VoiceDirector Device Configuration Guide
Linksys PAP2
Disclaimer
The content of this manual is subject to change without notice and should not be
construed as a commitment by the manufacturer, distributor, or service
provider. This manual is furnished for informational use only and the
manufacturer, distributor, or service provider assumes no responsibility for any
errors or inaccuracies that may appear herein.
Any services provided through this equipment are not intended to replace or be
a substitute for primary line voice services or Plain Old Telephone Service
("POTS") and are not meant to provide guaranteed Automatic Number
Identification or Automatic Location Information capabilities associated with 911
or E911 services or to permit access to 411 directory assistance services. The
manufacturer, distributor, or service provider will not be liable for any damages,
expenses, liabilities, risks, or harms arising out of or related to the services
provided through this equipment.
04.24.2006
Page ii
All manuals and user guides at all-guides.com

VoiceDirector Device Configuration Guide Linksys PAP2
Table of Contents
1. Linksys PAP2 ........................................................................ 1
STEP 1 – SETUP ACCOUNT................................................................ 1
STEP 2 – ACCESSING THE PAP2 ....................................................... 1
STEP 3 - LOGGING INTO THE WEB CONFIGURATION INTERFACE.... 1
STEP 4 – CONFIGURING THE PAP2 FOR OUTBOUND CALLING......... 2
STEP 5 – LINE-SPECIFIC CONFIGURATION...................................... 3
Page iii
All manuals and user guides at all-guides.com

VoiceDirector Device Configuration Guide Linksys PAP2
1. Linksys PAP2
This guide contains VoiceDirector configuration instructions for the Linksys PAP2
device.
STEP 1 – SETUP ACCOUNT
Make sure you have an account on the VoiceDirector server to which you are
connecting.
STEP 2 – ACCESSING THE PAP2
Connect an analog phone to the RJ-45 connector on the PAP2.
1. Using the telephone keypad, press the star key (*) four (4) times: ****.
You will be prompted to enter a code.
2. Enter the code 110 followed by the pound key (#).
The system announces the IP address. Write it down.
STEP 3 - LOGGING INTO THE WEB CONFIGURATION
INTERFACE
To log into the WRP200’s Web Configuration Interface:
1. Launch Microsoft©Internet Explorer.
2. In the Address bar, enter http://, followed by the IP address you wrote
down in step 3 above.
For example, if your IP address is 192.168.1.100 you would enter
http://192.168.1.100 in the Address bar.
3. Press the Enter key on your keyboard, or click the Go button.
The status screen displays. You are now logged into the PAP2’s Web
Configuration Interface.
Page 1
All manuals and user guides at all-guides.com

VoiceDirector Device Configuration Guide Linksys PAP2
PAP2 Web Configuration Screen
STEP 4 – CONFIGURING THE PAP2 FOR OUTBOUND
CALLING
1. Click on the Admin Login link in the upper right corner of the page, and
then click the switch to advanced view link.
PAP2 Web Interface – Main Window
2. Click the System tab, and in the Internet Connection Type section, click
the DHCP drop-down menu, and select yes or no.
Page 2
All manuals and user guides at all-guides.com

VoiceDirector Device Configuration Guide Linksys PAP2
System Tab
3. If you set DHCP to no, enter the Static IP, NetMask, and Gateway
information.
If you set DHCP to yes, continue to step 5.
4. Click the Save Settings button at the bottom of the page to save the
settings.
STEP 5 – LINE-SPECIFIC CONFIGURATION
1. Click the Line1 or Line2 tab at the top of the page, and in the NAT
Settings section, change the following setting:
Field Value
NAT Keep Alive Enable no
2. In the Proxy and Registration section (see the screen on the following
page), change the following settings:
Field Value
Proxy
NOTE: If using a DNS, do not
include “http://” in the Proxy
name. For example, if the DNS
name is 000.00.000.00, enter
000.00.000.00 as the Proxy.
Enter the
VoiceDirector
IP address or
DNS name.
Page 3
All manuals and user guides at all-guides.com
all-guides.com

VoiceDirector Device Configuration Guide Linksys PAP2
Field Value
Use Outbound Proxy no
Use OB Proxy In Dialog no
Make Call Without Reg yes
Ans Call Without Reg yes
DNS SRV Auto Prefix no
3. In the Subscriber Information section (as shown in the Line 1/2 Page
screen on the following page), enter a Display Name. This value can be
any alphanumeric string, such as your VoiceDirector extension or other
identifying information.
4. Enter the User ID (VoiceDirector extension) and Password (password).
IMPORTANT If using the two lines on the device, you must have a different
account and PIN for Line 1 and Line 2.
5. Click the Use Auth ID drop-down menu, and click no.
Page 4
All manuals and user guides at all-guides.com

VoiceDirector Device Configuration Guide Linksys PAP2
Line1/2 Page
Page 5
All manuals and user guides at all-guides.com

VoiceDirector Device Configuration Guide Linksys PAP2
6. Scroll to the Audio Configuration section (as shown in the Line 1/2 Page
screen on the previous page), and change the following settings:
Field Value
Preferred Codec Select VoiceDirector’s
primary codec.
Use Pref Codec Only no
G729a Enable yes
G723 Enable yes
G726-16 Enable no
G726-24 Enable no
G726-32 Enable no
G726-40 Enable no
DTMF Tx Method AVT
7. Click the Save Settings button to save the settings.
