Liko UltraSling Mod. 06 User manual

Liing extremely heavy paents demands specially developed
assisve devices and methods. Liko has developed the Ultra
product series to enable caregivers to li heavy paents both
safely and comfortably.
UltraSling supports the enre back right up to the shoulders. Its
design allows each leg support to be connected to the slingbar
individually, allowing more room for the stomach and opmal
support for the legs.
We recommend that at least two caregivers assist during the
transfer.
UltraSling is used in combinaon with Liko’s UltraTwin™ li
system. Depending on which individual accessories are used,
the system will li maximum load of 500 kg (1100 lbs.). Versions
of the UltraTwin system are available for both permanent
installation and for freestanding installation, e.g., on Liko
FreeSpan™ system.
Product Descripon
In this document, the person being lied is referred to as the paent and the person helping them is referred to
as the caregiver.
Liko™ UltraSling Mod. 06
Instrucons for Use
7EN160121 Rev. 5
ENGLISH 2020
IMPORTANT!
Liing and transferring a paent always involves a certain level of risk. Read the instrucons for use for both the paent
li and liing accessories before use. It is important to completely understand the contents of the instrucons for use.
The equipment should only be used by trained personnel. Ensure that the liing accessories are suitable for the li used.
Exercise care and cauon during use. As a caregiver, you are always responsible for the paent’s safety. You must be aware
of the paent’s ability to make it through the liing situaon. If something is unclear, contact the manufacturer or supplier.

27EN160121 Rev. 5 • 2020 www.hillrom.com
These symbols can be found in this document and/or on the product.
Symbol Descripon
Symbol Descripon
Warning; this situaon requires extra care and aenon.
Read instrucons for use before use
CE mark
Legal manufacturer
Date of manufacturing
Product idener
Serial Number
Medical device
Do not dry clean
Do not iron
Tumble drying
Do not tumble dry
Washing
Symbol is always in combinaon with recommended temperature
in °C and °F.
Latex Free
Periodic inspecon
Do not bleach
Line drying in shade
Facing Out Direcon upwards and symbol on outside of equipment.
Facing Out Symbol on outside of equipment.
(01) 0100887761997127
(11) Y Y MM DD
(21) 012345678910
GS1 Data Matrix Barcode that may contain following informaon.
(01) Global Trade Item Number
(11) Producon Date
(21) Serial Number

37EN160121 Rev. 5 • 2020 www.hillrom.com
Safety Instrucons
Before liing, keep the following points in mind:
• A responsible person within your organizaon should decide on a case-by-case basis whether one or more caregivers are
needed.
• Ensure that the sling selected meets the paent’s needs with reference to model, size, fabric and design.
• For safety and hygiene reasons, use individual slings.
• Plan the liing operaon so that it can be done as safely and smoothly as possible.
• Check that the liing accessory hangs vercally and can move freely.
• Although the Liko sling bars are equipped with latches, special cauon must be exercised. Before the paent is lied from
the underlying surface, but when the straps are fully extended, make sure the straps are correctly connected to the sling
bar hooks.
• Make sure the paent is sing securely in the sling before transferring to another locaon.
• Never li a paent higher o the underlying surface than is needed to complete the liing and transfer procedure.
• Never leave a paent unaended during a liing situaon.
• Make sure that the wheels on the wheelchair, bed, gurney, etc., are locked during the liing/transfer operaon.
• Always work ergonomically. Use the paent’s ability to acvely parcipate in the operaons.
• When the sling is not being used, do not place in direct sun light.
• It is recommended to remove the sling aer the transfer.
Incorrect aachment of sling to slingbar may cause severe injury to the paent.
Manually turning the paent in bed may cause injuries to the caregiver.
Product Changes
Liko’s products undergo connuous development, which is why we reserve the right to make product changes without prior
noce. Contact your Hill-Rom representave for advice and informaon about product upgrades.
Design and Quality by Liko in Sweden
Liko is quality cered according to ISO 9001 and its equivalent for the medical device industry ISO 13485.Liko is also cered
according to environmental standard ISO 14001.
Noce to Users and/or Paents in EU
Any serious incident that has occurred in relaon to the device, should be reported to the manufacturer and the competent
authority of the Member State in which the user and/or paent is established.
Medical Device Class I Product

47EN160121 Rev. 5 • 2020 www.hillrom.com
Denions
1. Upper strap loop
2. Handles
3. Outer leg support loop
4. Product label
5. Label: Periodic Inspecon
6. Label: Individual marking (Belongs to)
7. Center back strap
8. Lower edge
9. Leg support
10. Inner leg support loop
146
5
9
32
8
7
Check the sling before each use. Check the following points with regard to wear and damage:
• Fabric
• Straps
• Seams
• Loops
Do not use damaged liing accessories.
If anything is unclear, please contact the manufacturer or supplier.
Washing Instrucons: Please see the sling’s product label and the aached appendix ”Care and Maintenance of Liko Slings”.
Periodic Inspecon
The product must be inspected at least once every 6 months. More frequent inspecons might be required if the product is used
or washed more oen than normal. For protocols please contact your Hill-Rom representave.
Expected Life Time
The product has an expected life me of 1-3 years with normal use. Expected life me varies depending on the fabric, use
frequency, washing procedure, and weight carried.
Recycling Instrucons
The enre sling, including laths, padding material, etc. should be sorted as Combusble waste.
Hill-Rom evaluates and provides guidance to its users on the safe handling and disposal of its devices to aid in the prevenon
of injury, including, but not limited to: cuts, punctures of the skin, abrasions, and any required cleaning and disinfecon of the
medical device aer use and prior to its disposal. Customers should adhere to all federal, state, regional, and/or local laws and
regulaons as it pertains to the safe disposal of medical devices and accessories.
If in doubt, the user of the device shall rst contact Hill-Rom Technical Support for guidance on safe disposal protocols.
Maximum load
Dierent maximum allowable loads may apply to dierent products on the assembled li system: rail system, li unit, slingbar,
sling and other accessories used. For the total li system, the lowest maximum allowable load indicated for the respecve
products on the system applies. For Liko UltraSling to be able to carry a weight of 500 kg (1100 lbs.), both the li unit, slingbar
and other accessories used must be approved for this maximum load. If quesons please contact your Hill-Rom representave.
Care and Maintenance
10

57EN160121 Rev. 5 • 2020 www.hillrom.com
Upper strap loop
Inner leg support loop
Outer leg support loop
C
C
B
B
A
A
How to Aach a Ultra Sling to a Sling Bar
1. Place the sling behind the paent’s back, with the label facing outward and upward. With the palm of your hand, guide the
lower edge of the sling down to the paent’s tailbone.
2. Place the leg supports alongside the outside of each thigh, so that the fabric of the lower edge of the sling is fully
extended.
3. Push the leg supports under the paent’s legs, with the leg support loops placed under the fabric. When the leg support
fabric reaches the inside of the thighs, pull out the leg support loops. Pull both the inner and outer leg support loops unl
they have the same length.
4. Connect the strap loops to the slingbar. The upper strap loops are hooked to the wide slingbar and the leg support loops
are hooked to the narrower slingbar.
5. Li the paent.
For applicaon of UltraSling in the horizontal posion, we recommend Liko RepoSheet™ Original to avoid the neccesity of log
rolling the paent. For more informaon please contact your Hill-Rom representave.
Applying UltraSling in the sing posion:
BB
AA
The illustraons 1, 2, and 3 shows the use of slingbars
with two dierent width, the same principle applies if
you use two Universal Slingbar 600.
1.
2. 3.
A
B
C
C
C

© Copyright Liko R&D AB 2020. ALL RIGHTS RESERVED.
Product Prod. No. Size Material Max. load
Liko UltraSling 3506115 Regular Polyester 500 kg (1100 lbs.)
Overview Liko™ UltraSling Mod. 06
Liko AB
Nedre vägen 100
975 92 Luleå, Sweden
[phone]
Liko AB is a subsidiary of Hill-Rom Holdings Inc.
www.hillrom.com
Recommended Combinaons
Ultra Li System: We recommend two Universal Slingbar 600 (Prod. No. 3156086) or Universal SlingBar 450 (Prod. No. 3156085)
together with Universal SlingBar 600 (Prod. No. 3156086). If you use slingbars with two dierent widths, the wider of the two
sling bars is intended for use with the sling’s upper strap loops and the narrower sling bar is to be used with the leg support´s
strap loops.
