Lightolier Calculite Matrix 9X9 User manual

631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2009 Philips Group • C1009
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Calculite® Matrix® Open Downlight 9X9
Page 1 of 2 9” X 9" Square Aperture (2) 26W Quad / 32/42W Triple Tube 4-Cell Parabolic Louver
4
23
1
6
9"
10 1/4"
1 1/4" Max.
CeilingThickness
5
7
9"
10 1/4"
5 1/2"
14 1/8"
8 1/8"
12 3/8"
9 9/16"
9 9/16"
Top View
Features
1. Reflector Trim: Pre-finished aluminum with low iridescence clear finish. 55°
visual and reflected cutoff. Overlap flange accommodates different ceiling
types. Precision mitered flange corners.
2. Upper Reflector: High efficiency, 97%, Specular Clear.
3. Housing: 20 ga. galvanized formed steel. Centerline notches and holes
for consistent alignment of multiple fixtures. Accommodates ceilings up to
1 1/4” thick.
4. Ballast Assembly: Door-mounted for easy service, allows replacement from
inside of fixture.
5. Torsiontite Springs: Precision-tooled steel springs secure reflector trim
to housing for quick tool-less installation. Positive tension holds flange tight
against ceiling.
6. J-Box: 14 ga. galvanized steel. Accessible from inside and outside of the
fixture. Outside J-box door is hinged for easy access.
7. Mounting Brackets: 16 ga. steel. Adjustable from inside fixture. Utilize 3/4”
or 1 1/2” lathing channel, 1/2” EMT, or optional mounting bars.
Options and Accessories
Chicago Plenum with Fuse (slow blow): Add LCF suffix to Frame-In Kit,
consult factory for specifications.
Emergency: Add EM suffix to Frame-In Kit, consult factory for specifications.
Mounting Bars / T-Bar Anchor Clips: See specification sheet “MBA”.
Electrical
UL Listed for through circuit wiring with max of (8) No. 12 AWG, 90°C supply
conductors.
Note: For complete ballast data and lamp / ballast compatibility refer to
“Ballast” specification sheet.
General
UL Listed for damp locations, I.B.E.W. Union Made.
Specular Clear finish (CL) reflector trims meet IES RP-1 practice.
Ceiling Cutout: 9 5/8" L X 9 5/8" W
Trim Kits Frame-In Kits
Reflector
Trims Finish / Flange Frame-In Kits Type Ballast Input
Voltage
Quad Tube
Wattage
Triple Tube
Wattage Length Width Height
9X9CLW Specular Clear / White 9X9242HU Non-IC Electronic 120/277V (2) 26W (2) 32/42W 12 1/2" 14" 5 3/4"
9X9CLP Specular Clear / Polished 9X9242HUEM Non-IC Electronic - Emergency 120/277V (2) 26W (2) 32/42W 12 1/2" 15 3/4" 5 3/4"
9X9CCLW Comfort Clear / White 9X9242HJUM7 Non-IC Mark 7® Dimming 120/277V (2) 32/42W 12 1/2" 13 3/4" 5 3/4"
9X9CCLP Comfort Clear / Polished 9X9242HJ1MX Non-IC Mark 10® Dimming 120V (2) 32/42W 12 1/2" 13 1/2" 5 3/4"
9X9CCDW Comfort Clear Diff. / White 9X9242HJ2MX Non-IC Mark 10® Dimming 277V (2) 32/42W 12 1/2" 13 1/2" 5 3/4"
9X9CCDP Comfort Clear Diff. / Polished
9X9CCGP Clear Corrugated / Self Flange
9X9WHW White / White

Job Information Type:
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2009 Philips Group • C1009
Calculite® Matrix® Open Downlight 9X9
Page 2 of 2 9” X 9" Square Aperture (2) 26W Quad / 32/42W Triple Tube 4-Cell Parabolic Louver
1 .69 .67 .66 .68 .66 .65 .65 .64 .63 .63 .62 .61 .61 .60 .59 .58
2 .64 .61 .59 .63 .60 .58 .61 .59 .57 .59 .57 .56 .57 .56 .54 .53
3 .59 .55 .52 .58 .55 .52 .56 .53 .51 .55 .52 .50 .53 .51 .50 .49
4 .54 .50 .47 .53 .50 .47 .52 .49 .46 .51 .48 .46 .49 .47 .45 .44
5 .50 .45 .42 .49 .45 .42 .48 .44 .42 .47 .44 .41 .46 .43 .41 .40
6 .45 .41 .38 .45 .41 .38 .44 .40 .38 .43 .40 .37 .42 .39 .37 .36
7 .41 .37 .34 .41 .37 .33 .40 .36 .33 .39 .36 .33 .38 .35 .33 .32
8 .37 .33 .30 .37 .33 .30 .36 .32 .30 .36 .32 .29 .35 .32 .29 .28
9 .34 .29 .26 .34 .29 .26 .33 .29 .26 .32 .29 .26 .32 .28 .26 .25
10 .31 .26 .23 .30 .26 .23 .30 .26 .23 .29 .26 .23 .29 .25 .23 .22
32W Quad Tube, Specular Clear Reflector Trim
Two Philips lamps, 2400 lumens each
ZONAL LUMENS AND PERCENTAGES
Zone Lumens % Lamp % Luminaire
0-30 1201 25.02 39.75
0-40 2095 43.66 69.35
0-60 3014 62.80 99.75
0-90 3021 62.95 100.00
0 1119 1119 1119 1119 1119
5 1182 1192 1188 1181 1183 114
10 1281 1297 1294 1309 1305
15 1391 1391 1394 1330 1284 386
20 1533 1536 1424 1322 1276
25 1664 1710 1479 1414 1400 701
30 1644 1774 1618 1426 1263
35 1441 1660 1709 1199 980 895
40 1149 1440 1491 1061 774
45 830 1056 1091 846 605 712
50 497 589 602 630 529
55 84 132 229 187 96 207
60 10 13 39 12 10
65 5 5 4 4 5 7
70 2 1 1 1 2
75 0 0 0 0 1 0
80 1 0 0 0 0
85 0 0 0 0 0 0
90 0 0 0 0 0
Test Report 1776FR Apr. 8, 2002
Angle Along 22.5 45 67.5 Across Lumens
CANDLEPOWER SUMMARY
Efficiency = 63.0% Spacing Criterion: Along = 1.6 Across = 1.4
% Effective Ceiling Cavity Reflectance
1 .54 .52 .51 .53 .51 .50 .51 .50 .49 .49 .48 .47 .47 .46 .46 .45
2 .50 .48 .46 .49 .47 .45 .47 .46 .44 .46 .45 .43 .44 .43 .43 .42
3 .46 .43 .41 .45 .43 .41 .44 .42 .40 .43 .41 .40 .42 .40 .39 .38
4 .42 .40 .37 .42 .39 .37 .41 .39 .37 .40 .28 .36 .39 .37 .36 .35
5 .39 .36 .34 .90 .36 .34 .38 .35 .33 .37 .35 .33 .36 .34 .33 .32
6 .36 .33 .31 .36 .33 .31 .35 .32 .30 .34 .32 .30 .34 .31 .30 .29
7 .33 .30 .28 .33 .30 .27 .32 .29 .27 .31 .29 .27 .31 .29 .27 .26
8 .30 .27 .25 .30 .27 .25 .29 .27 .25 .29 .26 .24 .28 .26 .24 .24
9 .28 .24 .22 .27 .24 .22 .27 .24 .22 .27 .24 .22 .26 .24 .22 .21
10 .25 .22 .20 .25 .22 .20 .25 .22 .20 .24 .22 .20 .24 .21 .20 .21
ROOM CAVITY RATIO
cu
50 30 10 50 30 10 50 30 10 50 30 10 50 30 10 0
80 70 50 30 10 0
26W Quad Tube, Specular Clear Reflector Trim
Two Sylvania lamps, 1800 lumens each
ZONAL LUMENS AND PERCENTAGES
Zone Lumens % Lamp % Luminaire
0-30 791 21.99 45.27
0-40 1274 35.39 72.86
0-60 1744 48.46 99.76
0-90 1748 48.57 100.00
0 806 806 806 806 806
5 830 860 877 880 878 83
10 887 918 930 934 930
15 918 844 980 946 948 269
20 935 975 977 1002 959
25 915 974 1009 988 908 440
30 879 943 949 844 726
35 763 888 851 684 611 482
40 576 761 702 554 447
45 404 549 501 453 380 365
50 244 278 326 338 320
55 41 60 121 82 49 105
60 5 6 20 7 6
65 2 2 3 1 3 4
70 1 1 1 1 1
75 0 0 0 0 0 0
80 0 0 0 0 0
85 0 0 0 0 0 0
90 0 0 0 0 0
Test Report 1775FR Apr. 8, 2002
Angle Along 22.5 45 67.5 Across Lumens
CANDLEPOWER SUMMARY
Efficiency = 48.6% Spacing Criterion: Along = 1.4 Across = 1.3
% Effective Ceiling Cavity Reflectance
ROOM CAVITY RATIO
cu
50 30 10 50 30 10 50 30 10 50 30 10 50 30 10 0
80 70 50 30 10 0
20% Floor Cavity Reflectance 20% Floor Cavity Reflectance
42W Quad Tube, Specular Clear Reflector Trim
Two Philips lamps, 3200 lumens each
ZONAL LUMENS AND PERCENTAGES
Zone Lumens % Lamp % Luminaire
0-30 1578 24.66 41.01
0-40 2680 41.88 69.63
0-60 3839 59.99 99.74
0-90 3849 60.15 100.00
0 1502 1502 1502 1502 1502
5 1567 1582 1606 1625 1623 155
10 1706 1741 1778 1803 1803
15 1826 1871 1931 1829 1770 522
20 1920 1970 1915 1824 1732
25 1943 2040 1915 1969 1964 902
30 1923 2077 1948 2001 1797
35 1706 1920 2016 1602 1353 1102
40 1346 1667 1809 1352 1089
45 1001 1258 1405 1085 830 890
50 635 724 819 776 742
55 114 164 306 262 125 269
60 13 13 51 18 14
65 6 5 5 6 6 9
70 3 2 1 2 3
75 1 1 0 1 1 1
80 0 0 0 0 0
85 0 0 0 0 0 0
90 0 0 0 0 0
Test Report 1777FR Apr. 8, 2002
Angle Along 22.5 45 67.5 Across Lumens
CANDLEPOWER SUMMARY Efficiency = 60.1% Spacing Criterion: Along = 1.5 Across = 1.4
1 .66 .64 .63 .65 .63 .62 .62 .61 .60 .60 .59 .58 .58 .57 .57 .56
2 .61 .59 .56 .60 .58 .56 .58 .56 .54 .56 .55 .53 .55 .53 .52 .51
3 .56 .53 .50 .55 .52 .50 .54 .51 .49 .52 .50 .48 .51 .49 .48 .47
4 .52 .48 .45 .51 .48 .45 .50 .47 .45 .49 .46 .44 .47 .45 .43 .42
5 .48 .44 .41 .47 .43 .41 .46 .43 .40 .45 .42 .40 .44 .41 .39 .38
6 .44 .40 .37 .43 .39 .36 .42 .39 .36 .41 .38 .36 .40 .38 .36 .35
7 .40 .35 .33 .39 .35 .32 .38 .35 .32 .38 .34 .32 .37 .34 .32 .31
8 .36 .32 .29 .36 .32 .29 .35 .31 .29 .34 .31 .29 .34 .31 .28 .27
9 .33 .29 .26 .32 .28 .26 .32 .28 .26 .31 .28 .25 .31 .28 .25 .24
10 .30 .26 .23 .29 .26 .23 .29 .25 .23 .28 .25 .23 .28 .25 .22 .22
% Effective Ceiling Cavity Reflectance
ROOM CAVITY RATIO
cu
50 30 10 50 30 10 50 30 10 50 30 10 50 30 10 0
80 70 50 30 10 0
20% Floor Cavity Reflectance
Based on specular clear (CL) finish. To estimate other finishes, multiply candelas
and CU values by 0.95 for CCL, by 0.90 for CCD.
