DEMO MANUAL DC1472A
DESCRIPTION
LTM4618EV:
6A Step-Down Power
µModule Regulator
Demonstration circuit 1472 features the LTM
®
4618EV
μModule
®
regulator, a complete high efficiency synchro-
nous buck regulator. The DC1472 input range is from 4.5V
to 26.5V and is capable of delivering up to 6A of output
current. However, current derating maybe necessary under
certain VIN, VOUT, frequency and thermal conditions. The
output voltage for the board is jumper programmable from
1.2V to 5V and can be set as low as 0.8V, the reference
voltage of the LTM4618EV.
Layout is simple, requiring only a few bulk input and output
capacitors externally. The TRACK/SS pin allows the user to
program the output voltage ramp-up and ramp-down, as
well as coincidentally or ratiometrically track an external
voltage. The LTM4618EV may be enabled or disabled by
the RUN pin. The MODE jumper (JP3) is available to select
L, LT, LTC, LTM, μModule, Burst Mode, Linear Technology and the Linear logo are registered
trademarks of Linear Technology Corporation. All other trademarks are the property of their
respective owners.
BOARD PHOTO
frompulse-skipping orBurst Mode
®
operationfor improved
efficiency at light load. DC1472 has a default switching
frequency of 500 kHz and is synchronizable to an external
clock from 250 kHz up to 750 kHz. These features and the
availability of the LTM4618EV in a compact 9mm ×15mm
×4.32mm LGA package make the demonstration circuit
ideal for use in many high density point-of-load regula-
tion applications. The LTM4618 data sheet must be read
in conjunction with this demo manual for working on or
modifying the demo circuit 1472A.
Design files for this circuit board are available at
http://www.linear.com/demo
Downloaded from Arrow.com.

2
dc1472af
DEMO MANUAL DC1472A
QUICK START PROCEDURE
PERFORMANCE SUMMARY
PARAMETER CONDITIONS/NOTES VALUE
Input Voltage Range 4.5V to 26.5V
Jumper Selectable Output Voltage, VOUT VIN = 4.5V – 26.5V, IOUT = 0A – 6A 1.2V, 1.5V, 1.8V, 2.5V, 3.3V or 5V ±2%
Maximum Continuous Output Current Derating is Necessary for Certain Operating Conditions.
See Data Sheet for Details
6ADC
Default Operating Frequency R3 = 10kΩ, R4 = 3.16kΩ 500kHz
External Clock Sync. Frequency Range 250kHz to 750kHz
Efficiency VIN = 12V, VOUT = 2.5V, IOUT = 6A 88.7% See Figure 2
Demonstration circuit 1472 is easy to set up to evaluate the
performance of the LTM4618EV. Please refer to Figure1
for proper measurement equipment setup and follow the
procedure below.
1. With power off, connect the input power supply, load
and meters as shown in Figure 1. Preset the load to 0A
and VIN supply to be 0V. Place jumpers in the following
positions for a typical 1.5VOUT application:
JP6 JP3 JP4 JP2
VOUT Select MODE RUN TRACK/SS
1.5V CCM OFF SS
2. Turn on the power at the input. Increase VIN to 12V
(Caution: Do not hot plug the input supply or apply
more than the rated maximum voltage of 26.5V to the
board or the part may be damaged).
3. Set the RUN pin jumper (JP4) to the on position. The
output voltage should rise to 1.5V. The output voltage
meter should read the selected output voltage ±2%.
4. Vary the input voltage from 6V to 24V and adjust the
load current from 0A to 6A. The output voltage meter
should read the selected output voltage ±2%. Set the
input voltage to 12V and the load current to 6A.
5. Measure the output voltage ripple at J5 with a BNC
cable and oscilloscope.
6. To set the output voltage to 5V, turn off the input supply
power, apply the following changes listed below and
repeat steps 2 to 5:
JP10 JP3 JP4 JP2
VOUT Select MODE RUN TRACK/SS
5V CCM OFF SS
7. Set the load current to 0A. Set the RUN pin jumper
(JP4) to the OFF position. Power off the input supply.
8. For loadtransient tests,apply an adjustablepositive pulse
signal between IOSTEP CLK and GND test points. The
pulse amplitude sets the load step current amplitude.
The pulse width should be short (<1ms) and pulse duty
cycle should be low (<15%) to limit the thermal stress
on the load transient circuit. The load step current can
be monitored with a BNC connected to J6 (10mV/A).
Downloaded from Arrow.com.Downloaded from Arrow.com.

3
dc1472af
DEMO MANUAL DC1472A
QUICK START PROCEDURE
Figure 1. Proper Measurement Equipment Setup
+
A
V
–
+
V
+
–
A
–+
+–
VIN
LOAD
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

4
dc1472af
DEMO MANUAL DC1472A
Figure 2. Measured Supply Efficiency at 12VIN and 24VIN
Efficiency vs Load Current, 12VIN
Efficiency vs Load Current, 24VIN
QUICK START PROCEDURE
LOAD CURRENT (A)
0
EFFICIENCY (%)
80
85
DC1472 F02a
75
70 246
95
90
5VOUT
3.3VOUT
2.5VOUT
1.8VOUT
1.5VOUT
1.2VOUT
fSW = 500kHz
CCM Mode
LOAD CURRENT (A)
0
EFFICIENCY (%)
80
85
DC1472 F02b
75
70 246
95
90
5VOUT
3.3VOUT
2.5VOUT
1.8VOUT
1.5VOUT
fSW = 500kHz
CCM Mode
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

5
dc1472af
DEMO MANUAL DC1472A
VIN (V) VOUT (V) COUT BULK COUT CERAMIC
12 1.5 330μF/6.3V POSCAP 1 ×47μF 10V
VIN (V) VOUT (V) IOUT (A) AIRFLOW AMBIENT (°C)
12 1.5 6 Natural Convection 27
Figure 3. Measured Load Transient Response (0A to 6A Load Step)
Figure 4. Measured Thermal Capture
QUICK START PROCEDURE
VOUT
100mV/DIV
IOUTSTEP
5A/DIV
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

6
dc1472af
DEMO MANUAL DC1472A
PARTS LIST
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
Required Circuit Components
1 1 C5 CAP, 150μF 35V, ALUM SANYO, 35ME150WXV+TS
2 2 C6, C7 CAP, X5R, 10μF 35V, 1210 TAIYO YUDEN, GMK325BJ106MN-T
3 1 C12 CAP, X5R, 47μF 10V, 1210 TDK, C3225X5R1A476M
4 1 C14 CAP, POSCAP, 330μF 6.3V, 7343 SANYO, 6TPC330MA
5 1 C15 CAP, X5R, 1μF 10V, 0805 AVX, 0805ZD105MAT2A
6 1 C20 CAP, X7R, 0.1μF 16V, 0603 AVX, 0603YC104KAT2A
7 1 R1 RES., 121k 1/16W 1%, 0603 VISHAY, CRCW0603121KFKEA
8 4 R3, R11 RES., 10k 1/16W 1%, 0603 VISHAY, CRCW060310K0FKEA
9 1 R4 RES., 3.16k 1/16W 1%, 0603 VISHAY, CRCW06033K16FKEA
10 1 R5 RES., 60.4k 1/16W 1%, 0603 VISHAY, CRCW060360K4FKEA
11 1 R14 RES., 69.8k 1/16W 1%, 0603 VISHAY, CRCW060369K8FKEA
12 1 R16 RES., 48.7k 1/16W 1%, 0603 VISHAY, CRCW060348K7FKEA
13 1 R17 RES., 28.7k 1/16W 1%, 0603 VISHAY, CRCW060328K7FKEA
14 1 R18 RES., 19.1k 1/16W 1%, 0603 VISHAY, CRCW060319K1FKEA
15 1 R19 RES., 11.5k 1/16W 1%, 0603 VISHAY, CRCW060311K5FKEA
16 1 U1 IC, LTM4618EV LINEAR TECH., LTM4618EV LGA
Additional Demo Board Circuit Components
1 0 C1-C4, C16, C19, C21-C24 CAP, 0603 Optional
2 0 C8, C9, C10, C11, C13 CAP, 1210 Optional
3 2 C17, C18 CAP, X5R, 1μF 10V, 0603 TAIYO YUDEN, LMK107BJ105MA-T
4 0 R6, R8, R10, R12 RES, 0603 Optional
5 4 R7 RES., 10k 1/16W 1%, 0603 VISHAY, CRCW060310K0FKEA
6 1 R9 RES., 0.01Ω 5% 1W, 2512 IRC, LRC-LRF2512LF-01-R010-J
7 1 R15 RES., 10k 1/16W 1%, 0603 VISHAY, CRCW060310K0FKEA
8 1 R2 RES., 100k 1/16W 1%, 0603 VISHAY, CRCW0603100KFKEA
9 1 R13 RES., CHIP, 0, 1/16W, 0603 VISHAY, CRCW06030000Z0EA
10 1 D1 DIODE, ZENER 350MW 4.7V, SOT-23 DIODES INC., BZX84C4V7-7-F
11 1 Q1 XSTR, SUD50N03-10CP MOSFET SILICONIX, SUD50N03-10CP
Hardware
1 10 E1-E10 TP, TURRET, 0.094", PBF MILL-MAX, 2501-2-00-80-00-00-07-0
2 3 JP1, JP2, JP4 JMP, 1X3, 0.079" SAMTEC, TMM-103-02-L-S
3 1 JP3 JMP, 1X4, 0.079" SAMTEC, TMM-104-02-L-S
4 6 JP5, JP6, JP7, JP8, JP9, JP10 JMP, 1X2, 0.079" SAMTEC, TMM-102-02-L-S
5 4 J1, J2, J3, J4 JACK, BANANA KEYSTONE, 575-4
6 2 J5, J6 CONN, BNC, 5 PINS CONNEX, 112404
7 5 JP1-JP4, JP6 SHUNT, 0.079" CENTER SAMTEC, 2SN-BK-G
8 4 4 Corners STANDOFF, SNAP ON, 0.50" KEYSTONE, 8833
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

7
dc1472af
DEMO MANUAL DC1472A
Information furnished by Linear Technology Corporation is believed to be accurate and reliable.
However,no responsibility is assumed for its use. LinearTechnology Corporation makes no representation
that the interconnection of its circuits as described herein will not infringe on existing patent rights.
