Lippert Components Solera Slide Topper Installation instructions

1
lci1.com 574-537-8900 Rev: 05.30.19
Solera®Slider
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0001264
Solera®Slider
Installation and
Owner’s Manual
(For Aftermarket Applications)
NOTE: The number of variances for the Solera Slider is
too extensive to list herein and beyond the scope of this
document. Contact LCI Customer Service
at [phone] or email: [e-mail]
to request the appropriate variance applicable to a
specific requirement.
NOTE: If the optional Solera Slider Access Kit was
purchased keep these instructions to reference the parts
list but use the installation instructions that were included
in the Solera Slider Access Kit.
Table of Contents
Introduction ............................................ 2
Safety Information ..................................... 2
Resources Required ................................... 2
Parts List ................................................ 3
Installation .............................................. 4
Installing the Awning Rail .............................. 4
Assemble the Extension Rod and Cap ................ 4
Installing the Solera Slide Topper Assembly ........... 5
Securing the Fabric .................................... 6
Maintenance ............................................ 6
Fabric Care ........................................... 6
Troubleshooting ........................................ 7
Notes .................................................... 8

2
lci1.com 574-537-8900 Rev: 05.30.19
Solera®Slider
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0001264
Introduction
Solera®Sliders are a high-quality, cost-effective way to
help keep slide-outs free of dirt, leaves and debris. Solera
Sliders are permanently attached to the slide-out and
retract/extend with the room. The easy-to-install kits are
designed to fit rooms from 66" to 192" in length. All Solera
Slider fabric produced before August 2014 allows for a 58"
projection and all fabric produced after that date allows for
a 48" projection. The hardware hole pattern is universal
and will match most competitive brands, which alleviates
the need to patch holes.
• The Solera Slider kit comes complete with mounting
hardware.
• Awning rail included.
• All fabric is 6” shorter than slide topper length, which is
measured from centerline of torsion arm to centerline of
torsion arm.
• Box width is measured on the outside front of the box.
Include the T-molding for a proper fit.
Additional information about this product can be obtained
from lci1.com/support or by using the myLCI app.
Replacement kits can be ordered from https://store.lci1.
com/ or by using the myLCI app.
The myLCI app is available for free on iTunes®for iPhone®
and iPad®and also on Google Play™for Android™users.
iTunes®, iPhone®, and iPad®are registered trademarks of
Apple Inc.
Google Play™and Android™are trademarks of Google Inc.
Safety Information
Read and fully understand all instructions before installing
or operating this product.
Adhere to all safety labels.
This manual provides general installation procedures.
Many variables can change the circumstances of the
procedure, i.e., the degree of difficulty involved in the
service operation and the ability level of the individual
performing the operation.
FAILURE TO FOLLOW THE INSTRUCTIONS
PROVIDED IN THIS MANUAL MAY RESULT IN DEATH,
SERIOUS INJURY, UNIT DAMAGE OR VOIDING OF
THE COMPONENT WARRANTY.
MOVING PARTS CAN PINCH, CRUSH OR CUT. KEEP
CLEAR AND USE CAUTION.
This manual cannot begin to plot out procedures for every
possibility, but will provide the general instructions for
effectively installing the system. In the event the skill level
required is too advanced or the procedure too difficult,
a certified technician should be consulted before
performing the necessary installation. Failure to correctly
install the system may result in voiding the warranty,
inflicting injury or even death.
Resources Required
• 1-2 people, depending on task
• Cordless or electric drill or screw gun
• Appropriate drive bits
• Screwdriver
• Tape measure
• Silicone sealant or butyl tape
• Silicone lubricant
ALWAYS WEAR EYE PROTECTION WHEN
PERFORMING SERVICE OR MAINTENANCE TO THE
UNIT. OTHER SAFETY EQUIPMENT TO CONSIDER
WOULD BE HEARING PROTECTION, GLOVES AND
POSSIBLY A FULL FACE SHIELD, DEPENDING ON
THE NATURE OF THE SERVICE.

3
lci1.com 574-537-8900 Rev: 05.30.19
Solera®Slider
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0001264
NOTE: Part numbers are shown for identification purposes
only. Not all parts are available for individual sale. All parts
with a link to the Lippert Store can be purchased.
Parts List
Solera Slide Topper - White
Letter PN Description Qty
A 272455 Drive Head (incl w/ roll tube) 1
B 272454 Idler Head (incl w/ roll tube) 1
C 2724561 Torsion Arm Cap 2
D 362117 Screw, #10 - 16 x 1 1/4” Pan Head,
Self Drilling 10
E 3452071 Extension Rod 2
F 2724411 Extension Rod Bracket 2
G 300247 Screw, #10 - 16 x 3/4”, Hex Washer
Head, Self Drilling 4
H 280648 Screw, 1/4” - 20 x 5/8” Slotted Pan
Head, Self Tapping 2
I 382228 Roll Tube 1
J 675906 Screw, #8 - 18 x 1/2” Pan Head, Self
Drilling (incl w/ roll tube) 8
K 281079 Screw, #6 - 20 x 1/2” Hex Washer,
Self Drilling 2
L 281928 Awning Rail 1
M 252593 Screw, #8 - 18 x 1” Square Pan
Head, Self Drilling 26
A B
C D E
F G H
I J K
LM
Solera Slide Topper - Black
Letter PN Description Qty
A 285149 Drive Head (incl w/ roll tube) 1
B 285148 Idler Head (incl w/ roll tube) 1
C 2724562 Torsion Arm Cap 2
D 362118 Screw, #10 - 16 x 1 1/4” Pan Head,
Self Drilling 10
E 3452072 Extension Rod 2
F 2724412 Extension Rod Bracket 2
G 300247 Screw, #10 - 16 x 3/4”, Hex Washer
Head, Self Drilling 4
H 280648 Screw, 1/4” - 20 x 5/8” Slotted Pan
Head, Self Tapping 2
I 676498 Roll Tube 1
J 276611 Screw, #8 - 18 x 1/2” Pan Head, Self
Drilling (incl w/ roll tube) 8
K 281079 Screw, #6 - 20 x 1/2” Hex Washer,
Self Drilling 2
L 281929 Awning Rail 1
M 364290 Screw, #8 - 18 x 1” Square Pan
Head, Self Drilling 26

4
lci1.com 574-537-8900 Rev: 05.30.19
Solera®Slider
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0001264
Assemble the Extension Rod and Cap
1. Slide the extension rod (Fig.2A) into the spring head
assembly torsion arm (Fig.2B), aligning the fastener
locations (Fig.2).
2. Slide the spring head assembly torsion arm end cap
(Fig.2C) into the extension rod (Fig.2A), aligning all three
fastener locations (Fig.2). Fasten using the provided
1/4” - 20 x 5/8” slotted pan head, self-tapping screw (Fig.3).
NOTE: Do not secure the second extension rod to the
spring head assembly torsion arm until the Solera Slider is
ready for installation on the unit.
fastener locations
Fig.2
Fig.3
A
B
C
Fig.1
A
Installation
All screws supporting the awning assembly MUST have a
backer within the structure of the wall of the unit. Refer to
unit manufacturer for proper location.
Installing the Awning Rail
Awning rail included.
1. Position the awning rail along the line where the roof and
wall meet or a minimum of 3” above the upper edge of the
slide room the Solera Slider will cover.
The awning rail must be level and parallel with the top of
slide room box of the unit.
2. After determining the awning rail’s proper location,mark
its position with a non-permanent method of marking.
3. Apply sealant to the back of the awning rail (Fig.1A).
4. Align the awning rail on the wall and secure with
#8 - 18 X 1” screws, using all fastener holes.

5
lci1.com 574-537-8900 Rev: 05.30.19
Solera®Slider
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0001264
Fig.4
Fig.5
4. Remove packaging from the roll tube and unroll a small
portion of fabric, no more than one turn.
Fig.6
5. Repeat Steps 1-4 for the other end, but do not secure
the second hex extension rod to the spring head assembly
torsion arm until the Solera Slider is ready for installation
on the unit.
Installing the Solera Slider Assembly
1. To prepare for fabric installation, use a screwdriver to
spread open either end of the awning rail on the installation
end (Fig.5A).
2. To protect the fabric from damage during installation,
le any sharp edges or burrs from the awning rail.
3. Spray the inside of the awning rail channel with silicone
lubricant (Fig.5B).
3. Seal the back side of the extension rod bracket screw
holes with sealant so that the sealant is against the unit
when mounting the extension rod bracket.
4. Place the support arm bracket against the bottom
of the T-molding at the top corner of the slide-out.
Make sure to keep the support arm bracket parallel with
the T-molding. Fasten using the provided #10 - 16 x 1 ¼”
self-tapping screws (Fig.4).
B
A
UNROLLING THE FABRIC MORE THAN ONE TURN
WILL CAUSE THE SLIDE TOPPER TO LOSE TENSION
AND CREATE SLACK WHEN CLOSING THE SLIDE
ROOM. MAKE SURE TO LEAVE THE SLIDE ROOM
CLOSED OR NOT TO EXTEND MORE THAN 6”.
5. Using at least two people, feed the polycord through the
awning rail channel (Fig.6A).
6. Feed one of the extension rods into the extension rod
bracket. By pulling the extension rod all the way into the
extension rod bracket, the opposite end extension rod can
now slide into the extension bracket or optional access
bracket at the opposite end.
7. Angle the extension rod so that the roll tube will not
be touching the slide room.
8. Secure the second extension rod to the spring head
assembly torsion arm using the provided 1/4” - 20 x 5/8”
slotted pan head, self-tapping screw (Fig.3).
9. Center the Solera Slider over the slide room using a
tape measure.
A

6
lci1.com 574-537-8900 Rev: 05.30.19
Solera®Slider
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0001264
10. Fasten the extension rods to the extension rod brackets
by installing two of the provided #10 - 16 x ¾” self drilling
hex washer head screws in each extension rod bracket
(Fig.7A).
A
Fig.7
ROLL TUBE SPRINGS ARE UNDER TENSION.
IMPROPERLY SECURED ROLL TUBE SPRINGS CAN
CAUSE PERSONAL INJURY AND/OR PRODUCT
DAMAGE. SLOWLY RELEASE SPRING TENSION
TO AVOID PERSONAL INJURY AND/OR PRODUCT
DAMAGE.
11. Firmly hold the roll tube when removing the spring clip
to relieve spring tension.
Securing the Fabric
1. Extend and retract the room several times to ensure that
the fabric is square on the roll tube.
2. Secure the fabric in the awning rail no more than 1”
inside the edge of the fabric on both ends using a #6 x ½”
hex head screw. Install the screw down through the awning
rail into the fabric and the polycord (Fig.8).
awning rail 1"
fabric stitching
Fig.8
Maintenance
Fabric Care
If the awning is retracted while wet, extend the awning
and let it dry as soon as conditions allow before
retracting. This will help prevent the formation of mildew
and add greatly to the life of the awning. Mildew does not
form on the fabric itself, but on the accumulated dust, dirt
and grime.
Periodically clean vinyl or woven acrylic fabric using a
mixture of ¼cup of dish soap and 5 gallons of warm
water. Liberally apply the mixture on the top of the fabric
and retract the awning for five minutes. This will apply
the mixture to the bottom of the fabric as well. Extend the
awning and hose off with fresh water. Repeat if necessary.
Allow fabric to dry before retracting.

7
lci1.com 574-537-8900 Rev: 05.30.19
Solera®Slider
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0001264
Troubleshooting
Solera®Slide Topper Troubleshooting Chart
What’s Happening? What Should Be Done?
Rub marks appear on the fabric. Check that there is no debris in the track where fabric goes into the case.
Fabric sags or is loose. Check tension on springs.
Make sure the end caps are properly secured.
Fabric will not roll up. Check tension on springs.
Make sure there are no debris or foreign objects in the fabric opening or case.
Fabric will not unroll. Make sure the spring clips that lock the tension for install have been removed
from both ends of the end caps.
Fabric appears to roll up
at an angle.
Make sure the rail that is mounted to the unit is square with the main housing
of the slide topper.
Make sure fabric is cut square.

8
lci1.com 574-537-8900 Rev: 05.30.19
Solera®Slider
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0001264
Manual information may be distributed as a complete
document only, unless Lippert Components provides
explicit consent to distribute individual parts.
All manual information is subject to change without
notice. Revised editions will be available for free
download at lci1.com. Manual information is considered
factual until made obsolete by a revised version.
Please recycle all obsolete materials and contact
Lippert Components with concerns or questions.
Notes
