Linksys WAP200 Operation manual

BUSINESS SERIES
PRODUCT DATA
Wireless-G
Access Point with Power Over
Ethernet and RangeBooster
Model: WAP200
High-Speed wireless access for
existing networks!
RangeBooster technology is a compatible add-on to standard Wireless-G which
increases your wireless network’s range up to two times, and its throughput by up
to 35%. Unlike ordinary wireless technologies that are confused by signal reflections,
RangeBooster uses two smart receivers at each end to detect and decode reflected
signals at distances where standard technologies give up. You’ll find that “dead spots” in
the wireless coverage area are reduced, too.
The Advanced security features makes this solution ideal for your Business. Advanced
wireless security using Wi-Fi Protected Access™ (WPA2 Enterprise) with up to 256-bit
encryption, and the new Wireless Security Monitoring functionality gives your business
the visibility and protection it needs. Used when Linksys 200-Series Wireless Adapters
are present, the Wireless Security Monitoring functionality alerts you of possible wireless
intruders, vulnerabilities in the wireless deployment, and visibility into Denial of Service
attacks.
The Linksys WAP200 Access Point lets you connect Wireless-G (802.11g) or Wireless-B
(802.11b) devices to your wired network so you can add PCs to the network with no cabling
hassle. Power over Ethernet support makes it easy to install – you can mount the Access Point
anywhere, even without ready access to a power plug. With appropriate Power over Ethernet
support at the other end, you only need to run one cable to the Access Point to deliver both
data and power. Of course, you can also use the included AC adapter if your installation point
has power available nearby.
Moreover, the integrated QoS features provide consistent voice and video quality on both
the wired and wireless networks, enabling the deployment of business quality VoIP and video
applications.
Additional features like Multiple BSSIDs, Wireless Roaming, Auto-channel selection, and Load
Balancing, make this solution ideal for your Business.
Standards-based POE (IEEE
802.3af) or External DC
power
RangeBooster technology
for up to twice the range,
reduced dead spots,
and up to 35% more
throughput than standard
Wireless-G
Advanced wireless security
using Wi-Fi Protected
Access (WPA2) with up to
256-bit encryption, and
new Security Monitoring
feature gives your business
the visibility and protection
it needs
Support for WMM provides
improved QoS over
wireless connections for
better video and voice
performance
WAP200

PRODUCT DATA
BUSINESS SERIES
Features
10/100 Base-T Ethernet Port,
Autosensing half/full duplex
& MDI/MDI-X
Full backwards compatibility
with 802.11b
Easy installation and
configuration
Supports WEP,WPA-PSK,
WPA2-PSK,WPA-ENT, WPA2-
ENT authentication (802.11i
ready)
SMA detachable Dipole
antennae with 1x2 MIMO to
increase coverage
Supports Power over
Ethernet (PoE) or external
DC power
Supports 4 BSSID and
802.1Q VLAN to SSID
mapping
Supports SNMP and intuitive
Web-based interface
WMM wireless QoS support
- upgradeable to 802.11e
Supports wireless roaming
based on 802.11F (IAPP)
Supports AP, Bridge Mode
and Repeater mode
Supports wireless security
monitoring (working
together with 200 series
client cards)
Supports wireless client
isolation
3 year limited warranty
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Wireless-G
Access Point with Power Over Ethernet
and RangeBooster
Specifications
Model WAP200
Standards IEEE802.11g, IEEE802.11b, IEEE802.3, IEEE802.3u,
IEEE802.3af (Power Over Ethernet), 802.1p (QoS priority),
802.1q (VLAN), 802.1X (Security Authentication),
802.11i - Ready (Security WPA2), 802.11e - Ready (Wireless QoS),
802.11F (Wireless Roaming)
Ports 10/100 Base-T Ethernet, 12 VDC Power
Buttons Reset
Cabling Type UTP CAT 5
LEDs Power, POE, Wireless, Ethernet
Operating System Linux
Setup/Config
WebUI Built in Web UI for Easy browser-based configuration (HTTP/HTTPS)
Management
SNMP Version SNMP Version 1, 2c, 3
Event Logging E-mail Notification
Remote Syslog
Web F/W upgrade Firmware Upgradable Through Web-Browser
Diags: Flash, etc. Diags: Flash, RAM, LAN, WLAN
DHCP DHCP Client
Operating Modes
Access Point Access Point Mode, point-to-point Bridge Mode,
point-to-multipoint Bridge Mode, Repeater Mode
Wireless
Spec/Modulation Radio and Modulation Type: 802.11b/DSSS, 11g/OFDM
Channels Operating Channels: 11 North America,
13 Most of Europe (ETSI and Japan)
# of External Ant. 2 (Omni-Directional) SMA detachable
Transmit Power Transmit Power (Adjustable) @ Normal Temp Range:
11b - 18 dBm; 11g - 14 dBm
Antenna Gain in dBi 2
Receiver Sensitivity 11.g: 54Mbps@ -72dBm, 11.b: 11Mbps@ -85dBM
Security
WEP/WPA/WPA2 WEP 64bit/128bit, WPA-PSK, WPA2-PSK, WPA-ENT, WPA2-ENT
Access Control Wireless Connection Control: MAC-Based
SSID Broadcast SSID Broadcast Enable/Disable
802.1X IEEE 802.1X support
Wireless Client Isolation Wireless Client devices can be isolated from each other
either within an SSID or between two SSIDs
Wireless Security Monitor Scan and Classify wireless devices in the network.
Report new client and AP joining network and suspicious network events
(Works together with 200 Business series client adapters):
1. Intrusion Alarms (e.g., Rogue Client Detected, Spoofed MAC address)
2. Denial of Service Alarms (e.g., Duration Attack, Association Table Full)
3. Vulnerability Alarms
(e.g., AP is not using encryption, AP is broadcasting SSID)
4. Other Alarms (e.g., Low speed connection)
Quality of Service
QoS 4 Queues
WMM Wireless priority
General
Wireless roaming based on IAPP
Load Balancing
Auto-channel selection

PRODUCT DATA
BUSINESS SERIES
Environmental
Dimensions 6.69" x 8.07" x 7.68"
W x H x D 170 x 205 x 195 mm
Unit Weight 0.88 lb (0.4 kg)
Power 12V 1A DC input, and IEEE 802.3af Compliant PoE
Certification FCC, ICES-003, CE
Operating Temperature 32 to 104ºF (0 to 40ºC)
Storage Temperature -4 to 158ºF (20 to 70ºC)
Operating Humidity 10 to 85% noncondensing
Storage Humidity 5 to 90% noncondensing
Package Contents
Wireless-G Access Point with Power Over Ethernet and RangeBooster
2 x SMA detachable Dipole antenna
User Guide on CD-ROM
Ethernet Network Cable
Power Adapter
Product Stands
Registration Card
Minimum Requirements
802.11b, 802.11g Wireless Adapter With TCP/IP Protocol Installed Per PC
Switch/Router with Power Over Ethernet (PoE) Support Or PoE Injector when used with PoE
Web-Based Configuration Java-Enabled Web Browser
•
•
•
•
•
•
•
•
•
•
Linksys
A Division of Cisco Systems, Inc.
121 Theory
Irvine, CA 92617 USA
E-mail: [email protected]
[email protected]
Web: http://www.linksys.com
Linksys products are available in more
than 50 countries, supported by
12 Linksys Regional Offices throughout
the world. For a complete list of local
Linksys Sales and Technical Support
contacts, visit our Worldwide Web Site
at www.linksys.com.
Check the product package and contents for specific features supported. Specifications are subject to change without notice. Linksys is a registered trademark or
trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2006 Cisco Systems, Inc. All rights reserved. Other brands
and Wireless-G Access Point with Power Over Ethernet and RangeBoosters are trademarks or registered trademarks of their respective holders.
Model: WAP200 6110610NC-RR
