Linksys HomeLink HPB200 User manual

HomeLink
™
Series
Phoneline 10M
Ethernet Bridge
Use this User Guide to install the following Linksys product:
HomeLink Phoneline 10M Ethernet Bridge (Model No.: HPB200)
User Guide

COPYRIGHT & TRADEMARKS
Copyright © 2000 Linksys, All Rights Reserved. HomeLink is a registered trademark of
Linksys. Microsoft, Windows, and the Windows logo are registered trademarks of
Microsoft Corporation. All other trademarks and brand names are the property of their
respective proprietors.
LIMITED WARRANTY
Linksys guarantees that every HomeLink Phoneline 10M Ethernet Bridge is free from
physical defects in material and workmanship under normal use for one (1) year from the
date of purchase. If the product proves defective during this warranty period, call Linksys
Customer Support in order to obtain a Return Authorization number. BE SURE TO HAVE
YOUR PROOF OF PURCHASE ON HAND WHEN CALLING. RETURN REQUESTS CAN-
NOT BE PROCESSED WITHOUT PROOF OF PURCHASE. When returning a product,
mark the Return Authorization number clearly on the outside of the package and include
your original proof of purchase.
IN NO EVENT SHALL LINKSYS’ LIABILITY EXCEED THE PRICE PAID FOR THE PROD-
UCT FROM DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAM-
AGES RESULTING FROM THE USE OF THE PRODUCT, ITS ACCOMPANYING SOFT-
WARE, OR ITS DOCUMENTATION. Linksys makes no warranty or representation,
expressed, implied, or statutory, with respect to its products or the contents or use of this
documentation and all accompanying software, and specifically disclaims its quality,
performance, merchantability, or fitness for any particular purpose. Linksys reserves the
right to revise or update its products, software, or documentation without obligation to
notify any individual or entity. Please direct all inquiries to:
Linksys P.O. Box 18558, Irvine, CA 92623.
FCC STATEMENT
The HomeLink Phoneline 10M Ethernet Bridge has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in a residen-
tial installation. This equipment generates, uses, and can radiate radio frequency ener-
gy and, if not installed and used according to the instructions, may cause harmful inter-
ference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which is found by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment or device
• Connect the equipment to an outlet other than the receiver’s
• Consult a dealer or an experienced radio/TV technician for assistance
010

Linksys HomeLink™ Series Phoneline 10M Ethernet Bridge
Introduction
The HomeLink Phoneline 10M Ethernet Bridge
The Linksys HomeLink Phoneline 10M Ethernet Bridge offers a complete
Internet connection solution for your Home Phoneline network.The HomeLink
Bridge makes sharing your broadband access easier than ever. This unique new
device features two 10BaseT/100BaseTx RJ-45Ethernet ports and one
HomeLink RJ-11 Port. Plug in your cable modem or DSL modem’s 10BaseT
connection, then attach the bridge to the nearest telephone jack using standard
phone cables, and any computer on your Home Phoneline network can access
the Internet.
Do you want to share your cable or DSL modem on your 10BaseT/100BaseTx
network? You can add a PC at any time by connecting it to any telephone jack
in your wall—or you can uplink an entire 10BaseT/100BaseTx network for
instant communication. The groundbreaking technology inside every
HomeLink Bridge delivers communication between home phoneline networks
and Ethernet networks. With your HomeLink Bridge, that means instant
Internet sharing across both networks at blazing broadband speeds.
Table of Contents
Introduction 1
The HomeLink Phoneline 10M Ethernet Bridge 1
Features 2
Package Contents 2
Getting to Know the HomeLink Phoneline
10M Ethernet Bridge 3
Rear Panel Ports 3
Front Panel LEDs 4
Using the HomeLink Phoneline 10M Ethernet Bridge 5
Installation Overview 5
Connecting Your Devices to the Bridge 6
Daisy-chaining to a HomeLink Network 7
Resetting the Phoneline Ethernet Bridge 8
Appendix 9
Twisted Pair Cabling 9
Telephone Cabling 10
Specifications 11
Environmental 11
Linksys Warranty Information 12
1

Phoneline 10M Ethernet Bridge
3
Getting to Know the HomeLink
Phoneline 10M Ethernet Bridge
Rear Panel Ports
HPNA 2.0 Use the HPNA 2.0 port to connect your Broadband Bridge to
your HomeLink network. This port is configured as a pass-
through port, meaning that the network data travels into the
Bridge through one side of the HomeLink port, then continues
out the other. Connect one HomeLink telephone cable into one
side of Port 1, then continue (with another cable) to your next
HomeLink device through the port's other side.
LAN Connect an Ethernet PC (or an Ethernet device) to your
HomeLink phoneline network through one of the Bridge’s
10BaseT ports.
Uplink Share your Internet access over your entire phoneline network
by connecting to your DSL or Cable modem through the
Broadband Bridge's uplink port. The Uplink port can also con-
nect to Ethernet devices such as hubs, routers, and switches. If
the Uplink port is used, the port right next to it (LAN) will be
inoperable.Any connections made through a LAN will be lost.
Power Connect your power adapter to your HomeLink 10M Bridge
through the Power port.
Linksys HomeLink™ Series
Features
• Share High-Speed Internet Access On Your Network Using Your Existing
Telephone Line
• Share a Cable Modem or DSL Service Without Interrupting Normal
Telephone Service
• Seamlessly Integrates an Ethernet Network with a Home Phoneline
Network
• Stand-alone Unit withTwo 10BaseT/100BaseTx RJ-45 Ports and one RJ-11
Modular Telephone Port
• Bridges a 10Mbps Cable Modem or DSL Connection and a 1Mbps
HomeLink Connection
• Fully HomePNA 1.0 and 2.0 Compatible
• Easy Installation—No Software Required
Package Contents
• One HomeLink Phoneline 10M Ethernet Bridge
• One AC Adapter & Power Cord
• One User Guide and Registration Card
2

Phoneline 10M Ethernet Bridge
Using the HomeLink Phoneline 10M
Ethernet Bridge
Installation Overview
Since the HomeLink Phoneline 10M Ethernet Bridge is a stand-alone device
that requires no software or system configuration, its setup involves nothing
but plugging everything in and turning all your hardware on. However, there
are a few limitations to the amount of physical distance your network can cover
without running the risk of data corruption. These restrictions are due to
HomePNA and Ethernet standard limits on the recommended length of your
networking cables. (See below.)
Ethernet Cabling
Although there are different grades of Ethernet network cabling, you should
use UTP Category 5 (unshielded twisted-pair) cables for each Ethernet con-
nection you make, and no Ethernet cable should exceed 100 meters (328 feet)
in length. Category 5 cabling are available at most computer stores, or you can
crimp your own network cables. See page 10 for details on crimping.
HomeLink Phoneline Cabling
Due to the limitations of standard telephone cables, HomeLink phoneline
devices require that no network of HomeLink cabling exceeds a total length of
150 meters (500 feet). In other words, if you have more than 500 feet of tele-
phone wires connecting your network, you will be more likely to experience
data loss.
Any standard telephone cable will do.
5
Linksys HomeLink™ Series
Front Panel LEDs
Power The Power LED will light up when the HomeLink Bridge is pow-
ered on. Note that there is no ON/OFF switch; simply plug in the
power adapter.
Link A Link LED will light up above a specific port number (1, 2 or
3) if the corresponding port is successfully connected to a net-
work device.
TX A TX LED will light up above HPNA or LAN if the matching
port is currently sending data over the network.
RX A RX LED will light up above HPNA or LAN if the correspon-
ding port is currently receiving data over the network
.
4

Phoneline 10M Ethernet Bridge
Daisy-chaining to a HomeLink Network
Daisy-chaining your HomeLink PCs and peripherals can create a simple net-
work that acts in the same way an Ethernet network acts on your PC's desktop.
While Ethernet networks usually revolve in a star topology around a hub or
switch, phoneline networks link together like a string of Christmas lights. In a
HomeLink network, data passes into on one side of a port, and a new telephone
cable continues out from the port’s other side. You can string up to 25 PCs on
a single HomeLink network, provided that the entire length of cable does not
exceed 150 meters (500 feet).
HomeLink networks can send data through existing telephone lines without
disrupting your telephone service, connecting over your existing telephone
jacks. If you have PCs on two different floors of your house, plug one of the
downstairs PCs into the phone jack in the wall, and you're able to network your
PCs upstairs without running excessive amounts of extra cable.
7
Linksys HomeLink™ Series
Connecting Your Devices to the Bridge
The following instructions will have your HomeLink 10M Bridge up and run-
ning in minutes.
Basic Installation
1. Make sure that every component of your network (including your PCs
and HomeLink Bridge) is powered off.
2. Connect your Ethernet devices to the Bridge through the Bridge's
10BaseT ports. If you have several Ethernet devices, connect the Bridge to
a 10/100 Ethernet hub or switch. Ethernet devices should be connected to
the Bridge with a network cable that is less than 100 meters (328 feet) in
length.
3. Daisy-chain the Broadband Bridge into the HomeLink network by run-
ning HomeLinked telephone lines through the Bridge's HomeLink port.
The entire length of telephone cable used in a HomeLink network should
never exceed 150 meters (500 feet). For more detailed information on daisy
chaining, see the next page.
4. Power everything on. Connect the supplied power cord to the power
adapter, then to the Power port on the rear of the Bridge. Plug the power
cord into an electrical outlet.
The Phoneline 10M Ethernet Bridge installation is now complete.
6
NNoottee: Power everything off before connecting PCs to the
HomeLink 10M Bridge. If both the PC and the Bridge are powered
on when the initial connection is made, the network will act errat-
ically and you will have to reset the Bridge.

Phoneline 10M Ethernet Bridge
Appendix
Twisted Pair Cabling
There are different grades, or categories,
of twisted-pair cabling. Category 5 is the
most reliable and is highly recommended.
Category 3 is a good second choice.
Straight-through cables are used for con-
necting computers to a hub. Crossover
cables are used for connecting a hub to
another hub. There is an exception: some
hubs have a built-in uplink port that is
crossed internally, which allows you to
link or connect hubs together with a
straight-through cable instead.
You can buy pre-crimped Category 5 cabling, or you can cut and crimp your
own. Category 5 cables can be purchased or crimped as either straight-through
or crossover cables.A Category 5 cable has 8 thin, color-coded wires inside that
run from one end of the cable to the other. All 8 wires are used. In a straight-
through cable, wires 1, 2, 3, and 6 at one end of the cable are also wires 1, 2,
3, and 6 at the other end. In a crossover cable, the
order of the wires change from one end to the other:
wire 1 becomes 3, and 2 becomes 6. See the dia-
grams on the next page for more detailed informa-
tion on straight-through and crossover cabling.
To determine which wire is wire number 1, hold the cable so that the end of the
plastic RJ-45 tip (the part that goes into a wall jack first) is facing away from
you. Face the clip down so that the copper side faces up (the springy clip will
now be parallel to the floor).When looking down on the copper side, wire 1 will
be on the far left.
9
Linksys HomeLink™ Series
Resetting the Broadband Network Bridge
If your network connections begins acting erratically, you may want to reset the
bridge.
To reset your Bridge, do the following:
1. Shut down all of your network components.
2. Disconnect the Bridge's power supply and wait five seconds.
3. Plug the Bridge’s power supply back into the power outlet.
8

Phoneline 10M Ethernet Bridge
Specifications
Standards IEEE 802.3, IEEE 802.3u, HPNA 1.0 and 2.0
Compatible
Protocol CSMA/CD
Ports 1 RJ-11 Standard Modular Telephone Port
2 10BaseT/100BaseTx RJ-45 Ports
(Includes One Shared Uplink)
Cabling Type Phoneline: Standard RJ-11 Telephone Cable
10BaseT: UTP Category 3 or better
100BaseTx: UTP Category 5 or better
Topology Star or Daisy Chain
Speed 1Mbps or 10Mbps (Phoneline)
Full Duplex: 20Mbps or 200Mbps
Half Duplex: 10Mbps or 100Mbps
LEDs Power
HPNA: Link,Tx,Rx
LAN: Link,Tx,Rx
Environmental Specifications
Dimensions: 7.31" x 6.16" x 1.88" (186mm x 154mm x 48mm)
Unit Weight: 12 oz. (0.34 kg)
Power Input: External, 5V DC, 3A
Certifications: FCC Class B, CE Mark Commercial
Operating Temp.: 32°F to 122°F (0°C to 49°C)
Storage Temp.: -4°F to 158°F (-20°C to 70°C)
Operating Humidity: 10% to 85% Non-condensing
Operating Humidity: 5% to 90% Non-condensing
11
Linksys HomeLink™ Series
Telephone Cabling
The telephone cables you use to build your HomeLink network can be either
crossover or straight-through cables. The connectors on phone cables are called
RJ-11 connectors, and have four wires inside the plastic tips.
Standard telephone cables like the ones you use every day in your home should
do the job.
10
Environmental Specifications

© Copyright 2000 Linksys, All Rights Reserved.
http://www.linksys.com
Linksys HomeLink™ Series
Linksys Warranty Information
BE SURE TO HAVE YOUR PROOF OF PURCHASE AND A BARCODE
FROM THE PRODUCT'S PACKAGING ON HAND WHEN CALLING.
RETURN REQUESTS CANNOT BE PROCESSED WITHOUT PROOF OF
PURCHASE.
IN NO EVENT SHALL LINKSYS’LIABILITY EXCEED THE PRICE PAID
FOR THE PRODUCT FROM DIRECT, INDIRECT, SPECIAL, INCIDEN-
TAL, OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE
OF THE PRODUCT, ITS ACCOMPANYING SOFTWARE, OR ITS DOCU-
MENTATION. LINKSYS DOES NOT OFFER REFUNDS FOR ANY PROD-
UCT.
LINKSYS OFFERS CROSS SHIPMENTS,A FASTER PROCESS FOR PRO-
CESSING AND RECEIVING YOUR REPLACEMENT. LINKSYS PAYS
FOR UPS GROUND ONLY. ALL CUSTOMERS LOCATED OUTSIDE OF
THE UNITED STATES OF AMERICA AND CANADA SHALL BE HELD
RESPONSIBLE FOR SHIPPING AND HANDLING CHARGES. PLEASE
CALL LINKSYS FOR MORE DETAILS.
12
