DEMO MANUAL DC2221A
Description
LTC3807EFE
Low Quiescent Current,
High Voltage Step-Down Converter
Demonstration circuit 2221A is a low quiescent current,
synchronous buck converter featuring the LT C
®
3807EFE.
This demo board converts a 16V to 38V input voltage to
a 12V at 15A output.
The main features of this board include an internal LDO
for gate drive power from VIN or EXTVCC, RUN and
PGOOD pins, a mode selector that allows the converter
to run in constant current mode (CCM), pulse-skipping
or Burst Mode
®
operation, and selectable current limit.
The DC2221A supports an adjustable output voltage,
soft-start and tracking. The wide input voltage range of
16V to 38V is suitable for automotive and distributed DC
power systems where low quiescent current is important.
The LTC3807 data sheet gives a complete description of
this part, operation and application information. The data
sheet must be read in conjunction with this quick start
guide for demo circuit 2221A.
L, LT, LTC, LTM, Burst Mode, Linear Technology and the Linear logo are registered trademarks
of Linear Technology Corporation. All other trademarks are the property of their respective
owners.
performance summary
The 40V rated MOSFETs, which are used on DC2221A, can
be operated at their rated voltage. MOSFETs with higher
voltage rating can be used for more safety margin.
The DC2221A supports the LFPAK, PowerPAK SO-8 and
Power 56 MOSFET packages. The following logic level
(SV gate) MOSFETs can be used with DC2221A.
RJK0451DPB Renesas
BSC093N04LS G Infineon
Si4124DY Vishay
FDS8447 Fairchild
For synchronization to an external clock, remove jumper
JP2 and apply sync signal on terminal SYNC.
Design files for this circuit board are available at
http://www.linear.com
Specifications are at TA= 25°C
PARAMETER CONDITIONS VALUE UNITS
Minimum Input Supply Voltage 16 V
Maximum Input Supply Voltage 38 V
Output Voltage Range VIN = 16V to 38V, IOUT = 0A to 15A 12 ± 2% V
Typical Switching Frequency 120 kHz
Typical Output Ripple (VOUT, 12V) VIN = 24V; ILOAD = 15A 80 mV
Efficiency Typical (VOUT, 12V) VIN = 24V; ILOAD = 15A 97 %
Supply Quiescent Current VIN = 24V; VOUT = 12V, IO= 0A, Burst Mode 110 μA
Supply Shutdown Current VIN = 24V 38 μA

2
dc2221af
DEMO MANUAL DC2221A
Quick start proceDure
Demonstration circuit DC2221A is easy to set up to evalu-
ate the performance of the LTC3807EFE. Refer to Figure 1
for proper measurement equipment setup and follow the
procedure below:
NOTE. When measuring the input or output voltage ripple,
care must be taken to avoid a long ground lead on the
oscilloscope probe. Measure the input or output voltage
ripple by touching the probe tip directly across the VIN
or VOUT and GND terminals or directly across relevant
capacitor. See Figure 2 for proper scope probe technique.
1. Place jumper JP1 in the ON position.
2. With power off, connect the input power supply to VIN
and GND.
3. Turn on the power at the input. Check for the proper
output voltage:
VOUT = 11.9V to 12.4V
NOTE. If there is no output, temporarily disconnect the
load to make sure that the load is not set too high.
4. Once the proper output voltages are established, adjust
the load within the operating range and observe the
output voltage regulation, ripple voltage, efficiency and
other parameters.
Figure 1. Proper Measurement Equipment Setup
Figure 2. Measuring Input or Output Ripple Across Terminals or Directly Across Bulk Capacitor
LOAD
+
–
IOUT
VIN SUPPLY
+
–
IIN
+ –
VOUT GND
COUT
GND VIN

3
dc2221af
DEMO MANUAL DC2221A
Quick start proceDure
Figure 3. 12V Output, Efficiency vs Load, Burst Mode Operation, VIN 16V, 24V, 36V
89
90
91
92
93
94
95
96
97
98
99
0.1 1 10 100
Efficiency (%)
Load Current (A)
VIN = 36V
VIN = 24V
VIN = 18V

4
dc2221af
DEMO MANUAL DC2221A
parts List
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
Required Circuit Components
1 1 Q4 N Channel, MOSFET INFINEON., BSC093N04LS
2 1 Q2 N Channel, MOSFET INFINEON., BSC035N04LS
3 1 RS1 RES, 0.003Ω, 1W, 1%, 2512 PANASONIC ERJM1WSF3M0U
4 1 R1 RES., 2.2Ω, 1%, 0603 VISHAY, CRCW06032R20FNEA
5 3 R2, R8, R10 RES., 0Ω, 1%, 0603 VISHAY, CRCW06030000Z0EA
6 2 R4, R20 RES., 100k, 1%, 0603 VISHAY, CRCW0603100KFKEA
7 1 R5 RES., 511k, 1%, 0805 VISHAY, CRCW0805511KFKEA
8 1 R6 RES., 27.4k, 1%, 0603 VISHAY, CRCW060327K4FKEA
9 1 R7 RES., 35.7k, 1%, 0603 VISHAY, CRCW060335K7FKEA
10 1 R13 RES., 10Ω, 1%, 0603 VISHAY, CRCW060310R0FKEA
11 1 R15 RES., 2Ω, 1%, 0603 VISHAY, CRCW06032R00FNEA
12 1 R17 RES., 15.4k, 1%, 10603 VISHAY, CRCW060315K4FKEA
13 1 R18 RES., 1k, 1%, 0603 VISHAY, CRCW06031K00FKEA
14 1 C12 CAP., X7R, 4.7nF, 50V, 10%, 0603 YAGEO CC0603KRX7R9BB472
15 1 C14 CAP., NPO, 47pF, 50V, 5%, 0603 NIC, NMC0603NPO470J50TRPF
16 2 C25, C30 CAP., X7R, 2.2µF, 50V, 10%, 0805 TDK, C2012X7R1H225K125AC
17 1 D1 DIODE, SCHOTTKY, SOD-323 CENTRAL SEMI., CMDSH-4ETR
22 1 L1 IND., 8.6µH, Pulse., PG1083.103NL
23 1 C16 CAP., Sanyo, 150µF, 16V, 20% SANYO, 16SVPC150M
24 2 C2, C23 CAP., X7R, 10µF, 50V, 10%, 1210 AVX, 12105C106KAT2A
25 1 C15 CAP., X7R, 10µF, 16V, 10%, 1206 MURATA, GCM31CR71C106KA64L
26 1 C3 CAP., Sanyo, 82µF, 50V, 20% SANYO, 50HVH82M
27 3 C4, C9, C13 CAP., X7R, 0.1µF, 100V, 10%, 0603 MURATA, GRM188R72A104KA35D
28 1 C5 CAP., COG, 10pF, 50V, 5%, 0603 AVX., 06035A100JAT2A
29 1 C6 CAP., X5R, 4.7µF, 16V, 10%, 0805 MURATA, GRM219R61C475KE15D
30 2 C7, C17 CAP., X7R, 1µF, 16V, 10%, 0603 TDK, C1608X7R1C105K
31 1 C8 CAP., X7R, 1000pF, 10V, 5%, 0603 AVX, 0603ZC102JAT2A
32 1 U1 I.C., LTC3807EFE#PBF, LINEAR TECH., LTC3807EFE#PBF
Additional Demo Board Circuit Components
33 0 R3, R9, R11, R12, R19, R21 RES., OPTIONAL
34 R22, R23, R24, R25 (OPT) OPTIONAL
35 0 C11, C18, C19, C20, C21, C22, OPTIONAL
36 C24, C26, C27, C28, C29, C31-C34 (OPT) OPTIONAL
37 1 R14 RES., 1M, 1% 0805 VISHAY, CRCW08051M00FKEA
38 1 R16 RES., 57.6k, 1% , 0603 VISHAY, CRCW060357K6FKEA
39 0 Q3, D3, Q1 (OPT) OPTIONAL
Hardware: For Demo Board Only
40 1 FAB, PRINTED CIRCUIT BOARD DEMO CIRCUIT 2221A
41 10 E1-E10 TESTPOINT, TURRET, .094" MILL-MAX, 2501-2-00-80-00-00-07-0
42 2 JP1, JP2 JMP, 3-PIN, 1 ROW, 0.079" SULLINS, NRPN031PAEN-RC
43 2 XJP1, XJP2 SHUNT, .079" CENTER SAMTEC, 2SN-BK-G
44 4 J1, J2, J3, J4 CONN, BANANA JACK, KEYSTONE-575-4 KEYSTONE, 575-4
45 4 MTGS at 4 Corners STANDOFF, NYLON .5 1/2" KEYSTONE, 8833 (SNAP-ON)
