Lippert Components 285318 Manual

Rev: 09.29.2015 Page 1 Power Tongue Jack Install Manual



Rev: 09.29.2015 Page 2 Power Tongue Jack Install Manual
Safety and System Information
Safety Information
The “WARNING” symbol above is a sign that an installation procedure has a safety risk involved and may cause
death or serious injury if not performed safely and within the parameters set forth in this manual. Always wear eye
protection when performing this installation procedure. Other safety equipment to consider would be hearing
protection, gloves, and possibly a full face shield, depending on the nature of the installation procedure.
Failure to act in accordance with the following may result in death, serious
injury, coach or property damage.
Preparation
Tools and Components Required
• Power Tongue Jack
• ⁄" - 16x1; serrated flange Grade 5 zinc bolts
• Cordless, power, or impact screw gun
• ½" socket bit
1. Remove the foot pad from the Power Tongue Jack (if necessary).
A. Remove the clevis pin holding the foot pad to the jack leg, and set the pin and the foot pad aside
(Fig. 1).
Fig. 1
2. Support the travel trailer according to OEM instructions.
Foot Pad
Clevis Pin
Moving parts can pinch, crush, or cut. Keep clear at all times.

Rev: 09.29.2015 Page 3 Power Tongue Jack Install Manual
The coach MUST be supported per OEM specifications before working underneath.
Failure to do so may result in death or serious injury.
Installation
1. Carefully slide the jack leg (Fig. 2A) through the hole in the coupler (Fig. 2B) on the travel trailer “A”
frame (Fig. 2C).
Fig. 2
2. Align the three (3) holes in the Power Tongue Jack mounting plate (Fig. 3A) with the three (3) holes in
the coupler (Fig. 3B).
Fig. 3
AA B
AA
B
C

Rev: 09.29.2015 Page 4 Power Tongue Jack Install Manual
3. Secure the Power Tongue Jack to the coupler plate with three (3) ⁄" - 16x1; Serrated Flange Grade 5
Zinc coated bolts (Fig. 4).
Fig. 4
4. Connect the red power wire from the Power Tongue Jack housing to a grounded 12V power supply on
the travel trailer.
NOTE: The Power Tongue Jack MUST be wired through a 30 amp fused circuit.
5. Reattach the foot pad to the jack leg by sliding the foot pad back over the bottom of the jack leg and
securing it with the clevis pin previously removed.

Rev: 09.29.2015 Page 5 Power Tongue Jack Install Manual
Notes

The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (“LCI”).
LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an
authorized LCI representative has been provided. Any unauthorized use shall void any applicable warranty.
The information contained in this manual is subject to change without notice and at the sole discretion of LCI.
Revised editions are available for free download from www.lci1.com.
Please recycle all obsolete materials.
