Lytespan Lighting LLACSW
Page 1 of 2 ColorWash LED Surface Wall-Washer
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • C0708
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
8
13
2
1
5
12
9
6
7
Features
1. Power Control Module: Extruded aluminum. High power factor power
supply unit. Thermally protected, Class 2, short circuit protection. Solid
state controller and driver. Providing power and data to accurately control
LED array. Thermally protected.
2. Synchronizer: Printed circuit board (PCB) mounted. With a sensitive capter
and audible captation fo rthe 4 button controller.
3. 4-Button Controller: 4 button interface allows selection of light show
and variation of intensity. Molded polycarbonate. Digital.
4. DMX Connector: Two RJ45e jacks mounted on printed circuit board (PCB),
for DMX connection and an exit for daisy chain mounting. Uses standard
CAT5 round 8 conductor stranded twisted pair shielded network cables.
5. Pivot w/Lock: Die-cast aluminum. Adjusts the aiming angle up to 120°
with a locking screw, using a 3/16" Allen key tool.
6. LED Optic Housing: Extruded aluminum. Integral heat sink and color
mixing chamber.
7. LED Array: 48 High-power linear lighting emitting diodes (LED) red, green,
blue and amber (RGBA). Thermally protected with color sensor for accurate
color adjustment over life.
8. LED Optics: Asymmetrical MicroBlend technology ensures smooth
washing and color uniformity and minimizes undesirable color fringing.
9. Lens: Tempered glass, fine prisms provide additional mixing at the
aperture and minimizes the appearance of the individul RGBA sources.
10.Wiring: 10 amperes SVT 2 wire cord with grounded plug. 8 feet.
11. ON/Off Switch: Rocker switch to disconnect power to the power supply unit.
12.Splice Door: 18 gauge steel. 7/8" (222.3 mm) K.O. accepts 3/8" low
profile connector for hardwiring in continuous row for flexible conduit.
Two connectors are included in the luminaire.
Features (continued)
13.Mounting Bracket: 14 Gauge steel. Pivots 360° to permit any type of
mounting with aligning features for accurate positioning.
Dimming
Not compatible w/dimmers.
Finish
All painted finishes are baked powder or enamel.
Labels
cULus, Suitable for damp locations.
Catalog No. Finish Specifications Mounting
LLACSWWH
LLACSWBK
LLACSWAL
White
Black
Aluminum
120V - 60Hz Portable luminaire not recommended for grid ceiling only. Designed for other
ceiling types, floor or wall (vertical and horizontal).
5" (129mm)
4-1/2" (114mm)
2-5/8" (65mm)
11
3
19-1/4" (489mm)
21-7/8" (576mm)
10
1-7/8" (46mm)
3-1/8" (80mm)
2" (51mm)
4
Isometric View

Lightolier is a Philips group brand
Job Information Type:
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • C0708
Lytespan Lighting LLACSW
Page 2 of 2 ColorWash LED Surface Wall-Washer
2' From Wall - Single 2' From Wall - 2' On Center 2' From Wall - 3' On Center 2' From Wall - 4' On Center
1 1 12 56 12 1 1 84 83 84 164 48 64 159 25 59
2 2 17 49 17 2 2 87 87 87 261 56 61 253 34 59
3 2 12 26 12 2 3 57 57 57 338 38 38 331 26 31
42 7 12 7 2 431 31 31 421 21 21 416 15 16
514541518 18 18 512 12 12 5 9 9 9
612321 611 11 11 68786555
711111 7888 7555 7444
811111 8666 8 4 4 4 8 333
901110 9 4 4 4 9 333 9222
3' From Wall - Single 3' From Wall - 3' On Center 3' From Wall - 4' On Center 3' From Wall - 5' On Center 3' From Wall - 6' On Center
1 2 10 25 10 2 1 34 32 34 128 20 28 127 13 27 126 825
2 3 13 27 13 3 2 41 41 41 233 28 33 230 19 30 228 13 28
3 3 13 23 13 3 3 40 40 40 330 29 30 326 21 26 325 15 25
4310 15 10 3431 31 31 423 23 23 419 18 19 417 13 17
53797 3 522 22 22 516 16 16 513 13 13 511 10 11
6 2 4542 6 15 15 15 611 11 11 6999 6 7 7 7
723332 710 10 10 7 7 7 7 7 6 6 6 7 555
812221 8777 8 5 5 5 8 4 4 4 8 333
911111 9 5 5 5 9 4 4 4 9 333 9333
Lighting Data (All data is based on 3000K color temperature and 45º tilt)
Example: With multiple units
located 3' from wall and spaced
4' on center, the illumination on
the wall 3' down from ceiling
will be 30 f.c. beneath units
and 29 f.c. between units.
Footcandle values are avaraged
and rounded off and are based
on a minimium of five units.
600
30°
60°
450
300
150
Color Temperature: 3000K
Max. Tilt: 45º
Report No: 22906
1
2
3
4
5
6
7
8
LIGHTOLIER
LYTEMODEÆ DMX
Control System
Strand Lighting
Accent DMX
DMX512 Out
DMX512 In
DMX512 Out
To Next Luminaire
or
RJ45 DMX Terminator
(Required to terminate
the last luminaire in the
same data line)
Entertainment
Technology
DMX Control
OPTIONS
DMX512
Systems*
RJ45 jacks
Color-Changing Adjustable Wall Washer
120VAC 50/60HZ. Power Input 120VAC 50/60HZ. Power Input
DMX512 In
RJ45 jacks
Shielded CAT5 (8) wires round cable with RJ45 connectors (by others) CAT5 (8) wires round cable with RJ45 connectors (by others)
Option
Option
Option Input Power
120 - 240VAC 50/60HZ.
120VAC 60 HZ.
Power Input
XLR-5(Femal port)
MARQUEEÆ PC DMX INTERFACE
USB Port to PC
DMX512 Cable
Compatible DMX controls by Lightolier Controls www.lolcontrols.com
Lightolier or other
Standard DMX512
Interface Control
1-7/8" (46mm)
3-1/8" (80mm)
2" (51mm)
4
1-7/8" (46mm)
3-1/8" (80mm)
2" (51mm)
4
LLACSW
DMX Network
Surface
Luminaires
Accessories
Addressable Interface Kit: Cat. No. CLEDAIK
Load addresses and select operating mode for
DMX protocol, load serial numbers and specific
lighting preset, update firmware to each LED
lighting unit
DMX Terminator: Cat. No. CLEDDMXTERM
