Lightolier Pristine Series User manual

Task Lighting Pristine Series
Page 1 of 2 22" Length, 1 Lamp T2 Linear
Features
•
Architecturally pleasing rounded slim profile only 3/4" deep x
4-3/4" wide.
• Provides median foot candle level of 55 on 2' x 5' desk top.
• Prismatic acrylic spread lens.
• Flush push button switch.
• Electronic program start <10 THD ballast.
• Lamp T2 13W, CRI=80, color temperature 3500K, lamp is
included.
• Nine foot straight black cord.
• Baked pewter polyester enamel finish.
• Meets New York City requirements for task lighting.
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
Lightolier a Genlyte Thomas Company www.lightolier.com
Technical Information: [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
Copyright 2004 Lightolier Section 5/Folio H150-15
5/04
Features Dimensions
Nine Foot
Straight Cord
Aluminum
Reflector
1-3/8"
(35mm)
4-3/4" (121mm)
22" (559mm)
12" (305mm)
5-1/16"
(132mm)
4-3/4"
(121mm)
3/4"
(19mm)
TM
Cord Set
Architecturally pleasing rounded slim
profile only 3/4" deep x 4-3/4" wide.

Task Lighting Pristine Series
Page 2 of 2 22" Length, 1 Lamp T2 Linear
Lightolier a Genlyte Thomas Company www.lightolier.com
Technical Information: [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
Copyright 2004 Lightolier Section5/Folio H150-15
Job Information Type:
Ordering Information
Explanation of Catalog Number. Example: PC2P13T2120PTCPB
Options/Accessories
Chicago Plug: Suffix: CH.
Dimming: Consult factory.
Specifications
Materials: Chassis parts are die-formed cold rolled steel.
Lens: Ribbed acrylic.
Reflector: Aluminum.
End Caps: Polycarbon.
Lamp: T2, 13 watt CRI=80, color temperature 3500K.
Finish: Cavity–pewter baked enamel, 85% reflectance. Phosphate
undercoating.
Chassis exterior–pewter baked enamel.
Electrical: Thermally protected class “P” ballast C.B.M. approved, sound rated
A, <10 THD, non PCB.
Labels: UL and ULc Listed.
PC
Pristine
Series:
Task Lighting
2
Length:
2=22"
P
Finish:
Pewter
13
Lamp:
13 Watt
T2
Lamp Type:
T2=835K
installed
with fixture
120
Voltage:
120
PT CPB
9' Black
cord & plug
Ballast:
PT = Elec. Program
Start <10 THD
for Linear
T2 Lamp
17-1/2"
(445mm) 6"
6"
6"
6"
6"
6"
6" 12" 12" 12" 12" 6"
60"
25 55 66 55 25
28 72 95 72 28
30 72 94 72 30
10 21 46 21 10
15 26 38 26 15
Pristine Footcandle Readings
TM
Back Wall
Desk Top
Options:
Add appropriate
suffix to catalog
no, ie: (CH)
