Liberty garden 778 User manual

Owner’s Manual

™

Model #778

IMPORTANT: READ THE OWNER’S MANUAL BEFORE ASSEMBLING

1161 SOUTH PARK DRIVE, KERNERSVILLE NC 27284

LIBERTY GARDEN PRODUCTS, INC.

VISIT OUR WEBSITE: WWW.LIBERTYGARDENPRODUCTS.COM

OR CALL US TOLL FREE AT 1-866-820-5805, MONDAY - FRIDAY 9 A.M. - 5 P.M. EST

Decorative Hose

Reel Box

PARTS LIST

A. Crank handle (1)

D. Leader Hose (1) E. Step down foot (1)

B. Slide in feet (3) C. Hose reel box (1)

IMPORTANT: LAY OUT ALL PARTS AND FASTENERS. MAKE SURE ALL PARTS ARE ACCOUNTED FOR. IF

ANY PART IS MISSING PLEASE CONTACT LIBERTY GARDEN PRODUCTS AT 1-866-820-5805.

DO NOT CONTACT THE RETAILER. YOU CAN ALSO VISIT OUR WEBSITE, WWW.LIBERTYGARDENPROD-

UCTS.COM, FOR MORE INSTRUCTIONS, PICTURES AND HELPFUL HINTS OR CONTACT CUSTOMER SERVICE

at CUSTOMER [email protected]

TOOLS REQUIRED:

HARDWARE INCLUDED

AA. Allen wrench (Supplied) Adjustable Wrench

Phillips screwdriver

or bit for an electric drill

DD. Allen screw (1)

M6 x 16M5 x 10

CC. Phillips head screws (4)

BB. Lawn stakes (4)

Note: Hardware not shown to actual size.

Estimated Assembly Time : 10 minutes (not including mounting the leader hose)

PRE-ASSEMBLY

ASSEMBLY

Attach the crank handle (A) to the hose reel

box (C) using the m6 x 16 allen screw (DD)

and tightening with the supplied allen

wrench (AA).

Flip the box upside down. Note: Make sure the

lip stays closed. Line up the holes and insert

the feet (B) and the step down foot holder (D).

Using the four Phillips head screws (CC)

tighten using a Phillips head screwdriver.

Tilt the hose reel box (C) upright and using

your fingers, push the step down foot (E)

down if using the product on a hard surface.

When winding your hose, step on this to

secure the product.

FIGURE 3

FIGURE 1

FIGURE 2

Warning: Possible pinching hazard

Please open and close slowly.

Step 1 x 4 Step 2 x 4

ASSEMBLY & INSTRUCTIONS

FIGURE 4

FIGURE 5 & 6

NOTE: Do not overtighten connections

as this could cause stripping of threads.

Attach leader hose (D) to the water connector on the hose reel box (C).

Attach end of leader hose to water source.

For access to the

inside spool and water

connector, flip the lid

of the hose reel box

up using the handle.

6Slide garden hose into the front opening of the

hose box, then tighten hose fitting on the hose

reel aluminum connector. The hose is now

ready to wind around the spool. The hose box

holds up to 200 ft. of 5/8” garden hose.

NOTE: An

adjustable

wrench may be

needed. Do not

overtighten

connections

this could cause

stripping of

threads.

NOTE: Check for leaks prior to using.

ASSEMBLY & INSTRUCTIONS

For a more secure fit into soft ground or your yard use the lawn stakes to secure unit. (BB)

Flip the hose reel box upside down.

Using your fingers twist and tighten

the lawn stakes (BB) into the slide in

feet. (B)

8With the stakes installed, push down

on the entire hose reel box with both

hands to sink the four stakes

securely in the ground or in mulch.

FIGURE 7

CAUTION: Product has sharp points.

Improper contact may result in injury.

Handle with care.

CAUTION: Do not sit or stand

on the hose reel box. Always

move using the side handles.

NOTE: Before use remove the

clear plastic from the top of

the lid.

CARE INSTRUCTIONS

Your hose reel box is manufactured with the finest quality components available. This product will give

you many seasons of reliable and functional hose storage. All components are manufactured to rigorous quality

standards not common in other consumer grade hose reels available today. As with any steel product, there is

always the chance for rust developing over time. Your hose reel box finish is designed for industrial applica-

tions, but even the toughest of coatings can be compromised by scratches. Such minor surface damage can

occur in shipping despite our best efforts. We have found that most scratches occur during assembly and/or

installation. If the base metal is exposed to the elements long enough, rust will develop. We recommend that

you periodically inspect your reel for any surface damage. Scratches can easily be repaired by using standard

automotive touch-up body paint. Some of our most loyal customers recommend that at the end of each season,

the unit be cleaned and painted with a clear acrylic paint.

Drain the hose reel prior to the onset of freezing temperatures. If any trapped water freezes, it may cause damage

to the hose reel, hose, and even your pipes.

Store the entire unit - including hose reel and hose - inside your garage or storage shed at above-freezing

temperatures. Storing your hose reel inside during the winter is an excellent way of protecting your garden hose,

leader hose and O-Rings.

CALL US AT 1-866-820-5805 IF YOU HAVE ANY QUESTIONS

REGARDING CARE AND MAINTENANCE

When you install your hose reel, be sure the hose washers are in place and all fittings are secure. If you live

in more tempera climates, be sure to drain the unit of any residual water before storing.

• DO NOT EXPOSE UNIT TO FREEZING TEMPERATURES while water remains in the plumbing system, this

can damage the hose connections.

• DO NOT leave water running through the reel while not in use or unsupervised

We recommend that you periodically inspect your hose reel box for any surface damage.

WARNING: DO NOT consume water from garden hose; not fit for human consumption

WARNING: Cancer and Reproductive Harm

- www.p65warnings.ca.gov

WINTERIZING AND STORAGE
