Linuo ETG19B User manual

ETG19B
Freeze RF cavitation inport system
User manual

1
WARNING
Dear user：
Thanks for using our company's products, in order to fully make use of the
products, we sincerely suggests follow:
◆◆Please read this instruction in detail, and keep it well for further reading and
consulting.
◆◆Please follow the instruction to fit and operate the machine correctly.
◆◆Please do not remove and change any accessories of the machine.
◆◆It forbids others to open and remove the mainframe except the authorized
people in the company.
◆◆It forbids others to change and maintain the machine except the
professional people.
◆◆Please contact us if there is any trouble during operation.
This product does not belong to medical, please don't use for disease treatment!

2
1.LCD touch screen
2.Cool&heat hammer socket 1
Inlet
4.Cool&heat hammer socket 2
5.Cool&heat hammer socket 3
6.Overflow
7.
8.Induction electrode socket
9.B work head
- work head
11.
12.
13.
3.
Coolant discharge valve
ipolar RF for eyes socket
10.8 polar RF for body socket
General power switch
Power supply line outlet
Coolant level window
14.Accessory frame
Induction electrode
Bipolar RF work head
Cool&heat hammer
8-polar RF work head
Parts Introduction
1
11 13
14
12
2
3
4
5
6
7
8
10
9
plug 2&3
plug 1

3
Transportation & Installation
Connect power supply line[12], turn on general power
switch [11].The system will enter interface as (Fig 1)shows,
Click “set” to enter interface as (Fig 2). Click “Liquid setting” to
enter interface as (Fig 3) add coolant sketch map, Click “start”
began to add coolant. Press “ ” to return back (Fig 2).
Use purified water(or special coolant)
Make sure the coolant discharge valve is closed
Will hard hose inserted excessive runner.
.Use special funnel to connect to coolant inlet[3], the
Add purified water(or special coolant) from the funnel.
6.Add liquid until there is overflow from [6].
7.Check from the window[13] whether the liquid is full.
8.Add cooling fluid successfully ,take off the funnel.
←
1. .
2. .
3.
4 funnel
higher than the inlet about 20cm.
5.
Note: Add water or special cooling fluid in the capacity of
about 500 ml, suggest 3 months replacement again.
Before transportation:
The coolant should be cleared before transportation.
Method:
pen the coolant discharge valve[7] (turn anticlockwise
and fasten the pull out the stopper), discharge the coolant,
shake the machine to help the coolant get out completely.
O ,
Add coolant steps
Basic Operation
1.Connect all accessories to the host
ipolar RF for facial handle to
Insert 8 polar RF for body handle to
2 Connect power line , turn on general power switch
①Insert “Cool/heat hammer”plug 1 to socket[2];
②Insert “Cool/heat hammer”plug 2 to socket[4];
③Insert “Cool/heat hammer”plug 3 to socket[5];
④Insert “Induction electrode” to socket[8];
⑤Insert b [9];
⑥ [10];
.[12] [11].
The system will enter in standby state as (Fig 1) shows.
3.
(1)In interface as (Fig 1) shows, Click “Set” to enter interface as
(Fig 2) shows.
(2)Click “Bipolar RF” to enter interface as (Fig 4) shows.
(Fig1)
(Fig2)
(Fig3)

(3)Click “8-polar RF” to enter interface as (Fig 5) shows.
(4)Click “Cool&heat hammer” to enter interface as (Fig 6).
(5)Click “ ” to enter interface as (Fig 2) shows.
4.
(1)In interface as (Fig 2) ,Click “Basic setting” to select
language.
(2)“Advanced setting” is only for manufacturer, Users do not
use.
(3)Click “Liquid Setting” to enter interface as (Fig 3),the steps
please refer to “ Add coolant steps”
Note:
Before turn on the machine, please check whether
[13], if not filled with liquid
Please cooling fluid and prevent affect
effect .
Coolant level window ,
add freeze (Fig4)
(Fig5)
1.In interface as (Fig 1), Click “Bipolar RF” to enter interface as
(Fig 4), begin facial treated function.
2.Click “Time” to set working time, the system default timing is
30 minutes, Press “<<”and “>>”to regulate. the range is 1 to
60 minutes .About 10 minutes for eyes, and 15 minutes for
face.
3.Click “Intensity” to regulate RF output intensity, the system
default is 1, Please Click “<<”and “>>”to regulate, the range
is 1(weak) to 6(strong).
4.Click “||” ,the system begin to work.
5.Apply gel on eyes around skin, move in circle, the electrode probe move from
inside out, move to the temple, don't let gel enter eyes. lift up the area of the Canthus and eyebrow,
move in line. The eye around skin is very sensitive, so be careful, don't make the probes too hot.dont
let gel into eyes.
6.Divide the facial skin into two part from the middle ,Apply gel on face around skin, move in circle,
move the electrode probe from inside out, along the direction of lymph, from the bottom up to
do thermal therapy. Do other side in the same way. Repeat for 5~8 times.
The Forehead has less fat, the edge of the eyebrows is also very sensitive, and the output
intensity should be lowered.
7.The machine will pause automatically if the setting time is over. Clean the leftovers with hot
towel, use warm towel to clean the RF electrode head.
Bipolar RF treatment for facial
1.Click “8-Polar RF” to enter interface as (Fig 5) shows, begin to body treated.
20~30minutes for body.2.Setting working time, about
8 polar RF Body Treatment
