Life Fitness SC9100 Configuration guide

Stepper SC9100 - S/N HSH100000
General Assembly
Operation Manual M051-00K20-A311
Service Manual M051-00K47-A013
Hardware Bag AK47-00050-0000
Kit: Serv: Network GK63-00002-0003
Shrouds
Crossover Pulley
Clutch Assembly - LT
Main Drive Pulley
and Clutch
Alternator Assembly
Pedal Assembly
Guide Rollers
Frame Componets
Cables
PCB/Resistor
Console Overlay
Bezel Assemlby
Bullhorns
Polar Receiver
Assembly
rev 10 Dec 2007
1 of 14

Page 2 of 14
Stepper SC9100 - S/N HSH100000
Console Overlay Bezel Assembly
Console Assembly Overlay Bezel Upper Overlay Lower Overlay
AK47-00016-0001 Eng Met AK47-00013-0001 Eng Met 0K47-01007-0001 Eng Met 0K47-01009-0001 Eng Met
AK47-00016-0003 Ger Met AK47-00013-0003 Ger Met 0K47-01007-0003 Ger Met 0K47-01009-0003 Ger Met
AK47-00016-0004 Spn Met AK47-00013-0004 Spn Met 0K47-01007-0004 Spn Met 0K47-01009-0004 Spn Met
AK47-00016-0006 Jap Met AK47-00013-0006 Jap Met 0K47-01007-0006 Jap Met 0K47-01009-0006 Jap Met
AK47-00016-0007 Frn Met AK47-00013-0007 Frn Met 0K47-01007-0007 Frn Met 0K47-01009-0007 Frn Met
AK47-00016-0008 Itl Met AK47-00013-0008 Itl Met 0K47-01007-0008 Itl Met 0K47-01009-0008 Itl Met
AK47-00016-0009 Dut Met AK47-00013-0009 Dut Met 0K47-01007-0009 Dut Met 0K47-01009-0009 Dut Met
AK47-00016-0010 Por Met AK47-00013-0010 Por Met 0K47-01007-0010 Por Met 0K47-01009-0010 Por Met
Console Board - Upper
A084-92220-A003
Console Case Assembly
AK63-00121-0000
Battery Door
0K63-01029-0000
Phillips Pan Screws(13)
0017-00101-1650
Bezel/Switch Assembly
AK63-00075-0000
Upper Overlay
Lower Overlay
Switch Membrane
118E-00001-0133

Page 3 of 14
Stepper SC9100 - S/N HSH100000
Frame Components
Mono-Column
AK47-00070-0000
Mono-Column Decal
0K47-01117-0000
Bull Horn w/HR - LT
AK47-00023-0002
Bull Horn w/o HR - LT
AK47-00024-0002
Bull Horn w/HR - RT
AK47-00023-0001
Bull Horn w/o HR - RT
AK47-00024-0001
Accessory Tray
0K63-01030-0000
Screws
0017-00101-1253
Handlebar
AK47-00057-0000
Leg Levelers
AK61-00035-0000
Jam Nut
0017-00103-0273
Vertical Handrail
0K47-01030-0000
Wheel w/Bearings
AK63-00016-0000
Wheel Insert
0K47-01085-0000
TORX Cap Screw(4)
0017-00101-1715
End Cap
0K-01156-0000
Console Screws
0017-00101-1253

Page 4 of 14
Stepper SC9100 - S/N HSH100000
Shrouds
Phillips Pan Screw(9)
0017-0010101242
Phillips Pan Screw(2)
0017-00101-1735
Left Shroud
AK47-00064-0000
Right Shroud
AK47-00064-0001
Center Shroud
0K47-01057-0000
Mono-Column Shroud
AK47-00083-0000 - SC85
AK47-00082-0000 - SC95/91
Phillips Pan Screw(2)
0017-00101-1242
Track Cover Plate
0K47-01128-0000
Cover Screw(2)
0017-00101-1732
Pedal Tube
0K47-01132-0000
Pedal Bolts
0017-00101-1719
Decal; ISO Track
0K47-01112-0000
Cover Rail Bracket
0K47-01146-0000
Bracket Screw
0017-00101-1732
Grommet
0017-00042-0754

Page 5 of 14
Stepper SC9100 - S/N HSH100000
Pedal Assembly
Sleeve Roller(2)
0K47-01136-0000
Side Roller Hex Bolt(4)
0017-00101-1731
Track Roller(4)
w/Busshing Assy
AK47-00087-0000
Center Track Roller
0K47-01084-0000
Thin Lock Nut(2)
0017-00103-0324
Pedal Bracket Assembly
w/o Rollers
AK47-00086-0000
Pedal Assembly LT
w/Rollers
AK47-00072-0000
Pedal Assembly RT]
w/Rollers
AK47-00073-0000
Pedal Only: RH or LT
0K47-1046-0000
Mono-roller Hex Bolt(2)
0017-00101-1730
Center Hex Bolt
0017-00101-1729
Belt/Spring Assembly
AK47-00154-0002
Spacer Plate
0K47-01148-0000
Lock Nut(11)
0017-00103-0282
Washer(2)
0017-00104-0159
Belt Terminator
0K35-01105-0000
Clamp Bracket
0K35-01142-0000
Low Head
Terminator Screw(2)
0K47-01153-0000
Roller Sleeve(2)
0K47-01084-0000
Track Roller
AK47-01087-0000
Mono Roller w/Bearings
AK47-00076-0000
Mono Roller &
Shaft Assy(2)
AK47-00071-0000
Shaft
0K47-01134-0000
Washer
0K47-01151-0000
Thrust Washer
0K47-01144-0000
Thrust Washer
0K47-01144-0000
Washer
0K47-01151-0000
Mono-roller Hex Bolt(2)
0017-00101-1730

Page 6 of 14
Stepper SC9100 - S/N HSH100000
Main Drive Pulley and Clutch
Thrust Washer(3)
0K47-01104-0000
Right Drive
Clutch Assembly
AK47-00043-0001
Flat Washer
0K47-01105-0000
Thrust
Washers
E-ring
0017-00100-0107
Main Drive Pulley/Shaft
AK47-00006-00000
Main Drive Belt
0K47-01054-0000

Page 7 of 14
Stepper SC9100 - S/N HSH100000
Clutch Assembly - LT
Thrust
Washer
Left Pulley Clutch
AK47-00043-0002
E-Rings(2)
0017-00100-0107
Thrust
Washer
Flat
W
asher
E-Ring
Flat Washers(3)
0K47-01105-0000

Page 8 of 14
Stepper SC9100 - S/N HSH100000
Crossover Pulley Assembly
Bolt
0017-00101-1717
Lock Nut
0017-00103-0025
Frame
Nut
0017-00103-0026
Washer
0017-00104-0043
Auto Start Switch
and Cable
AK63-00050-000
0
Adjustable Bracket
0K47-01052-0000
Plate
0K47-01056-0000
Bolts(2)
0017-00101-1048
Magnet
118E-00001-0124
Screw
0017-00101-1713
Crossover Pulley Assy
AK47-00007-0000
Tensioning Bolt
0017-00101-0928

Page 9 of 14
Stepper SC9100 - S/N HSH100000
Alternator Assembly
Alternator Belt
0K47-01106-0000
Tensioning Bracket Bolt
0017-00101-0986
Alternator w/Flywheel
AK47-00038-0000
Locking Nut
0017-00103-0117
Washer
0017-00104-0044
Alternator Pivot Bolt
0017-00101-0956
Alternator Flywheel
0K47-01069-0000
Tensioning Bracket
0K47-01053-0000

Page 10 of 14
Stepper SC9100 - S/N HSH100000
Guide Rollers
Spring Guide Pulley(2)
0K47-01066-0000
Snap Ring(6)
0017-00100-0050
Shaft
0K47-01154-0000
Belt Guide Pulley(2)
AK63-00008-0000
Bolt - 0017-00101-1722
Nut - 0017-00143-0025
Belt Idler Pulley(2)
0017-00009-1147
Bolt(2)
0017-00101-1098
Nut
0017-00103-0025
Bolt
0017-00101-1048

Page 11 of 14
Stepper SC9100 - S/N HSH100000
PCB and Resistor
Plastic Grommet(4)
0017-00042-0821
Phillips Screw(4)
0017-00101-0823
Power Control Board
B084-92239-0000
PCB Bracket
0K47-01087-0000
Resistor
AK47-00037-0000

Page 12 of 14
Stepper SC9100 - S/N HSH100000
Polar Receiver Assembly
Polar
Receiver
SK40-00045-0001
Screw
0017-00101-1723
Screw
0017-00101-1728
Polar Cap
0K47-01075-0000
Isolator
0K36-01059-0002
Cap
0K63-01114-0000

Page 13 of 14
Stepper SC9100 - S/N HSH100000
Cable
Description Part Number
Domestic 120/60 Battery Charge w/Cord 118E-00001-0148
Universal Battery Charger w/o Line Cord 118E-00001-0147
Line Cord 220V/60Hz
Line Cord 100V/50Hz 0017-00003-0704
Line Cord 240+ 0017-00003-0918
Line Cord 220V/50Hz
Line Cord 200V/50Hz
Line Cord 230V/50Hz
0017-00003-0691

Page 14 of 14
Stepper SC9100 - S/N HSH100000
UNLABELED PARTS
.ONTRAPNOITPIRCSED
5/16-18X24 NO HXW L BLT G5 ZN B 0017-00101-0933
6-32X14 HXS SOC CS G5 BO B 0017-00101-1348
8-32X6 HEX PAN TT ST BZ B 0017-00101-1732
RETAINER: BELT; BOTTOM C 0K35-01144-0001
RETAINER: BELT; TOP C 0K35-01144-0003
EXTRUSION: RUBBER; LWR-STOP B 0K47-01152-0000
DPLT:USE AK47-00154-0001/2#13748 C AK47-00041-0000
