Sorelle Emerson User manual

Made in Vietnam
Important Information:
Emerson Double Dresser
Assembly Instruction
Read all instructions BEFORE assembling.
KEEP INSTRUCTIONS FOR FUTURE USE.
IMPORTED BY C&T International, Inc. / IMPORTE` PAR de C&T International, Inc.
CANADA ADDRESS:
105 Stonehurst Ct Northvale, NJ 07647 U.S.A.
3453, DU PRESIDENT KENNEDY LAC MEGANTIC, QUEBEC, CANADA G6B 2Y4
Tel, 201- 531-1919 Fax, 201- 531-1920
Website: www.sorellefurniture.com / Site Internet : www.sorellefurniture.com

Page 2
(A) Left Side Panel (x1) (B) Middle Panel (x1) (C) Right Side Panel (x1)
(D) Back -Top Rail (x1) (E) Back- Middle Rail ( x2 ) ( G ) Front - Middle Rail ( x2 )
( H ) Front Top Rail ( x1 ) ( I ) Top Frame ( x1 ) ( J ) BackPanel ( x1 ) ( K ) Center Leg ( x1 )
SORELLE
(R4) Drawer Bottom (x6)
(R5) Drawer Bottom Support (x6)
(R3) Drawer Back (x6)
(R1) Drawer Left (x6) (R2) Drawer Right (x6)
( R ) Drawer Front (x6)( L ) Front- Bottom Rail (x1)
Assembly Parts

Page 3
Hardware list
SORELLE
Assembly Parts
SORELLE
Assembly Parts
r (X1)
1/4"*25
a (X4)
1/4"*45
n (X14)
Φ
ΦΦ Φ
ΦΦ
Φ
12*6*1.2 Φ11*6*1.5
c (X20) d (X30)
M4x115
s (X1)
1/4"*32
b (X10)
20*10*8
e (X10) 8*15
f (X28)
8*25
g (X48)
7*12
h (X18)
8*30
i (X23)
6*30
m (X24)
5/32*22
k(X6)
j(X6)
40*15*2
o (X6)
20*18*16
p (X6)
1/4"*15
t (X2)
32x21x18x2
q (X1)
T
Tool required

Page 4
Figure 1
Figure 2
SORELLE
Assembly Steps
Attach Rails to Middle panel (B) as Figure 2.
Attach center leg (K) to Middle panel (B) ,
1
2
K
B
B
b
d
c
ii
i
HD
G
G
LB
L
tdcc
dt
q
i
B
B
E
E
L
&
H
X 2
Mode shown is example only
Styles may vary

Page 5
SORELLE
Assembly Steps
3Attach Left side panel and Right side panel to Rails as Figure 3.
4
Figure 3
Figure 4
e
i
n
b
d
d
c
s
A
A
C
C
&
D
X 10
L
A
X 2
X 4
a
d
c
G
A
Attach Top Frame ( I) to Dresser.
i
X 6
n
I
s
c
d
X 4
X 5
b
c
d
Mode shown is example only
Styles may vary
Mode shown is example only
Styles may vary

Page 6
SORELLE
Finley Double Dresser Assembly
5Attach Back- Upper Panel (J ) to Dresser
.
as Figure 5.
Assembly Steps
f x 28
I
J
B
Figure 5
Mode shown is example only
Styles may vary

Page 7
SORELLE
Drawer Assembly
g
g
5
4
3
3. Secure both sides of
Drawer Front (R) to drawer
assembly with four (4)
Screws ( g ) . Figure 3
Check all screws for
tightness.
5. Using Drawer Knob
Screw ( k ), install one (1)
Knob ( j ) on Drawer.
Figure 5.
Repeat for all drawers.
Set drawers aside for
later use.
( j )
( k )
2. Slide Drawer Bottom (R4) and into drawer Bottom
Support (R5) assembly. Figure 2
4. Attach Matel Connector A (o)and
Matel Connector B (p). Figure 4
(R)
(h)
(h)
(h)
(o)
(p)
(m)
(m)
(R4) (R5)
2
i
i
1
1.Working on a padded
flat surface, attach Drawer
Sides (R1&R2) to Drawer
Back (R3) with Philips Head
Screw( i ). Figure 1 (R3)
(R2)
(R1)
ox2
T
Tool required
Mode shown is example only
Styles may vary

Page 8
SORELLE
Assembly Steps
Assembly the drawer as Figure 6.
6
Figure 6
