Introduction
The exible light strip slides onto an integrated light cord
included on all Solera® Universal Awning Fabric, the Prep
Flex or Fabled Fabric Awning. The innovative design
allows you to enjoy dramatic lighting outside of the RV
when the awning is extended or retracted.
NOTE: Images used in this document are for reference
only when assembling, installing and/or operating this
product. Actual appearance of provided and/or purchased
parts and assemblies may differ.
Additional information about this product can be
obtained from lci1.com/support or by using the
myLCI app. Replacement kits can be ordered from
https://store.lci1.com/ or by using the myLCI app.
The myLCI app is available for free on iTunes® for iPhone®
and iPad® and also on Google Play™for Android™users.
iTunes ®, iPhone®, and iPad®are registered trademarks of
Apple Inc.
Google Play™and Android™are trademarks of Google Inc.
NOTE: This manual will refer to the “drive side” and “idler
side” throughout for various instructions. The “drive side”
is the right hand side of the awning when facing the awning
from the exterior of the unit. The “idler side” is the left
hand side of the awning when facing the awning from the
exterior of the unit.
MOVING PARTS CAN PINCH, CRUSH, OR CUT. KEEP
CLEAR AT ALL TIMES.
Safety
Read and fully understand all instructions before installing
or operating this product. Adhere to all safety labels.
This manual provides general instructions. Many variables
can change the circumstances of the instructions, i.e.,
the degree of di󰀩culty, operation and ability of the
individual performing the instructions. This manual
cannot begin to plot out instructions for every possibility,
but provides the general instructions, as necessary,
for e󰀨ectively interfacing with the device, product
or system. Failure to correctly follow the provided
instructions may result in death, serious personal injury,
severe product and/or property damage, including voiding
of the LCI limited warranty.

3
lci1.com 574-537-8900 Rev: 02.06.20
Solera®Awning LED
Light Strip Kit
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0002359
Preparation
Custom Sizing of the LED Light Strip
There are two available sizes for the awning fabric LED light
strip kit. If the awning width, measuring the awning fabric
edge-to-edge, measures 10’ - 15’ the 15’ LED light strip
kit should be used. If the awning fabric measures 16’ - 21’
the 21’ awning LED light kit should be used. To achieve a
custom size, the LED light strip can be cut along the black
line at the nearest copper cut tab (Fig.1A).
NOTE: If cutting the LED light strip is required, it is very
important to cut only on the given cut line between the
copper cut tabs (Fig.1A). Cutting through or before the
copper cut tabs will result in no electrical conductivity to
the following section.
1. At the closest applicable length needed, usually the
width of the awning fabric, measure from the wired side out.
2. Cut the excess light strip from the opposite side of
the wiring on the LED light strip. Use a pair of sharp
scissors to cut the LED light strip directly down the
given cut line (Fig.1A).
3. Seal the LED light strip cut end with a dab of silicone
along the edge and let dry.
Fig.1
A
Resources Required
• Cordless or electric drill
or screw gun
• Appropriate drive bits
• Cordless or electric saw
• Appropriate cutting blades
• Sharp scissors,
if applicable
• Fuse appropriate for wiring
• Silicone sealant
• Marker
15’ Solera® Awning Aftermarket LED Light Strip15’ Solera® Awning Aftermarket LED Light Strip
Kit PN 674282Kit PN 674282
LetterLetter PNPN DescriptionDescription QtyQty
A 387593 15’ LED Light Strip 1
B 431032 Light Switch 1
C 431033 Light Switch Plate 1
D 227619 #8 x 1” Square Pan Head Screw 2
E 388271 #10 - 16 x 3/8” Pan Head Screw 1
Parts List
21’ Solera® Awning Aftermarket LED Light Strip21’ Solera® Awning Aftermarket LED Light Strip
Kit PN 674283Kit PN 674283
LetterLetter PNPN DescriptionDescription QtyQty
A 387594 21’ LED Light Strip 1
B 431032 Light Switch 1
C 431033 Light Switch Plate 1
D 227619 #8 x 1” Square Pan Head Screw 2
E 388271 #10 - 16 x 3/8” Pan Head Screw 1
B
C
D
E
NOTE: Part numbers are shown for identification purposes
only. Not all parts are available for individual sale. All parts
with a link to the Lippert Store can be purchased.
A

4
lci1.com 574-537-8900 Rev: 02.06.20
Solera®Awning LED
Light Strip Kit
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0002359
Fig.4
Installation
LED Light Strip
NOTE: Awning MUST be extended to access the polycord
on the awning fabric and to run the LED power wire down
the drive mount arm.
1. Starting on the drive side of the awning, slide the LED
light strip (non-wired end) (Fig.3A) onto the polycord of
the awning fabric (Fig.3B), located close to the awning rail
(Fig.3C) down the width of the awning fabric to the end,
towards the idler side.
2. Flip the LED light strip drive side (wired end) up to see the
back side of the light strip.
3. Install a #10 - 16 x 3/8” pan head screw (Fig.4A) into the
black plastic track of the LED light strip. Make sure to install
the screw at a slight angle in between the LED light strip and
the polycord in the awning fabric, to prevent the LED light
strip from sliding o󰀨 the awning fabric polycord.
Fig.3
A
B
C
Removing the Old LED Light Strip
NOTE: Awning MUST be extended to access the polycord
on the awning fabric and the LED power wires down the
drive mount arm.
1. If replacing only the LED light strip, remove the old LED
light strip by locating and removing the #10 - 16 x 3/8” pan
head screw (Fig.2A) located on the drive side, in the back of
the LED light strip, holding the LED light strip in place.
Fig.2
A
2. Cut the wires to the old LED light strip just inside the
wall of the unit. The wires to the new LED light strip can be
spliced into the old wires rather than replacing all the wiring
to the switch and power source and replacing the switch.
3. Remove the old LED light strip by sliding the LED light
strip completely out from the awning fabric polycord.
NOTE: If the light switch needs to be replaced as well,
remove the two #8 x 1” pan head screws in the light switch
plate (Fig.5B). Remove the light switch, plate and disconnect
the wiring to the LED light strip and the power source.

5
lci1.com 574-537-8900 Rev: 02.06.20
Solera®Awning LED
Light Strip Kit
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0002359
LED Light Switch Installation
1. Determine where to mount the LED light switch. The
LED light switch can be mounted anywhere inside the
trailer or trailer compartment. The mounting location must
be watertight. The typical location for the LED light switch
is near the entry door, close to where the wires from the
LED light strip enter inside the unit wall.
2. Cut a hole in the wall or wall of the compartment using
the inside opening of the switch plate as a guide (Fig.6D).
Use the switch plate to trace where the cutout should be
located. The top and bottom horizontal cuts should be
parallel.
3. Place the light switch (Fig.6C) into the switch plate (Fig.6A).
NOTE: Make sure the switch is oriented correctly with the on
position (vertical line) located at the top of the switch.
4. Located on the backside of the light switch, insert the
LED light strip wires onto the proper spade. Red wire is
positive, black wire is negative.
5. Connect the LED red power wire to the unit’s power
source. Make sure the black wire is connected to a ground
and the red wire is connected to 12V DC power source
6. Connect the 3A fuse to protect all wiring going to the
light, that meets or exceeds RVIA standards. See the
Wiring Diagram section.
7. Test the light switch to make sure the LED light strip is
wired properly.
8. Secure the switch plate onto the unit wall with the two
provided #8 x 1” pan head screws (Fig.6B).
D
B
A
C
Fig.6
NOTE: Make sure the screw does not completely go through
the polycord and into the awning fabric. Make sure that the
LED light strip is hanging straight, parallel to the ground.
4. Depending on top wire or bottom wire installation,
remove the wire covers in the drive side mount arm.
5. If bottom installation, take the LED light strip power wire
(Fig.5A) from the light track and run it down the drive arm.
Make sure to run the wires over the center pin of the drive
mount arm. If top installation, run the wires through the top
hole in the drive side mount arm (Fig.5B) inside the unit wall
and down to the switch.
NOTE: If completing an entirely new installation, proceed
to the LED Light Switch Installation
6. Splice the new LED light strip power wires onto the old
wires just inside the unit’s wall.
NOTE: Make sure the red wire is to power and the black
wire is to ground.
7. Test the light switch to make sure the LED light strip is
wired properly.
8. Reinstall wire covers in the drive mount arm.
A
Fig.5
B

6
lci1.com 574-537-8900 Rev: 02.06.20
Solera®Awning LED
Light Strip Kit
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0002359
LED Light Switch Operation
NOTE: Leaving the LED light strip switch on for an
extended period of time can drain the trailer’s battery.
1. To turn the LED light strip on, press the toggle switch to
the vertical line symbol (Fig.7A).
2. To turn the LED light strip o󰀨, press the toggle switch to
the circle symbol (Fig.7B).
Fig.7
A
B
Wiring Diagrams
Front of Switch
Back of Switch
red wire
black wire
LED light strip
front of light switch
3A circuit protection
per RVIA code
ground power
ground
battery
light switch plate
light switch
light red wire
power red wire
light black wire
ground black wire

7
lci1.com 574-537-8900 Rev: 02.06.20
Solera®Awning LED
Light Strip Kit
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0002359
Notes

8
lci1.com 574-537-8900 Rev: 02.06.20
Solera®Awning LED
Light Strip Kit
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0002359
Manual information may be distributed as a complete
document only, unless Lippert Components provides
explicit consent to distribute individual parts.
All manual information is subject to change without
notice. Revised editions will be available for free
download at lci1.com. Manual information is considered
factual until made obsolete by a revised version.
Please recycle all obsolete materials and contact
Lippert Components with concerns or questions.
Notes
