after it
is disconnected from the wall
outlet.
-This may result in electric
shock.
• Only use the official power cord
provided by LG Electronics. Do
not use other power cords.
-This may result in re or
electric shock.
WheninUse
WARNING
• Do not place anything containing
liquid on top of the projector
such as a vase, ower pot,
cup, cosmetics, or medicine; or
ornaments, candles, etc.
-This may result in re or
electric shock, or cause injury
due to falling.
• In the event that there is a
heavy impact or the cabinet is
damaged, switch it off, unplug
it from the power outlet and
contact an authorized service
centre.
-This may result in electric
shock.
• Do not insert pieces of metal
such as coins, hairpins or metal
debris, nor ammable materials
such as paper or matches into
the projector.
-This is to prevent electric
shock or re.
• In the event that liquid or a
foreign object falls into the
projector, switch it off and
unplug it from the power outlet
and contact our service centre.
-This may result in re or
electric shock.
• Make sure that a child does
not swallow the batteries when
you replace the old remote
control batteries with new ones.
Keep batteries out of reach of
children.
-If a child swallows a battery,
consult a doctor immediately.
• Never open any cover on the
projector.
-There is a high risk of electric
shock.
• Do not look directly into the lens
when the projector is in use.
-The bright light may damage
your eyes.
• When the lamp is on or has just
been turned off, avoid touching
the air vent or lamp, because
these will be very hot.
• If there is a gas leak in the
room with the projector, do not
touch the projector or power
outlet. Open the windows for
ventilation.
-Sparks may cause re or
burns.

8SAFETYPRECAUTIONS
• Unplug the power cord from the
outlet during a lightning storm.
-This will prevent shock or
damage to the projector.
• Do not use the projector near
electronic devices that generate
a strong magnetic eld.
• Do not put the plastic package
used to pack the projector
around your head.
-This may cause suffocation.
• Do not keep your hand on the
projector for a long time when it
is running.
• When you play a game by
connecting a game console to
a projector, it is recommended
that you maintain a distance
of more than four times the
diagonal length of the screen.
-Make sure that the
connecting cable is long
enough. Otherwise, the
product may fall causing
personal injury or damage to
the product.
• Do not place the projector or its
remote control with battery in
an extremely high temperature
environment.
-This may result in re.
CAUTION
• Do not place heavy objects on
the projector.
-It may fall down and cause
personal injury.
• Be careful not to allow any
impact to the lens during
transport.
• Do not touch the lens of the
projector.
-The lens may be damaged.
• Do not use any sharp tools on
the projector such as a knife
or hammer, because this may
damage the casing.
• In the event that no image
appears on the screen or no
sound is heard, stop using
the projector. Switch off the
projector, unplug it from the
power outlet and contact our
service centre.
-This may result in re or
electric shock.
• Do not drop anything onto the
projector or allow anything to
bang into the projector.
-This may cause damage
to the projector or personal
injury.
• It is recommended that you
maintain a distance of at least
5-7 times the diagonal length of
the screen.
-If you watch the screen at
a close distance for a long
time, your eye sight may
become worse.

9
SAFETYPRECAUTIONS
• Do not block the light beam
emitted from the projector using
a book or other object.
-Lengthy exposure to the
projector beam may result in
re. In addition, the lens may
be overheated and damaged
by the reected heat. Disable
the AV function to stop
projection temporarily or turn
off the power.
• Do not start the projector with
the volume turned up high.
-High volume may damage
hearing.
• Do not use high voltage
electrical equipment near the
projector, (e.g., a bug zapper.).
This may result in product
malfunction.
Cleaning
WARNING
• Do not spray the projector with
water when cleaning. Make sure
water does not flow into the
projector.
-This may result in re or
electric shock.
• When there is smoke or a
strange smell coming out from
the projector or a foreign object
falls into the projector, please
switch it off and unplug it from
the power outlet and contact our
service centre.
-Otherwise, this may result in
re or electric shock.
• Use air spray, a soft cloth or
a cotton swab moistened with
a lens cleaning chemical or
alcohol to remove dust or stains
on the front projection lens.

10 SAFETYPRECAUTIONS
CAUTION
• Contact your seller or our
service centre once a year to
clean the internal parts of the
projector.
-If you do not clean the
projector for a long period of
time, dust will accumulate,
which may result in re or
damage to the projector.
• When cleaning plastic parts
such as the projector case,
unplug the power rst and wipe
with a soft cloth. Do not spray
with water or wipe with a wet
cloth. Never use glass cleaner,
automobile or industrial shiner,
abrasives, wax, benzene, or
alcohol as these can damage the
projector.
-This can result in re, electric
shock or cause damage to
the product (deformation and
corrosion).
• Remove the plug from the outlet
before cleaning the product.
-Otherwise, this may result in
electric shock.
Others
WARNING
• When you go out, place the
projector out of reach of
animals, and remove the power
plug from the wall outlet.
-Using a damaged power cord
may result in short circuit
or re.
• Do not use the projector near
highprecision electronic devices
or those that transmit weak
radio signals.
-This may affect the operation
of the product, causing an
accident.
• Only a qualified technician
can disassemble or modify
the projector. For diagnosis,
adjustment, or repair, contact
your seller or our service centre.
-This may result in re or
electric shock.
• Do not stare directly into lens
when in operation, eye damage
can occur.
• No user serviceable parts
inside unit. High voltage parts
can cause shock and even
electrocution.
• Proper ventilation required, do
not block airow around unit.
Doing so can cause injury and
internal overheating.

11
SAFETYPRECAUTIONS
• To prevent damage to lamp,
unit must remain plugged in for
approximately 3 minutes after
power down to allow for proper
cool down (not applicable on
LED models).
• Do not touch the lens; doing so
can result in burns or damage
to lens. Lens and unit may be
HOT during and immediately
after use. Use caution when
handling unit, allowing for proper
cool down.
• Only use a grounded electrical
outlet.
• Do not insert anything into or
cover up the exhaust vents.
-This may result in re or
electric shock.
• Follow all maintenance
guidelines for optimal use;
service only at an authorized
service centre.
• Lamp contains mercury and
as such must be disposed of
according to local, state and
federal laws (not applicable on
LED models).
CAUTION
• Do not mix new batteries with
old ones.
-Burst or leaking batteries may
result in damage or injury.
• Be sure to unplug if the projector
is not to be used for a long
period.
-Accumulated dust may result
in re or electric shock due to
overheating, ignition, or poor
insulation.
• Only use the specified type of
battery.
-Burst or leaking batteries may
result in damage or injury.
• Dispose of used batteries
properly.
-This may result in explosion
or re. The correct method of
disposal may vary depending
on your country or region.
Dispose of the battery pack
as instructed.
• Do not throw or disassemble the
battery.
-This may result in re or
explosion due to damage to
the battery.
• Store batteries away from
metallic objects, such as keys
and paper clips.
-Excess current may cause a
rapid increase in temperature,
resulting in re or burns.
• Do not store the batteries near
any heat source, such as a
heater.
-This may result in re or
damage to the product.

12 SAFETYPRECAUTIONS
• Do not store batteries at
temperatures higher than 60 °C
or in high humidity.
-This may result in explosion
or re.
• Keep the batteries and remote
out of reach of children.
-This will prevent personal
injury or damage to the
product.
• Make sure that the battery is
installed correctly.
-This prevent explosion or re.
• Make sure you use the same
type of batteries for replacement.
• Incorrect battery replacement
may cause re.
RiskGroup2
CAUTION Possibly hazardous
optical radiation emitted from this
product. Do not stare at operating
lamp. May be harmful to the eye.


13
CONTENTS
CONTENTS
LICENSES 2
SAFETYPRECAUTIONS 4
PREPARATION 16
Accessories 16
OptionalExtras 17
PartsandComponents 18
-Main Unit 18
-Side 19
-Back 20
UsingtheJoystickButton 21
-Basic functions 21
-Adjusting the menu 22
ProjectorStatusIndicators 22
Installation 23
-Installation Precautions 23
-Projection Distance per
Screen Size 24
-How to Install the Projector
On a Tripod 26
-Kensington Security System 27
MAGICREMOTECONTROL
 28
-To Register the Magic
Remote Control 30
-To Re-register the Magic
Remote Control 30
-Using the Magic Remote
Control 31
USINGTHEPROJECTOR32
WatchingProjector 32
-Initial Setup 32
-Focus and Position of the
Screen Image 35
-Watching With the Projector 36
AdditionalOptions 37
-To adjust Aspect Ratio 37
-Using the Edge Adj (4 Corner
Keystone) Function 38
-Changing Input Device 39
-To Use SIMPLINK 41
UsingtheQuickMenu 43
ToSetSound 44
-To Set Sound Output 44
ENTERTAINMENT 46
TouseSmartFeatures 46
-To use Home Screen 46
-To use MY APPS 47
-To edit items in MY APPS 47
ToConnectNetwork 48
-One-click Network
Connection 48
-To Connect to a Network
Through Set Expert 48
-To Use the Wi-Fi Direct
Function 49
-Tips for Network Settings 50

14 CONTENTS
SMARTSHARE 51
BeforeUsing 51
-Connecting a USB Device 51
-Removing a USB Device 51
TouseSmartShare™ 53
-Watching the Videos 54
-Viewing the Photos 56
-Listening to Music 57
-Viewing Files 58
-To Set SmartShare™
Related Functions 59
TouseSCREENSHARE
(Miracast™/Intel'sWiDi
Function) 61
-To Use the Miracast™ /
Intel's WiDi Function 61
ToconnectDLNA 62
-To connect a DLNA-
authenticated Smartphone 62
-To connect DLNA DMR
(Digital Media Renderer) 63
-To connect a DLNA DMP
(Digital Media Player) 63
-SmartShare™ PC SW
Installing and Setting 64
-In Case of a DLNA
Malfunction 65
ToUseaPremiumService 66
-To Use Paid Content 67
-To Reset Premium 68
ToUseLGSmartWorld 69
-To Sign Up With LG Smart
World 70
-To Install An App On Your
Projector 70
-To Manage My Information 71
ToUseSearchFunction 72
ToUsetheVoiceRecognition
Function 73
-Using this Function Through
Search 73
-Using this Function on the
Internet 73
ToUseVoiceMateFunction 75
-What Is Voice Mate? 75
-How to Use Voice Mate? 76
-What Are Other Functions of
Voice Mate? 76
SeeAvatar 77
-Using the Avatar 77
ToUseInternet 78
FrequentlyAskedQuestions
forProjector 79
USINGADVANCED
FUNCTIONS 83
ToUseScreenRemote 83
-To Use Screen Remote 83
-To Control a Device
Connected to the Projector
Using the Screen Remote 83
ToUsetheUniversalControl
function 84
ToUseaUSBInputDeviceOn
aProjector 85
-To Use a USB Wired/wireless
Mouse 85
-To Use a USB Wired/wireless
Keyboard 85

15
CONTENTS
3DFUNCTION 86
WhileWatching3D 86
RequirementsforWatching3D
Images 89
-Using the DLP-LINK (DLP-
Ready) Type Glasses 90
Toview3Dimages 90
-Supported 3D Mode 91
CUSTOMIZINGSETTINGS 92
SETTINGS 92
PICTURESettings 93
SOUNDSettings 100
TIMESettings 103
LOCKSettings 104
OPTIONSettings 105
NETWORKSettings 108
SUPPORT 110
CONNECTINGDEVICES111
ConnectingtoHDReceiver,
DVD,orVCRPlayer,External
Devices 112
-HDMI Connection 112
-HDMI to DVI Connection 113
-AV Connection 113
-Component Connection 114
ConnectingaPC 114
-HDMI Connection 114
-HDMI to DVI Connection 115
ConnectingaLaptop 116
-HDMI Connection 116
ConnectingHeadphones 117
ConnectingaDigitalAmp 117
UsingtheMirroringFunction
ofaMobilePhone 119
-MHL Connection 119
MAINTENANCE 120
Cleaning 120
-Cleaning the Lens 120
-Cleaning the Projector Case
120
INFORMATION 121
ToUpdateProjectorSoftware

 121
BeforeReportingaProblem,
ChecktheFollowing: 122
-General 122
-Picture 122
-Sound 123
-PC Connection Problem 124
-Problems Replaying Movies
in My Media 125
SPECIFICATIONS 127

16 PREPARATION
PREPARATION
The pictures may differ slightly from the actual product.
Accessories
Accessories included with the projector are show below.
Accessories are subject to change without prior notice.
New accessories may be added or old ones removed.
Magic Remote Control
Two AA Batteries Owner's Manual CD Owner's Manual
Composite Gender Component Gender Power cord
AC-DC Adaptor
• When connecting an HDMI or USB
cable, or connecting a USB flash drive
to the HDMI or USB port, use a product
that has a width of 18 mm or less and a
height of 10 mm or less.
• When connecting two USB devices at
the same time, each one should have
bezels less than 8.5 mm thick.
• If the USB cable or USB flash drive
does not fit the USB ports of the
projector, use an extension cable that
supports USB 2.0.

17
PREPARATION
• Use a certified cable with the HDMI logo attached.
• If you do not use a certified HDMI cable, the screen may not display or a
connection error may occur. (Recommended HDMI cable types)
-High-Speed HDMI®/™ Cable
-High-Speed HDMI®/™ Cable with Ethernet
OptionalExtras
To purchase optional accessories, visit an electronics store or online
shopping site or contact the retail store where you purchased the product.
Optional accessories are subject to change without prior notice.
Projection Screen Tripod HDMI Cable
Video Cable Audio Cable
3D glasses
(DLP-LINK or DLP
Ready Type)
Optical Cable LG Audio Device MHL Cable

18 PREPARATION
PartsandComponents
This projector is manufactured using high-precision technology. You may,
however, see tiny black dots and/or bright coloured dots (red, blue, or
green) that continuously appear on the projector screen. This is a normal
result of the manufacturing process and does not indicate a malfunction.
MainUnit
Lens2)
Zoom ring
Vent1)
Vent1)
Speaker
Joystick Button
Speaker
Vent1)
Focus Ring
Vent1)
1) Due to the high temperature of vent area, do not get close to the vent area.
2) Do not touch the lens when using the projector. The lens may be damaged.

19
PREPARATION
Side
1 2 3 4 5 6 7 8
Description
1
PUSH button
2
(Headphone Port)
3
COMPONENT IN Port
4
AV IN Port
5
OPTICAL DIGITAL AUDIO OUT Port
6
(USB port)
7
LAN Port
8
Port

20 PREPARATION
Back
21 3
No. Description
1
IR Reciver
2
Port
3
DC IN Port
