Little Tikes 633904M User manual

ASSEMBLY INSTRUCTIONS
Cook 'N Grow™ BBQ Grill
XIM633904 - 9/20
1
Adult assembly required. Approx. assembly time: 25min.
Look for video of assembly at
littletikes.com/videoinstructions
#633904M
18+
months

2
WARNINGS!
• Adult Assembly Required
• Keep these instructions for future reference.
• Prior to assembly, this package contains small parts: hardware which is a choking hazard
and may contain sharp edges and sharp points. Keep away from children until assembled.
• This product is intended for indoor family use only.
• This product is intended for use by children ages over 18 months and up.
• Do not allow children to sit, stand, play or climb on the top surface. Failure to do so may
cause the product to become unstable.
• Protect your eyes. Always wear safety glasses when using power tools.
• Thoroughly wash accessories before contact with food or beverage.
DISPOSAL
Disassemble and dispose of equipment in such a manner that no hazardous conditions such as, but not limited to,
small parts and sharp edges exist at the time equipment is discarded.
Thank you for choosing the Little Tikes©Cook 'N Grow™ BBQ Grill .
We strive to provide a durable, easy-to-assemble toy thats made to last,
giving your child years of imaginative, engaging fun!
• Read through all the instructions rst.
• Clear a at surface to lay out all the materials so everything is close at hand.
• You will need a Phillips head screwdriver, and safety glasses (not included) to assemble
the Cook 'N Grow™ BBQ Grill.
- When installing screws, be sure screws are tightened snugly, but do NOT OVERTIGHTEN.
• Be sure to locate your decals and set aside. Decals are easier to apply when the part is
laying at, so you may want to apply the decals before assembly.
• The parts are listed below - each part is identied with a letter in RED for easy reference.
• Illustrations are for reference only. Styles may vary from actual contents.
• If you have any questions, we’re here to help. Give our customer service team a
call at 1-800- 321-0183.
Really important information you should know!
Accessories
Plate (1) Hamburger (1) / Bun (1) Hot Dog (1) / Bun (1)
Spatula (1) Tongs (1) Ketchup (1)

(Recommended)
(Recommandé)
(Recomendado)
Grill Base (1)
A
Door Frame (1)
B
Grill Doors (2)
C
3
(4) 1" (2,54 cm)
Shown actual size
Fastener (4)
Countertop (1)
D
Burner (1)
F
Sink (1)
G
Grill Lid (1)
E
A Few Things Before You Start!
BEFORE you begin assembly, make sure
you have all the parts listed below.
Some packages of hardware may have extras pieces.
!
Questions? We’re here to help.
Little Tikes customer service team at 1-800-321-0183.
!
Faucet Fastener (1)
I
Knobs (2)
J
Faucet (1)
H
Tools required (not included)
Grill Knob (1)
K
Illustrations are for reference only.
Styles may vary from actual contents.
Locate your
decal sheet.

4
1
Ready...let’s start with decals!
Decals must be applied to a clean, dry surface. Wipe clean with a dry rag before application.
Remove air from under decals by applying pressure to the decals starting from the center,
and work towards edges. NOTE: If decals bubble, prick with a pin to remove the air.
Locate your
decal sheet.
1
x2
2
4
3
67
5
x2

2
Turn it on
PUSH in (2) knobs (part J) into the
countertop (part D) snap into place.
5
3
One more knob
PUSH in grill knob (part K) onto the
burner (part F) snap into place.
D
J
Snap!
Snap!
K
F
J

6
4
Grill and SINK it!
Snap the grill (part F) into the countertop.
Snap the sink (part G) into the countertop.
G
F
5
Ready for the faucet
Insert faucet (part H) into the countertop and secure by
attaching the faucet fastener (part I) under the countertop
from the back of the unit.
Snap!
Snap!
x4
1" (2,54 cm)
H
II
1
2
4
Grill and SINK it!
Snap the grill (part F) into the countertop.
Snap the sink (part G) into the countertop.
H

7
6
Frame it!
Push each fastener into the door frame (part B)
Then rmly push each fastener into the holes on
the grill base (part A).
3
1
2
4
B
A
x4
Fastener

8
7
2 ways to assemble!
Cook‘N Grow™ BBQ Grill GROWS WITH YOUR CHILD!
Choose from 2 heights
#1
STAGE
#2
STAGE

9
7a
STAGE #1
Attach the grill lid (part E) onto the counter top.
Then slide the counter top into the grill base (part A).
Finally, pop the 2 doors (part C) onto the grill base.
E
A
C
1
2
21
C
Snap in one side of the
grill lid rst, then the
other side
Attach doors in 2 steps.

10
7b
STAGE #2
When converting from STAGE 1 to STAGE 2.
Remove the countertop from the grill base (part A).
Remove the doors and turn the grill base into the tall position.
A
Re-attach the countertop
then pop the doors back
into place.
