Lightmybricks LEGO Ship In A Bottle 21313 Lighting Kit User manual

The following page is the instructions for the Light My Bricks LEGO Ship In A
Bottle (21313) LED light kit.
If you run into any issues, please refer to the online troubleshooting guide.
To ensure a trouble-free installation of your light kit, please read and follow
each step carefully. These instructions can be downloaded in PDF format here
Please note: This page lists instructions for the LED light kit only. If you are
wishing to purchase the Light My Bricks LEGO Ship In A Bottle (21313) LED light
Light My Bricks: LEGO Ship In A Bottle 21313
Lighting Kit

kit , please click here to view the product page
Package Contents:
4x White 30cm Bit Lights
6x Blue 30cm Bit Lights
1x Multi Effects Board
1x 6-Port Expansion Board
1x 8-Port Expansion Board
2x 5cm Connecting Cables
1x AA Battery Pack
6x Adhesive Squares
Important things to note:
Laying cables in between and underneath bricks
Cables can fit in between and underneath LEGO® bricks, plates, and tiles
providing they are laid correctly between the LEGO® studs. Do NOT forcefully
join LEGO® together around cables; instead ensure they are laying comfortably
in between each stud.

CAUTION: Forcing LEGO® to connect over a cable can result in damaging the
cable and light.
Connecting cable connectors to Expansion Boards
Take extra care when inserting connectors to ports of Expansion Boards.
Connectors can be inserted only one way. With the expansion board facing up,
look for the soldered “=” symbol on the left side of the port. The connector side
with the wires exposed should be facing toward the soldered “=” symbol as you
insert into the port. If a plug won’t fit easily into a port connector, do not force it.
Incorrectly inserting the connector can can result in bent pins inside the port
or possible overheating of the expansion board when connected.

Connecting cable connectors to Strip Lights
Take extra care when inserting connectors to ports on the Strip Lights.
Connectors can be inserted only one way. With the Strip Light facing up, ensure
the side of the connector with the wires exposed is facing down. If a plug won’t
fit easily into a port connector, don’t force it. Doing so will damage the plug and
the connector.
Installing Bit Lights under LEGO® bricks
and plates.
When installing Bit Lights under LEGO® pieces, ensure they are placed the
correct way up (Yellow LED component exposed). You can either place them
directly on top of LEGO® studs or in between.

OK, Let’s Begin!
1.) First remove the bottle from the stand and disconnect the bottle top as well
as top window sections to allow us to remove the ship.

2.) Remove the three masts from the ship, then disconnect the following
sections around the front:

3.) Take a White 30cm Bit Light and thread the connector end of the cable
through the gap of the brown clip on the back of the ship. Thread it all the way
through until the Bit Light is up against the edge of the gap. Ensure the LED is
facing up, then lay the cable down the side of the ship as shown below. Secure
it in place by reconnecting the back section over the top. The Bit Light should
be seen slightly peaking out from below the brown clip.

4.) Take another White 30cm Bit Light and slightly bend the wire down about
1cm from the top of the Bit Light as shown below. Hook the bit light over the
following stud, then secure it in place by reconnecting the brown grill tile over
the top.

Lay the cable down in between studs, then reconnect the side brown wall tile.
Repeat this process to install another White 30cm Bit Light to the left, securing
it in place by reconnecting the brown tile over the top.

5.) Before reconnecting the brown wall tile, slide in the 1×6 plate as shown
below. You may need to slightly lift up the two bit lights to reconnect the plate
back in place. Reconnect the brown wall tile by sliding it in and connecting it
underneath, then reconnect the last remaining section to the back of the ship.

Reconnect the three masts then group the three cables together and
twist/wind them around each other a few times at the top to lock them in
place.
6.) Take the AA Battery Pack and insert 3x AA Batteries to it. Connect the
battery pack cable to the first port on the 6-Port Expansion Board. Connect the
three cables from the ship to the spare ports on the expansion board, then turn
ON the battery pack to test the lights connected are working OK.

Note: If you experience any issues with the lights not working and suspect an
issue with a component, please try a different port on the expansion board to
verify where the fault lies (with the light or expansion board). To correct any
issues with expansion board ports, please view the section addressing
expansion board issues on our online troubleshooting guide.
Disconnect the three bit lights and battery pack from the expansion board,
then continue to twist/wind the cables around each other all the way to the end
so they all come together to form one larger cable.

7.) Take two trans light blue round plates from inside the bottle then take out a
Blue 30cm Bit Light and place it directly over one of studs. Secure the Bit Light
in place by reconnecting the other trans light blue round plate over the top as
shown below:
Repeat this step to install another 5x Blue 30cm Bit Lights using more of the

trans light blue round plates from inside the bottle to secure them in place.
Take the 8-Port Expansion Board and connect the AA Battery Pack to it, then
connect all six Blue Bit Light cables. Turn ON the battery pack to test all the
blue lights are working OK.

Note: If you experience any issues with the lights not working and suspect an
issue with a component, please try a different port on the expansion board to
verify where the fault lies (with the light or expansion board). To correct any
issues with expansion board ports, please view the section addressing
expansion board issues on our online troubleshooting guide.
8.) Tip all the trans light blue round plates out of the bottle then take an
Adhesive Square and stick it to the side of the trans light blue plates where we
have installed one of the Blue Bit Lights to. We will be installing 6 blue lights
around the base of the bottle.

Mount the LEGO plates with Bit Light to the base of the bottle as shown below,
then thread the connector end of the cable through the lower gap of the bottle.
Pull the cable all the way out from behind.
We will now install the remaining five Blue Bit Lights around the base of the
bottle. Using the same method as above, mount the other five trans light blue
round plates with Bit Lights to the base of the bottle using extra Adhesive
Squares. Continue to thread the other end of the cables through the same gap

we did for the first Blue Bit Light.

9.) Turn the bottle around to the back, then ensure all cables inside the bottle
are laid away from the brown plates except for the two cables shown below. Lay
these two cables in between the brown plates.

Twist/wind the six cables around each other all the way to the ends so they
come together to form one larger cable, then starting with the shorter two
cables, connect all six cables to the 8-Port Expansion Board.

Group all the cables closest the expansion board and twist/wind them around
the larger cable so they group together.
10.) Pour back in, all of the trans light blue round plates into the bottle. Spread
the pieces out evenly to try and cover the cables inside, then turn the bottle
back around to the front.
