Lifebreath 1500I-ECM User manual

Application
General........................................................................1
Engineering Data.......................................................2-4
Duct Configurations .....................................................5
Optional Ventilation Control
Optional 3 Speed Control .............................................6
Optional Dehumidistat .................................................7
Optional Timers ....................................................10-12
Connecting Optional Dehumidistat ................................9
Function and Controls .................................................13
Aircom Relays ............................................................14
Servicing.....................................................................15
Mounting the 1500......................................................16
Roof Curb Assembly Instructions ..................................17
Roof Curb Detail .........................................................18
Ducting -- General ......................................................19
Ducting -- Distribution
Electrical Connections
Balancing....................................................................20
The Integrated HVAC System ......................................21
Adjusting the Airflow
Defrost Time Adjustment ............................................22
Pitot Tube Air Flow Balancing ......................................23
Wiring Diagram...........................................................24
Warranty ...................................................................25
69-1500
INTERIOR MODEL
1500I-ECM
OUTDOOR MODELS
1500E-ECM (EXTERIOR ROOFTOP DESIGN)
1500E-ECM-E (EXTERIOR HORIZONTAL DUCTING DESIGN)
*LEAVE WITH EQUIPMENT
NOTE: Due to ongoing research and product development,
specifications, ratings and dimensions are subject to change without notice.
Before installation, careful consideration must be
given to how this system will operate if
connected to any other piece of mechanical
equipment, i.e. a forced air furnace or air handler,
operating at a higher static. After installation, the
compatibility of the two pieces of equipment must
be confirmed by measuring the airflows of the
Heat Recovery Ventilator (HRV) by using the
balancing procedure found in this manual.
It is always important to assess how the
operation of any HRV may interact with
vented combustion equipment (ie. Gas
Furnaces, Oil Furnaces, Wood Stoves, etc.).
NEVER install a ventilator in a situation where
its normal operation, lack of operation or partial
failure may result in the backdrafting or improper
functioning of vented combustion equipment!
Caution
Application
Table of Contents
Heat Recovery Ventilators (HRV) are designed to provide
fresh air while exhausting an equal amount of stale air.
The HRV is equipped with an aluminum core. The
device uses the stale air that is being exhausted to
condition the fresh air as it is being brought in.
These instructions are intended as a general guide and
do not supersede local codes in any way. Consult
authorities who have jurisdiction before installation.
General
Do not apply electrical power to the unit
until installation has been fully completed
(including low voltage control wiring).
012616
Connecting Optional Ventilation Control ........................8

SPECIFICATIONS
AIRFLOW
1500 cfm (705 L/s) at 1.0”wg ESP.
PERFORMANCE
65% effective at 1500 cfm (705 L/s).
CORES
Six patented aluminum heat recovery cores arranged for efficient
cross-flow ventilation.
MOTORS
Two single shaft ECM variable speed, 240V, 9.1 A, 1 ph, 1 hp.
(18.2 a total) MCA: 22.8 MOP: 30
BLOWERS
Two direct drive centrifugal blowers, one per airstream.
FILTERS
Two - 20” x 16” x 2” (508 mm x 406 mm x 50 mm) pleated filters in
each airstream. MERV 6 efficiency 60% @ 4.69 microns.
CONNECTION DUCT SIZES
Four 18” x 18” (457 mm x 457 mm)
CABINET
20 gauge powder coated steel 1” (25 mm) thick Elastomeric insulation.
DRAIN
Two powder coated galvanized steel drain pans with 1/2” (12 mm)
O.D. drain connections.
MOUNTING
Unit to be set on support brackets hung by threaded rod type
apparatus. Brackets and rod not included.
ELECTRONICS
Integrated microprocessor circuit board. Three (3) independently
adjustable motor speeds.
CONTROL OPTIONS
ABCDEF GHIJL
ECM inches 18 2.5 18 12 37 66.75 18 18 10.25 2.5 44
ECM mm 457 64 457 305 940 1695 457 457 260 64 1118
Service Clearance 30”
All units conform
to CSA and UL
standards.
2
Date: ___________________________________________
Tag: _____________________Qty:___________________
Project: _________________________________________
Engineer: _______________________________________
Contractor: ______________________________________
Supplier: ________________________________________
Quote#: _________________________________________
Submitted by: ____________________________________
DEFROST
Factory set defrost time. Supply motor is shut off while exhaust air
defrosts core.
WEIGHT 460 lbs (210 kg) SHIPPING WEIGHT 580 lbs (260 kg)
NOTE: All
specifications
are subject to
change without
notice.
DIMENSIONS 1500I-ECM (in inches)
Specifications 1500I-ECM
TIMER OPTIONS
99-DET01 Lifebreath 20/40/60 Minute Timer
•Initiates high speed Ventilation for 20, 40 or 60 minutes
•3 wire connection; 20 gauge wire (minimum)
99-DET02 Lifebreath WIRELESS 20/40/60 Minute Timer
•Initiates high speed Ventilation for 20, 40 or 60 minutes
•Wirelessly connects to main control for ease of installation
•40' approximate range
99-RX02 Lifebreath WIRELESS Repeater
•Used to extend range of 99-DET02 Wireless Timers when
Timers are out of range
•Plugs into 120V power outlet and wirelessly connects to main
control and 99-DET02
INLET END VIEW SIDE VIEW OUTLET END VIEW
WARRANTY
Units carry a 15 year warranty on the HRV core
and a 2 year replacement parts warranty.
99-BC02 Lifebreath Ventilation Control
•2 speed fan setting (Low/High)
•Humidity control through adjustable Dehumidistat
•Compatible with 99-DET02 Wireless Timers
•3 wire connection; 20 gauge wire (minimum)
99-500 3 Speed Control
•3 Speed Fan setting (Low/Medium/High)
•4 wire connection; 20 gauge wire (minimum)
99-DH01 Lifebreath Dehumidistat
•Humidity control through adjustable Dehumidistat
•3 wire connection; 20 gauge wire (minimum)
AIRFLOW PERFORMANCE
1800
1600
1400 HIGH SPEED
1200
1000 MED SPEED
800
600 LOW SPEED
400
200
AIRFLOW (CFM)
0 0.25
0.5 0.75 1.0 1.25 1.5
EXTERNAL STATIC PRESSURE (in. w.g.)
1.75 2.0

SPECIFICATIONS
AIRFLOW
1500 cfm (705 L/s) at 1.0”wg ESP.
PERFORMANCE
65% effective at 1500 cfm (705 L/s).
CORES
Six patented aluminum heat recovery cores arranged for efficient
cross-flow ventilation.
MOTORS
Two single shaft ECM variable speed, 240V, 9.1 A, 1 ph, 1 hp.
(18.2 a total) MCA: 22.8 MOP: 30
BLOWERS
Two direct drive centrifugal blowers, one per airstream.
FILTERS
Two - 20” x 16” x 2” (508 mm x 406 mm x 50 mm) pleated filters in
each airstream. MERV 6 efficiency 60% @ 4.69 microns.
CONNECTION DUCT SIZES
Two 19” x 16” (482 mm x 406 mm) to and from building under cabinet.
Two 18” x 17” (457 mm x 431 mm) hoods included on side of cabinet
with washable screens.
CABINET
20 gauge powder coated steel 1” (25 mm) thick Elastomeric insulation.
DRAIN
Two powder coated galvanized steel drain pans with 1/2” (12 mm)
O.D. drain connections.
MOUNTING
Unit to be set on support brackets hung by threaded rod type
apparatus. Brackets and rod not included.
ELECTRONICS
Integrated microprocessor circuit board. Three (3) independently
adjustable motor speeds.
CONTROL OPTIONS
3
Date: ___________________________________________
Tag: _____________________Qty:___________________
Project: _________________________________________
Engineer: _______________________________________
Contractor: ______________________________________
Supplier: ________________________________________
Quote#: _________________________________________
Submitted by: ____________________________________
DIMENSIONS 1500E-ECM (in inches)
Specifications 1500E-ECM
DEFROST
Factory set defrost time. Supply motor is shut off while exhaust air
defrosts core.
WEIGHT 530 lbs (240 kg) SHIPPING WEIGHT 650 lbs (290 kg)
TIMER OPTIONS
99-DET01 Lifebreath 20/40/60 Minute Timer
•Initiates high speed Ventilation for 20, 40 or 60 minutes
•3 wire connection; 20 gauge wire (minimum)
99-DET02 Lifebreath WIRELESS 20/40/60 Minute Timer
•Initiates high speed Ventilation for 20, 40 or 60 minutes
•Wirelessly connects to main control for ease of installation
•40' approximate range
99-RX02 Lifebreath WIRELESS Repeater
•Used to extend range of 99-DET02 Wireless Timers when
Timers are out of range
•Plugs into 120V power outlet and wirelessly connects to main
control and 99-DET02
J
M
STALE AIR
TO OUTSIDE
FRESH AIR
FROM OUTSIDE
STALE AIR
FROM BUILDING
FRESH AIR
TO BUILDING
STALE AIR
TO OUTSIDE
ABC DEF GH I J K L NM
EFD inches 20 1.5 17 16.5 41 69.5 20 17 14.5 1.5 20 44 46.5 67
EFD mm 508 38 432 419 1041 1765 508 432 368 39 508 1118 1181 1702
Service Clearance 30”
All units conform
to CSA and UL
standards.
NOTE: All
specifications
are subject to
change without
notice.
INLET END VIEW SIDE VIEW OUTLET END VIEW
WARRANTY
Units carry a 15 year warranty on the HRV core
and a 2 year replacement parts warranty.
99-BC02 Lifebreath Ventilation Control
•2 speed fan setting (Low/High)
•Humidity control through adjustable Dehumidistat
•Compatible with 99-DET02 Wireless Timers
•3 wire connection; 20 gauge wire (minimum)
99-500 3 Speed Control
•3 Speed Fan setting (Low/Medium/High)
•4 wire connection; 20 gauge wire (minimum)
99-DH01 Lifebreath Dehumidistat
•Humidity control through adjustable Dehumidistat
•3 wire connection; 20 gauge wire (minimum)
AIRFLOW PERFORMANCE
1800
1600
1400 HIGH SPEED
1200
1000 MED SPEED
800
600 LOW SPEED
400
200
AIRFLOW (CFM)
0 0.25
0.5 0.75 1.0 1.25 1.5
EXTERNAL STATIC PRESSURE (in. w.g.)
1.75 2.0

SPECIFICATIONS
AIRFLOW
1500 cfm (705 L/s) at 1.0”wg ESP.
PERFORMANCE
65% effective at 1500 cfm (705 L/s).
CORES
Six patented aluminum heat recovery cores arranged for efficient
cross-flow ventilation.
MOTORS
Two single shaft ECM variable speed, 240V, 9.1 A, 1 ph, 1 hp.
(18.2 a total) MCA: 22.8 MOP: 30
BLOWERS
Two direct drive centrifugal blowers, one per airstream.
FILTERS
Two - 20” x 16” x 2” (508 mm x 406 mm x 50 mm) pleated filters in
each airstream. MERV 6 efficiency 60% @ 4.69 microns.
CONNECTION DUCT SIZES
Two 18” x 18” (457 mm x 457 mm) to building on ends of cabinet.
Two 18” x 17” (457 mm x 431 mm) hoods included on side of cabinet
with washable screens.
CABINET
20 gauge powder coated steel 1” (25 mm) thick Elastomeric insulation.
DRAIN
Two powder coated galvanized steel drain pans with 1/2” (12 mm)
O.D. drain connections.
MOUNTING
Unit to be set on support brackets hung by threaded rod type
apparatus. Brackets and rod not included.
ELECTRONICS
Integrated microprocessor circuit board. Three (3) independently
adjustable motor speeds.
CONTROL OPTIONS
4
Date: ___________________________________________
Tag: _____________________Qty:___________________
Project: _________________________________________
Engineer: _______________________________________
Contractor: ______________________________________
Supplier: ________________________________________
Quote#: _________________________________________
Submitted by: ____________________________________
DIMENSIONS 1500E-ECM-E (in inches)
Specifications 1500E-ECM-E
DEFROST
Factory set defrost time. Supply motor is shut off while exhaust air
defrosts core.
WEIGHT 530 lbs (240 kg) SHIPPING WEIGHT 650 lbs (290 kg)
TIMER OPTIONS
99-DET01 Lifebreath 20/40/60 Minute Timer
•Initiates high speed Ventilation for 20, 40 or 60 minutes
•3 wire connection; 20 gauge wire (minimum)
99-DET02 Lifebreath WIRELESS 20/40/60 Minute Timer
•Initiates high speed Ventilation for 20, 40 or 60 minutes
•Wirelessly connects to main control for ease of installation
•40' approximate range
99-RX02 Lifebreath WIRELESS Repeater
•Used to extend range of 99-DET02 Wireless Timers when
Timers are out of range
•Plugs into 120V power outlet and wirelessly connects to main
control and 99-DET02
B
M
STALE AIR
TO OUTSIDE
FRESH AIR
FROM OUTSIDE
STALE AIR
TO OUTSIDE
G
G
K
AA
STALE AIR FROM
BUILDING
C
HH
G
K
FRESH AIR TO
BUILDING
GA
ABC DEF GH I K L NM
ECM inches 20 1.5 17 16.5 41 69.5 18 2.5 14.5 16 44 46.5 67
ECM mm 508 38 432 419 1041 1765 457 64 368 406 1118 1181 1702
Service Clearance 30”
All units
conform to
CSA and UL
standards.
NOTE:
All
specifications
are subject to
change without
notice.
INLET END VIEW SIDE VIEW OUTLET END VIEW
WARRANTY
Units carry a 15 year warranty on the HRV core
and a 2 year replacement parts warranty.
99-BC02 Lifebreath Ventilation Control
•2 speed fan setting (Low/High)
•Humidity control through adjustable Dehumidistat
•Compatible with 99-DET02 Wireless Timers
•3 wire connection; 20 gauge wire (minimum)
99-500 3 Speed Control
•3 Speed Fan setting (Low/Medium/High)
•4 wire connection; 20 gauge wire (minimum)
99-DH01 Lifebreath Dehumidistat
•Humidity control through adjustable Dehumidistat
•3 wire connection; 20 gauge wire (minimum)
AIRFLOW PERFORMANCE
1800
1600
1400 HIGH SPEED
1200
1000 MED SPEED
800
600 LOW SPEED
400
200
AIRFLOW (CFM)
0 0.25
0.5 0.75 1.0 1.25 1.5
EXTERNAL STATIC PRESSURE (in. w.g.)
1.75 2.0

Duct Configuration Model 1500I-ECM
FRESH AIR
FROM OUTSIDE
STALE AIR
FROM BUILDING
FRESH AIR
TO BUILDING
STALE AIR
TO OUTSIDE
Duct Configuration Model 1500E-ECM
FRESH AIR
FROM OUTSIDE
STALE AIR FROM
BUILDING
FRESH AIR TO BUILDING
STALE AIR TO OUTSIDE
Duct Configuration Model 1500E-ECM-E
FRESH AIR
FROM OUTSIDE
STALE AIR FROM
BUILDING
FRESH AIR TO BUILDING
STALE AIR TO OUTSIDE
5
The 1500E-ECM-E is designed for outdoor
installations. The duct connections for the Stale Air
From Building and Fresh Air to Building ducts are at
the ends of the unit.
The 1500E-ECM is designed for
outdoor rooftop installations. The duct
connections for the Stale Air From
Building and Fresh Air to Building
ducts are located at the bottom of the
unit. A roof curb is required for this
installation.
The 1500I-ECM is designed for indoor
installa-tions. The duct connections for the
Stale Air From Building and Fresh Air to
Building ducts are at the ends of the unit.

6
Optional Lifebreath Ventilation Control - Part #99-BC02
2 speed fan setting (LOW / HIGH)
Standby setting (fan OFF)
Electronic Dehumidistat
Compatible with 99-DET02 Wireless
Timers
Slim-line design
Connect to 3 wire 20 gauge low voltage
wire
Humidity
Setting
Fan Speed
Indicator
ON/OFF Light
Fan Speed
ON/OFF Button Button
Dehumidistat
Button
BC02 Operating Instructions:
Turning on the Control
Press and release the ON/OFF button . The light above will illuminate.
Setting the Ventilation Speed
Press and release the Fan button to select LOW or HIGH fan speed. The corresponding “Indicator Light" will illuminate. If
both LO and HI indicator lights are off, the fan is OFF but will turn ON if required by the Dehumidistat or remote Timer (if
installed).
Humidity Control
Your unit will reduce indoor humidity when outdoor humidity levels are lower than indoor humidity levels. This feature is only
effective when the outdoor temperature is below 59˚F (15˚C).
Setting the Dehumidistat
Press and release the Dehumidistat button until the Dehumidistat Light is at the desired setting. After a few seconds the
Dehumidistat light will either flash or be on continuous.
A flashing light indicates the humidity level is higher than the setting and the unit is operating on high speed ventilation. A
continuous light indicates the humidity level is lower than the setting. Refer to the unit's Home Owner’s manual for instructions
on how the Dehumidistat works.
The Dehumidistat will override the current speed setting to HIGH speed.
button until no Dehumidistat light is on.The Dehumidistat function can be turned OFF by pressing the
Note - Only 1 Dehumidistat should be installed in a system.
Key Features:
Optional Lifebreath 3 Speed Control - Part #99-500
HIGH
OFF
OFF
OFF
MED
LOW
•3 Speed Fan setting (LOW / MEDIUM / HIGH)
•4 wire; 20 gauge wire (minimum)
•Connect to Red, White, Yellow, Green.
ATTENTION
When used in conjunction with the 99-BC02, the
BC02 control must be ON for the 99-500 control
to operate. The 99-BC02 will override the
99-500 control when the Dehumidistat is
operating or the control is set to HIGH speed.
Key Features:

Key Features
•The Dehumidistat measures the indoor humidity level and
will initiate high speed ventilation when the moisture level
in the building exceeds the set point on the control.
•Once the humidity in the building is reduced, the HRV will
revert back to its previous setting.
•The Dehumidistat should be set to OFF for all season
except the heating season.
•Connect to 3 wire 20 gauge low voltage wire.
Humidity Control
Your HRV will produce a dehumidifying effect when outdoor
humidity levels are lower than indoor humidity levels. Never
use the Dehumidistat feature when outdoor temperatures are
above 59 F (15 C).
Note: The indoor humidity level is measured at the control.
Setting the Dehumidistat
Press and release the Dehumidistat button until the
Dehumidistat Light is at the desired setting. After 5 seconds the
Dehumidistat light will either flash or be on continuous.
A flashing light indicates the humidity level is higher than the
setting and the unit is operating on high speed ventilation. A
continuous light indicates the humidity level is lower than the
setting. Refer to the unit's Operation & Installation Manual for
instructions on how the Dehumidistat works.
Note - Only 1 Dehumidistat should be active on a system.
Optional Lifebreath Dehumidistat - Part #99-DH01
%
80
20
Instruction card
Dehumidistat
Indicator LEDs
Set to the desired
humidity level. High
speed ventilation will
initiate when the indoor
moisture level exceeds
the set point on the
control.
Dehumidistat
Adjust button
7

Connecting Optional Control - Part #99-BC02
The control may be installed onto a flush mounted 2" x 4" electrical
switch box or it may be surface mounted onto a wall.
Only 1 master control should be installed to a ventilation system
(the Face Plate on this illustration may not be exactly the
same as yours).
ATTENTION
Pay special attention not to damage the Contact
Pins when attaching and detaching the Face Plate.
(Figure B)
REDGRNYEL
DET
Digital Controls
Figure D
Terminal strip on
Aircom circuit
board
•Yellow to YEL
•Red to RED
•Green to GRN
•Use 3/20 wire
8
1. Separate the Face Plate from the Back
Plate by firmly pulling apart (Figure A).
Be careful not to damage Face
Plate Contact Pins.
2. For mounting the control without a
Decora plate, break off top and
bottom tabs and refer to Figure C for
mounting.
3. Place the Back Plate of the control in the
desired location on the wall and pencil
mark the top and bottom screw holes
(Figure B or C).
4. Remove the Back Plate and mark the
center hole for the wires in the middle of
the screw holes. Refer to Figure B or
C for placement.
5. Cut in a 3/4 in by 1 in oval hole in the
wall to allow for the wire opening and
drill (two) 1/8 in holes for the screws and
wall anchors (Figure B or C).
6. Pull 3 wire 20 gauge (min.) 100 ft length
(max.), through the opening in the wall.
7. Connect red, green, and yellow to the
Wiring Terminals located on the Back
Plate (Figure B or C).
8. Attach the Back Plate to the wall using
the 2 supplied screws and anchors.
9. Attach the Face Plate to the Back Plate
(Figure A). Note: Be careful to
correctly align the Face Plate to avoid
damaging the Face Plate Contact Pins.
10. Connect the 3 wire 20 gauge (min.) 100
ft length (max.) to the digital controls
terminal strip located on the Aircom
circuit board (Figure D).
Figure A
Keep top / bottom
vent openings clear
Figure B
1.625"
0.75"
1"
1.625"
1/8 in hole for
screw and
anchor
1 in x 3/4 in
for wire
opening
Wiring
Terminals
1/8 in hole
for screw and
anchor
oval hole
Break off tab
Figure C
Alternate Wall Mount
1/8 in hole for
screw and
anchor
1 in x 3/4 in 0.75"
oval hole
1/8 in
for wire
hole for
opening
screw and
anchor
Wiring
Terminals
Break off tab
1"
Wire hole
centered
between
screw
holes
Back Plate
Face Plate

9
P
F
Connecting Optional Control - Part #99-DH01
The Lifebreath Dehumidistat may be installed onto a
flush mounted 2" x 4" electrical switch box or it may be
surface mounted onto a wall.
Only 1 master control should be installed to a ventilation
system (the Face Plate on this illustration may not be
exactly the same as yours).
1. Remove the Operating Instructions Card from the
top of the Control (Figure A).
2. Separate the Face Plate from the Back Plate by
firmly pulling apart (Figure B). Be careful not to
damage Face Plate Contact Pins.
3. Place the Back Plate of the control in the desired
location on the wall and pencil mark the wall in
the center of the Wire Opening, Top Screw Hole
and Bottom Screw Hole (Figure C).
4. Remove the Back Plate and drill a 3/8" opening in
the wall to allow for the Wire Opening and a 1/8"
hole for the Wall Anchors for the top and bottom
screw holes (Figure D).
5. Pull 3/20 wire through the opening in the wall
and the Wire Opening of the Back Plate (Figure C).
6. Connect Red, Green and Yellow to the Wiring
Terminals located on the Back Plate (Figure C).
7. Secure a single wire to the Wire Retainer located
on the Back Plate (Figure C).
8. Attach the Back Plate to the wall using the 2
supplied screws and anchors.
9. Attach the Face Plate to the Back Plate (Figure
B). Note: Be careful to correctly align the Face
Plate to avoid damaging the Face Plate Contact
Pins.
10. Insert the Operating Instructions Card into the
control (Figure A).
11. Connect the 3 wire 20 gauge (min.) 100 ft length
(max.) to the digital controls terminal strip located
on the Aircom circuit board (Figure E).
%
80
20
HIGH
ATTENTION
Pay special attention not to damage the Contact
Pins when attaching and detaching the Face Plate.
(Figure B)
Figure A - Face Plate
Operating
Instructions Card
Back
Plate
Figure B
Face Plate
Contact
Pins
Face
Plate
Separate the
Face Plate from
the Back Plate.
Side View
Figure C
Front View of Back Plate
Wire
Opening
Wiring
Terminals
Wire
Retainer
TOP
Top Screw
Hole
Bottom
Screw Hole
Drill a 1/8” hole
for the Top Screw
and Anchor
Figure D
Drill holes in
wall
Drill a 3/8” hole
for the Wire
opening
Drill a 1/8” hole
for the Bottom
Screw and
Anchor
Wall Face
Dehumidistat Sensor
Openings to room
air allow accurate
sensor readings.
Figure F
Correct Installation
of Back Plate Back
Plate
Face Plate
Contact
Pins
Face
Plate
REDGRNYEL
DET
Digital Controls
Figure E
Terminal strip on
Aircom circuit
board
•Yellow to YEL
•Red to RED
•Green to GRN
•Use 3/20 wire

10
Optional Lifebreath Wireless Timer - Part #99-DET02
ATTENTION
The Wireless Timers and Repeaters must be
matched to the main wall control of the HRV.
This process is called "Pairing". Multiple
Timers and Repeaters can be paired to a single
wall control.
BC02
Control
Press Simultaneously to
Initiate Pairing Mode
Figure A
Figure B
1/8 in hole for
screw and
anchor
1/8 in hole
for screw and
anchor
Break off tab
Alternate Wall Mount
1/8 in hole for
screw and anchor
Figure C
Back Plate
Face Plate
1/8 in
hole for
screw and
anchor
Break off tab
Figure E
Figure D
DET02 Timer
20/40/60 Minute
Status Lights
Select Button
initiates high speed
ventilation for 20, 40
or 60 min.
Battery Indicator
Removable
Backplate
The timer will override the operational mode
(regardless of the settings) and initiate HIGH speed
Ventilation. Upon completion of the timer cycle, the HRV
will return to your selected operational mode and speed
setting.
Initiates HIGH speed ventilation for 20, 40 or 60 minutes. The
20/40/60 minute Status Lights indicate HIGH speed
operation.
The Wireless Timers are to be surface mounted onto a
wall. Multiple Wireless Timers may be installed in a ventilation
system. To increase the range of a Wireless Timer, a RX02
Repeater should be used.
Pairing:
To pair additional DET02 Timers with the same wall
control, or if pairing was not successful, repeat steps
1-6.
When paired, the DET02 Timers can be moved and
installed elsewhere. Estimated range of the Timer is 40’
with no obstructions. A RX02 Repeater may be installed to
increase the range of the Timers.
Test if pairing was successful by pressing the Select Button
and listen for the HRV to initiate HIGH fan speed
Ventilation.
Un-pairing:
1. Turn on the main wall control by pressing the ON/OFF
button and remove the battery from Timer.
2. Press the left and right buttons simultaneously on the
main wall control ( and ). The bottom row of 3
LED's will begin flashing. This indicates that the
main control is now in pairing mode. (Figure D)
3. Keep the Timer within 16” of the main wall control
when pairing.
4. Install the battery in the DET02 Timer. All four lights
on the Timer will immediately flash 5 times, then only
the red battery light will remain on for approximately
12 seconds after which the "40" light flashes the rev
code. 20, 40, 60 lights will flash until paired or will
stop if not paired within 12 seconds. If pairing was not
successful you now must return to step 1 to restart the
pairing process.
5. Press the button on the main wall control to exit
pairing mode when Timers have been successfully
paired.
1. Remove the battery from the back of the DET02 Timer
2. Press and hold the Select Button on the front of the
Timer
3. While holding the Select Button, reinsert the battery in
the Timer. Continue holding the Select Button until the
LED under "40" begins flashing. The DET02 Timer will
now be unpaired with the main wall control.
