LG LVC-S60HM User manual

Operating Instructions
LVC-S60HM
LVC-S60HP
LVC-S60NM
LVC-S60NP
Before installing and using the camera,
please read these instructions thoroughly
and retain them for later reference.
All manuals and user guides at all-guides.com
all-guides.com

2
Regulatory Notices For U.S.A
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation! This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This Class A digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
This symbol is intended to alert
the user to the presence of
uninsulated “dangerous voltage”
within the product’s enclosure
that may be of sufficient
magnitude to constitute a risk
of electric shock to persons.
This symbol is intended to
alert the user to the presence
of important operating and
maintenance (servicing)
instructions in the literature
accompanying the appliance.
CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE,
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Warning
To prevent fire or shock hazard, do not expose the unit to rain or moisture.
To avoid electrical shock, do not open the cabinet Refer servicing to qualified
personnel only.
Wiring methods shall be in accordance with the National Electric Code,
ANSI/NFPA 70.
This product is manufactured to comply with the radio interference
requirements of EEC DIRECTIVE 89/336/EEC, 93/68/EEC and
73/23/EEC.
All manuals and user guides at all-guides.com

Contents
Features ..................................................................................................................................3
Cautions for Safe Operation ......................................................................................................4
Operating Controls and Their Functions ..............................................................................5-6
Connections .........................................................................................................................7-8
Back Focus Adjustment ..........................................................................................................9
Installation of Camera............................................................................................................10
Specifications.........................................................................................................................11
FEATURES
This color video camera is designed for use
in monitoring system.
•High resolution and high sensitivity with a
1/3 inch Super HAD CCD (Charge Coupled
Device)
•
Line Lock when using AC24V power.
• CS Mount (Adapter Ring Mount for C Lens:
Optional)
• Dual power AC 24V / DC 12V
• Non-polarity DC12V
Maintence of the unit
•Remove dust or dirt on the surface of the
lens with a blower.
•Use a dry soft cloth to clean the body. If it
is very dirty, use a cloth dampended with
a small quantity of neutral detergent and
then wipe dry.
•Avoid the use of volatile solvents such as
thinners, alcohol, benzene, and
insecticides
. They may damage the
surface of the body.
3
All manuals and user guides at all-guides.com

4
Power Supply
They must be operated with a AC 24V class 2
power supply and DC12V alternatively.
* Notes: Be careful of AC frequency when the
camera is operated with Line lock mode.
AC24V(60Hz):S60HM/S60NM
AC24V(50Hz): S60HP/S60NP
Handling of the unit
Be careful not to spill water or other liquids on the
unit. Be cautions not to get combustible or metallic
material inside the body. If used with foreign
matter inside, the camera is liable to fail or to get a
cause of fire or electric shock.
Operating and storage location
Avoid viewing a very bright object (such as light
fittings) during an extended period. Avoid
operating or storing the unit in the following
locations.
•Extremely hot or cold places (operating
temperature -10
o
C~50
o
C, however, we
recommend that the unit be used within a
temperature range of 0
o
C~45
o
C)
• Damp or dust place
• Places exposed to rain
• Places subject to strong vibration
• Close to generators of powerful electromagnetic
radiation such as radio or TV transmitters.
Cautions for Safe Operation
All manuals and user guides at all-guides.com

5
1Tripod adapter
2CCD cover
3Dip switches
4Line phase adjustment volume
5Lens selection switch
6DC iris level adjustment volume
7Back focus lock screw
8Auto iris lens connector
9Back focus adjustment screw
0Power LED
qa BNC connector for video output
qs Power input connector
OPERATING CONTROLS AND THEIR FUNCTIONS
2
Pin assignment of auto iris lens connector
Pin No. DC iris Video iris
1 Damping - Vcc (+9V)
2 Damping + Not used
3 Drive + Video
4 Drive - Ground
1
3
2
1
4
4 3 5 6
VIDEO
AES
PHASE
DC
IRIS
8
79
10 12 11
POWER
AC 24V~
CLASS 2
ONLY
VIDEO
OUT
DC 12V
All manuals and user guides at all-guides.com

The Adjustment method of Line Lock Phase
When using a camera switcher to connect 2 cameras or
more to one monitor, there may be a vertical roll of the
images when switched. In such a case, refer to the
below.
-The vertical sync phase can be manually adjusted
within the range approximately from -90oto +90o.
- Switch the display on the monitor from camera1 to
camera2.
Adjust the PHASE volume on camera2 until the
vertical roll of the image stops.
If more than two cameras are used, please repeat this
procedure for all the cameras.
- If you can’t adjust vertical sync. phase,
Please exchange the polarity of input terminal.
➀ Camera switcher
② Monitor
➂ Vertical phase
6
OPERATING CONTROLS AND THEIR FUNCTIONS
➀②
➂
All manuals and user guides at all-guides.com
all-guides.com

7
CONNECTIONS
Power Connection
LVC-S60 (DC12V/AC24V Compatible)
1. DC 12V Power Supply
Remove the insulation on the power cable as illustrated and
connect the power cord to the AC/DC compatible terminals
on rear panel of the camera.
Note :
You don't need to be cautious of the polarity of positive
and negative.
(Auto polarity sensing)
2. AC 24V Power Supply
Connect the power cable to the AC/DC compatible input
terminal on the rear panel of the camera
Note :
To get the optimum performance from the unit, be sure to
connect to an AC supply of 24V ±10%
Connecting the monitor
➀To VIDEO OUT
②To video input on the monitor
DC12V
DC 12V
AC 24V~
AC24V
1 2
All manuals and user guides at all-guides.com

Lens Mounting
Remove the CCD cover. Then attach the CS mount lens to the camera. Please
refer to the drawing on the left.
C Mount Lens: You have to use the Adapter Ring Mount (not supplied).
CAUTION
Be cautious not to use Auto Iris Lens with over 30mA
DC iris level is preset in the factory. Only if necessary, adjust the DC iris level
to achieve the proper picture with AGC off.
Auto Iris Mode Selection
Set the auto iris mode selection
switch to the position that
corresponds to the lens which is
mounted to the camera. Please refer
to the table on the left.
8
POSITION LENS
DC DC iris lens
AES Manual or fixed iris lens
VIDEO Video iris lens
VIDEO AES DC
No. NAME POSITION FUNCTION
1 Synchronization mode L.L. Line lock mode
(SYNC) INT. Internal synchronization mode
2 Back light compensation ON sets to this position when strong light comes in behind the target
(BLC) OFF normal position
3 Auto gain control ON AGC level varies from 10dB to maximum 30dB
(AGC) OFF 10dB (Max.)
4 Flickerless ON shutter speed is fixed. (NTSC : 1/100 sec, PAL : 1/120 sec)
(FL) OFF
shutter speed is not fixed.
5 White Balance HOLD WB is fixed
(WB) ATW tracks and adjusts WB automatically
* Factory Setting
All manuals and user guides at all-guides.com

9
If back focus has to be adjusted after mounting the lens,
1. Loosen the back focus lock screw(1) on top of the camera with a (+) screwdriver
2. Turn the back focus adjustment screw(2) on top of the camera with hands until the
desired focus is reached.
3. Tighten the back focus lock screw(1).
Note :
When tighten screw, do not inflict unreasonable force. It may damage to the unit.
BACK FOCUS ADJUSTMENT
(1) (2)
All manuals and user guides at all-guides.com

10
This camera is mounted with tripod which makes it possible to install from both of
the bottom and the top of the unit as illustrated.
INSTALLATION OF CAMERA
All manuals and user guides at all-guides.com

11
Specifications
Model LVC-S60HM LVC-S60HP LVC-S60NM LVC-S60NP
Signal System NTSC PAL NTSC PAL
Total/Effective Pixels 410K/380K 470K/440K 270K/250K 320K/290K
Pick-Up Device 1/3 - Inch Interline Color CCD(Super HAD)
Lens C / CS MOUNT (Adapter Ring Mount for C Lens: Optional)
Iris Control DC / AES / VIDEO
Signal Process Digital Signal Process
Scanning System 2:1 Interlace
Sync. System Internal / External (Line Lock) Internal
Scanning Frequency 59.94Hz(VD) 50Hz(VD) 59.94Hz(VD) 50Hz(VD)
Resolution More than 500Line(H) More than 500Line(H) More than 330Line(H) More than 320Line(H)
S/N Ratio More than 50 dB
Standard Illuminance 2000Lux (5100°K)
Sensitivity (1/3 Output) 0.4Lux (F1.0) 0.1Lux (F1.0)
Video Output Signal 1Vp-p Composite (75Ω)
Back Light Manual ON / OFF (with DIP Switch)
Gain Control ON (Max. 30dB) / OFF (Max.10dB) (with DIP Switch)
Flickerless ON / OFF (with DIP Switch)
White Balance ATW / HOLD (with DIP Switch)
Exposure Automatic control with DC Iris meter / Video Iris meter / Auto Electronic Shutter (Max. 1/100000)
Power Source DC 12V ±10% (Auto Polarity Sensing) / AC 24V ±10%
Power Consumption 3.5W
Operation Temp. -10oC ~ 50oC (Humidity : 0%RH ~ 60%RH)
Storage Temp. -20oC ~ 60oC (Humidity : 0%RH ~ 85%RH)
Weight Approximately 300g
Dimensions 55 (H) X 56 (V) X 123 (D)
All manuals and user guides at all-guides.com
all-guides.com

P/NO.: 3834RS0072E
All manuals and user guides at all-guides.com

ݷᔫᒎฉ
LVC-S60HM
LVC-S60HP
LVC-S60NM
LVC-S60NP
Ᏼิဧ፿ࠥ࿳ስ૦ᒄ༄ ༿ᅲᑳᏞࣗࠥݷᔫ
ᒎฉጲ৙ݬఠ
All manuals and user guides at all-guides.com

2
ࢾဉී U.S.A
۾ޘອளހ၂ FCC ࢒15 ݝᎌ A ಢၫᔊ࿸۸ࡼሢᒜᄟୈ ᑚቋሢᒜᄟ
ୈဵᆐᄋ৙ಯࡼۣઐࡅဗ ᒏᏴᓕᐤཌڔᓤ࿸۸ဟޘညᎌছཷᒜࢾࡼƽ
۾࿸۸્ޘည ဧ፿࿴ᇄሣ࢟ຫൈถ೟ ྙᆚᑵཀྵڔᓤဧ፿ భถ࣪ᇄሣ
࢟ᄰ኶ᐆ߅ᎌছཷ
཭ ݀ݙۣᑺᏴᄂၐࡼڔᓤါሆݙޘညছཷ ྙ۾࿸۸ཀྵဣ࣪ᇄሣ࢟૞࢟
၁୻၃࿸۸ᐆ߅ዏᒮছཷ ᑚభጲᄰܕࡌఎ۾࿸۸౶ཀྵࢾ ഍ᅪ ᆸඣ༿
፿ઓᄰጲሆ౶యছཷ
•ᒮቤࢾሶ૞ᒮቤࢾᆡ୻၃ᄖሣ
•ᐐࡍ۾࿸۸୻၃࿸۸ᒄମࡼ௦ಭ
•୓۾࿸۸ރྜྷ഍ጙৈރᔭ ဧ۾࿸۸୻၃࿸۸ᆡ᎖ݙᄴࡼ࢟വᒦ
•ᓽኯளሾ࿜૞ᎌளዩࡼᇄሣ࢟/࢟၁ଆၣཽᏋጲ૝ནۑᓐ
۾A ಢၫᔊ࿸۸ଝ෽ࡍ᎖ޘညছཷࡼ࿸۸ᒄࢾᒦࡼཝݝገཇ
ࠥ፿᎖வာ፿ઓLjޘອᅪ
ఫࡀᏴᆚ௾Ꮟࡼᆉሙ࢟ኹLj્
ޘညཽ࣪࿽ᐆ߅࢟ૣࡼᆉሙă
ࠥ፿᎖ᄋታ፿ઓ Ⴒ࿸۸
ጙ໦ᄋ৙ࡼ፝ၮອᒦ۞ᒮገ
ࡼݷᔫᆒઐ ᆒኀ ᒎฉ
ᆐ೫ି࿩࢟ૣࡼᆉሙ
༿ᇖގሆ༄ঙ ૞ઁঙ
ดݝ඗ᎌྀ፿ઓభጲᆒኀࡼഃݝୈ
ྙኊᆒኀ ༿ೊᇹᓜጓᆒኀཽᏋ
ᓖፀ
࢟ૣᆉሙ
༿ᇖࡌఎ
வস
ᆐ೫ᒏ࢟ૣူ৺ ༿ݙገ୓কޘອ۩ഴᏴᎦᒦ૞ޭဘࡼણஹᒦ ᆐ೫ܜ඾࢟ૣ
ࡼᆉሙ ༿ݙገࡌఎ૦ఫ ྙኊᆒኀ ༿ೊᇹᓜጓᆒኀཽᏋ
୻ሣ።কගଜ࢟໮߈ ANSI/NFPA 70 ᒄࢾ
ࠥޘອဵږᑍ EEC DIRECTIVE 89/336/EEC 93/68/EEC 
73/23/EEC ᇄሣ࢟ছཷܪᓰညޘࡼ
All manuals and user guides at all-guides.com

෹ഺ
ᄂ࢛ .........................................................................................................................................3
ڔཝݷᔫᓖፀူሲ ....................................................................................................................4
ݷᔫ఼ᒜૺ৖ถ ....................................................................................................................5-6
ೌ୻ ......................................................................................................................................7-8
ઁୡ௦ࢯᑳ...............................................................................................................................9
࿳ስ૦ڔᓤ.............................................................................................................................10
ৃ........................................................................................................................................11
ᄂ࢛
ࠥݨྻ࿳ስ૦ဵᆐପ၁ᇹᄻᓜඡ࿸ଐࡼă
•঱ܦൈ ঱ഉැࣞࡼ 1/3 ፞ࡁ
Super HAD CCD (࢟Ắᓤᒙ)
•ࡩဧ፿ AC24V ࢟ᏎဟቲჄࢾ
•CS ڔᓤ ፿᎖ C ஻ᄿࡼೌ୻ણڔᓤ :
భኡ
•ၷ࢟Ꮞ AC 24V / DC 12V
•ᇄ૵ቶ DC12V
࿸۸ᆒઐ
•ဧ፿ࠏ૦୓ܭෂࡼા޺૞ᏺᇕࠏࢬă
•༿ဧ፿ྟݚ༹ஈ૦࿽ăྙვᏺLj༿ဧ፿ࡒ
ᎌ࿩೟ᒦቶ༹ஈଋࡼྟݚ༹ஈLj཭ઁݟছă
•༿ݙገဧ፿િቶྎଋLjྙᇥျଋĂௌறĂ
۽࿁ߢଋLj჈ඣ્Ⴜડܭෂ૞૦࿽ă
3
All manuals and user guides at all-guides.com

4
࢟Ꮞ
჈ඣܘኍဧ፿ AC 24V 2 ಢ࢟Ꮞ૞ᑗ DC12V
࢟Ꮞ
ᓖፀ : ࡩ࿳ስ૦ᏴቲჄࢾෝါሆ৔ᔫဟ
༿ᓖፀ AC ࢟Ꮞࡼຫൈ
AC24V(60Hz):S60HM/S60NM
AC24V(50Hz): S60HP/S60NP
ۃᏥ࿸۸
༿ᓖፀݙገ୓ၺ૞໚჈ጘᄏ୎ࡵ࿸۸࿟ă૦࿽ด
ݙถᎌጵ཮ᇕ૞ࠟቶᇕᒠăྙ࿳ስ૦ดݝᎌᏭ
ᒠLjᐌభถ્ࡴᒘ࿳ስ૦৺ᑇ૞፛૜Ᏸ૞࢟
ૣă
ဧ፿ࡀ࢐࢛
ݙገޠဟମఘ᎖ීೡࡼᇕᄏDŽྙࡾ௥Džă
ܜ඾Ᏼጲሆણஹᒦဧ፿૞ࡀࠥ࿸۸ă
• ེ૞ದࡼ࢐ (৔ᔫᆨࣞᆐ
-10°C~50°C ࡣဵᆸඣ୐ፇࠥ࿸۸ဧ፿ࡼᆨ
ࣞᆍᆐ 0°C~45°C)
• ޭဘ૞ᎌા޺ࡼ࢐
• ۩ഴᏴᎦᒦ
• ۩ഴᏴᎌ༓ೲᑩࣅࡼણஹᒦ
• ణதᎌ༓࢟ࠟ࿴ࡼ࢐Ljྙ၃ፒ૦૞࢟၁
࿴૦এதă
ڔཝݷᔫᓖፀူሲ
All manuals and user guides at all-guides.com
all-guides.com

5
①ྯ୭ଦᓞ୻໭
➁CCD ঙ
➂DIP ఎ
➃ቲሤᆡࢯஂఎ
➄஻ᄿኡᐋఎ
➅DC མ଀ܰࢯஂ
➆ઁୡ௦Ⴤࢾ൛ႋ
➇ᔈࣅམ஻ᄿ୻ా
⑨ઁୡ௦ࢯஂ൛ႋ
➉࢟Ꮞ LED
፿᎖၁ຫၒ߲ࡼ BNC ୻ా
࢟Ꮞၒྜྷ୻ా
ݷᔫ఼ᒜૺ৖ถ
ᔈࣅམ஻ᄿ୭ࢾፃ
୭ܠ DC མ ၁ຫམ
1 ၱି - Vcc (+9V)
2 ၱି +ᆚဧ፿
3 དࣅ +၁ຫ
4 དࣅ -࢐
11
12
All manuals and user guides at all-guides.com

ቲჄࢾሤᆡࢯᑳ
ࡩဧ፿࿳ስ૦༤ધ໭ೌ୻ 2 ݝ૞ࣶݝ࿳ስ૦ࡵጙგପ၁
໭ဟ Ᏼ༤ધဟᅄስభถ્ᎌጙৈࠓᒇࣅ Ᏼࠥ༽ౚ
ሆ༿ݬᑍጲሆႁී
-ࠓᒇᄴݛሤᆡభጲ၄ࣅࢯᑳ ࢯᑳᆍࡍᏖᆐ
-90°ࡵ90°
- ୓ପ၁໭࿟ࡼመာ࠭࿳ስ૦ 1 ༤ધࡵ࿳ስ૦ 2
ࢯஂ࿳ስ૦ 2 ࿟ࡼ PHASE ፒ೟ ᒇࡵᅄስࡼࠓᒇ
ࣅᄫᒏ
ྙဧ፿ࣶݝ࿳ስ૦ ༿࣪Ⴥᎌ࿳ስ૦ᒮআࠥ߈
- ྙิᇄࢯஂࠓᒇᄴݛሤᆡ
༿ୣધၒྜྷ࣡ᔇࡼ૵ቶ
➀ ࿳ስ૦༤ધ໭
② ପ၁໭
➂ ࠓᒇሤᆡ
6
ݷᔫ఼ᒜૺ৖ถ
➀②
➂
All manuals and user guides at all-guides.com

7
ೌ୻
࢟Ꮞೌ୻
LVC-S60 (DC12V/AC24V ରྏ)
1. DC 12V ࢟Ꮞ
ᑍᅄჅာ۠ఎ࢟Ꮞሣࡼ௾Ꮟށ ୓࢟Ꮞሣೌ୻ࡵ࿳ስ૦ઁෂ
ۇ࿟ରྏ AC/DC ࡼ࣡ᔇ࿟
ᓖፀ:
ิᇄኍᓖፀᑵঌ૵ቶă
DŽᔈࣅ૵ቶଶހDž
2. AC 24V ࢟Ꮞ
୓࢟Ꮞሣೌ୻ࡵ࿳ስ૦ઁෂۇ࿟ରྏ AC/DC ࡼၒྜྷ࣡ᔇ࿟
ᓖፀ:
ገ૝ࡻᔢଛࡼ࿸۸ቶถ ༿ೌ୻ 24V ±10% ࡼAC ࢟Ꮞ
ೌ୻ପ၁໭
➀ࡵVIDEO OUT
②ࡵପ၁໭࿟ࡼ၁ຫၒྜྷ
DC12V
DC 12V
AC 24V~
AC24V
1 2
All manuals and user guides at all-guides.com

஻ᄿڔᓤ
ནሆ CCD ঙ ཭ઁ୓CS ڔᓤ஻ᄿৼࢾࡵ࿳ስ૦࿟ ༿ݬ୅ᔧᅄ
CS ڔᓤ஻ᄿ : ิܘኍဧ፿ೌ୻ણڔᓤ ݙএࡒ
ᓖፀ
༿ݙገဧ፿ި 30mA ࡼᔈࣅམ஻ᄿ
DC མ଀ܰᏴ৔ޣᎾ࿸ ྙܘገ ࢯஂ DC མ଀ܰጲ૝ࡻৎࡼᅄስ
AGC ܕ
ᔈࣅམෝါኡᐋ
୓ᔈࣅམෝါኡᐋఎ࿸ࢾࡵᎧ࿳
ስ૦࿟ڔᓤࡼ஻ᄿሤ࣪።ࡼᆡᒙ ༿
ݬ୅ᔧܭ
8
ᆡᒙ ஻ᄿ
DC DC མ஻ᄿ
AES ၄ࣅ૞ৼࢾམ஻ᄿ
VIDEO ၁ຫམ஻ᄿ
VIDEO AES DC
ܠ ෗߂ ᆡᒙ ৖ถ
1ᄴݛෝါ L.L. ቲჄࢾෝါ
(SYNC) INT.
ดݝᄴݛෝါ
2۳ݗޡ ON ࡩᇕᄏઁෂᎌ༓ဟ࿸ࢾࡵࠥᆡᒙ
(BLC) OFF
໋ᄰᆡᒙ
3ᔈࣅᐐፄ఼ᒜ ON AGC
࢟ຳܤછ ࠭ 10dB ࡵᔢࡍ 30dB
(AGC) OFF 10dB (ᔢࡍ)
4ᇄ࿑ႄ ON ౐ඡႥࣞৼࢾ (NTSC 1/100 ෇PAL 1/120 ෇)
(FL) OFF
౐ඡႥࣞᆚৼࢾ
5ڹຳ HOLD WB
ৼࢾ
(WB) ATW ᔈࣅৌᔍࢯᑳ WB
* ߲ޣ࿸ᒙ
All manuals and user guides at all-guides.com
