PORTABLE INFRARED HEATER
With Remote Control
OWNER’S MANUAL
Model No. LS-3ECO
WARNING: READ THIS ENTIRE OWNER’S MANUAL CAREFULLY BEFORE USE.

18
Thank you for choosing a Lifesmart Infrared Heater. This owner’s manual will provide you with valuable
information necessary for the proper care and maintenance of your new product. Please take a few moments
to thoroughly read the instructions and familiarize yourself with all the operational aspects of your new
heater.
PLEASE SAVE THESE INSTRUCTIONS

18
IMPORTANTSAFETYINSTRUCTIONS
READANDUNDERSTANDALLINSTRUCTIONS,SAFETYWARNINGS,
ANDFAQ’sBEFOREUSINGTHEHEATER
WARNING!
!POTENTIALFORELECTRICALHAZARDIFNOTADHEREDTO!
When using electrical appliances, basic precautions should always be followed to reduce the
risk of fire, electric shock, and injury to persons, including the following:
1. This heater must be plugged into a 120V, 15 amp (or more) circuit of its own. Nothing
else can be plugged into the same circuit. If unsure if your home meets this
specification, consult a certified electrician prior to use. Risk of fire, overheat,
malfunction, property damage, injury, or even death may result if not adhered to!
2. Connect to a properly grounded, 3-prong outlet only. Do not connect the heater to
extension cords, surge protectors, timers, direct breakers, or an outlet with other
appliances connected to the same outlet. Risk of fire, overheat, malfunction,
property damage, injury, or even death may result if not adhered to!
3. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces.
Use handles (certain models) or wheels to move this heater.
4. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and
curtains at least 3 feet (0.9m) from the front of the heater and keep them away from the
sides and rear of the heater.
5. Extreme caution is necessary when any heater is used by or near children, invalids,
pets, or when the heater is left operating unattended.
6. Always unplug the heater when not in use.

18
7. Do not operate any heater with a damaged cord or plug or after the heater malfunctions,
has been dropped, or damaged in any manner. Contact the manufacturer for resolution
options.
8. Do not use outdoors. Exposure to outdoor elements such as rain, snow, sun, wind or
extreme temperatures may cause the heater to become a safety hazard.
9. This heater is not intended for use in bathrooms, laundry areas and similar indoor
locations, nor any locations that use GFCI outlets.
10.Never place heater where it may fall into a bathtub or other water receptacles.
11.Do not run cord under carpet. Do not cover cord with throw rugs, runners, or similar
coverings. Arrange cord away from traffic area and where it will not be tripped over.
12.The heater must be plugged into a wall outlet that is a DEDICATED CIRCUIT, with a
minimum 15 amp rating on that individual circuit.
13.To disconnect the heater: FIRST, turn the power button to the “off” position, then
remove plug from the wall outlet.
14.Do not allow foreign objects to enter or block any ventilation or exhaust opening as this
may cause an electric shock or fire, or damage the heater.
15.Allow at least 3 feet of unobstructed space to the front and rear of the heater to allow for
maximum heat, air, and ventilation flow.
16.A heater has hot and arcing or sparking parts inside. Do not use it in areas where
gasoline, paint, or flammable liquids are used or stored, nor use flammable solvents to
clean the heater. Also, make sure to keep heater dry at all times.
17.Use this heater only as described in this manual. Any other use not recommended by
the manufacturer may cause fire, electric shock, or injury to persons.
18.Do not use abrasive solvents to clean the heater as it may cause damage to the finish
or casing.
PLEASE REVIEW FREQUENTLY ASKED QUESTIONS ON THE NEXT
FEW PAGES PRIOR TO USING YOUR HEATER.

18
FREQUENTLY ASKED QUESTIONS (FAQ’S)
My heater emits a “strange” odor when I first open the box/when I turn the heater on for the first
time. Why is this happening?
This is normal. This heater is treated with a special heat safe/resistant coating. This odor will
sometimes be present when the box is opened, and may be compared to a heaters version of “new
car smell.” Also, similar to all hearth appliances (woodstoves, etc.), the coating, exposed to heat, will
produce this particular odor during the first few hours of operation. This will dissipate after the break-
in period. If you are sensitive to odors, you may want to pre-burn the unit in a garage with the
door open until the initial odor dissipates.
If my heater runs on approximately1500 Watts, how many BTU’s is that? Is that a lot of heat?
At 1500 Watts, your heater will use approximately 5100 BTUs. 5100 BTUs, compared to your home
furnace, is a very small amount of heat (this heater is intended to be used as supplemental heat in
areas most needed). It may take several minutes, to several hours to heat your area, depending on
various factors (see Heater Placement).
Can my heater really operate on less money per day? What are my operating costs?
Yes. If the heater is used as it is intended (as supplement/assist heat), it should cycle on and off,
allowing for it to heat a total of approximately 8 out of the 24 hours of the day. Using the national
average of approximately 10¢ per kWh (look at your bill for exact cost per kWh--will vary per state),
your average heating cost (add a few cents just for having it plugged in) should be less per day
compared to your main furnace. The costs will increase if it is used as the single source of heat, or if
heat somehow escapes the room being heated, since the “on” cycle will run longer.
The Formula: To determine the cost of this or ANY 1500 watt appliance, multiply 1.5 X your cost per
Kilowatt Hour to determine approximately how much it costs you to run the heater. You can find the
cost per KWH prices for your state at: http://www.eia.doe.gov/fuelelectric.html
What is the life expectancy for the Heating Elements? Can the heating elements be replaced?
The life expectancy of the heating elements is typically 25,000 hours. Heating elements may be
replaced by obtaining parts from the Manufacturer, although it is not recommended, due to the
amount of work (unless you are a certified heater technician or authorized directly by SGH Technical
Support). All parts may be purchased through SGH if your product is out of warranty. Note: If you feel
that the elements are definitely faulty right out of the box, contact the SGH Technical Support
department first (for troubleshooting and verification).They can then direct you on to the next step.
Once I plug the unit in and turn it on, how long will it take to heat my room?
The heating process in the heater begins immediately upon powering on, and setting the desired
temperature above the ambient temperature. A noticeable change in the l room’s ambient
temperature will vary. Remember that with any type of heating process, there are many variables:
Location of heater (in the home), floor plan and size of the room, how well the room is insulated, how

18
many doors/windows, how much bare concrete (acts as a heat sink with any type of heating), the
opening and closing of an exterior door, long hallways, high ceilings, etc. Customers with smaller
rooms experience quick heat changes. Rooms with larger and open floor plans can expect up to 24
hours to completely heat up.
I don’t have a grounded outlet; can I use adapters, a 2-prong power strip, or remove the ground
prong from the cord?
Definitely NOT! If you don’t have a grounded outlet, contact a certified electrician for advice.
Removing or altering any part of the heater’s original design or intent (including the power cord) will
not only void the warranty, but will make you liable for any unexpected or hazardous results.
Why doesn’t the temperature on my heater match the temperature display on my wall, or external
thermostat?
This is completely normal. The temperature display on your heater may vary from the temperature
display on another thermostat (like the one mounted to your wall or a purchased external thermostat).
This is because the temperature sensor on the heater reads the temperature directly around the
heater. With the heater near the cold floor (and heat rising), any readings on elevated or external
thermostats will differ in readings on the heater. The best way to operate your heater is just to set
the unit on “High” and dial up to a temperature that feels comfortable to you. Then, leave it at that
temperature, regardless of the mismatch. The heater will cycle off when the set temperature is met or
exceeded slightly.
My home is not insulated very well, will this heater help me? Can I use the heater if I have vaulted or
cathedral ceilings? I live in a structure that is larger than 1000 square feet. Will this heater help me? Can I
use the heater to heat multiple rooms at the same time? Will I be able to use the heater in a basement or
garage?
The answer to these is the same. Yes. You will be able to use it, but keep in mind that
rooms/structures with open floor plans, minimal insulation, adjacent rooms, or high ceilings will not
retain the heat as efficiently, and noticeable heat changes will come slowly. Also, the heater will stay
on for longer periods of time (since it takes so long to cycle off), and may increase your electric costs.
Note that if you do use it in a garage or basement, the moisture levels must be very low and the
heater must have a dedicated circuit (15 amps minimum) with no GFCI outlets being used. If unsure
what a GFCI outlet is, contact a certified electrician.
Can I use more than one heater at a time? Can I use the heater and another appliance at the same time?
Yes. But make sure they are not plugged into the same circuit. Each heater (heaters are considered
appliances, and draw out high amperage) requires its own minimum 15 amp circuit (with no other
items plugged into that circuit or outlet). If unsure your circuit meets these requirements, verify
with a certified electrician. Risk of fire, damage to property, or injury may result if requirements
are not met.
Why does my heater’s fan continue to run after the set temperature is reached or the power is turned
off?
This is normal. The heater’s fan will continue to run, even after the heater automatically cycles
down. The fan continues to run so that every last bit of heat is blown out of the heat chamber, while
allowing the unit to continue filtering your air. Once the internal box/components cool completely, the

18
fan should then shut off on its own. In this case, allow a few minutes after the heat cycles off (with
power on). The fan will shut off faster when the power is turned off.
Why doesn’t the fan speed increase when I change the setting from Low to High?
This is normal. The heater’s fan’s speed is not affected by the High/Low settings. The fan is
designed to vent the heat at one soft, comfortable, and energy efficient speed. What is affected by
the High setting is the heat output. In essence, in the High mode, the heater produces “more” heat,
rather than “faster” heat.
I want to make sure my warranty is registered. What do I send to make sure it is registered? Where
do I send it?
The heater comes with an automatic 1 year limited manufacturer’s warranty at the time of purchase.
Your receipt is considered your proof of purchase and registration. Keep it in a safe place. As long
as it is legible, a copy may be used for any future warranty claims (if requested). If you have access
to e-mail, and would like peace of mind, e-mail us to: [email protected] In the
body of the e-mail, include your full name, address, phone number, model, serial number, and
scanned copy of your legible receipt. You may also register in the “registration” tab at:
www.lifesmartproducts.com
My heater does not perform as well as another brand heater that I purchased. Why Not?
There are many brands of heaters on the market. Each brand is designed with different heat
specifications, designs, trademarks, fan speeds, colors, material types, displays, and electrical
components. They are manufactured this way for you, as the consumer to have choices, selection,
and preferences. As long as the unit functions as specifications indicate, comparison to other brands
will ultimately depend on individual consumer perception.
I purchased my heater so that it could cut my heating costs, but my electric bill has gone up. Why?
The compact SGH heater can definitely save you on heating costs, when compared to the existing
central heating system in your home, and when used as supplemental heat. Your heater is designed
to give your main heat source a supplement “boost,” or allow for you to have extra heat (in the form of
soft infrared waves) in locations where you would otherwise be short. It is meant to cycle on and off
as it provides the central heat the boost it needs. If you intend on using it as a single heat source,
especially in larger homes (which you may), expect the heater to 1) take as much as 24 hours to heat
the area, 2) stay on for longer periods of time (without cycling off) due to heat loss, and 3) increased
use time, and electric costs.
My heater’s display shows my ambient temperature to be in the 20’s, when I know it is warmer than that.
Why?
The heater’s display is defaulted to read the temperature as Fahrenheit. If your heater is definitely
heating, but shows it is in the 20’s, you probably have the setting to read your temperature in Celsius,
rather than Fahrenheit. See Users Guide to change.
My heater has a temperature setting indicating ECO. It is supposed to be efficient, but it seems to not heat as
much. Why?
The ECO mode on your heater is a program that attempts to keep the temperature strictly at a
“warm” 68° F. This also helps with efficiency, as it is programmed to 1) Increase the wattage used to
1500W if the temperature drops below 64.4°F 2) Gradually reduce the wattage used as it approaches
66.2° F and 3) Stop heating when 68° F is achieved. This is considered an Economical function,

18
since in the ECO setting, the heater is almost never running on the full 1500 Watts. If this “warm”
heat is not plentiful or is “On” constantly, and you fear it will increase your electric bills, we
recommend you set it to the High or Low setting and have it cycle off when your set temperature is
achieved. You may also set the timer to allow your heater to shut off at the given hour increments you
desire. See User’s Guide to set the timer.
SPECIFICATIONS
Voltage Rating 120 V (60Hz)
Power Consumption 1000W/1500W
Unit Size 7.5 in. (W) x 12.8 in. (D) x 12.4in. (H)
Unit Weight 12.34 lbs
SAFETY FEATURES
Tip-Over Safety Feature
This heater is equipped with a tip-over safety feature. Once the heater is tipped over, an internal switch will
automatically shut the heater off. Once the heater is restored an upright position, the heater will reset. To
continue operation, turn on the heater using the supplied remote control or the control panel on the heater.
Overheat Safety Feature
This heater is equipped with a overheat safety feature. When the heater’s internal components reach a
certain temperature that could cause overheating or possible fire, the heater will automatically shut off.
WARNING: It is normal for the power cord to feel warm to touch; however, a loose fit between the outlet
and the plug may cause overheating of the plug. If this occurs, try inserting the plug into a different outlet.
Contact a qualified electrician to inspect the original outlet for damage.

18
IN THE BOX
·INFRARED HEATER
·REMOTE CONTROL (2 AAA batteries not Included)
·INSTRUCTION BOOKLET
PRODUCT DIAGRAM
Transport Handles
Control Panel
Foot pad Remote Control
Air Outlet (Vent) FRONT
VIEW

18
Control Panel
1. Energy-saving mode (ECO) indicator: Will be lit when ECO mode is engaged
2. Low Mode indicator light: Will be lit when Low Heat mode is engaged
Air Intake (Vent)
Master
Power Switch
Filter Cover and Mesh
Temperature Sensor
REAR
VIEW
