Lightolier Lytespan DR2C User manual

Lightolier a Genlyte company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2006 Genlyte Group LLC • B1107
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lytespan®Track Lighting System DR2C
Page 1 of 1 Director®Sequencing Laser Remote Control
Ordering Information
Catalog No. Finishes Luminaire Compatibility
DR2C Silver Compatible with all Lytespan, ProSpec and Monopoint Director Remote Controlled luminaires.
Description
Hand-held controller equipped with a laser and infrared transmitters that is
used to aim and change light levels of Director luminaires from a remote
location. The visible laser selects the unit and allows it to receive movement
and dimming commands by infrared. The laser signal accuracy allows a single
unit to be easily selected, however any number of Director luminaires can be
controlled by a single controller. The controller allows the user to remotely aim
the unit, set the light level and set up timed sequences of moves.
Features
1. LCD Display
2. Tilt Up
3. Select: Activates laser.
4. Tilt Down
5. Step: Allows stepping through a sequence one position at a time.
6. Edit: For editing a position.
7. Go: Starts a sequence
8. Record: For recording a sequence.
9. Global Command Buttons: Allows recording and recalling of a sequence
for a group of Directors without the need to select them first with the laser.
10. Pan Right
11. Pan Left
12. Dim Up (low voltage Directors only)
13. Dim Down (low voltage Directors only)
14. Cancel
Electrical
Uses (3) AAA batteries (provided).
2 3/16”
(55)
5 11/16”
(145)
