Lightolier Calculite ProSpec Linear Downlight PS4M1650 User manual

12 10
7
9
8
123
11
5
4
6
10 1/4"
7 1/4"
21 5/16"
14 1/4"
8 3/4"
1 3/4"
18 9/16"L x 6 1/16"W
4" OC 4" OC 4" OC
16"L x 3 1/2"W Opening
17"L x 4 9/16"W Ceiling Cutout
Depth
TOP VIEW
Flanged Trimless
Calculite®ProSpec®Linear Downlight PS4M1650
Page 1 of 2 4 Light MR 16 Series S
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier a Genlyte Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2005 Genlyte Group LLC • C1105
Features
1. Aperture Frame: Provides clean support for lamp holders and overlapping
flange or trimless installation. Extruded aluminum. Rigidly welded together
on all corners.
2. Lamp Shields: Die-formed aluminum. Shields spill light from lamp.
Removable for relamping
3. Adjustable Ring: Die-cast aluminum. 30° vertical adjustment.
4. Tortiontite Spring: For easy installation of aperture frame.
5. Housing: Die-formed NYC 20 ga. steel. Finish: Black.
6. Mounting Brackets: Adjustable vertically from outside of housing.
7. Thermal Protector: Meets NEC, CEC, UL & CSA requirements.
8. Lampholder: Steatite for GX/GY 5.3 Bi-Pin MR-16 lamps. 250°C Teflon®
leads.
9. Heat Shield: Die-formed aluminum.
10.Junction Box: 14 ga. steel, 4" x 3-1/2" x 3" box. Allows inspection from
below.
11.Lamp Guard: Heat resistant Micro prismatic clear glass. Lamp manufac-
turer’s requirement
12. Transformer Housing: Die-formed steel.
Electrical
Electronic Transformers: Offer reliable operation and are accessible from
below for servicing. 12V. Secondary 50 VA. each lamp.
Dimming Controls: Use only dimmers specifically designed for use with
electronic transformers. Low Voltage fixtures may produce audible sound
when used with dimmers, which may be objectionable in acoustically
critical areas.
UL/cUL listed for through branch circuit wiring with maximum of (4) no. 12
AWG, 90°.
Ceiling Cutout: 17" L x 4 9/16" W
Ordering Information: MR 16 Series S
Cat. No. Lamp Ceiling Trim Aperture Finish
PS4M165EBL (4) 50W MR 16 Overlap Black with White Flange
PS4M165EWL (4) 50W MR 16 Overlap White with White Flange
PS4M165EBTL (4) 50W MR 16 Trimless Black
PS4M165EWTL (4) 50W MR 16 Trimless White
Finish
All painted finishes are powder coated baked enamel.
Labels
UL/cUL (Suitable for Damp Location), I.B.E.W.
Teflon®is a registered trademark of E.I. DuPont.
Top View
PS4M165EBL = (Flanged) Black/White
PS4M165EWL = (Flanged) White
PS4M165EBTL = (Trimless) Black
PS4M165EWTL = (Trimless) White
Add a “1” for 120v or “2” for 277v at the end of the catalog number for voltage

DFC L W DC FC L W DC FC L W
MR16 LOW VOLTAGE HALOGEN BI-PIN LAMPS
Lamps Beam Spread CBCP Rated
(To 50% CBCP) Life (Hrs.)
(FC) is initial footcandles at center of beam.
Beam length (L) and beam width (W) are to
where the candlepower is reduced to 50% of the
center beam candlepower.
CBCP is center beam candlepower.
(C) is distance to the center of the beam.
Lamp data shown is typical, and is based on bare
lamp photometrics. Contact lamp manufacturers
for availability and performance.
7’ 167 0.9’ 0.9’
10’ 82 1.2’ 1.2’
13’ 49 1.6’ 1.6’
16’ 32 2.0’ 2.0’
6’ 3.5’ 148 1.0’ 0.8’
9’ 5.2’ 66 1.5’ 1.3’
12’ 6.9’ 37 2.0’ 1.7’
15’ 8.7’ 24 2.3’ 2.1’
2’ 3.5 256 1.0’ 0.5’
3’ 5.2’ 114 1.5’ 0.7’
4’ 6.9’ 64 2.0’ 1.0’
5’ 8.7’ 41 2.5’ 1.2’
8200 3000
20W MR16
VNSP (EZX) 7˚
6’ 100 1.4’ 1.4’
8’ 56 1.8’ 1.8’
10’ 36 2.3’ 2.3’
12’ 25 2.7’ 2.7’
5’ 2.9’ 94 1.5’ 1.3’
7’ 4.0’ 48 2.1’ 1.8’
9’ 5.2’ 29 2.7’ 2.4’
11’ 6.4’ 19 3.4’ 2.9’
2’ 3.5’ 113 1.9’ 0.9’
3’ 5.2’ 50 2.8’ 1.4’
4’ 6.9’ 28 3.8’ 1.8’
5’ 8.7’ 18 4.7’ 2.3’
3600 5000
20W MR16
NSP (ESX) 13˚
7’ 178 1.5’ 1.5’
10’ 87 2.1’ 2.1’
13’ 51 2.7’ 2.7’
16’ 34 3.4’ 3.4’
6’ 3.5’ 157 1.7’ 1.5’
9’ 5.2’ 70 2.5’ 2.2’
12’ 6.9’ 39 3.4’ 2.9’
15’ 8.7’ 25 4.2’ 3.6’
2’ 3.5’ 272 1.7’ 0.8’
3’ 5.2’ 121 2.6’ 1.3’
4’ 6.9’ 68 3.5’ 1.7’
5’ 6.7’ 44 4.3’ 2.1’
8700 4000
35W MR16
NSP (FRB) 12˚
8’ 205 1.3’ 1.3’
12’ 91 1.9’ 1.9’
16’ 51 2.5’ 2.5’
20’ 33 3.1’ 3.1’
7’ 4.0 174 1.5’ 1.3’
10’ 5.8’ 85 2.1’ 1.8’
13’ 7.5’ 50 2.7’ 2.4’
16’ 9.2’ 33 3.4’ 2.9’
3’ 5.2’ 182 1.9’ 0.9’
4’ 6.9’ 102 2.6’ 1.3’
5’ 8.7’ 66 3.2’ 1.6’
6’ 10.4 45 3.8’ 1.9’
13100 3500
42W MR16
VNSP (EZY) 9˚
8’ 159 2.0’ 2.0’
12’ 71 2.9’ 2.9’
16’ 40 3.8’ 3.9’
20’ 26 4.9’ 4.9’
7’ 4.0’ 135 2.3’ 2.0’
10’ 5.8’ 66 3.3’ 2.8’
13’ 7.5’ 39 4.3’ 3.7’
15’ 9.2’ 28 5.3’ 4.5’
3’ 5.2’ 142 3.1’ 1.5’
4’ 6.9’ 80 4.1’ 2.0’
5’ 8.7’ 51 5.1’ 2.5’
6’ 10.4’ 35 6.2’ 2.9’
10200 4000
50W MR16
NSP (EXT) 14˚
2’ 131 1.5’ 1.5’
3’ 58 2.2’ 2.2’
4’ 33 2.9’ 2.9’
5’ 21 3.6’ 3.6’
2’ 1.2’ 85 2.0’ 1.7’
3’ 1.7’ 38 3.0’ 2.5’
4’ 2.3’ 21 4.1’ 3.4’
5’ 2.9’ 14 5.1’ 4.2’
1’ 1.7’ 66 4.8’ 1.5’
2’ 3.5’ 16 9.7’ 2.9’
3’ 5.2’ 7 14.5’ 4.4’
4’ 6.9’ 4 19.3’ 5.8’
525 5000
20W MR16
FL (BAB) 40˚
4’ 100 2.9’ 2.9’
6’ 44 4.4’ 4.4’
8’ 25 5.8’ 5.8’
10’ 16 7.3’ 7.3’
3’ 1.7’ 115 3.0’ 2.5’
5’ 2.9’ 42 5.1’ 4.2’
7’ 4.0’ 21 7.1’ 5.8’
9’ 5.2’ 13 9.1’ 7.6’
1’ 1.7’ 200 4.8’ 1.5’
2’ 3.5’ 50 9.7’ 2.9’
3’ 5.2’ 22 14.5’ 4.4’
4’ 6.9’ 13 19.3’ 5.8’
1600 4000
35W MR16
FL (FMW) 40˚
4’ 116 2.9’ 2.9’
6’ 51 4.4’ 4.4’
8’ 29 5.8’ 5.8’
10’ 19 7.3’ 7.3’
3’ 1.7’ 134 3.0’ 2.5’
5’ 2.9 48 5.1’ 4.2’
7’ 4.0’ 25 7.1’ 5.9’
9’ 5.2’ 15 9.1’ 7.6’
1’ 1.7’ 231 4.8’ 1.5’
2’ 3.5’ 58 9.7’ 2.9’
3’ 5.2’ 26 14.5’ 4.4’
4’ 6.9’ 14 19.3’ 5.8’
1850 6000
50W MR16
FL (EXN) 40˚
3’ 128 3.1’ 3.1’
5’ 46 5.2’ 5.2’
7’ 23 7.3’ 7.3’
9’ 14 9.4’ 9.4’
3’ 1.7’ 83 4.6’ 3.6’
5’ 2.9’ 30 7.6’ 6.0’
7’ 4.0’ 15 10.7’ 8.4’
9’ 5.2’ 9 13.7’ 10.8’
1’ 1.7’ 144 22.3’ 2.1’
2’ 3.5’ 36 44.5’ 4.2’
3’ 5.2’ 16 66.8’ 6.2’
4’ 6.9’ 9 89.1’ 8.3’
1150 4000
50W MR16
WFL (FNV) 55˚
6’ 108 2.1’ 2.1’
8’ 61 2.8’ 2.8’
10’ 39 3.5’ 3.5’
12’ 27 4.2’ 4.2’
5’ 2.9 101 2.4’ 2.0’
7’ 4.0’ 52 3.3’ 2.9’
9’ 5.2’ 31 4.3’ 3.7’
11’ 6.4’ 21 5.2’ 4.5’
2’ 3.5’ 122 3.1’ 1.4’
3’ 5.2’ 54 4.7’ 2.1’
4’ 6.9’ 30 6.2’ 2.8’
5’ 8.7’ 20 7.8’ 3.5’
3900 4000
35W MR16
SP (FRA) 20˚
6’ 94 2.9’ 2.9’
8’ 53 3.8’ 3.8’
10’ 34 4.8’ 4.8’
12’ 24 5.8’ 5.8’
5’ 2.9’ 88 3.3’ 2.8’
7’ 4.0’ 45 4.6’ 3.9’
9’ 5.2’ 27 5.9’ 5.0’
11’ 6.4’ 18 7.2’ 6.1’
2’ 3.5’ 106 4.6’ 1.9’
3’ 5.2’ 47 7.0’ 2.9’
4’ 6.9’ 27 9.3’ 3.6’
5’ 8.7’ 17 11.6’ 4.8’
3400 6000
50W MR16
NFL (EXZ) 27˚
6’ 180 1.4’ 1.4’
12’ 80 2.1’ 2.1’
16’ 45 2.8’ 2.8’
20’ 29 3.5’ 3.5’
7’ 4.0’ 152 1.6’ 1.4’
10’ 5.8’ 75 2.3’ 2.0’
13’ 7.5’ 44 3.0’ 2.8’
16’ 9.2’ 29 3.7’ 3.2’
3’ 5.2’ 160 2.1’ 1.0’
4’ 6.9’ 90 2.9’ 1.4’
5’ 8.7’ 58 3.6’ 1.7’
6’ 10.4’ 40 4.3’ 2.1’
11500 4000
37W MR16 IR
NSP 10˚
6’ 97 2.7’ 2.7’
8’ 55 3.5’ 3.5’
10’ 35 4.4’ 4.4’
12’ 24 5.3’ 5.3’
5’ 2.9’ 91 3.0’ 2.6’
7’ 4.0’ 46 4.2’ 3.6’
9’ 5.2’ 28 5.4’ 4.6’
11’ 6.4’ 19 6.6’ 5.6’
2’ 3.5’ 109 4.2’ 1.8’
3’ 5.2’ 49 6.2’ 2.7’
4’ 6.9’ 27 8.3’ 3.5’
5’ 8.7’ 18’ 10.4’ 4.4’
3500 4000
37W MR16 IR
NFL 25˚
4’ 128 2.9’ 2.9’
6’ 57 4.4’ 4.4’
8’ 32 5.8’ 5.8’
10’ 21 7.3’ 7.3’
3’ 1.7’ 148 3.0’ 2.5’
5’ 2.9’ 53 5.1’ 4.2’
7’ 4.0’ 27 7.1’ 5.9’
9’ 5.2’ 16 9.1’ 7.6’
1’ 1.7’ 258 4.8’ 1.5’
2’ 3.5’ 64 9.7’ 2.9’
3’ 5.2’ 28 14.5’ 4.4’
4’ 6.9’ 16 19.3 5.8’
2050 4000
37W MR16 IR
FL 40˚
0° Aiming Angle 30° Aiming Angle 30° Aiming angle
Accent Lighting Performace Data
