Linksys WAP54G - Wireless-G Access Point User manual

A Division of Cisco Systems, Inc.
®
Model No.
Model No.
Wireless Quick Installation Guide Wireless
1
Model No.
Quick Installation Guide
WAP54G (EU/LA/UK)
Access Point
Wireless-G
Package Contents
• Wireless-G Access Point
• Detachable Antennas
• Power Adapter
• Setup CD with User Guide
• Ethernet Network Cable
• Quick Installation (some models
may only have the Quick Installation
on the Setup CD)
GHz
2
802.11g
4
,

2
1
AConnect your Ethernet network
cable to your network router or
switch. Then connect the other
end of the network cable to
the Access Point’s LAN
(Ethernet network) port.
BConnect the included power
adapter to the Access Point’s
Power port. Then plug the
power adapter into an
electrical outlet. The LEDs on
the front panel will light up as
soon as the Access Point
powers on.
Connecting the Access Point
A
B

3
2
E
AInsert the Setup CD into your
PC's CD-ROM drive. The Setup
Wizard should run
automatically, and the
Welcome screen should
appear. If it does not, click Start
and select Run. Enter
D:\setup.exe (if “D” is the letter
of your PC's CD-ROM drive).
BOn the Welcome screen, click
Click Here to Start.
CThe following screens display
how the Access Point should
be connected during this
Setup Wizard. Optimally, you
should set up the Access Point
using a PC on your wired
network. Click Next.
DCheck the cable connecting
the Access Point to your
network router or switch. Click
Next.
EMake sure the Access Point is
powered on. Click Next.
Configuring the Access Point
B
C
D

4
FMake sure the Access Point’s
Power, Act, and Link LEDs are lit.
If they are not, check the
cable connections. Click Next.
GThe Setup Wizard will search for
the Access Point within your
network and display a list of all
access points. If more than
one are displayed, select the
Access Point by clicking on it.
Then click Yes to change its
settings.
HYou will be asked to sign onto
the Access Point you have
selected. Enter the default
password, admin. Then click
Enter.
IEnter a descriptive name in the
Device Name field and then
create a new password.
If your network router will
automatically assign an IP
address to the Access Point,
then select Automatic-DHCP.
If you want to assign a fixed IP
address to the Access Point,
then select Static IP. Enter an IP
Address, Subnet Mask, and the
IP address of your network
gateway (usually your router).
Then click Next.
F
G
I
H

5
JThere are two ways to
configure the Access Point’s
wireless settings.
If you have other
SecureEasySetup devices, then
proceed to “SecureEasySetup.”
Otherwise, proceed to
“Manual Configuration.”
SecureEasySetup
aLocate the SecureEasySetup
button for your devices. (You
can only add one device at a
time.)
bPress the Access Point’s Cisco
logo for only one second and
then release it.
cWait five to ten seconds. When
the logo turns white and begins
to flash, press the
SecureEasySetup button on
another device. The Access
Point’s Cisco logo will stop
flashing when the device has
been configured.
dRepeat steps b and c to add
more SecureEasySetup
devices.
eWhen you are finished, click
Next on the Configure Wireless
Settings screen.
e
NOTE: SecureEasySetup uses
WPA-Personal encryption. If your
current wireless devices do not
support WPA-Personal security,
then you cannot use
SecureEasySetup. You will need
to manually configure your
network security using the
encryption supported by your
existing devices.
NOTE: If you accidentally press
the Cisco logo for five to eight
seconds, then the Access Point’s
SSID and WPA-Personal settings
will be changed, and you will have
to re-configure all of your
wireless client devices.
NOTE: If you have already set up
your network using your router’s
SecureEasySetup feature, then
you cannot use the Access Point’s
SecureEasySetup feature. You
must manually configure the
Access Point’s wireless settings
to match your existing network’s
settings.

6
fReview the new settings, and
click Yes to save them.
NOTE: Write down these
settings. You may need
to manually configure
non-SecureEasySetup
devices in the future.
gClick Online Registration to
register the Access Point, or
click Exit to end the Setup
Wizard.
Congratulations! The installation of
the Wireless-G Access Point
is complete.
Manual Configuration
aOn the Configure Wireless
Settings screen, click Enter
Wireless Settings Manually.
bEnter the SSID or name of your
wireless network. Then select
the operating channel for your
network.
Select the mode for your
network. If you have 802.11g
devices only, select G-Only. If
you have 802.11g and
802.11b devices, keep the
default, Mixed Mode.
Click Next.
b
f
g
a

7
cSelect the level of security you
want to use: WEP, WPA/WPA2
Personal, WPA-Enterprise, or
Linksys Wireless Guard. Click
Next.
dFollow the appropriate
instructions.
WEP - Select the level of
encryption you want to use,
WEP (64-bit) or WEP (128-bit).
Enter a passphrase to
automatically generate a WEP
key, or manually enter the WEP
key in the Key 1 field.
NOTE: The WEP key can consist
of the letters “A” through
“F” and the numbers “0”
through “9”. It should be
10 characters in length
for 64-bit encryption or
26 characters in length
for 128-bit encryption.
Then click Next.
WPA/WPA2 Personal - Select
WPA Personal. Select TKIP or
AES for your encryption
method. Enter a passphrase of
8 to 32 characters and then
click Next.
c
WEP
WPA Personal

8
WPA2 Personal - Select WPA2
Personal. AES is automatically
selected as your encryption
method. Enter a passphrase of
8 to 32 characters and then
click Next.
WPA2 Mixed Mode - Select
WPA2 Mixed Mode. TKIP + AES
is automatically selected as
your encryption method. Enter
a passphrase of 8 to 32
characters and click Next.
WPA-Enterprise or Linksys
Wireless Guard - Refer to the
User Guide on the Setup CD for
more information.
eReview the new settings, and
click Yes to save them.
fClick Online Registration to
register the Access Point, or
click Exit to end the Setup
Wizard.
Congratulations! The installation of
the Wireless-G Access Point
is complete.
For additional information or troubleshooting
help, refer to the User Guide on the CD-ROM
or the Technical Support Insert. You can also
e-mail for further support.
Website
http://www.linksys.com/international
Product Registration
http://www.linksys.com/registration
WAP54G v3-QIG-EU-LA-UK-50715 KL
Linksys is a registered trademark or trademark of
Cisco Systems, Inc. and/or its affiliates in the U.S.
and certain other countries. Copyright © 2005
Cisco Systems, Inc. All rights reserved.
WPA2 Personal
WPA2 Mixed Mode
NOTE: For advanced configuration, use
the Access Point’s Web-based Utility.
Refer to the User Guide on the CD-ROM
for more information.
