Lightife MAIYUN HX-YL001 User manual

USER’S MANUAL
Manufacturer: !ANHUI GRIZZLY VISION TECHNOLOGY CO.,LTD "
Address: High-Tech Industrial Park, GaoXin District, HuaiNan City, Anhui Province, CHINA. "
Medical device registration certificate No.: 皖械注准20202070080 "
Medical device production license No.: 皖⻝药监械⽣产许20200030号
Thank&you&for&purchasing&HX-YL001.&&
In&order&to&use&this&product&safely&and&correctly,&please&read&this&
instruc?on&manual&before&use.&
Please&keep&it&in&a&safe&place&aCer&reading&for&easy&reference&and&
reference.&&
A&warranty&card&is&aFached&to&this&manual.&Please&keep&it&in&a&safe&
place.&
MAIYUN'
HX-YL001'

Content
Features!3"
Product Usage!3"
Specification!3"
Instructions!3"
Caution!3"
Batteries!3"
Usage!3"
Preset parameters!4"
Setting Operation Instruction!4"
Units Settings- F1!4"
Alerts Settings- F2!4"
Thermometer: Body or Surface -F3!4"
Parameters Tuning Settings- F4!4"
Alert mode On/OffSettings - F5!5"
Exit Settings!5"
Storage Review!5"
Changing Batteries!5"
Maintenance!5"
Storage!6"
Q & A!6"
Basic Knowledge!6"
Body Temperature!6"
Anal temperature!6"
Oral Temperature!6"
Auxiliaries temperature!6"
Cochlear temperature!7"
Forehead temperature!7"
Different measurements!7"
Temperature changes!7"
Female basal temperature!7"
How to confirm pregnancy through body temperature differences!7"
Parts list!7
Manufacturer: !ANHUI GRIZZLY VISION TECHNOLOGY CO.,LTD "
Address: High-Tech Industrial Park, GaoXin District, HuaiNan City, Anhui Province, CHINA. "
Medical device registration certificate No.: 皖械注准20202070080 "
Medical device production license No.: 皖⻝药监械⽣产许20200030号

Features
Accuracy! ! Plus or minus < ±0.3degrees."
Precision! ! 32°C-36°C = +/-0.3°C, 36°C~39°C = +/-0.2°C, 39°C~42.9°C = +/-0.3°C"
Detection time! ! Less than 1 second."
User friendly! ! One touch access, one touch switch to capture Body / Surface / Room temperature."
Non-Contact! ! Forehead heat-capturing, no skin contact."
Durability! ! 20k measurements with 2pcs of AAA batteries; with 100k measurements product lifecycle."
Optimal measure range!Within 5-15cm."
Large Display! ! Large-size LCD display with white backlight, easy to read."
Over-Heat Alerts! ! Adjustable alarms."
Data Memory! ! Storage up to 32 records."
Adjustable Parameters!Preset parameters can be adjust to fine-tune measurements on different faces. "
!!!(ie. Yellow, White, Black)"
Unit Switching! ! Adjustable display units of °C or °F"
Product Usage
Human Body Temperature: !To read human body temperature accurately, replacing the"
!!!!traditional mercury reading system."
Bio-Surface Temperature: !! To read bio-surface temperature accurately, i.e:measuring human skin surface "
!!!!temperature before a surgery."
Object Temperature:! ! To capture temperature of an object."
Liquid Temperature:! ! To read liquid temperature; i.e: hot water, or meals for babies."
Room Temperature:! ! To capture room temperature accurately. One press instant measurement."
Specification
Instructions
Caution
•Strictly follow instructions for product maintenance."
•This product is suitable for both professional and home use."
•Product operating window must be within 10-40°C."
•Keep the product clean and dry; do not store in area that humidity is above 85%."
•Do not place the product near electricity."
•Do not place the product with extreme environment: Above 50°C or below -20°C."
•Keep special care of the mirror-reflection area of the product.."
•Do not touch the lens."
•Do not put the product in water or put it under direct sun light."
•Do not purposely drop the product."
•Do not try to fix the product when a problem occurs; contact your local authorized dealer for repair."
Batteries
•Uses 2 pcs of AA battery, make sure the batteries are installed correctly."
Usage
•Correct usage is the key for accurate measurements, please operate under the following Instructions:"
Object: 0°C~118°C
Room: 0°C-49°C
Precision: 32°C-36°C = +/-0.3°C
36°C-39°C = +/-0.2°C
39°C-42.9°C = +/-0.3°C
Power Consumption: <50mW
Measuring Distance: 5cm-15cm
Auto Power-Off: 5 seconds
Product Package Includes: User Manual
AAA Batteries 2Pcs (Battery not included while shiiping outside China)
Optimal Operating Condition: Environment: 10°C~40°C, Humidity: 85%.
Power: DC3V (2pcs AAA batteries)
Dimensions: 220(L) X 155(W) X 55(H)mm
Weight: 90g
Measure Range: Human Body: 36.2°C-42.9°C

•Human body measuring: point the product to human forehead within a range of 5-15cm and press the button.
Make sure the measuring area has not been covered by human hair or sweat."
•When the product has been carried to another environment; stay put for at least 5 minutes before
measurement begins. Extreme room temperature differences may affect capture results."
•The product should be used in stable room temperature, avoid to make measurements close to fans or air-con
ducts."
•Capture five readings for each measurement, take-up the result that appears the most as result."
Preset parameters
•Preset parameters can be adjusted to fine-tune measurements on different races. However, do not change
manufacture settings if not necessary."
Setting Operation Instruction
To change settings, follow the steps below:"
Units Settings- F1
Alerts Settings- F2
Thermometer: Body or Surface -F3
Parameters Tuning Settings- F4
Press-Hold the SETTING key for 2 seconds until display F1. "
Select v for °C and ^ for °F. Press key to confirm. (manufacture default is °C)
Press-Hold the SETTING key for 2 seconds until display F1, press SETTING again to enter F2 mode."
Select ^ to increase 0.1°C, v to decrease 0.1°C."
Press SETTING to confirm. (Manufacture default at38.0°C)
Press-Hold the SETTING key for 2 seconds until display F1.Press SETTING key twice to enter F3."
Press v to select 0 to enter "Body" mode."
Press ^ to select 1 to enter "Surface" mode."
Press SETTING to confirm. (manufacture default at Body mode)"
Important: Only use "Body" mode to capture human body temperature; surface mode should only be used to capture
object temperature.
Parameters can be tuned to suit different skin types"
(DO NOT RECOMMEND TO CHANGE THIS SETTING) "
Press-Hold the SETTING key for 2 seconds until display F1, press SETTING Key 3 times to enter F4.
Select ^ to increase 0.1°C, press v to decrease 0.1°C. (Manufacture default at +0.8°C)"
Press SETTING to confirm.

Alert mode On/OffSettings - F5
Exit Settings
Under F5 mode, Press-hold SETTING key until display turned off; Exit settings."
Storage Review
The product will automatically store up measuring results up to 32 records; Do the followings for review:"
Press-hold ^ and v key for 2 seconds to display last record; press M to view previous record and onwards. Stay put for
5 seconds will exit history viewing mode automatically."
"
Changing Batteries
The Product uses 2pcs of AAA batteries, and may use for100 thousand measurements in
theory. When a battery symbol has been displayed and flashing; that means low battery.
Replace new batteries as soon as possible."
When replacing the batteries, make sure the new batteries are installed correctly! positive to "+"
and negative to "-". The product will not be working with a wrong battery installation, however,
it will not harm the product."
Use disposable alkaline batteries for each replacement, and DO NOT USE RECHARGEABLE
BATTERIES.
The product contains a very low power consumption during idle, take out the batteries only if
idle period is more than 6 months."
Maintenance
•External Cleaning: use a piece of clean cloth or medical alcohol to clean up dirt and stains Surrounding the casing."
•Internal Cleaning: the internal "mirror" is an important component of the product! DO NOT TOUCH it or else it will
affect measuring accuracy. In case of Cleaning, use 95% Alcohol with a piece of clean cloth only. DO NOT USE ANY
OTHER KINDS OF CHEMICAL."
Press-Hold the SETTING key for 2 seconds until display F1, press SETTING key 4 times to enter F5."
Press ^ to turn on Alert Alarm (Alert symbol will be displayed on screen), Press to turn offAlert"
Alarm.(Alert symbol will be disappeared). Press SETTING to confirm. (manufacture default at Alert
turned on)

Storage
Keep in a cool and dry place, without exposure of direct sunlight."
Q & A
1. Display temperature is greater than 95."
•Display units shall be °F, try to switch back to °C."
•Please follow the steps of F1 in the user menu."
2. Display temperature is lower than 32°C"
•Capturing mode shall be in "Surface" mode, try to switch back to “Body" mode. Please follow the steps of F3
in the user menu."
3. When "HI" message has been displayed"
•Under "Body" mode, when a reading is above 42.9°C, a “HI" message will be displayed. Make sure the there
is no external heat that surround the product or object during measurement. If the message continue occurs,
please contact local dealer for Service."
4. When "LO" message has been displayed"
•Under "Body" mode, when a reading is below 32°C, a "LO" message will be Displayed. Make sure the
measurement is not taken under a fan or air-condition; If the message continue occurs, please contact local
dealer for Service."
Major reason of "Lo" :
Basic Knowledge
Human being is a highly sophisticated species; Human body temperature is one kind of reflection that whether whom is
normal or not. The followings are some basic knowledge:"
Body Temperature
Anal temperature
Oral Temperature
Auxiliaries temperature
Reason
Suggestion
Covered by Human hair or sweat
Clean up or test another spot
Under a fan or Air-condition
Avoid the wind duct
Forehead has been cool-off
Wait for 10 minutes before another test
Out of measure range
Measure within 5-15cm
Explanation:!
the pulmonary artery, internal organ, or the true temperature of oesophageal.
Measurement:
specific products with a temperature detector deep into the lung artery, or oesophagus.
Advantage:
precise, invariable, truly reflects the body inner organ temperature.
Disadvantage:
immersion measurement requires special thermometer"
and expertise.
Explanation:!
anorectic temperature.
Measurement:
insert the anus rectum with thermometer.
Advantage:
Rectal temperature is relatively stable, closing to the internal temperature.
Disadvantage:
unacceptable because easy to cross-infect.
Explanation:!
Human oral sublingual temperature
Measurement:
measuring under the oral cavity/tongue and close your mouth.
Advantage:
oral cavity temperature is relatively stable, closing to the internal temperature.
Disadvantage:
unacceptable because easy to cross-infect.
Explanation:!
Auxiliaries temperature
Measurement:
measuring under Auxiliaries.
Advantage:
easy to measure, non cross infected; should be the most common for clinical
application.
Disadvantage:
lower than the actual temperature, not precise enough as results may be different each
time.

Cochlear temperature
Forehead temperature
Different measurements
Different typed of measurements lead to different temperatures range."
See the following differences as a guideline:"
!Anal temperature: !34.7°C-37.3°C"
!Oral Temperature: !35.8°C~37.8°C"
!Auxiliaries temperature: !36.6°C-38°C"
!Cochlear temperature: !35.8°C~38°C"
!Forehead temperature:!35.5°C-37.5°C"
Temperature changes
Human beings are homeothermic; their temperature is stable, but not immutable! Temperature may change constantly
in a day as follows:"
!Evening: !lowest; activities reduce (lower than 37°C)"
!Morning: !higher; muscle contracts, which generates heat. "
!Noon:! ! highest; naturally regulates, lazy and sleepy. "
!3-4 PM: !! lower; physical exertion and blood sugar is low."
!Nightfall: !lowest; as room temperature goes down after sunset."
Female basal temperature
Female basal temperature is different than men, generally men's is 0.3°C higher, plus a further 0.3°C-0.5°C higher
during adulatory period."
How to confirm pregnancy through body temperature
differences
Basic temperature will increase with ovulation, in the first half of the menstrual cycle, temperature should be under
36.6°C. At the latter half of the menstrual cycle, temperature should be higher than the first half. The range shall be
between 36.6°C and 37°C, body temperature increased indicates that the particular tested female shall be pregnant!
The higher body temperature should last for 2 weeks and then reduced. In case of pregnancy, body temperature won't
reduce and remains high. Temperature will continuously be high during the period of pregnancy. However, pregnancy or
fever will also affect the body temperature curve, so it is not 100% accurate. Please consult a doctor to verify."
Parts list
Explanation:!
tympanic membrane temperature
Measurement:
infrared thermometer for cochlea.
Advantage:
tympanic membrane temperature is relatively stable, close to internal
temperature.
Disadvantage:
infrared measurement is easy to be affected by different sizes and earwax
(commonly known as cerumen), and cause deviation.
Explanation:!
forehead temperature.
Measurement:
capturing with MW-151 infrared thermometer.
Advantage:
non-contact, rapid, and precise.
Disadvantage:
high demand environment requirement, such as air-condition outlet or not close
to other heat energy source. Also, human hair or sweat may also affect reading
precision.
Manufacturer: !ANHUI GRIZZLY VISION TECHNOLOGY CO.,LTD "
Address: High-Tech Industrial Park, GaoXin District, HuaiNan City, Anhui Province, CHINA. "
Medical device registration certificate No.: 皖械注准20202070080 "
Medical device production license No.: 皖⻝药监械⽣产许20200030号
•User Manual%
