LEGO® STAR WARS AT-AT
#75288 LIGHT KIT
INSTALLATION GUIDE

LEGO STAR WARS AT-AT 75288 LIGHT KIT INSTALL GUIDE
INSTALLATION GUIDE 2
Light My Bricks
LEGO® STAR WARS AT-AT #75288
LIGHT KIT INSTALLATION GUIDE
Hi There!
We’re here to help you get started on the LEGO®
Star Wars AT-AT (75288) Light Kit.
This PDF details the instructions for the LED light kit only. If
you are wishing to purchase this product, please click here
to view the product page.
If you run into any issues, please refer to the troubleshoot-
ing section towards the end of this guide.
Have fun and enjoy!

LEGO STAR WARS AT-AT 75288 LIGHT KIT INSTALL GUIDE
v
PACKAGE CONTENTS 3
PACKAGE CONTENTS: LEGO PIECES:
1 x Light My Bricks Lightsaber - Blue
1 x Rotating Bit Light 30cm
1 x White Strip Light
2 x Red 15cm Micro Bit Light
4 x Red 30cm Bit Light
1 x 2-Port Expansion Board
1 x 6-Port Expansion Board
1 x 4-Port Micro Expansion Board
• 1 x Round Brick 1x1 - Trans Red
• 1 x Round Plate 1x1 - Trans Red
• 4 x Plate 1x2 - Trans Red
• 4 x Round Plate 1x1 Open Stud - Light Grey
• 1 x Plate 1x6 - Black
1 x Gun Eects Board (G3FX V2)
3 x 30cm Connecting Cable
1 x 5cm Connecting Cable
1 x USB Power Cable
(Power Source not Included)

LEGO STAR WARS AT-AT 75288 LIGHT KIT INSTALL GUIDE
CONTENTS 4
Contents
Before You Begin
Blueprint
Instructions
Final Product
Troubleshooting
Contact
5
8
9
24
25
30

LEGO STAR WARS AT-AT 75288 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 5
Before You Begin
Laying cables in between
and underneath bricks
Cables can fit in between and underneath
LEGO® bricks, plates, and tiles providing
they are laid correctly between the
LEGO® studs. Do NOT forcefully join
LEGO® together around cables; instead
ensure they are laying comfortably in
between each stud.
CAUTION: Forcing LEGO® to connect over
a cable can result in damaging the cable
and light.
Connecting Cable
Connectors To Expansion
Boards
Take extra care when inserting connectors
to ports of Expansion Boards. Connectors
can be inserted only one way. With the
expansion board facing up, look for the
soldered “=” symbol on the left side of the
port. The connector side with the wires
exposed should be facing toward the
soldered “=” symbol as you insert into the
port. If a plug won’t fit easily into a port
connector, do not force it.
Incorrectly inserting the connector can re-
sult in bent pins inside the port or possible
overheating of the expansion board when
connected.

LEGO STAR WARS AT-AT 75288 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 6
Before You Begin
Connecting Cable
Connectors To Strip Lights
Take extra care when inserting connectors
to ports on the Strip Lights. Connectors
can be inserted only one way. With the
Strip Light facing up, ensure the side of
the connector with the wires exposed is
facing down. If a plug won’t fit easily into
a port connector, don’t force it. Doing so
will damage the plug and the connector.
Connecting Micro Cable
Connectors To Micro
Expansion Board Ports
Take extra care when inserting the
micro connectors to micro ports of Micro
Expansion Boards. Connecting Micro Bit
Lights to Micro Expansion Boards is similar
to connecting lights and cables to Strip
Lights. With the expansion board facing
up, ensure the side of the connector with
the wires exposed is facing down. If a plug
won’t fit easily into a port connector, do
not force it. Use your fingernail to push the
plastic part of the connector to the micro
port.

LEGO STAR WARS AT-AT 75288 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 7
Before You Begin
Installing Bit Lights Under
Lego® Bricks And Plates
When installing Bit Lights under LEGO®
pieces, ensure they are placed the correct
way up (Yellow LED component exposed).
You can either place them directly on top of
LEGO® studs or in between.

LEGO STAR WARS AT-AT 75288 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 8
BLUEPRINT

LEGO STAR WARS AT-AT 75288 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 9
INSTRUCTIONS
To ensure a smooth installation of
your light kit, please read and follow
each step carefully. If you run into
any issues, please refer to the online
troubleshooting guide.

LEGO STAR WARS AT-AT 75288 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 10
1
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON

LEGO STAR WARS AT-AT 75288 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 11
2
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
3
LMB Lightsaber - Blue

LEGO STAR WARS AT-AT 75288 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 12
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
6-Port Expansion Board
Rotating Bit Light 30cm Round Brick 1x1 - Trans Red
Round Plate 1x1 - Trans Red
Thread the
lightsaber cable
between the gun
barrels, then wrap it
around the rope
Bend the
Rotating Bit Light
cable so it fits inside
the Round Brick
4

LEGO STAR WARS AT-AT 75288 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 13
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
30cm Connecting Cable
5

LEGO STAR WARS AT-AT 75288 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 14
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
2-Port Expansion Board
USB Power Cable
Ensure the
2-Port Expansion
Board sits in the
space at the bottom
of the leg piece
Partially remove
the black round
plate enough for
the cable to fit
underneath
6

LEGO STAR WARS AT-AT 75288 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 15
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
White Strip Light Plate 1x6 - Black
30cm Connecting Cable
Connect to a
USB Power Bank, AA
Battery Pack, or USB
Wall Adapter (each
sold seperately)
7

LEGO STAR WARS AT-AT 75288 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 16
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
9
Put the wire
behind the column
LEGO piece, and
on the inside of the
red clip
8
30cm Connecting Cable

LEGO STAR WARS AT-AT 75288 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 17
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
10
Thread the
Connecting Cable
through the rings on
the neck
Thread the 30cm
Connecting Cable
from step 9 through
to the neck
Please thread
the cable under the
door hinge

LEGO STAR WARS AT-AT 75288 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 18
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
11
4 x Plate 1x2 - Trans Red
Red 15cm Micro Bit Light
Place the Micro
Bit Lights face down
in the corner of the
inner Trans Red Plates
4-Port Micro Expansion Board

LEGO STAR WARS AT-AT 75288 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 19
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
12 Red 30cm Bit Light
Round Plate 1x1 Open Stud
- Light Grey
Red 15cm Micro Bit Light

LEGO STAR WARS AT-AT 75288 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 20
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
13 Red 30cm Bit Light Gun Eects Board
Red 30cm Bit Light
14
Round Plate 1x1 Open Stud
- Light Grey
Round Plate 1x1 Open Stud
- Light Grey
x2
Connect the two
Red 30cm Bit Lights
to the “OUT” ports on
the Gun Eects Board
