ASSEMBLY INSTRUCTIONS
Jett Car Racer™
XIM646768-R1 - 4/21
1
Adult assembly required. Approx. assembly time: 50 min.
Look for video of assembly at
littletikes.com/videoinstructions
3-10
#660443M8
#646768M8P
years

2
WARNINGS!
• Keep these instructions for future reference.
• Prior to assembly, this package contains small parts: hardware which is a choking hazard
and may contain sharp edges and sharp points. Keep away from children until assembled.
• Ride-on toys should not be used near swimming pools, on or near steps, hills, roadways,
or inclines.
• Shoes must be worn at all times.
• Only one rider at a time.
• Maximum weight limit: 105 lbs. (47.6 Kg)
• This product is intended for use by children ages over 3 - 10 years.
• Adult supervision required. Do not leave children unattended.
• This product is intended for outdoor domestic family use only.
• Protect your eyes. Always wear safety glasses when using a hammer.
• When temperatures fall below 0°F/-18°C, outdoor use of this product is not recommended.
In extreme cold, plastic materials lose resilience and may become brittle and crack upon
impact. Store product in a warmer, protected place.
DISPOSAL
Disassemble and dispose of equipment in such a manner that no hazardous conditions such as,
but not limited to, small parts and sharp edges exist at the time equipment is discarded.
Thank you for choosing the Little Tikes©Jett Car Racer™.
We strive to provide a durable, easy-to-assemble toy thats made to last,
giving your child years of imaginative, engaging fun!
• Read through all the instructions rst.
• Clear a at surface to lay out all the materials so everything is close at hand.
• You will need a Phillips head screwdriver (power driver, recommended, not included)
hammer and safety glasses (not included) to assemble the Jett Car Racer™.
- When installing screws, be sure screws are tightened snugly, but do NOT OVERTIGHTEN.
• Be sure to locate your decals and set aside. Decals are easier to apply when the part is
laying at, so you may want to apply the decals before assembly.
• The parts are listed below - each part is identied with a letter in RED for easy reference.
• Illustrations are for reference only. Styles may vary from actual contents.
• If you have any questions, we’re here to help. Give our customer service team a call at 1-800- 321-0183.
Really important information you should know!

3
Tools required (not included)
(Recommended)
(Recommandé)
(Recomendado)
Included in hardware pack.
Discard after use.
Tool color may vary.
Cap nut tool (1)Top hat tools (2)
Hardware Guide
Shown actual size
Top hat tool
A Few Things Before You Start!
BEFORE you begin assembly, make sure
you have all the parts listed below.
Some packages of hardware may have extras pieces.
!
Questions? We’re here to help.
Little Tikes customer service team at 1-800- 321-0183.
!
Fastener (4)
Cap nut tool
(4) 3/4" (1.9 cm)
(for axle retainers)
Top hat (4)
A
Cap nut (2)
B
Steering linkage pins (2)
F
Spacer (2)
C
Wheel bushing (4)
D
Washer (4)
E
(8) 3/4" (1.9 cm)
(for pedals) (for handles)
(4) 11/4" (3.17 cm)

4
(1) Decal sheet
is located in the
hardware pack.
Body (1)
G
Rear axle (1)
H
Front axle (1)
I
Steering linkage (2)
J
Steering linkage covers (2)
K
Steering linkage tool (1)
L
Wheels (4)
Center caps (4)
R
Axle retainer
- INSIDE (2)
N
Axle retainer
- OUTSIDE (2)
M
Pedals (2)
P
FRONT BACK
Handles (2)
O
Q

5
Place axle retainer halves (parts M & N) over
axle and on each side of body. Push until they t
tightly together.
Screw holes face INSIDE.
Let’s start in the front!
Place front axle (part I) into the body (part G).
21
GI
N
M
Body is positioned
upside down.
Hold the 2 retainer parts together, and install (2)
3/4” (1.9 cm) screws (these are the 3/4” screws with
the pointed end).
Repeat on the other side
(4) 3/4" (1.9 cm)
(for axle retainers)
3/4" (1.9 cm)
(for pedals)
M

6
Pedaling along next!
While the body is still positioned upside down, t pedal halves (part O) around the axle. Check
to be sure you have the front of the pedal facing up and the screw holes facing down.
22
3 4
2
1
Each pedal
(8) 3/4" (1.9 cm)
(for pedals)
3/4" (1.9 cm)
(for axle retainers)
Install (4) 3/4" (1.9cm) screws (each
pedal). (These are the 3/4" screws
with the at end).
O

7
The longer side of the
steering linkage center
should be pointed to the
outer side of the body.
Steering - insert, twist & turnback!
Insert a steering linkage (part J) into the side of the body; into
the opening and through the hole located in the rear of the
bottom of the body.
23
JJ
Hole located in
bottom of the body.
Side view
IMPORTANT: Follow steps
exactly! Certain parts of
product DO NOT come
apart once installed.

8
Steering - insert, twist & turnback! - cont.
3
Turn the steering linkage clockwise to t the
center column through the opening.
1
2
Once the center column is through, push the
steering linkage into the opening.
Turn steering linkage BACK counterclockwise.
3
Fit the steering arm beneath
the opening.
4
The longer side of the
steering linkage center
should be pointed to the
outer side of the body.

9
Place on the end of the steering
linkage pin. Hammer cap nut onto
steering pin. Repeat on other side.
x2
Steering - finish up!
4
F
Inside, align the steering linkage center with the pin opening. From inside the body, insert a
steering linkage pin (part F) and push through to the outer side. REPEAT ON THE OTHER SIDE.
Locate pin hole, inside the body.
Insert the steering linkage TOOL
(part L) into the body.
L
B
Place large cap nut (part B)
into cap nut tool.
Really give it a good hit!

10
5
Cover it...
Fit steering linkage covers (part K) over each steering arm.
Secure each side using 2 fasteners.
x4
K
Fastener (4)
6
Ready for REAR wheels..
Insert wheel bushing (part D) into
wheel (part Q) center - INSIDE (x4).
INSIDE OF WHEEL
D
Q
