Linksys USB10T User manual

USB Network
Adapter
he USB Network Adapter allows you to
instantly connect to a network from any
Windows 98, Windows 2000 USB-
enabled PC, notebook PC, or a USB hub.
Connect a standard Category 5 network cable to
one end of the adapter, connect the other end to
your PC or USB hub with a standard USB
cable, install the driver included, and go. You’ll
be networked in no time.
USB stands for Universal Serial Bus, a standard
for connecting peripherals to your PC with little
or no configuration, and without having to
open up your computer. The USB Network
Adapter also features a low power consumption
rate to preserve battery life if you’re using a
notebook. Connecting to a 10Mbps network has
never been easier.
• One B-type USB Port For a Standard USB
Cable
• One RJ-45 10BaseT Port For a 10BaseT
Twisted Pair Cable
• Connects to 10BaseT and 10/100 Ports and
Any USB Port on a Windows 98 or 2000 PC
• Compatible with Virtually All
USB-enabled PCs
• Fast 8Mbps Data Throughput with 6Mbps
Burst Transfer
• No External Power Supply Required
• Low Power Consumption Rate of 75mA
• Plug-and-Play Compatible with Windows 98 and
Windows 2000 for Easy Installation
• Free Technical Support and Driver Upgrades
• 1-Year Limited Warranty
•Connect to Any 10BaseT Ethernet
Network UsingYour USB Port
•Fast 8Mbps DataTransfer Rate
•Bus Powered --No External Power Supply
Needed
•Easy and Fast Installation
•Free Technical Support
•1-Year Limited Warranty
UUSSBBNNeettwwoorrkkAAddaapptteerr((UUSSBB1100TT))
T
Use your PC’s USB Port to Connect to
Any 10BaseT or 10/100 Network
NetworkThrough
YourUSBPort!
Features
Features
Benefits
Benefits

Specifications
Model Number USB10T
Standards IEEE 802.3, ISO 8802/3, USB version 1.1
Protocol CSMA/CD
Ports 1 10BaseT RJ-45 Port,
1 USB Type B (female) Port
Transfer Rate Maximum 8Mbps (Buffered)
Memory Buffer 32KB
Cabling Network: UTP/STP Category 3 or 5
100 meters (328 feet) Maximum
USB: Standard Shielded USB Cable
5 meters (16.4 feet) Maximum
Speed 10Mbps
Duplex Half Duplex
LEDs Link, Transmit/Receive
Environmental
Dimensions 3.2” x 2.1” x 1.0”
Unit Weight 2.0 oz.
Power Input 5V Bus Power from USB Host Controller
or USB Hub
Certifications FCC Class B,
CE Mark Commercial
Operating Temp. 32ºF to 104ºF (0ºC to 40ºC)
Storage Temp. -4ºF to 158ºF (-20ºC to 70ºC)
Operating Hum. 10% to 85%, Non-Condensing
Storage Hum. 5% to 90%, Non-Condensing
Package Contents
USB Network Adapter
• One USB Network Adapter
• One USB Cable
• One Driver Disk
• One User Guide and Registration Card
(Model No.: USB10T)
