ALTER METALYTE
2’ X 4’ RECESSED DIRECT/INDIRECT FLUORESCENT
2 LAMP, T8, 5 1/2” DEEP
MICROPERFORATED MESH LAMP SHIELD
STATIC
Efficiency 44.8%.
Semi-specular aluminum reflectors with
lengthwise ridges.
Swing down microperforated lamp shield
for easy relamping and maintenance.
Alter soft white film on inside of mesh conceals
lamp image and provide balance between
reflected light and direct light.
Fully recessed luminaire and lamp
compartment.
Specular interior reflector.
One piece body for easy installation.
Easy access to ballast through lamp
compartment.
Fits standard T-Grid ceilings.
Optional acrylic drop-down visual element.
MOUNTING METHODS/FEATURES DIMENSIONS
FIXTURE TYPE
JOB INFORMATION:
VOLTS
L30-50
QVS2GPTOS232
Suited to standard exposed Slot T-grid ceilings
Ceiling compatibility
Suited to standard exposed T-grid ceilings
Swing down optical system for
easy relamping and maintenance
Microperforated mesh lamp shields Semi-specular aluminum reflector
with lengthwise ridges
Genlyte Thomas Company

OS =Open slot (no acrylic)
OP =One Piece (no center slot)
GC =Clear acrylic
GG =Clear acrylic / Green projected color face
GB =Clear acrylic / Blue projected color face
GR = Clear acrylic / Red projected color face
ORDERING INFORMATION Explanation of Catalogue Number Example: QVS2GPTOS232120SO
SPECIFICATIONS
MATERIALS: One piece chassis constructed from die formed
20 gauge cold rolled steel. Reflectors - Semi-specular matte aluminum
reflector with lenghtwise ridges. Soft white acrylic film on inside of lamp
shield conceals lamp image.
FINISH: Chassis exterior - phosphate undercoating, baked white acrylic
matte high reflectance paint finish.
ELECTRICAL: Rapid start HPF, thermally protected class “P” ballast (Bi-tube
type). If K.Os are within 3” of ballast use wire suitable for at least 90C.
LABELS: Listed by CSA, UL
QVS2GPTOS232
QVS
QUALITY
VISUAL
STATIC
2
FIXTURE
WIDTH
G
CEILING
TYPE
PT
LAMP
SHIELD
LAMP
QUANTITY
LAMP/FIXTURE
LENGTH
120
VOLTAGE
120,277
347
SO
OPTIONS
Standard exposed
T-grid ceilings
(NOMINAL 24”)
32 = 32W T8
R =Radio Interface Filter
O =Emergency Lighting
System (for Canada)
N =Emergency Lighting
System (for U.S.)
Recessed direct
indirect soft light
optical system
PT=Semi-
specular matte
reflector /
Microperforated
mesh
lamp shield
CLEAR POLISHED
ACRYLIC DROP
DOWN VISUAL ELEMENT
We reserve the right to change, materials and finish in any way that will not alter installed appearance or reduce function and performance.
ALTER METALYTE
2’ X 4’ RECESSED DIRECT/INDIRECT FLUORESCENT
OS 2 32
2’
BALLAST
SO: 2 LPB T8 Elect.
PS: T8 PowerSpec HDF Dimming †
DA: iGEN DALI †
† Not available in 347V.
Genlyte Thomas Company
631 Airport Road, Fall River, MA 02720 - Tel. [phone]
C.F.I. Division of Canlyte, Inc.
525 Education Road, Cornwall, Ontario
Canada K6H 6C7 - [phone]
