Lightolier 16FR2X6 User manual

16FR2X6
Lytecaster recessed downlighting 16" O. C.
Fire rated enclosure
Page 1 of 1
Job Information Type:
Job Name:
Cat. No.:
Notes:
Features
1. DriClad™ fire rated enclosure: 1” thickness, rated for minimum 2” x 6”
construction.
2. Parts bag: (containing)
4 - 2” Drywall Screws
4 - 1-1/4” Drywall Screws
4 - Eyelets
1 - Square, Mineral Wool
1 - Metal Cap
3. Reflector trim: (See reflector trim specification sheet.)
4. Lamp: (See reflector trim specification sheet and above.)
5. Frame-in kit: (See frame-in kit specification sheet.)
Labels
UL Classified for use in one-hour
fire rated L500 Series floor/ceiling
assemblies (Excludes Truss ceilings)
DriClad™ is a registered trademark of Stan Chem, Inc.
Luminaire assemblies
classified for
fire resistance
14 3/8" 20 3/8"
5 3/8"
16FR2X6
Complete fixture consists of fire rated enclosure, reflector trim & frame-in kit. Select each separately.
FireLine catalog no. Use with frame-in kit Use with Lamp reflector trim
16FR2X6 Fluorescent
1102T1
1102TH1
1102TH2
1102T13U
1102T18U
1050RN Series
1050SQ Series
All applicable trims All applicable lamps
LED
1050LRN Series
1050LSQ Series
