Lightolier VL Series User manual

Vanity Light VL Series
Page 1 of 2 4-3/4" Wide , 24", 36" or 48" Lengths
1 Lamp T8
• Can be horizontally or vertically mounted.
• 4-3/4" diameters opal white acrylic lens.
• Positive stainless steel lens retainers.
• Permanently installed milk white opaque diffuser ends with
decorative trim.
• Efficiency 76.6% (T8).
• Quarter turn latch secures channel cover for easy wireway access.
• Heavy duty channel of code gauge die formed steel.
• Fully enclosed wireway.
• UL Listed snap-on end caps (body).
• Green grounding screw installed in channel.
Features Dimensions
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
Lightolier a Genlyte company www.lightolier.com
Technical Information: [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2005 a Genlyte company Section 4/Folio I50-10
10/05
24" (610mm)
36" (914mm)
48" (1219mm)
7/8" Dia. K.O.
4-3/4" (121mm)
4"
(102mm)
2"
(51mm) 24" (254mm)
36" (406mm)
48" (559mm)
2-1/2"
(64mm)
•
25-1/2" (648mm)
37-1/2" (953mm)
49-1/2" (1257mm)
•

0.0 45.0 90.0 FLUX
0 475 475 475
5 470 474 478 45
15 452 459 467 130
25 418 432 446 200
35 370 394 418 247
45 310 349 385 269
55 239 299 347 265
65 160 246 307 238
75 78 196 265 196
85 13 151 224 151
90 4 132 204
95 4 118 188 119
105 6 91 153 92
115 18 73 122 71
125 24 61 97 53
135 28 49 77 40
145 36 37 55 27
155 44 55 42 21
165 51 35 54 12
175 55 35 39 4
180 53 53 53
Lightolier a Genlyte company www.lightolier.com
Technical Information: [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2005 a Genlyte company
A0902 Section 4/Folio I50-10
Job Information Type:
Specifications
Materials: Chassis parts are die-formed heavy gauge code cold rolled steel,
1-13/16" deep, 2-1/2" wide.
Ballast Cover: Code gauge steel secured with 1/4 turn fasteners, for easy
wireway access.
Finish: Chassis exterior–exterior phosphate undercoating, baked white
polyester enamel.
Lens: 4-3/4" diameter opal white acrylic with permanently installed opal white
opaque diffuser ends with decorative trim..
Electrical: Thermally protected class “P” ballast, non PCB. If K.O. is within 3"
of ballast, use wire suitable for at least 90°.
Labels: I.B.E.W./UL and ULc Listed.
Vanity Light VL Series
Page 2 of 2 4-3/4" Wide, 24", 36" or 48" Lengths
1 Lamp T8
Chassis
Model No. SN4S132HPFUNVHI
with shielding VLW4X48
LER = FP - 68.2 IW - 29.6 BF - 0.92
Comparative yearly lighting energy cost per
1000 lumens = $3.52
Report Number: G2005214
Lamp: F32/T8 TL841
Luminaire: 4' Vanity Light, with 4-3/4" wide
milk white acrylic lens
Ballast: 1X32/T8
Report is based on 2850 Lumens per lamp.
Efficiency: 76.6%
CIE Type-Direct-Indirect
Plane: 0-Deg 90-Deg
Spacing Criteria: 1.2 1.4
Shielding Angles: 90 90
CANDELA DISTRIBUTION0
AVERAGE AVERAGE AVERAGE AVERAGE
IN DEG. 0-DEG. 45-DEG. 90-DEG.
45 2586. 2180. 1922.
55 2382. 2035. 1793.
65 02058. 1903. 1697.
75 01478. 1819. 1629.
85 0496. 1822. 1605.
LUMINANCE DATA IN CANDELA/SQ. METER
COEFFICIENTS OF UTILIZATION –
ZONAL CAVITY METHOD. EFFECTIVE
FLOOR CAVITY REFLECTANCE 0.200
RC 80 50 30
RW 70 50 30 50 30 10 50 30 10
01787369646158585654
02706357555046504643
03635448474238433936
04584841423632383430
05534235373227342926
06493831332824312622
07453427302521282320
08423125282218262117
09392822252016231916
10 36 26 20 23 18 15 22 17 14
ZONE LUMENS % LAMP % FIXT
00-030 375 13.2 17.2
00-040 622 21.8 28.5
00-060 1157 40.6 53.0
00-090 1743 61.2 79.9
90-120 282 9.9 12.9
90-130 335 11.7 15.3
90-150 403 14.1 18.4
90-180 440 15.4 20.1
00-180 2183 76.6 100.0
ZONAL LUMEN SUMMARY
Ordering Information
NOTE: Chassis and shielding are packed in separate cartons. When ordering, enter as separate line items.
Length Shielding Chassis Lamp Ballast 20THD 10THD
2' VLW4X24 SN2S117HPFUNVHI1-T8 1 Lamp Elec. T8 – HI
3' VLW4X36 SN3S125HPFUNVHI1-T8 1 Lamp Elec. T8 – HI
4' VLW4X48 SN4S132HPFUNVHI1-T8 1 Lamp Elec. T8 – HI
NOTE: Chassis and shielding shown are stock items. For other ballast options see Folio H110-40.NOTE: UNV =120-277.
