Lightstar AIRLITE Series User manual

AIRLITE Series
User Manual

User Manual
Version: 23. Dezember 2021, 11:37 AM
Lightstar Lights
[email protected]

Table of Contents
Product Overview 1
Product Features 1
Technical Information 2
Operational Instructions 3
DMX Control 5
Wireless DMX Control 6
Notice and Maintenance 7
Service Warranty Ordinance 8

1
Product Overview
Product Features
Lightstar LED Airlite is a Bi-Color LED Balloon light. It features:
- high efciency
- low power consumption
- low operating temperature
- Color temperatures from 2800 - 6500K
- DMX and Wireless DMX
• 360° light illumination
• self inateable system - replenishes air automatically
• high quality bi-color light, CRI = 95
• brightness adjustable from 0 - 100%
• color temperature adjustable between 2800K and 6500K
• luminous ux output stays relatively stable when temperature is adjus-
ted
• supports DMX512 protocol
• LCD software control, easy to operate
• adjustable frequency from 1Hz to 50Hz
• no UV output
• lamp and power-supply are easy to maintain

2
Technical Information
SKU: LMSA-2000
Description: Bi-Color LED Spotlight
Power: 1000W
Material: different materials
Cooling: Active Cooling
Color Temperature: 2800-6500K
Dimming: 0-100%
CRI: 95
TLCI: >96
AC Input (indirect): 100-240V AC
Control: DMX In- & Output (5-Pin XLR socket)
Frequency: 1-50Hz
IP Class: IP20
Diameter (inated): 1800mm
Dimensions: 300 x 1500mm
Weight: 8‘000g

3
Operational Instructions
Connect the power supply to the input socket of the lamp head. The
fan will inate at 100% speed automatically. After 10 seconds, the light
brightness will turn on 10%. 1 minute later, the light brightness becomes
100%. 2 minutes later, the light is fully infated and it enters the fan mode
to sustain the air level. The fan turns to 20% speed to sustain air level and
reduce operation noise.
Enter fan mode from menu, or click button E to enter the silent fan mode.
This will reduce noise a lot - due to the reduced fan speed of 15%. The fan
control function is not available under fan mode. If you need more ina-
tion, turn off the silence mode.
Once the lamp is restarted, it will power on. According to above mentioned
procedure it will inate at full speed for 2 minutes. To prevent overload of
air, you can click button E to stop the ination.
The home screen shows the brightness value which can be adjusted by
turning the adjustment knob on the right side of the display. Select button
A to adjust color temperature. Select button A or M to switch back to the
home screen.
100%
3200K
Figure 1 - Brightness Adjustment
- > > - - - - - - - - - - - - - -
3200CCT
K
Figure 2 - Temperature Adjustment
100%

4
Light Mode
DMX Setup
FAN Mode
Figure 3 - Menu Screen
Bi-Color
Strobe
LIGHT MODE
Figure 4 - Light Mode Screen
Information
Select button M or quick link button E to enter light mode selection screen.
At light mode selection screen, select quick link button A/B to enter light
mode. Select button E to enter light parameter adjustment screen.
On the light mode screen, select the corresponding adjustment parame-
ters by selecting operating buttons, and then adjusting the parameter data
by adjusting the knob. The same prosedure goes throught the menu, as
well as in the FAN mode.
Brightness
Strobe
Strobe Set
Figure 6 - Strobe Mode Screen
Brightness
Color
Bi-Color
Figure 5 - Brightness Mode Screen
Duty Cycle
FAN Mode
Figure 7 - Fan Mode Screen
80% 50%
3000K 5000K
1Hz
Frequency
50%

5
DMX Control
There are two kinds of DMX signal control: Wireless DMX and DMX. By
default, DMX is selected. There are 5-Pin XLR In- & Outputs on the console
for DMX via cable. For wireless DMX, there is an antenna mounted on the
side of the ballast.
DMX512 Data Pinout is as followed:
Pin 1 Data Link Common GND
Pin 2 Signal GND
Pin 3 Signal +
Pin 4 not used
Pin 5 not used
On menu screen, select DMX to adjust DMX settings. By turning the ad-
justment knob, you can select the start address from 1 - 512.
Further adjustments are made as mentioned before.
DMX Add
WDMX Switch
DMX Switch
DMX SETUP
Figure 1 - DMX Setup Screen
001
on
off

6
Wireless DMX Control
Click the push button to show current ID settings. Click the push button to
increase number.
1 - Red
2 - Green
3 - Yellow
4 - Blue
5 - Purple
6 - Bluish Green
7 - White
Working Status:
LED is always on no DMX or no signal
Red LED ashing sending
Green LED ashing receiving
RF freqency features 126 bands, which are selected automatically to avoid
interference.
Communication
1. Power on the transmitter and receiver
2. Press key, set same ID for transmitter and receiver. If there is more than
one group of wireless LAN, make sure the ID of each network is different.
3. After sender receives DMX data, the sender will select a non-interfering
frequency band. The receiver will change communication bands until the
same ID data is found (green LED ashes). If DMX data communication
has been established, LED will blink faster.

7
Notice and Maintenance
1. LED‘s operating temperature range must be guaranteed between - 20°C
to +40°C. Overheating or undercooling can both reduce the xtures life
span.
2. The product must be placed on a solit, at and dry surface. The surface
temperature should be less than 50°C. Avoid exposure to direct sunlight
and operation in an enviroment with high humidity or explosive gas.
3. Do not beat, knock or shake the light violently or it may inuence the
normal use of the light.
4. Do not cover lamps with paper, cloth or similar materials that could
ignite due to high temperature.
5. Put the lamp in a cool and dry place when you do not use it for a long
time.
6. Avoid any ammable liquid, water or metal material entering the machi-
ne. Cut off the power supply as soon as this happens.
7. Do not use machines in dirty and dusty environments and clean them
regularly.
8. The technicians must get professional trainings to install, operate or
repair LED‘s.
9. If any equipment from Lightstar doesn‘t work properly, please get in
contact with a Lightstar special repair department or professional techni-
cian. Do not disassemble or reassemble the parts by yourself.

8
Service Warranty Ordinance
Customers enjoy a one-year free warranty service as of the date of purcha-
sing our product.
1. If the expiry date of the warranty is reached, our product can still be
repaired for an according price.
2. In any of the following circumstances, the product is not repaired free of
charge, whether the warranty period expires or not.
- Damage caused by misuse or abuse, disassembly and non-original parts
replacement.
- Damage caused by natural disasters, unconventional voltage and envi-
ronmental factors
3. Lightstar will remain in the power of interpretation.
4. Software version modication without further notice.
