Lionel G-Gauge User manual

71-0000-250
4/15
Lionel
G-Gauge Steam Set
Owner's Manual
Adult assembly required
Batteries not included

2
Congratulations!
Congratulations on your purchase of this Lionel G gauge set. This set features everything you need to get started – a wireless remote control, a huge loop of easy-to-assemble track,
a string of detailed cars, a tender and locomotive.
Read this instruction manual thoroughly for important tips on operating and
maintaining your ‘G’ Gauge set.
Set Inventory
• 1 Steam locomotive with head lamp, bell (depending on set purchased), and sounds
• 1 Tender
• 2 Rolling Stock cars
• 12 curved track sections
• 4 straight track sections
• 1 Wireless Remote Controller
• 1 Owners manual
Scan this QR code for help setting up and
operating your G Gauge set as well as a
troubleshooting video.

3
FCC and RSS Statements
Warning: Changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user authority to operate the equipment.
Notes: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipement off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference that may cause
undesired operation.
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.

4
Table of contents
Track assembly and layout
Joining the track sections 5
Layouts 6
Battery installation and options
Installation and options
Installing 'AA' batteries into the wireless controller 7
Installing 'C' batteries into the tender 8
Operating your train
Connecting the engine and coal tender 9
Power switches on the wireless controller 10
Operating your wireless controller 11-12
Power activation button on the engine 13
Maintenance and operations
Battery Warning 14
Cleaning the track 14
Troubleshooting 15
Limited Warranty/Lionel Service 16
The following Lionel marks are used throughout this Owner’s Manual and are protected under
law. All rights reserved.
Lionel®, LionChief™, LionChief Plus™, LEGACY™, FasTrack®,TrainMaster®, Odyssey®, RailSounds®,
CrewTalk™, TowerCom™, DynaChuff™, StationSounds™, Pullmor®, ElectroCoupler™, Magne-
Traction®, CAB-1®Remote Controller, American Flyer®, Lionel ZW®, ZW®, MagniVision®, TMCC®,
Lionelville®, Wireless Tether™, Powerhouse™, LionMaster®, Conventional Classics™, Postwar
Celebration Series™, TruRail™, PH-1 Powerhouse®, Powermaster®, Powerstation-Powerhouse®,
Accessory Motor Controller™, AMC™, Accessory Switch Controller™, ASC™, Action Recorder
Controller™, ARC™, Track Power Controller 300™, TPC 300™, Track Power Controller 400™, TPC
400™, Block Power Controller™, BPC™, Operating Track Controller™, OTC™, FatBoy™, Lionel
Lines®, Joshua Lionel Cowen Series™, Lockon®, TrainSounds™, MultiHorn™, MultiWhistle™,
Choo-Choo™, SensorTrack™, Plug-n-Play™

5
Track assembly and layout
Joining the track sections
Join the track sections together by placing them on a flat surface and inserting the plastic tabs of each track section into the corresponding openings of the next section. Press or
squeeze the ties together to connect. This may require the help of an adult. Recheck all track
connection points upon completing your layout to be sure they are secure.
To disassemble the track just lift one of the track sections slightly at an angle where they
join together and they will snap apart. See Figure 1.
The rails should be kept clean, dry, and free from oil, grease, and dirt. Clean the track
periodically with a clean soft cloth.
Figure 1. Assembling and disassembling the track
Ties

6
Track assembly and layout
Layouts
These are three possible layouts you can make with the track provided. See Figure 2.
Circle
• Connect all curved track sections
Extended Circle
• Make four ninety-degree curves by joining three curved sections each
• Connect the three-section ninety-degree curves with one straight section in between
Oval
• Make two half-circles using six curved sections for each. Make two long straight tracks
using two sections each. Join the curves using the two long straight sections.
Figure 2. Possible track layouts
Figure 3. Additional track is now available separately to create new layouts
7-11111 Left-Hand Manual
Switch (available separately)
7-11110 Right-Hand Manual
Switch (available separately)
7-11039 Add-On Track 4-Pack
Straight (available separately)
7-11040 Add-On Track 6-Pack
Curved (available separately)

7
Installing AA batteries into the Remote Control
Using a Phillips Head screwdriver, have an adult loosen the screw on the battery compartment cover. Once the battery cover has been removed (as shown in figure 4)
install 2 'AA' Alkaline Batteries (not included). Please be sure the +/- of each battery is
positioned properly in the battery compartment. Replace the battery door and tighten the
Phillips head screw. Be careful to avoid over-tightening the screw.
Use only Alkaline AA batteries. Use only new batteries. Never mix new and used
batteries or use different types together.
Figure 4. Opening and closing the battery compartment
REMOVE ALL BATTERIES WHEN THE TRAIN WILL NOT BE USED FOR AN
EXTENDED PERIOD OF TIME. LIONEL'S LIMITED WARRANTY DOES NOT
COVER DAMAGE TO YOUR REMOTE CAUSED FROM LEAKING BATTERIES.
Important!
When you are not operating the train, move the On/Off switch to the
Off position to conserve the battery life.
Important!
Important!
Battery installation and options

8
Battery installation and options
Installing ‘C’ batteries into the tender
Using a Phillips Head screwdriver, have an adult loosen the screw on the battery compartment cover. Once the battery cover has been removed install 6 'C' Alkaline
Batteries (not included). Please be sure the +/- of each battery is positioned as shown in the
battery compartment. See Figure 5.
Use Alkaline ‘C’ batteries. Use only new batteries. Never mix new and used
batteries or use different types together.
Close the battery compartment by inserting the slot on the front end of the tender lid onto
the retaining rib. Then lower the back end of the lid and secure by tightening the Phillips
Head screw.
FRONT
FRONT
REAR REAR
Loosen screw
Loosen screw
Remove all batteries when the train will not be used for an extended
period of time. Lionel's Limited Warranty does not cover damage to your
tender caused from leaking batteries.
Important!
Important!
Figure 5. Installing ‘C’ batteries in the tender
FRONT FRONT
Berkshire General
REAR REAR

9
Operating your train
Connecting the engine and coal tender
Place the engine on the track first. Be sure that all wheels are within the track rails. Next insert the power plug into the receptacle in the center back of the engine platform. See
Figure 6.
The engine will not run without this power plug inserted into the engine.
Place the Coal Tender on the track behind the Engine and connect the couplers. Be sure all
the Coal Tender's wheels are all on the track rails.
Figure 6. Connecting the engine and the coal tender
Note!
Note!
Connecting the
couplers
Remove all batteries when the train will not be used for an extended
period of time. Lionel's Limited Warranty does not cover damage to your
tender caused from leaking batteries.
Important!
When you have finished running your train, unplug the harness from the
locomotive to stop the sounds from playing. Once the harness is plugged back in,
the sounds will reset to default. Unplugging the harness will also conserve battery
life.

10
Operating your train
Power switches on the wireless controller
Turn the power switch on the side of the wireless remote to the up or ON position. The red LED at the top of the speed dial will illuminate to tell you the controller is on.
Turn the power switch on the Wireless Controller to the down position or OFF when not in
use. The LED at the top of the dial will go out to indicate the power is off. See Figure 7.
Leaving the Wireless Controller power ON when not in use will drain the controller’s
battery.
Figure 7. Using the wireless controller
Note!
F
O
R
W
A
R
D
R
E
V
E
R
S
E
W
H
I
S
T
L
E
B
E
L
L
F
O
R
W
A
R
D
R
E
V
E
R
S
E
W
H
I
S
T
L
E
B
E
L
L
F
O
R
W
A
R
D
R
E
V
E
R
S
E
W
H
I
S
T
L
E
B
E
L
L
F
O
R
W
A
R
D
R
E
V
E
R
S
E
W
H
I
S
T
L
E
B
E
L
L
Power on light
Power on light
3 BUTTON REMOTE
2 BUTTON REMOTE
ON
ON
OFF
OFF

11
Operating your train
Operating your wireless controller
Turn your Wireless Controller to the ON position by sliding the button on the right side of the controller up. An LED on top of the dial will light to indicate the power is on (See Figure 7 on
page 10). See Figures 8 and 9 on page 12 for button operations.
The controller must be within 10 feet of the engine to operate the train. The controller
may not operate if placed flat on the ground even if it is near the train.
Forward
Turn the dial towards the green FORWARD position to move the train forward. There are three
speeds forward and the more you turn the dial along the green arrow the faster the train will run.
Stop
Turning the dial to the top will stop the train. Note that it may take up to several seconds for the
train to come to a complete stop depending on how fast it was going. Make sure to bring the train to
a complete stop before changing direction.
Reverse
Turn the dial towards the blue REVERSE position to have the train move in reverse. Again,
there are three speeds in reverse. The more you turn the dial along the blue arrow the faster
the train will go.
Bell
Pressing the BELL button activates the engine's bell sound.
Center Button (Depending on which set purchased)
Pressing the UNMARKED center button activates a special announcement.
Whistle
Pressing the WHISTLE button activates the engine's whistle.
Note!

12
Operating your train
Operating your wireless controller continued
F
O
R
W
A
R
D
R
E
V
E
R
S
E
W
H
I
S
T
L
E
B
E
L
L
F
O
R
W
A
R
D
R
E
V
E
R
S
E
W
H
I
S
T
L
E
B
E
L
L
F
O
R
W
A
R
D
R
E
V
E
R
S
E
W
H
I
S
T
L
E
B
E
L
L
FORWARD STOP REVERSE
WHISTLE
ANNOUNCEMENT
BELL
3 BUTTON REMOTE
Figure 9. Operating your 3 Button Wireless Controller
Figure 8. Operating your 2 button Wireless Controller
F
O
R
W
A
R
D
R
E
V
E
R
S
E
W
H
I
S
T
L
E
B
E
L
L
F
O
R
W
A
R
D
R
E
V
E
R
S
E
W
H
I
S
T
L
E
B
E
L
L
F
O
R
W
A
R
D
R
E
V
E
R
S
E
W
H
I
S
T
L
E
B
E
L
L
2 BUTTON REMOTE
FORWARD STOP REVERSE
WHISTLEBELL

13
Operating your train
Power activation button on the engine
Press the grey Power Activation button located on top of the boiler just in front of the cab area of the engine. The light in the front of the engine and stationary sounds will come
on to indicate the train is operational. See Figure 10.
The engine power automatically turns off if not used after 10
minutes. When the engine automatically times out into the off mode
the light and stationary sounds shut off.
Just press the start button again to continue to play. Pressing the start button again will not shut the
train off. You can either let it time out for 10 minutes or if required, disconnect the power cord from
the back of the engine. Note the engine was designed to use the auto shut off to turn the engine
off. Very little power is used during the time out period if Wireless Controller is not activating any
operations. The stationary sounds and light will continue during this time out period until the engine
shuts off at the end of the ten minutes.
Note!
Figure 10. Power Activation Button
Berkshire
General

14
Maintenance and operations
IMPORTANT : BATTERY INFORMATION
Please retain this information for future reference.
Batteries should be replaced by an adult.
CAUTION:
• Do not mix alkaline, standard (carbon-zinc), or rechargeable
(nickle-cadmium) batteries.
• Do not mix old and new batteries.
• Only batteries of the same or equivalent type as recommended are to be
used.
• Batteries are to be inserted with correct polarity.
• Exhausted batteries are to be removed for the product.
• The supply terminals are not to be short-circuited.
• Dispose of battery(ies) safely.
• Do not dispose of this product in a fire. The batteries inside may explode
or leak.
Cleaning the track
It is very important to keep the track and wheels free from dirt and grease. Wipe them with a soft cloth whenever they get dirty. This will help the engine run more efficiently.

15
Maintenance and operations
Troubleshooting
Train will not run and engine light is not on.
1. Check if engine automatically timed out and shut off by pressing the engine's Power
Activation button (see page 11).
2. Check that the wire connecting the engine and coal tender is securely in its socket (see
page 9). After checking this connection press the Power Activation button (see page 11).
3. After checking the above and if the light is still not on replace the 6 ‘C’ batteries in the
tender. Be sure the batteries are oriented as indicated in the battery compartment (see page
8). After replacing batteries press the Power Activation Button (see page 11).
Train will not run but engine headlight and sounds are on.
1. Check to make sure the Wireless Controller power switch is in the On position. This will be
indicated by the red LED being illuminated.
2. Try moving the controller closer to the engine. Although designed for an optimal range of
10 feet the signal can be weakened by a metal object or other interference.
3. Be sure the controller is not lying flat on floor and it's antenna is positioned above the
level of the train.
4. Replace the 2 AA batteries in the controller (see page 7). Be sure the batteries are oriented
as indicated in the battery compartment.
Train will not run and firebox red light is flickering.
1. Check to see if your wireless remote's power light is on. Give the train a new command such
as the whistle button. If the lamp remains flickering and the whistle will not sound, either
your engine or remote need repair. If the firebox lamp changes to a steady red glow and the
whistle does not sound, your engine needs repair. Please contact Lionel service. See page 16.
Train runs but wheels slip on track.
1. Check top of track rails and rubberized drive wheels for dirt or grease. Clean with a soft dry
or slightly dampened cloth.
2. Check to see that all wheels of both engine, tender and cars are located properly on the
track.
Firebox flickering red light.
Under normal conditions the firebox light
will flicker realistically as the train runs,
and the flicker will change to a constant
red glow when you give your train a new
command.

©2015 LIONEL L.L.C., CONCORD, NC 28027
UNITED STATES OF AMERICA
PRINTED IN CHINA
QUESTIONS?
This product is covered by a ONE year limited warranty effective from
the date of purchase against defects in materials and workmanship.
Consumer Assistance:
586-949-4100 option 2
