Lifetime 0150 User manual

MODEL N° 0150
OWNER’S MANUAL
Keep this Product ID Number and use when contacting Customer Service:
Copy

2
Most injuries are caused by misuse and/or not following instructions. Use caution when using this product.
To ensure safety, do not attempt to assemble this product without following the instructions carefully. Check entire box and inside all
packing material for parts and/or additional instruction material. Before beginning assembly, read the instructions and identify parts
using the hardware identifier and parts list in this document. Proper and complete assembly, use and supervision are essential to
reduce the risk of accident or injury.
FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN SERIOUS INJURY OR PROPERTY
DAMAGE AND WILL VOID WARRANTY.
• Do not use or store hot objects such as grills, blowtorches, welding equipment, etc. near the product.
• If using a ladder during assembly, use extreme caution.
• Two capable adults are required for assembly. (It is also recommended that a third adult function as an instruction reader.)
SAFETY INSTRUCTIONS
REGISTER YOUR PRODUCT ONLINE AT WWW.LIFETIME.COM
LIFETIME’S PROMISE TO YOU:
We invite you to read our privacy policy at www.lifetime.com
REGISTER today!
At Lifetime, we are committed to providing innovative and quality products. While registering, you will have the opportunity to give us your feedback. Your input
is valuable to us.
• You can also opt in to receive new product notifi cations or promotions.
• In the unlikely event of a product recall or safety modifi cation, your registration provides the information we need to notify you
directly.
• Registration is fast, easy, and completely voluntary.
Maintaining your privacy is our long-standing policy at Lifetime. And you can rest assured that Lifetime will not sell or provide your
personal data to other third parties, or allow them to use your personal data for their own purposes.
**For customers outside the U.S. or Canada, please contact the store for assistance.**
**U.S. and Canada customers ONLY**
IF ASSISTANCE IS NEEDED,
DO NOT CONTACT THE STORE!
CALL OUR CUSTOMER SERVICE DEPARTMENT at 1 [phone]
HOURS: 7:00 a.m. to 5:00 p.m. Monday through Friday (Mountain Standard Time)
**Call, or visit our Web site for Saturday hours**
2/10/2012INSTRUCTION #1051091 D
Copy

3
(1) (1 for each person)
TOOLS REQUIRED FOR ASSEMBLY
*Two adults required to complete assembly*
TOOLS REQUIRED FOR THIS ASSEMBLY
Only adults should set up the product. Do not allow children
in the setup area until assembly is complete.
BEFORE BEGINNING ASSEMBLY
Keep the hardware bags and their contents separate. If any parts are missing, call our
Customer Service Department.
Identify and inventory all parts and hardware using the parts and hardware lists and
identifiers in this document.

Safety GlassesPhillips Screwdriver

4
This area is located at the top, left-hand
corner of the page and indicates which tools
and hardware are needed to complete the
assembly steps on a page.
This area is located at the top, right-hand
corner of the page and shows an image of the
product with shaded parts indicating which
section is being assembled.
SEC
#
Note:
!
Refer to the following areas throughout the instructions
to assist in the assembly process:
This area is usually located in the bottom,
left-hand corner of a step and indicates that
special attention is needed to perform a
particular part of a step.
These areas are usually located in the bottom,
right-hand corner of a step and indicate that
damage to the product or serious injury may
occur if the caution or warning is not heeded.
Throughout the Parts & Hardware List, Part
& Hardware Identifiers, and instructions
are three-letter IDs. These IDs are below
the images of the parts and hardware to
help you locate and identify the parts and
hardware during assembly. These IDs are not
necessarily on the parts themselves.
WARNING
ASSEMBLY GUIDES
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
CAUTION
ADZ (x10)
1/4” x 5/8” Pan-Head Screw

5
ID Description Quantity
Main Parts
AFV 90” Long Shelf 1
BHH 90” Shelf Hardware
AIY Shelf Support Bracket 2
ADZ 1/4” x 5/8” Phillips Pan-Head Screw (Only six are used) 14
90” SHELF HARDWARE [BHH]
Hardware shown at actual size (Unless indicated otherwise*)
Part shown at 8% actual size
ADZ (x14)
1/4” x 5/8” Phillips Pan-Head Screw
(Only six are used)
AFV (x1)
90” Long Shelf
HARDWARE & PARTS LIST
HARDWARE IDENTIFIER
PLASTIC PARTS IDENTIFIER
AIY (x2)*
Shelf Support Bracket
Note: Throughout the Parts & Hardware List, Part & Hardware Identifiers, and instructions are three-
letter IDs. These IDs are below the images of the parts and hardware to help you locate and identify
the parts and hardware during assembly. These IDs are not necessarily on the parts themselves.
!

6
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
SEC
SEC
Fold up flaps on the end of 90” Shelf (AFV). Set Shelf on Brackets with indentations toward wall, and secure with
six (6) 1/4” x 5/8” Phillips Pan-Head Screws (ADZ).
Upward view
ADZ (x6)
Note: There are only holes for screws along front side of the Shelf (front is labeled “Front” on underside of Shelf).
!
SEC
Set a Shelf Support Bracket (AIY) into the slots of each of the Shelf Support Channels. The slots must be at the
same height.
90” SHELF INSTALLATION
Note: Insert Shelf Support Bracket at an angle.
!
AIY
AIY
AFV
ADZ
ADZ ADZ
WARNING
The weight limit for a 90” Shelf is 30 lb. per 30”
section of Wall Panel. Failure to heed this warning
could result in property damage and/or personal
injury.
1.2
1.1
1

7
