Build a high-speed wireless network optimized for gaming!
Wireless-N
Gigabit Gaming Router Product Data
Model WRT330N
The Wireless-N Gigabit Gaming Router is really four devices in
one box. First, there’s the Wireless Access Point, which lets you
connect to the network without wires. There’s also a built-in
4-port full-duplex 10/100/1000 Switch to connect your wired-
Ethernet devices together at up to gigabit speeds. The Router
function ties it all together and lets your whole network share a
high-speed cable or DSL Internet connection.
We’ve also included a Network Optimizer that applies various
Quality of Service (QoS) techniques to your network traffic to
make sure that time-sensitive applications like online and local
network gaming run smoothly. It automatically determines what
data is time-sensitive and what isn’t, and prioritizes delivery
of that data to its destination, ensuring the best-possible
performance for the various types of data that go through your
network.
The Access Point built into the Router uses the very latest
wireless networking technology, Wireless-N (draft 802.11n). By
overlaying the signals of multiple radios, Wireless-N’s “Multiple
In, Multiple Out” (MIMO) technology multiplies the effective data
rate. Unlike ordinary wireless networking technologies that
are confused by signal reflections, MIMO actually uses these
reflections to increase the range and reduce “dead spots” in
the wireless coverage area. The robust signal travels farther,
maintaining wireless connections up to 4 times farther than
standard Wireless-G.
With Wireless-N, the farther away you are, the more speed
advantage you get. It works great with standard Wireless-G
and -B equipment, but when both ends of the wireless link are
Wireless-N, the router can increase the throughput even more
by using twice as much radio band, yielding speeds up to 12
times as fast as standard Wireless-G.
Share a high-speed Internet connection Play on-line and networked games lag-free Ultra-fast wired speeds with built-in Gigabit switch
WIRELESS

Wireless-N
Gigabit Gaming Router
Features
Internet-sharing Router and 4-port
Gigabit Switch, with a built-in speed
and range enhanced Wireless Access
Point
Optimizer for time-sensitive
applications provides reduced game lag
and cleaner sounding VoIP calls
MIMO technology uses multiple radios
to create a robust signal that travels
up to 4 times farther and reduces dead
spots
Up to 12 times as fast as Wireless-G,
and works great with Wireless-G, -B
devices
•
•
•
•
Specifications
Model WRT330N
Standards 802.11b, 802.11g, 802.3, 802.3u, draft 802.11n
Ports Power, Internet, Ethernet
Buttons Reset
LEDs Power Internet, Ethernet (1-4), Wireless, Security
Cabling Type CAT 5e
# of Antennas 3
Connector type N/A
Detachable (y/n) No
RF Pwr (EIRP) in dBm 14
Antenna Gain in dBi 1.5 dBi
Security features WEP, TKIP, AES
Security key bits 64, 128
Environmental
Device Dimensions W H D Weigh
Metric 188 40 176 mm 0.527 kg
English 7.40" 1.57" 6.93" 1.16 lbs or 18.59 oz
Power 12V 1.0A
Certification FCC, IC-03
Operating Temp. 32 to 122 degrees F (0 to 50 degrees C)
Storage Temp. -4 to 167 degrees F (-20 to 75 degrees C)
Operating Humidity 10 to 85% non-condensing
Storage Humidity 5 to 95% non-condensing
Linksys
A Division of Cisco Systems, Inc.
121 Theory
Irvine, CA 92617 USA
E-mail: sales@linksys
[email protected]
Web: http://www.linksys.com
Linksys products are available in more than 50
countries, supported by 12 Linksys Regional
Offices throughout the world. For a complete
list of local Linksys Sales and Technical Support
contacts, visit our Worldwide Web Site at
www.linksys.com.
Minimum Requirements Package Contents
Internet Explorer 5.5 or Firefox 1.0 or higher
CD-ROM Drive
Windows 2000 or XP
Network Adapter
•
•
•
•
Wireless-N Gigabit Gaming Router
Setup Wizard CD-ROM
User Guide on CD-ROM
Quick Install
Network Cable
Power Adapter
•
•
•
•
•
•
Model WRT330N
Check the product package and contents for specific features supported. Specifications are subject to change without notice. Linksys is a registered trademark or trademark of
Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2006 Cisco Systems, Inc. All rights reserved. Other brands and product names are
trademarks or registered trademarks of their respective holders.
WRT330N-DS-61121-NC-DF
