Lippert Components Standalone Smart Jack Manual

Rev: 09.23.2016 Page 1 Standalone Smart Jack OEM Install Manual
Standalone Smart Jack
OEM INSTALL MANUAL

Rev: 09.23.2016 Page 2 Standalone Smart Jack OEM Install Manual
Safety Information
Warning, Caution and Danger symbols indicate that an installation procedure has a safety risk involved and may
cause death, serious injury or property damage if not performed safely and within the parameters set forth in
this manual. Always wear eye protection when performing this installation procedure. Other safety equipment
to consider would be hearing protection, gloves, and possibly a full face shield, depending on the nature of the
installation procedure
TABLE OF CONTENTS
Safety Information 2
Product Information 2
Resources Required 2
Preparation 3
Installation 3
Operation 5
Setting Hitch Height Memory 5
Normal Operation 5
Return To Hitch Height Operation 5
Failure to act in accordance with the following may result in death, serious injury,
trailer or property damage.
Moving parts can pinch, crush, or cut. Keep clear at all times.
Product Information
The Standalone Smart Jack features:
• High efficiency motor, new streamlined plastic shroud, new user interface with overlay
• Single power lead
• Internal controls allowing operation with the touch pad buttons located on the Smart Jack. This
includes hitch height memory.
Resources Required
• Cordless or Electric Drill or Screw Gun
• Appropriate Drive Bits
• ½" Socket

Rev: 09.23.2016 Page 3 Standalone Smart Jack OEM Install Manual
Installation
Fig. 1
Fig. 2
AA
BC
Foot
Pad
Power Tongue
Jack Leg Clevis
Pin
Hairpin
Cotter Pin
Preparation
1. Remove the Smart Jack foot pad from the Smart Jack (if necessary).
A. Remove the hairpin cotter pin and clevis pin, which hold the foot pad to the jack leg. Set the pins
and the foot pad to the side (Fig. 1).
2. Support the trailer according to OEM instructions.
The trailer MUST be supported per OEM specifications before working underneath.
Failure to do so may result in death or serious injury.
1. Carefully slide the jack leg (Fig. 2A) through the hole in the coupler (Fig. 2B) on the trailer A-frame
(Fig. 2C).

Rev: 09.23.2016 Page 4 Standalone Smart Jack OEM Install Manual
Fig. 4
A
Fig. 3
B
AA
2. Align the 3 holes in the Smart Jack mounting plate (Fig. 3A) with the 3 holes in the coupler (Fig. 3B).
3. Secure the Smart Jack to the coupler with three ⁄" - 16 x 1" serrated flange grade 5 zinc coated bolts
(Fig. 4A).
4. Connect the red power wire from the Smart Jack housing to a grounded 12V power supply on the
trailer.
NOTE: The Smart Jack MUST be wired with a 30 amp in-line fused circuit.
5. Reattach the foot pad to the jack leg by sliding the foot pad back over the bottom of the jack leg and
securing it with the previously-removed clevis pin and hairpin cotter pin.

Rev: 09.23.2016 Page 5 Standalone Smart Jack OEM Install Manual
Operation
NOTE: The hitch height MUST be set in the memory prior to the normal operation of the Smart Jack.
Failure to do so will cause the Smart Jack and the trailer to not function as intended.
NOTE: To cancel an action, press either the up arrow or down arrow. The action in process will stop.
Setting Hitch Height Memory
1. Press and hold the up arrow (Fig.5A) and down arrow (Fig. 5B) at the same time for a minimum of 5
seconds to store the vertical position of the Smart Jack.
2. The battery indicator lights (Fig. 5C) will all flash 5 times to show that the new position is successfully
stored in memory.
Normal Operation
1. Press and hold the up arrow (Fig.5A) to extend the Smart Jack.
2. Press and hold the down arrow (Fig. 5B) to retract the Smart Jack.
Auto Retract
NOTE: This function should only be utilized once the tow vehicle has been reconnected and secured to the
trailer, prior to travel.
1. Press the down arrow 3 times. On the 3rd time, hold the down arrow for 3-5 seconds. The jack will then
begin auto retracting from the hitch height into the fully-stowed position for travel.
Return To Hitch Height Operation
1. Press and release both the up arrow (Fig.5A) and the down arrow (Fig. 5B) simultaneously 3 times
within 2 seconds.
2. The jack will automatically retract or extend to the original hitch height position.
NOTE: Visual indication that the jack is actuating to the hitch height is seen through the oscillation of the
battery LED indicator: i.e. lights will illuminate left to right, and then right to left. This will continue
until level.
Fig. 5
C
A B
