Linksys AS1SMA Operation manual

Model No.
Product Data
Wireless
AS1SMA
Improve the reception of your wireless devices!
Relocate your antenna to avoid reflective or sig-
nal blocking obstacles
Mounts on a desktop, wall, or ceiling
The best place to locate wireless network antennas is out of the way of any reflective or signal blocking
obstacles such as furniture, cabinets, mirrors, or even people. The Linksys Antenna Stand allows you to
relocate your wireless networking device's current antenna, or better yet, a Linksys High Gain Antenna, to a
location with clearer signal paths to the other devices in your wireless network.
The Antenna Stand can be mounted up to 6 feet away from the wireless device. It comes with mounting
slots to attach it to the ceiling, high on a wall, or it can just stand on a tall bookcase or shelf. Note that
although the Antenna Stand's cable and connector cause some loss to the wireless signal, effective
placement of the antenna above signal obstacles can easily create a net gain in wireless communica-
tions range and reliability.
Increase your wireless network's performance with the Linksys Antenna Stand.
Antenna Stand
for SMA Connectors

Model No.
Product Data
Model No.
Linksys
A Division of Cisco Systems, Inc.
18582 Teller Avenue
Irvine, CA 92612 USA
E-mail: [email protected]
[email protected]
Web: http://www.linksys.com
Linksys products are available in more than 50
countries, supported by 12 Linksys Regional Offices
throughout the world. For a complete list of local
Linksys Sales and Technical Support contacts, visit
our Worldwide Web Site at www.linksys.com.
AS1SMA
Package Contents
• One Antenna Stand for
SMA Connectors
• Wall Mount screws
Works With:
•WRV54G
• WMP54GS
• WMP54G
• WET54G
• WET54GS5
• HGA7S (High Gain Antenna)
Specifications
Model Number AS1SMA
Connector one reverse SMA, one SMA
Cable Length 6 feet (152.4mm)
Environmental
Dimensions 7.87" x 1.81" x 2.80"
W x H x D (200 mm x 46 mm x 71 mm)
Unit Weight 7.58 oz. (0.22 kg)
Operating Temp. -4ºF to 149ºF (-20ºC to 65ºC)
Storage Temp. -22ºF to 167ºF (-30ºC to 75ºC)
Operating Humidity 0% to 85% Non-Condensing
AS1SMA-DS-40713NC KL
Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2004
Cisco Systems, Inc. All rights reserved. Other brands and product names are trademarks or registered trademarks of their respective holders.
Antenna Stand for SMA Connectors
Features
• Relocate your Wireless-B or Wire-
less-G antennas to avoid obsta-
cles and improve signal strength
• Easy to install and use, no config-
uration necessary
• 3-years limited warranty
