Limacorporate SMR Stemless User manual

STEMLESS
INSTRUMENT
DISASSEMBLY AND ASSEMBLY
INSTRUCTIONS

INSTRUMENT DISASSEMBLY / ASSEMBLY INSTRUCTIONS
Table of Contents
NOTE Consult also to the Instructions for Use “Instrument Care, Cleaning, Disinfect and Sterilization” downloadable from www.limacorporate.com
The present document refers to the SMR Instrument Sets 9013.57.000, 9013.58.000.
Guide for Resection Jig
9013.50.303
Pag. >> 06
06
Glenosphere Impactor-Extractor
9013.74.141
Pag. >> 10
10
Humeral Head Impactor
9013.22.100
Pag. >> 05
05
Reamer Shaft
9013.55.039
Pag. >> 08
08
Multipurpose Handle
9095.11.251
Pag. >> 12
12

SMR SYSTEM INSTRUMENT DISASSEMBLY/ASSEMBLY INSTRUCTIONS 5
INSTRUMENT DISASSEMBLY / ASSEMBLY INSTRUCTIONS
Humeral Head Impactor
01
DISASSEMBLY INSTRUCTION
Unscrew the pusher from the handle and then remove it.
Cod. 9013.22.100
(Humeral Head Impactor)
01
ASSEMBLY INSTRUCTION
To reassemble you have to reproduce the same step in reverse order.

6INSTRUMENT DISASSEMBLY/ASSEMBLY INSTRUCTIONS SMR SYSTEM
INSTRUMENT DISASSEMBLY / ASSEMBLY INSTRUCTIONS
Guide for Resection Jig
Cod. 9013.50.303
(Guide for Resection Jig)
01
02
DISASSEMBLY INSTRUCTION
Unscrew the threaded rod and separate it from the Guide for Resection Jig.
Turn counter-clockwise the red knob to disassembly the guide.

SMR SYSTEM INSTRUMENT DISASSEMBLY/ASSEMBLY INSTRUCTIONS 7
INSTRUMENT DISASSEMBLY / ASSEMBLY INSTRUCTIONS
Guide for Resection Jig
01
02
ASSEMBLY INSTRUCTION
To reassemble the Guide for Resection Jig you have to reproduce the same steps in
reverse order. Connect the two components and turn clockwise the red knob.
Afterwards screw the threaded rod into the Guide for Resection Jig.

8INSTRUMENT DISASSEMBLY/ASSEMBLY INSTRUCTIONS SMR SYSTEM
INSTRUMENT DISASSEMBLY / ASSEMBLY INSTRUCTIONS
Reamer Shaft
Cod. 9013.55.039
(Reamer Shaft)
01
Pull and hold the red part of the Reamer Shaft.
03
Remove the black handle.
DISASSEMBLY INSTRUCTION
Pull and Hold
02
Rotate the red part and slide it away from the Reamer Shaft.
A) Rotate B) Slide away

SMR SYSTEM INSTRUMENT DISASSEMBLY/ASSEMBLY INSTRUCTIONS 9
INSTRUMENT DISASSEMBLY / ASSEMBLY INSTRUCTIONS
Reamer Shaft
01
To reassemble the Reamer Shaft you have to reproduce the same steps in reverse
order.
To make sure that the locking mechanism is properly set the pin should be in the
neutral position.
ASSEMBLY INSTRUCTION
NEUTRAL

10 INSTRUMENT DISASSEMBLY/ASSEMBLY INSTRUCTIONS SMR SYSTEM
INSTRUMENT DISASSEMBLY / ASSEMBLY INSTRUCTIONS
Glenosphere Impactor-Extractor
Cod. 9013.74.141
(Glenosphere Impactor-Extractor)
01
Grasp the Glenosphere Impactor-Extractor and unscrew the internal shaft.
02
Slide the internal stem off the Glenosphere Impactor-Extractor.
DISASSEMBLY INSTRUCTION
A) Rotate
B) Slide away

SMR SYSTEM INSTRUMENT DISASSEMBLY/ASSEMBLY INSTRUCTIONS 11
INSTRUMENT DISASSEMBLY / ASSEMBLY INSTRUCTIONS
Glenosphere Impactor-Extractor
Cod. 9013.74.141
(Glenosphere Impactor-Extractor)
01
Thread the internal stem in the Glenosphere Impactor-Extractor.
02
Screw the internal shaft.
ASSEMBLY INSTRUCTION

12 INSTRUMENT DISASSEMBLY/ASSEMBLY INSTRUCTIONS SMR SYSTEM
INSTRUMENT DISASSEMBLY / ASSEMBLY INSTRUCTIONS
02
Remove the red button with rod from the posterior part of the Multipurpose Handle.
01
Disengage the red button using the 3.5mm Allen Wrench to rotate the red
button counter-clockwise.
DISASSEMBLY INSTRUCTION
Multipurpose Handle
Cod. 9095.11.251
(Multipurpose Handle)
+
Cod. 9013.50.211
(Allen Wrench 3.5mm)

SMR SYSTEM INSTRUMENT DISASSEMBLY/ASSEMBLY INSTRUCTIONS 13
INSTRUMENT DISASSEMBLY / ASSEMBLY INSTRUCTIONS
Multipurpose Handle
02
Fasten the red button to the Multipurpose Handle using the 3.5mm Allen Wrench
to rotate clockwise.
01
Insert the red button with rod into the posterior part of the Multipurpose
Handle.
ASSEMBLY INSTRUCTION
Cod. 9095.11.251
(Multipurpose Handle)
+
Cod. 9013.50.211
(Allen Wrench 3.5mm)

B.1355.63.001.1 101500
